INSTALLATION AND INSTRUCTION MANUAL
The
The
Starburst Phantom
Starburst Phantom
®
Undercover Interior LED Lightbar
With Generation-4 LED
Takedown and Directional Pursuit Lights
Models
ULB42-DLP
ULB44-DLP
(Discrete)
(Gen 4 Starburst)
IMPORTANT:
Please read all of the following instructions before installing your new warning light.
PLIT395 REV. B
4/27/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Starburst Phantom ULB42-DLP and is the answer not in the manual?

Questions and answers

Summary of Contents for Starburst Phantom The Starburst Phantom ULB42-DLP

  • Page 1 INSTALLATION AND INSTRUCTION MANUAL Starburst Phantom Starburst Phantom ® Undercover Interior LED Lightbar With Generation-4 LED Takedown and Directional Pursuit Lights Models ULB42-DLP ULB44-DLP (Discrete) (Gen 4 Starburst) IMPORTANT: Please read all of the following instructions before installing your new warning light.
  • Page 3 Star Headlight & Lantern Co., Inc. assumes no responsibility for the integrity of the installation for this or any of its products. The Starburst Phantom ® uses state-of-the-art Light Emitting Diode (LED) technology. This warning light is comprised of ultra-high intensity LEDs that are operated by a micro-controller to efficiently produce light output with lifetimes up to 100,000 hours.

  • Page 4: General Information

    It is the sole responsibility of the owner to ensure the light is secure. ® Starburst Phantom is designed to be mounted on the inside of your vehicle. It is not intended for exterior applications and is not warranted against water damage.
  • Page 5 Starburst Phantom The mounting hardware enclosed with your should ® include the following: PART# DESCRIPTION P30150-220LP LEFT ATTACHING BRACKET P30150-220RP RIGHT ATTACHING BRACKET P30150-79P FORKED "L" BRACKET (Style 1) P30150-189P FORKED "L" BRACKET (Style 2) P30054-27 #10-32 x 1/2" CARRIAGE BOLT...
  • Page 6 Mounting (CONT'D) 1. Slide the enclosed rubber channel over the front edge of the baffle . 2. Insert one of the carriage bolts through one of the washers. Please note that washer is used as a spacer on the square neck of the carriage bolt.
  • Page 7 Mounting (CONT'D) 5. Repeat steps 1-3 for the right attaching bracket . 6. Standard mounting uses the factory installed visor clips already located on the vehicle. If you do not have any, use the Alternate Mounting section page 7. Locate the two visor clips on the vehicle. The style may vary from vehicle to vehicle.
  • Page 8 Mounting (CONT'D) 11. Loosen the five Baffle Adjusting Screws located on the bottom of the ® Starburst Phantom 12. Slide the baffle forward until it satisfactorily blocks any reflected light. 13 Tighten the Baffle Adjusting Screws to secure the baffle in place .

  • Page 9: Alternate Mounting

    Mounting (CONT'D) Alternate Mounting If you are not using the visor clip installation described on the previous page, continue below. 1. Some vehicles may not have visor clips appropriate for the previously described installation, or may completely lack any visor clips. An alternate mounting screw hole is provided in the Alternate bracket for these situations.

  • Page 10: Quick Wiring Guide

    Wiring For proper installation and full operability, this light requires a 10.5A ignition switched power source, connections to the negative terminal of the battery, and four external switches rated for a minimum 1A (user supplied). These lights come with a pre-installed 6-conductor harness. In addition, the cable also contains a bare drain wire and foil shielding.
  • Page 11 Detailed Wiring Descriptions Black: (Ground) Connect the Black wire to the negative side of the battery (preferred) or a good chassis ground. This wire provides the ground for the operation of the light. Bare: (Ground) Connect the bare wire to the negative side of the battery (preferred) or to a good chassis ground.

  • Page 12: Warning Lights

    Operating Instructions Functions Switched Through Wires Main control of this light is done though four of the wires in the harness. They should be connected to +12VDC through 4 switches (user supplied) as described in the Wiring section. Applying power to the appropriate wire elicits the functions described below. LED Flashing Mode (Orange w/Red) The Warning LEDs will flash according to the pattern you have selected (See Pattern Select/Burst Mode Button section on next page).
  • Page 13 Flashing Mode, the Pattern Select/Burst Mode button will act as the Pattern Select button. Each time this switch-button is depressed, ® ® The Star Phantom The Star Phantom will cycle to the next pattern. designed with thirty-five different patterns (see next page).

  • Page 14: Indicator Led

    Operation (CONT'D) Indicator LED ® The Star Phantom Located on the bottom of , below the Map Light is an Indicator LED. When your light is activated in any mode, this LED will flash to alert you to the lightbar activity in the daylight.
  • Page 15 These lights use state-of-the-art Light Emitting Diode (LED) technology. These warning lights are comprised of ultra-high intensity LEDs that are controlled by a solid state flasher unit to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any LEDs in this light. If any of the LED's in your light do fail, please contact Star Headlight for arrangements to have them repaired.
