Summary of Contents for Qvis LED-HDMI2406-MA
- Page 1 24” LED SECURITY MONITOR LED-HDMI2406-MA LED-HDMI2406-PA User’s Manual V1.0 01 / 2014...
- Page 2 Here you can find information about the corresponding model’s features and functions, as well as detailed instructions on how to operate the device. Before you operate the device please read the following safeguards and warnings carefully! © Copyright Qvis ®. All documentation rights reserved.
-
Page 3: Table Of Contents
On Screen Display (OSD) control adjustment ............9 4.3.1 PICTURE ....................... 11 4.3.2 COLOR ......................12 4.3.3 TRACKING ....................12 4.3.4 SETUP ..................13 4.3.5 Other functions ....................14 Troubleshooting ......................15 Product Specifications ....................18 © Copyright Qvis ®. All documentation rights reserved. -
Page 4: General Information
Contents of the box LCD monitor User’s Manual Power cord 15-pin D-Sub signal cable Audio cable (optional) © Copyright Qvis ®. All documentation rights reserved. -
Page 5: Warnings
Stop using the device if water or other material should penetrate inside; risk of fire and electrocution. Contact the retailer or authorized installer. Slots and openings in the cabinet are provided for ventilation. These openings © Copyright Qvis ®. All documentation rights reserved. -
Page 6: Cleaning The Device
Product users shall be responsible for checking and respecting all local rules and regulations concerning monitoring and recording video signals. The manufacturing SHALL NOT MADE BE LIABLE for use of this product not in compliance with the laws in force. © Copyright Qvis ®. All documentation rights reserved. -
Page 7: Hardware Setup
After installation, you can adjust the position of the panel in various ways for maximum comfort. Tilt Range: 5~15 degrees. (Do not touch or press the screen when adjusting the angle of the monitor). © Copyright Qvis ®. All documentation rights reserved. -
Page 8: Connecting With The Pc
3. Connect the DVI-D (Digital signal) cable if has DVI-D. 4. Press the power button on the front panel to turn the power on. When monitor power is turned on, the 'Auto' is executed automatically. © Copyright Qvis ®. All documentation rights reserved. -
Page 9: Controls & Settings
& darkness and enables the viewer to see more layers and details of the picture, especially in the darker areas. Please note when DCR is on, DCB will be disabled. © Copyright Qvis ®. All documentation rights reserved. -
Page 10: On Screen Display (Osd) Control Adjustment
4. Press the MENU button once to return to the main menu and to select another function. 5. Press the MENU button twice to exit from the OSD. © Copyright Qvis ®. All documentation rights reserved. - Page 11 FACTORY RESET Listed below are the icons, icon names, and icon, descriptions of the all items shown on the menu. Press the MENU Button, then the main menu of the OSD will appear. © Copyright Qvis ®. All documentation rights reserved.
-
Page 12: Picture
To adjust the contrast of the screen. GAMMA: Set your own gamma value. : -50 / 0 / 50 On the monitor, high gamma values display whitish images and low gamma values display blackish images. © Copyright Qvis ®. All documentation rights reserved. -
Page 13: Color
Set your own red color levels. GREEN: Set your own green color levels. BLUE: Set your own blue color levels. 4.3.3 TRACKING HORIZONTAL: To move image left and right.. VERTICAL: To move image up and down © Copyright Qvis ®. All documentation rights reserved. -
Page 14: Setup
To adjust the clearness of the screen. 4.3.4 SETUP LANGUAGE: To choose the language in which the control names are displayed. OSD: To adjust the position of the OSD window on the screen. © Copyright Qvis ®. All documentation rights reserved. -
Page 15: Other Functions
WHITE BALANCE function again. This function will be enabled only when the input signal is an Analog signal. 4.3.5 Other functions Press: MENU key to long-term, OSD LOCKED. Then press: MENU key to long-term, OSD UNLOCKED. © Copyright Qvis ®. All documentation rights reserved. -
Page 16: Troubleshooting
Display mode of the computer is outside the range of the monitor. The display mode the monitor uses is controlled by your computer. Therefore, you should refer to your computer's documentation for details on how to change display modes. © Copyright Qvis ®. All documentation rights reserved. - Page 17 The monitor is not receiving a video signal. Perform the following steps to fix the problem: 1. Check that the signal cable is firmly connected to your computer. 2. Check that no pins are bent in the signal cable connector. © Copyright Qvis ®. All documentation rights reserved.
- Page 18 Select (Menu) from the OSD menu. Select (Color Temp) to adjust the color mode or fine tune the colors using the User menu depending on what you find the most comfortable. © Copyright Qvis ®. All documentation rights reserved.
-
Page 19: Product Specifications
Work Humidity 20 % - 70 % Work Temperature - 10 to 50 °C IN/OUT INTERFACE Video Interface VGA x 1 HDMI x 1 Audio Interface Audio in x 1,Audio Out x 1, © Copyright Qvis ®. All documentation rights reserved. - Page 20 Plastic: 5.35KG Metal: 6.745KG POWER Power Supply 12VDC, 3 Amp Voltage AC100 - 240V 50 / 60Hz Power Consumption <110W (Standby Power <1.3W) IMPORTANT NOTE: Product specifications may be subject to change without prior notice. © Copyright Qvis ®. All documentation rights reserved.
- Page 21 For more information about our accessories and other available cameras, NVRs & cameras, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
