Summary of Contents for Audio Limited TX2040
- Page 1 2040 User Guide...
- Page 2 ......The TX2040 is a pocket transmitter that provides 32 pre- The HX2040 is a handheld transmitter designed in a classical...
- Page 3 CHAPTER TX2040 Pocket Transmitter The TX2040 is a small, lightweight battery-powered pocket transmitter for use with a wide range of lapel microphones. All settings can be read and changed via the infra-red port using the SwitchiR™. Controls, display and connections Brown reset button .
- Page 4 A low transmitter battery indicator • Check or set the microphone gain. is provided on the RK2040 receiver and on the TX2040 • Check or set the low frequency cut filter. transmitter. • Check the battery status.
- Page 5 CHANNEL Both positive and negative microphone bias voltages are provided, enabling the majority of Lavalier microphones to • Point the SwitchiR at the infra-red port on the TX2040 and be used with the TX2040. press OK. Selecting the operating frequency...
- Page 6 • Align the front of the SwitchiR with the infra-red port of Setting the low frequency cut filter the TX2040 and press OK. The LF cut filter gives an approximately 6dB cut at 50Hz to The display will show the current AF LEVEL reduce handling and wind noise.
-
Page 7: Sleep Mode
The TX2040 can be put into sleep mode using the SwitchiR. current battery status: In the sleep mode the TX2040 uses very little current and the The battery level can also be checked from the receiver; see SwitchiR can still be used to read all settings. -
Page 8: Technical Specification
-6dB input in overload Alternatively, you can use the tip of the antenna to press the Battery 9V (IEC 6LR61) Alkaline brown On/Reset button to turn the TX2040 on again. Battery life Typically 10 hours Size 89 x 60 x 21mm... - Page 9 CHAPTER Control-X Transmitter Controller The Control-X uses electromagnetic induction to switch on or off the TX2040 transmitter, or check its frequency, even when the transmitter is hidden beneath clothing. It has a built-in frequency counter and battery tester. Controls, display, and connections Display .
- Page 10 Checking whether the TX2040 is switched on Checking battery voltages You can use the Control-X to check the status of the TX2040, ......
- Page 11 Control-X Transmitter Controller Checking the battery of other Audio Ltd RMS2020 or Technical specification ......RMS2000 transmitters •...
-
Page 12: Switchir Infra-Red Controller
CHAPTER SwitchiR Infra-Red Controller The SwitchiR is a compact custom-designed infra-red controller for use with the 2040 Range. It provides functions to allow you to read the status of a device, or change its settings. In addition it includes a convenient built-in 9V battery tester: Menu/On button Turns on the SwitchiR . -
Page 13: Using Switchir
SwitchiR Infra-Red Controller Using SwitchiR Menu Description ......Full instructions for using SwitchiR with each of the products Press OK to read the serial number of a receiver or transmitter and display it on the display. -
Page 14: Controls, Displays, And Connections
CHAPTER HX2040 Hand-Held Transmitter The HX2040 is a multi-frequency UHF hand-held transmitter for use with all the receivers from the RMS 2040, RMS 2020, and Envoy ranges. It is also compatible with the older RMS 2000 range. It provides 32 switchable frequencies, and is configured entirely by infra-red control using the supplied SwitchiR. - Page 15 HX2040 Hand-Held Transmitter Setting up the HX2040 ..... . . To set up the HX2040 : Windshield • Fit the battery. Anti-roll ring •...
- Page 16 HX2040 Hand-Held Transmitter Switching on For example: CHANNEL * Press and hold the grey On button below the infra-red port for one second until the ring above the battery • Press a or v to scroll through the 32 frequencies read compartment glows red.
- Page 17 HX2040 Hand-Held Transmitter The display will indicate: Setting the low frequency cut filter AF LEVEL The LF cut filter gives an approximately 10dB cut at 50Hz to TxRx reduce handling and wind noise. • Align the front of the SwitchiR with the infra-red port of the HX2040 and press OK.
-
Page 18: Fitting The Microphone Capsule
HX2040 Hand-Held Transmitter Otherwise the display will show: The display Error dISABLE Ir ? will show: TxRx TxRx • Repeat the previous steps if an error message is • Align the front of the SwitchiR with the infra-red port on displayed, moving the SwitchiR closer to the infra-red the transmitter and press OK. - Page 19 HX2040 Hand-Held Transmitter Holding the HX2040 Available capsules A02S bright omni ..... . . AC4 cardioid AC4A cardioid for vocal use and The HX2040 should be held above the illuminated On/ others from Schoeps Colette range...
-
Page 20: Ec Declaration Of Conformity
Declaración de Conformidad EG-Conformiteitsverklaring AUDIO LIMITED Audio House, Progress Road High, Wycombe, HP12 4JD, U.K. declare that these devices / déclarons que ces appareils / erklären, dass die Produkte / declaramos que estos aparatos / dichiaria che questi apparecchi / verklaren, dat deze toestelen...
