Apex Digital GT2015, GT2415, GT2715, GT3215 Instruction Manual

Apex digital gt-series color television instructions
Hide thumbs Also See for GT2015, GT2415, GT2715, GT3215:

Advertisement

GT S
C
T
ERIES
OLOR
ELEVISIONS
INSTRUCTION MANUAL
Standard - GT2015, GT2415, GT2715, GT3215
Please read this manual carefully before operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT2015, GT2415, GT2715, GT3215 and is the answer not in the manual?

Questions and answers

Summary of Contents for Apex Digital GT2015, GT2415, GT2715, GT3215

  • Page 1 GT S ERIES OLOR ELEVISIONS INSTRUCTION MANUAL Standard - GT2015, GT2415, GT2715, GT3215 Please read this manual carefully before operation.
  • Page 2: Safety Precautions

    Record these numbers in the spaces provided beIow. Refer to them whenever you caII upon your Apex deaIer regarding this product. Model Numbers: GT2015, GT2415, GT2715, GT3215 Chassis Number: CH-12C2 Avoid dispIaying stationary images on your TV screen for extended periods of time. Stationary patterns generated by computer dispIays, video games, stock market reports, etc.
  • Page 3: Important Safety Instructions

    BEFORE OPERATiON (continued) Important Safety Instructions CAUTION PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS AND HEED ALL WARNINGS. FOLLOW ALL INSTRUCTIONS. Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. However improper use can result in potential electrical shock or fire hazards.
  • Page 4 BEFORE OPERATiON (continued) Precautions (continued) Damage Requiring Service - Unplug the TV set from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. lf the power cord or plug is damaged or frayed. b. lf liquid has been spilled or objects have fallen into the TV set. c.
  • Page 5: Fcc Warning

    BEFORE OPERATlON (continued) FCC Warning Class B Computing Device Information to User This equipment has been tested and found to compIy with the Iimits for a class B digitaI device pursuant to part 15 of FCC Rules. These limits are designed to provide reasonabIe protection against harmful interfer- ence in a residential installation.
  • Page 6 BEFORE OPERATlON (continued) FCC Warning Class B Computing Device Information to User This equipment has been tested and found to compIy with the Iimits for a class B digitaI device pursuant to part 15 of FCC Rules. These limits are designed to provide reasonabIe protection against harmful interfer- ence in a residential installation.
  • Page 7: Table Of Contents

    lNTRODUCTlON Features...9 ControI Buttons...10 Menus...12 INSTALLATION To Connect the Antenna...13 Remote Batteries...13 To Connect ExternaI Equipment...14 BASlC FUNCTlONS Power On/Off...15 On - Screen DispIay..15 Tuning in...16 Function SeIection...17 GeneraI Operation... 20 Picture Improvement... 22 Sound Improvement... 23 ADDlTlONAL FEATURES Time Setting...
  • Page 8: Features

    FeaturesINTRODUCTION Features True FIat Picture Tube DeIivers real pictures, which ensures that you can watch sharper and more natural pictures. By adopting the invar shadow - mask, the tube increases the transparency and reduces thermaI deformation, which greatly improves the picture stability and deIivers more vivid pictures. English/French/Spanish Menus The unique English/French/Spanish menu control function makes the operation more easily.
  • Page 9: Control Buttons

    INTRODUCTION (continued) Control Buttons Front panel (GT2015) Press to open the door. VIDEO MENU TV/VIDEO SELECT MENU SELECT Note: The buttons on the TV set share the same functions with those buttons of the same name on the remote controI. The foIlowing section of this manuaI wiIl focus on operation of the remote controI. Top panel See the right figure.
  • Page 10: Top Panel

    INTRODUCTION (continued) Control Buttons Front panel (Gt2415, GT2715, GT3215) Press to open the door. VIDEO MENU TV/VIDEO SELECT MENU SELECT VOLUME DOWN/UP Note: The buttons on the TV set share the same functions with those buttons of the same name on the remote controI.
  • Page 11 INTRODUCTION (continued) Control Buttons (continued) Remote control STANDBY Channel Number CHANNEL UP VOLUME DOWN CHANNEL DOWN RECALL CHANNEL SCAN CCD/TEXT PICTURE MODE SELECT SOUND MODE SELECT STEREO SELECT TIME SELECT Notes: 1 When in operation, please point your remote control directly to the infrared sensor. 2 Do not expose the remote control to impacts,water or disassemble it.
  • Page 12: Menus

    INTRODUCTION (continued) Menus Press the MENU button , and the TV will display the primary menu as follows: To adjust a function, press the sub-menu. (Take English menus for example). Picture Tint Brightness Contrast Color Sharp Time Time On Time Cn Channel Off Time After selecting a sub- menu, press the...
  • Page 13: Installation

    INSTALLATION Please read the safety instructions in this manual completely before installation. Install your TV in a room where direct sunlight will not fall upon the screen. Allow enough space (at least 10cm) between the TV and the wall for proper ventilation. It is recommended to watch TV in soft and indirect light.
  • Page 14: To Connect Externai Equipment

    INSTALLATION (continued) To Connect External Equipment The following are optional connections. Please refer to operation manuals of external audio/video equipment that will be con- nected to your set. Connect VCR' s or DVD player' s RF OUT terminal to the AN- TENNA IN jack located on the rear panel.
  • Page 15: Basic Functions

    BASIC FUNCTIONS Power On/Off 1.Power on Plug in the supply socket, and press the MAIN POWER SWITCH on the TV to enter the Power On mode. 2.Standby When in the Power On mode, press the this time, part of circuit on the TV set remaims active. In the Standby mode, press the 3.Power off When in the Power On or Standby mode, Press the MAIN POWER SWITCH on the TV to turn off the power...
  • Page 16: Tuning In

    BASIC FUNCTIONS (continued) Tuning in This section gives descriptions about adjustment of items in the Tuner menu. 1.Auto program 1)Press the buttons to highlight 2)Press the button, and the TV will search automatically in sequence. After auto search, the TV will store receivable channels and return to the lowest channel number.
  • Page 17: Function Selectionmenus

    BASIC FUNCTIONS (continued) Function SelectionMenus 1.Language selection 1)Press the ¸ buttons to highlight 2)Press the buttons to select a desired language display (English/French/Spanish). 2.Blue screen display When there is no signal received with Blue Back On, the TV will display a soft blue backgrund on the screen.
  • Page 18 BASIC FUNCTIONS (continued) Function Selection (continued) Captions will appear at either the top or bottom of the screen while a captioned broadcast is received. When you select the Text (T1-T4) mode, the TV can receive teletext signal. When you select “CCD/Text Off ”, the CCD / Text function is off. 3)Press the CC button to turn on/off the CCD/Text mode.
  • Page 19: Function Selection

    BASIC FUNCTIONS (continued) Function Selection (continued) Press the button to move the cursor from “ Pass Code Menu ”,“ MPAA Rating ”, “TV-Rating” to “System”, and select “ Parental Guide Off ” to stop circulation. The following is the MPAA-Rating menu. Press the button repeatedly to recall the Pass Code menu as follows.
  • Page 20: Generai Operation

    BASIC FUNCTIONS (continued) General Operation 1.To control volume Press the - VOL + buttons to decrease or increase the vol- ume. While adjusting volume, press the F and - VOL + buttons at the same time and the volume decreases or increases by 4 levels. During normal play, press the MUTE button to eliminate the sound until you press the VOL + or MUTE button again.
  • Page 21 BASIC FUNCTIONS (continued) General Operation (continued) 4) SCAN 1 Press the SCAN button so that “ Scan Off ” appear on the screen. 2 Press the SCAN button again so that “Scan On ”appear on the screen and the TV begins to scan from the current channel. Note: During scanning, pressing any button can interrupt scanning.
  • Page 22: Picture Improvement

    BASIC FUNCTIONS (continued) Picture Improvement 1.To seIect picture modes Press the PICTURE button repeatedly to seIect one of the Normal, Memory and Theater modes. PICTURE Refer to the foIIowing introduction about each mode. Mode Normal Standard mode, suitable for watching ordinary program. Memory Picture quality users set.
  • Page 23: Sound Improvement

    BASIC FUNCTIONS (continued) Sound Improvement 1. To seIect sound modes Press the SOUND button repeatedIy to seIect one of the Speeh, Music, Theater and Memory modes. SOUND Refer to the foIIowing introduction about each mode. Mode Speech Music Suitable for enjoying music programs Theater Memory 2.
  • Page 24: Additional Features

    ADDITIONAL FEATURES Time Setting In the Standby or Power On mode, the TV can automatically complete some functions such as power -on, channel preset and power-off as desired. 1 . Press the TIMER button to turn on the Timer menu display as shown right. 2 .
  • Page 25: Programming The Remote Control

    ADDITIONAL FEATURES (continued) Programming the Remote Control 1. Remote - controI switchover Press the TV, VCR/DVD, SAT/CAB or AUX button to seIect the device you want to controI. 2. To program the remote control Press and hoId the TV, VCR/DVD, SAT/CAB or AUX button for over 2 seconds until the lNDlCATOR on the remote controI turns off.
  • Page 26 ADDITlONAL FEATURES (continued) Programming the Remote Controller (continued) Operating a DVD pIayer Press 1. Power on the VCR 2. SeIect channeIs directly 3. PIay DVD 4. Stop 5. Pause 6. Move the cursor in the men 7. Display the DVD menu 8.
  • Page 27: Specifications

    SPECIFICATIONS Model Number Television system Channel coverage Channels preset Antenna input 280mm x 210mm Pictue tube 15.98 x 12.01 in. Effective screen dimensions (Approx.) Max.audio output Power source 25.2kg (55.44 lbs) Weight(Approx.) Dimensions(W/H/D) 512 x 522 x 510mm (20.16 x 20.55x 20.08 in. ) (Approx.) 614 x 634 x 614mm Packing Dimensions...
  • Page 28: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Check the following guide for a possible correction to a problem before contacting customer service.Check FAQ at our website: www.apexdigitalinc.com. Symptoms and Correction Symptoms No power No picture No sound No TV signal Stripe or purple interfe- rence appears in the screen.
  • Page 29: Limited United States Warranty

    Depending on the type of repair required, the service will either be performed in your home or the set will be taken to the Authorized Apex Digital, Inc. Service Center' s repair facility for repair and then returned to your home at no cost to you.
  • Page 30: Packing List

    Parts GT Series Color TV Receiver K12C-C1 Infrared Remote Control Operation Manual AAA Alkaline Batteries Packing List Quantity APEX Digital, lnc. 2919 E. Philadelphia Street Ontario, CA 91761 www.apexdigitalinc.com Remarks...
