- Page 1 Document No: 1015454 Revision: A WatchMaster IP Elite 3000 ® F i x e d M o u n t , F i x e d F o c u s T h e r m a l I P a n d A n a l o g C a m e r a U s e r M a n u a l...
- Page 2 ©Copyright 2012-2013, DRS TECHNOLOGIES, Inc. - All rights reserved. 13532 N. Central Expressway Dallas, TX 75243 877.377.4783 www.drsinfrared.com The contents of this document may not be reproduced in whole or in part without the written consent of the copyright owner.
- Page 3 TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE ARE PROVIDED “AS IS” WITH ALL FAULTS. DRS DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
- Page 4 DRS Software shall be owned or licensed exclusively by DRS. Except for the license provided in Section 2, you shall have no right, title or interest in or to the DRS Software. The DRS Software is licensed, not sold, to you for use only under the terms and conditions of this Agreement.
- Page 5 Rights, as such term is defined in 48 C.F.R. Part 252.227-7014(a)(14). 10. THIRD PARTY SOFTWARE LICENSES: The DRS Software may contain third party software, which requires the application of third party terms and conditions (reference Table 1 below). Such third party terms and conditions are located in .txt files or other documentation of each third party software component.
- Page 6 CAN/CSA-C22.2 No. 60065-03, 1st Edition, 2006-04 + A1:2006 RoHS This equipment complies with the European ROHS directive, 2002/95/EC. WEEE This equipment must be disposed of as electronic waste. Contact your nearest DRS Representative for instructions on how to return the product for proper disposal.
-
Page 7: Table Of Contents
Access ........................... 18 Camera Discovery and IP Address ................. 18 4.10 Login to the IP Camera ....................19 Configuration and Management ..................20 DRS Web Interface ......................20 Access Privilege ......................21 Setup ..........................22 IP Network Settings ......................22 Other Network Settings .................... -
Page 8: A B L E O F
Figure 19: Camera mounted to the Axis Bracket ..................17 Figure 20 Camera Discovery with Windows 7....................18 Figure 21: DRS Web Interface and Main Menu .................... 21 Figure 22: DRS Web Interface Setup Menu ....................22 Figure 23: TCP/IP Network settings ......................23 Figure 24: FTP Server settings........................ - Page 9 ® WatchMaster IP Elite User Manual Figure 47: Camera Maintenance Functions ....................45 Figure 48: Auto Calibration Control ....................... 46 Figure 49: Constant Recording Control ......................46...
- Page 10 Table 4: IP Elite Focus Information ....................... 17 Table 5: DRS Web Interface Main Menu ....................... 20 Table 6: Camera Main Menu and Access Privileges using the DRS Web Interface........21 Table 7: Network TCP/IP Settings ......................... 22 Table 8: Other Network Settings ........................24 Table 9: Accounts and Users ........................
- Page 11 ® WatchMaster IP Elite User Manual C R O N Y M S A N D B B R E V I A T I O N S Abbreviation Description Vanadium Oxide Internet Protocol Open Network Video ONVIF Interface Forum Noise Equivalent Delta NEDT Temperature...
- Page 12 DRS WinXP UPnP Procedure DRSWatchMaster® IP Family Interface Control document (ICD) http://www.drsinfrared.com DRS WatchMaster® IP Elite Training Videos --Please note these videos are applicable to WatchMaster® IP Elite only. For IP Elite 3000 training, please refer to the above Quick Start Guide.
- Page 13 When a notification is present, it is important that the user review and understand all statements related to the notification before proceeding. If questions arise, please contact your authorized dealer or DRS Technologies. Notifications are preceded by a symbol and followed by highlighted text.
- Page 14 ® WatchMaster IP Elite User Manual WARNING IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Install in accordance with the manufacturer’s instructions. Installation of the equipment must comply with local and national electrical codes. This product must be connected to a Power Over Ethernet IEEE 802.af compliant power source or a UL Listed “Class 2”...
- Page 15 ® WatchMaster IP Elite User Manual This page intentionally left blank. xiii...
-
Page 16: Introduction
IP Elite 3000 Fixed Mount, Fixed Focus Thermal IP and Analog Camera User Manual, provides details about the IP Camera features, installation, access, configuration, application, interoperability, troubleshooting, warranty support. ® This document also applies to the DRS WatchMaster IP Elite Fixed Mount, Fixed Focus Thermal IP Camera. -
Page 17: Product Overview
2 frame rates (versions), 30Hz and 9Hz. The WatchMaster IP Elite 3000 employs DRS’s proven uncooled 320 x 240, 17 μm Vox thermal imaging technology. Unlike ® many conventional and low light video surveillance cameras, the WatchMaster IP Elite 3000 does not require any ambient light or illumination. - Page 18 H264 and MJPEG streams. Web-based management – Administration and management of the IP camera can be performed through the DRS web-based configuration menus. Motion detection – The IP camera can detect motion based on region of interest definitions and can generate events/alerts if motion is detected.
-
Page 19: Camera Hardware
® WatchMaster IP Elite User Manual CAMERA HARDWARE Physical detail of the IP Camera is provided below. Figure 1: Camera Hardware Overview Table 1: Camera Hardware Components Item Description Camera Body Base Mount Back Cover Solar Shroud 4 Hole Axis Mount Adapter (optional) Cable Sealing Gland with electrical nut Tamper Resistant Screws Stem Bumpers... -
Page 20: Figure 2: Ip Elite 3000 Camera Rear View
® WatchMaster IP Elite User Manual Figure 2 and Table 2 below describe the details of the rear of the camera. Figure 2: IP Elite 3000 Camera Rear View Table 2: Camera LED Indicators Item Description Accepts a standard LAN cable to connect the IP camera to a Network Port 10/100 BaseT Switch or Router. -
Page 21: Specifications
® WatchMaster IP Elite User Manual P E C I F I C A T I O N S QUICK REFERENCE SPECIFICATIONS ® The WatchMaster IP Elite 3000 Specifications is detailed below in Table 3. ® Table 3: WatchMaster IP Elite 3000 Specification Quick Reference Table Focal Plane Array Sensor Type Uncooled VOx Microbolometer... - Page 22 Athermalized Fixed Focus Horizontal Field of View (HFOV) f/no Effective Focal Length 7.5 mm 19 mm 35 mm Software Administrator, Operator, and Viewer with DRS Web Interface Password Protection Hardware Embedded Memory 2 GB for Video Storage and Image Capture...
-
Page 23: Range Performance
® WatchMaster IP Elite User Manual RANGE PERFORMANCE ® The WatchMaster IP Elite 3000 range data assumptions and performance are provided below. Typical detection and recognition range performance has been modeled for multiple available lens solutions using NVTHERM . See Figure 3. ®... -
Page 24: Installation And Access
When unpacking, please note any damage that may have occurred during shipping and review the contents of the package to ensure all components are present. If any discrepancies arise, please notify your authorized dealer or DRS Technologies directly. The list of standard shipping contents is provided below. -
Page 25: Installation
The camera electronics and electronic interfaces are sensitive to electrostatic discharge. Please follow appropriate ESD procedures when handling the camera and during installation. For PoE installations, DRS strongly recommends the use of STP cabling and an earth grounded end point to ensure proper ESD immunity. -
Page 26: Installation Procedure
IP Elite User Manual CAUTION To ensure a proper earth ground (between the DRS camera and a PoE switch) DRS strongly recommends the use of Shielded Twisted Pair (STP) cabling. Installations of DRS cameras using a STP cabling and a properly earth grounded PoE switch are tested to comply with industry immunity standards for Electro Static Discharge. -
Page 27: Preparing The Cable
® WatchMaster IP Elite User Manual Figure 7: Recommended Analog Figure 6: Recommended Tool Kit Tools PREPARING THE CABLE 1. Disconnect power from the exposed cable(s) of the standard Bracket. 2. Take the number 2 Phillips head screwdriver and pierce the membrane of the cable gland. 3. -
Page 28: Figure 8: Ip66 With Poe
® WatchMaster IP Elite User Manual Figure 8: IP66 with POE Securing for IP66 (Ethernet & AC/DC power): 1. Slide the Ethernet cable through the threaded end of the cable sealing gland, with Orange O-Ring installed. 2. Slide the 2, 20 AWG power wires through the back side of the cable sealing gland. 3. -
Page 29: Assembly
® WatchMaster IP Elite User Manual 3. Measure approximately 4.5 inches of cable slack from the end of the cable to the rubber grommet of the sealing gland. Use a scale to measure the length. 4. Attach one open end wrench onto the flange of the cable gland and tighten the compression nut, with the second open wrench, to approximately 50-55 in-lbs. -
Page 30: Figure 10: Ip Elite 3000 Pin-Out
® WatchMaster IP Elite User Manual Figure 10: IP Elite 3000 Pin-Out Pins 1-3: Power (GND, 24V AC, 12-24 DC/24V AC) Pins 4-5: RS-485 (POS, NEG) Figure 11: IP Elite Pin-Out (24V AC, 24V AC, 12V DC, GND) d. RS-485: Connect wires to power block according to the previous pin-outs (IP Elite 3000 only) 4. -
Page 31: Figure 12: Possible Configurations Of The Ip Elite And Ip Elite 3000(Far Right)
® WatchMaster IP Elite User Manual 8. Assemble the 2 Rubber Stem Bumpers onto the 2 detents in the concave surface of the Solar Shroud. 9. Snap the Solar Shroud to the Base Mount. Figure 12: Possible Configurations of the IP Elite and IP Elite 3000(far right) Figure 13: POE with Power Figure 14: Back Cover and White Desiccant... -
Page 32: Mounting The Camera
Make sure not to touch the lens when adjusting the focus. However, the 40° lens may require the use of a focus tool. The focus tool is available from DRS as an optional accessory item. For ordering details, please refer to the DRS WatchMaster IP Elite 3000 price sheet. -
Page 33: Access
Windows 7 OS: Click on Start, Click on Computer and Click on Network. A list of devices connected to your network will appear as below. Double Click on the name (DRS WM IP Elite) of the camera to launch the default browser. You can see the IP address of the camera in the Browser URL. -
Page 34: 4.10 Login To The Ip Camera
® WatchMaster IP Elite User Manual 4.10 LOGIN TO THE IP CAMERA 1. Enter the IP address of the IP Camera on the Browser URL line. 2. Enter the default username and password when prompted. 3. Default username and password are given below for Administrator access Username is admin (lower case) Password is... -
Page 35: Configuration And Management
DRS provided Web Interface. This section covers the configuration and management of the IP camera using the DRS Web Interface. DRS WEB INTERFACE The DRS Web Interface main menu is organized as shown in Table 5 and in Figure 21 below. Table 5: DRS Web Interface Main Menu Command... -
Page 36: Access Privilege
After you log in to the WatchMaster™ IP Elite 3000 Camera, you can access the different menus and perform administrative and user actions using the DRS Web Interface. Administrators can access all of the IP camera menus, features and functions. Operators have access to limited IP camera menus, features and functions. -
Page 37: Setup
Enter the IP address of the DNS server that is used in your DNS Server network. Use the same value that is used for the PCs on your LAN. Default name is DRS WM IP Elite <MAC Addr>. Enter a Host Name nickname for the IP Camera, if desired. -
Page 38: Figure 23: Tcp/Ip Network Settings
® WatchMaster IP Elite User Manual Figure 23: TCP/IP Network settings... -
Page 39: Other Network Settings
® WatchMaster IP Elite User Manual OTHER NETWORK SETTINGS Table Figure through Figure 28 below provides details on configuring other IP network settings of the camera. Table 8: Other Network Settings Network Setting Description Enter the FTP Server address, FTP port, FTP user name, ftp password and the ftp path name which is a default folder in FTP Server the ftp server. - Page 40 ® WatchMaster IP Elite User Manual Network Setting Description IEEE 802.1x is an IEEE standard for port-based Network Admission Control. It provides authentication to clients (IP camera) attaching to a network port. 802.1x is based on Extensible Authentication Protocol (EAP). 802.1X is typically administered on the Ethernet Switch.
-
Page 41: Figure 24: Ftp Server Settings
® WatchMaster IP Elite User Manual Figure 24: FTP Server settings Figure 25: E-mail server settings... -
Page 42: Figure 26: Ping Target Settings
® WatchMaster IP Elite User Manual Figure 26: Ping Target Settings Figure 27: 802.1X settings... -
Page 43: Accounts And Users
® WatchMaster IP Elite User Manual Figure 28: Zero Network Configuration Settings ACCOUNTS AND USERS Table 9 and Figure 29 below provide details on managing accounts and users. Table 9: Accounts and Users Accounts Description New user accounts can be created for accessing the IP camera. -
Page 44: Camera Functions
® WatchMaster IP Elite User Manual Figure 29: User Accounts CAMERA FUNCTIONS Table 10 and Error! Reference source not found. through Figure 35: Analog Video Output Settings below provides details on the camera functions. These functions include Date/Time settings, Video Streaming, and Motion Detection. The settings for these functions can be managed by the administrator. -
Page 45: Table 10: Ip Camera Functions
Settings too high may cause latency H264 Network Cache between live action and stream display. Settings too low may cause instability in the stream display. Default value is DRS tested optimum for selected frame rate. H.264 RTSP Port Allows for setting of a custom port for RTSP streaming. -
Page 46: Figure 30: Camera Functions Menu
Settings too high may cause latency MJEPG Network Cache between live action and stream display. Settings too low may cause instability in the stream display. Default value is DRS tested optimum for selected frame rate. MJPEG RTSP Port Allows for setting of a custom port for RTSP streaming. -
Page 47: Figure 31: Camera Date And Time Settings
® WatchMaster IP Elite User Manual Figure 31: Camera Date and Time settings Figure 32: Camera Video Streaming settings... -
Page 48: Figure 33: Camera Motion Detection Settings
® WatchMaster IP Elite User Manual Figure 33: Camera Motion Detection settings Figure 34: Pelco-D Settings Figure 35: Analog Video Output Settings... -
Page 49: Use And Application
P P L I C A T I O N The WatchMaster® IP Elite 3000 camera can be used for a variety of Security & Surveillance Applications. Live video can be easily accessed and managed using the DRS Web Interface for any of these applications. -
Page 50: Table 11: Live Video And Controls
® WatchMaster IP Elite User Manual Table 11: Live Video and Controls Live Video Description Select the appropriate video stream H264, MJPEG, or HTTP JPEG. It is possible to select multiple video streams from a Video Stream single camera. However, separate browser windows are required to do this. -
Page 51: Figure 37: Live Video Image With Auto Agc
® WatchMaster IP Elite User Manual Figure 37: Live Video Image with Auto AGC Figure 38: Snapshot... -
Page 52: Motion Detection
® WatchMaster IP Elite User Manual Live video can also be viewed by using the following RTSP URLs below: Table 12: RTSP URIs Codec Transport Method rtsp://<camera ip>:8557/2?videoCodecType=H.264 H.264 UDP/TCP rtsp://<camera ip>:8555/0?videoCodecType=MJPEG MJPEG UDP/TCP rtsp://<camera ip>:8080/2?videoCodecType=H.264 H.264 HTTP rtsp://<camera ip>:8081/0?videoCodecType=MJPEG MJPEG HTTP rtsp://<camera ip>:8557/12?videoCodecType=H.264... -
Page 53: Figure 39: Motion Detection Menu
® WatchMaster IP Elite User Manual Figure 39: Motion Detection Menu Table 13: Motion Detection Settings Motion Detection Description Press the Enable Motion Detection button to enable the Enable Motion Detection analytics. The color of this button turns to Red. Pressing again will disable motion detection. -
Page 54: Figure 40: Region Of Interest (Roi) Settings
® WatchMaster IP Elite User Manual Motion Detection Description Click on save ROI button to save the settings and changes Save ROI Configuration made. Figure 40: Region of Interest (ROI) settings Figure 41: Enable Motion Detection Button Activated... -
Page 55: Video Storage
® WatchMaster IP Elite User Manual VIDEO STORAGE 6.3.1 Access to Video Storage The IP Camera can record video and store video and images on the camera internal memory. The stored video and images can be transferred to an FTP server manually. 6.3.2 Web Interface Access to Video Storage The IP Camera can record video and store video and images on the camera internal memory. -
Page 56: Figure 42: Video Storage Menu
® WatchMaster IP Elite User Manual Figure 42: Video Storage Menu Table 14: Video Storage and Recording Video Storage Description There are 3 video categories in the pull down menu. These Recorded Video categories are Constant Recorded Video, Video Archive and Category Motion Detection Capture Events. -
Page 57: Figure 43: Video Archive Menu
® WatchMaster IP Elite User Manual Figure 43: Video Archive Menu Figure 44: Motion Detection Capture Menu... -
Page 58: Maintenance
IP Elite User Manual MAINTENANCE The IP Camera is shipped with default software from the factory. DRS may make available software updates and enhancements to the IP camera from time to time. Table 15 and Figure 45 through Figure 49 provide details on the maintenance menu. -
Page 59: Figure 45: Maintenance System Status
Click on Log Viewer to see the list of logs. The logs Log Viewer may include camera start time, camera logout time, camera recording start time, and motion event time. Click on Copyright to see the DRS Technologies Copyright Copyright statement. Figure 45: Maintenance System Status... -
Page 60: Figure 46: Firmware Update And Camera Configuration
® WatchMaster IP Elite User Manual Figure 46: Firmware Update and Camera Configuration Figure 47: Camera Maintenance Functions... - Page 61 ® WatchMaster IP Elite User Manual Figure 48: Auto Calibration Control Figure 49: Constant Recording Control...
-
Page 62: Log Out
® WatchMaster IP Elite User Manual LOG OUT To log out of the IP Camera, click on the Log Out link in the main menu or click on the Log Out link at the bottom of the screen. All of the five main menus also have the Log Out link at the bottom of the screen which can be used to log out of the camera. -
Page 63: Interoperability
Please note “ONVIF” and the ONVIF logo are trademarks of ONVIF Inc. In addition, DRS has implemented many commands and controls to manage the camera through the DRS Web Interface using HTTP POST methods. These commands are available for 3rd party ®... -
Page 64: Maintenance And Troubleshooting
4. Allow to dry. 5. If haze or smears are present, repeat procedure until surface is clean. TROUBLESHOOTING This section highlights some common issues that may be encountered while using the DRS IP ® WatchMaster Elite 3000 Camera, possible causes, and recommended actions. -
Page 65: Table 16: Troubleshooting Symptoms, Causes And Recommendation
VLC media player may not Camera will prompt for the VLC menu or the view menu have been installed install. Alternatively, download of the DRS Web Interface from the VLC website http://www.videolan.org/vlc/ Reset IE or Firefox browser VLC media player may not... -
Page 66: Warranty
User Manual during normal use for a period of twenty-four (24) months from the ® original shipment date. This limited warranty is void if failure of the DRS WatchMaster IP Elite Camera to conform to the warranty has resulted from improper installation, testing, misuse,... -
Page 67: Support
IP Elite User Manual U P P O R T ® For any support questions on WatchMaster IP Elite 3000 Camera, DRS may be contacted through the DRS web site or through the DRS phone number listed below. http://www.drsinfrared.com 877.377.4783...
