8900NET
NETWORK INTERFACE MODULE
Instruction Manual
SOFTWARE VERSION 4.2.0
071061205
NOVEMBER 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8900NET and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRASS VALLEY 8900NET

Summary of Contents for GRASS VALLEY 8900NET

  • Page 1 8900NET NETWORK INTERFACE MODULE Instruction Manual SOFTWARE VERSION 4.2.0 071061205 NOVEMBER 2007...
  • Page 2 Affiliate with the N.V. KEMA in The Netherlands CERTIFICATE Certificate Number: 510040.001 The Quality System of: Grass Valley, Inc. 400 Providence Mine Road 15655 SW Greystone Ct. 10 Presidential Way Nevada City, CA 95945 Beaverton, OR 97006 Floor, Suite 300...
  • Page 3 8900NET NETWORK INTERFACE MODULE Instruction Manual SOFTWARE VERSION 4.2.0 071061205 NOVEMBER 2007...
  • Page 4 Benelux/Belgium: +32 (0) 2 334 90 30 Benelux/Netherlands: +31 (0) 35 62 38 42 1 N. Europe: +45 45 96 88 70 Germany, Austria, Eastern Europe: +49 6150 104 444 UK, Ireland, Israel: +44 118 923 0499 Copyright © Grass Valley. All rights reserved. This product may be covered by one or more U.S. and foreign patents.

  • Page 5: Preface

    GeckoFlex Signal Processing System families As part of this module family, it is subject to Safety and Regulatory Compliance described in the Gecko 8900 Series frame and power supply documentation (see the Gecko 8900 Frames and the GeckoFlex Frames Instruction Manuals 8900NET — Instruction Manual...
  • Page 6 Preface 8900NET — Instruction Manual...

  • Page 7: Table Of Contents

    8900NET Module Interface ......... . . 8900NET Module Status Web Page........
  • Page 8 8900NET Network Web Page ........

  • Page 9: 8900Net Network Interface (Net Card) Module

    8900NET Network Interface (Net Card) Module Introduction The 8900NET Network Interface module (Net Card) provides control and monitor access to the Gecko 8900 and GeckoFlex frames and the audio/video media modules in the frames through a web browser graph- ical user interface (GUI), the Newton Control Panel, and SNMP manage- ment applications.

  • Page 10: Remote Control Panels

    Introduction Remote Control Panels The 8900NET module with version 3.2.0 or later software allows the frame to be remotely controlled by the Newton Control Panel via the Ethernet port. Refer to the Newton Control Panel documentation for details. Basic Network Design The 8900NET module can be employed in either a point-to-point or local area network (LAN) control/monitoring configuration.

  • Page 11: Installation

    The GeckoFlex frame requires an 8900NET module running 4.0.0 or later software. 8900NET Module Alarm DIP Switches There are two eight-position DIP switches (S1 and S2) on the 8900NET module for enabling or disabling the overall status reporting of the frame and modules.

  • Page 12: Module Placement In The Gecko 8900 And Geckoflex Frame

    Gecko and GeckoFlex frames do not use the same power supply. Refer to Power Supply/Demand Web Page on page The third cell from the right is allocated for the 8900NET Network Interface or Frame Monitor module (GeckoFlex 8900FF and Gecko 8900TF-V/A). For additional information concerning the Frame Monitor module, refer to the 8900 Frames Instruction Manual or the GeckoFlex Frames Instruction Manual.
  • Page 13 8900NET Network Interface Module (only) Note The 8900NET module can be plugged in and removed from an 8900 frame with power on. When power is applied to the module, LED indicators reflect the initialization process (see Power Up on page 20).

  • Page 14: Cabling

    There are variations for the AC rears in the Gecko 8900 and GeckoFlex Series. Refer to the manual for you specific frame if the information is not covered here. Figure 6. 8900NET Input/Output Connectors on 8900TFN -V/-A Frame Frame Alarm (Video Frame – J102 pins 8 and 9) RS232 (Audio Frame –...

  • Page 15: Rs-232 Communication Port

    8900NET module startup routine. Note The cable used for this connection is a DB-9F to DB-9M, straight-through cable available from Grass Valley as part of cable kit model 8900CAB (10 ft./3 m length). The communication parameters for the RS-232 connection are: •...
  • Page 16 DB-9 Male Female Only pins Pin 1 Pin 5 Pin 9 2,3, & 5 are required Pin 9 Pin 5 Pin 1 DB-9 DB-9 Female Male Pinout Pinout Comm. Parameters: 9600 baud, 8 bits, parity-none, 1 stop, flow-none 8900NET—Instruction Manual...
  • Page 17 If the PC uses a 25-pin RS-232 connector, use a cable adapter as shown in Figure Note The 25-pin adaptor is available from Grass Valley as part of cable kit model 8900CAB. Figure 9. DB-9 Cable and DB-25 Cable Adaptor Pinout...

  • Page 18: Ethernet Cable

    PC. Note This Category 5, UTP Crossover Cable is available from Grass Valley as part of cable kit model 8900CAB (10 ft./3 m length). Figure 10. Point-to-Point RJ-45 Connection and Cable Pinout...
  • Page 19 LAN connection to a network hub. Note Because of varying length requirements and ready availability from network equipment suppliers, this cable is not supplied by Grass Valley. Figure 11. LAN RJ-45 Connection and Cable 8900 Frame Network Ethernet Hub (typical)

  • Page 20: Power Up

    Some functions specific to the 8900NET module are also reported (PWR, ETHER, COMM). LED reporting for each specific LED on the front of the 8900NET module can be disabled if desired on the LED Reporting web page...

  • Page 21: 8900Net Module Indicator Leds

    One of the on-board fault LEDs on a media module in the frame is illuminated or flashing (red) Flashing Indicates the MOD (module health LED) is flashing COMM Indicates 8900NET module is polling the devices on the internal frame communication bus (yellow) ETHER Indicates active communication detected from the 8900NET module on the Ethernet bus (yellow)

  • Page 22: Establishing Frame Network Identity

    With software release 3.2.0 and later, 8900 frames can interface with Net- Config (Network Configuration Application). NetConfig is a PC software tool for configuring and setting up NetConfig-enabled Grass Valley devices. Refer to the NetConfig Manual or the 8900NET Release Notes for current information on using this tool. Good Networking Practices The Local IP Address form of a URL can be used within an intranet to address the Gecko frame’s web page.

  • Page 23: Setting Frame Network Identity

    At the prompt enter: setup You will see: -> setup Here are the current parameters and their values: Local IP Address: 192.168.0.105 Gateway IP Address: 192.168.0.1 Subnet Mask: 255.255.255.0 If a change is made, it is necessary to reboot 8900NET—Instruction Manual...
  • Page 24 It consists of four numbers separated by pe- riods ('.'). Each number can be in the range of 0 to 255. For example: 255.255.255.0 If you respond with a single period (.), a Subnet Mask will not be assigned. Subnet Mask (255.255.255.0): 8900NET—Instruction Manual...

  • Page 25: Network Configuration Storage

    14). In earlier versions of software and frame types with no storage capacity, the IP addresses are stored on the 8900NET module and stay with the module when it is moved to another frame. There are a number of ways to determine what type of frame you have.

  • Page 26: Web Browser Notes

    Figure 6 on page 14). If this memory is missing, the 8900NET module will substitute a default MAC address: 08-00-11-09-CD-AB. If more than one 8900 frame in your network is assigned the default MAC address, network conflicts will occur. To verify...

  • Page 27: Status Monitoring And Reporting

    This section provides a complete summary of frame and module status monitoring and reporting in a Gecko or GeckoFlex system with an 8900NET module installed in the frame. It summarizes what status items are reported and how to enable/disable reporting of each item.

  • Page 28: External Frame Alarm

    Module Health Bus Line The reporting is done using a voltage level sent by the front media module on the Module Health bus to the 8900NET module indicating a fault con- diton. The 8900NET or Frame Monitor module reports this voltage level to the external Frame Alarm connector on the rear of the frame.
  • Page 29 (warning), and not monitored. • Signal output states with reporting functionality (reference output). The Module Health Bus status is also reflected on the 8900NET module. When one of the above conditions exists on a media module, the MOD LED...

  • Page 30: Led Status Reporting

    When the red FAULT LED is lit on an 8900NET module the fault will also be reported on the frame front cover. The LEDs on the front of the 8900NET...

  • Page 31: Web Browser Status Reporting

    Status Monitoring and Reporting Web Browser Status Reporting When the 8900NET module is installed in the frame, a web browser GUI can indicate frame and module status on the following web pages: • Frame Status web page – reports overall frame and module status in graphical and text formats.

  • Page 32: Snmp Monitoring

    33. The SNMP trap reports available and their severity are configured on the Gecko Frame SNMP Reporting web page for all media modules, the 8900NET module, Power Supply 1 and 2, the Frame Bus Status, and Module Health status (8900TFN Video and GeckoFlex frames only).
  • Page 33 Some GeckoFlex modules have additional SNMP controls with the 8900NET version 4.2.0 release. The version 2.0.0 MIB must be used in con- junction with this 8900NET release for the additional. Details for using these additional controls are included in the specific module instruction manual.

  • Page 34: Using The 8900Net Gui

    Using the 8900NET GUI Using the 8900NET GUI Once the frame’s first web page—Frame Status—has been accessed (see Figure 15 on page 36), navigation can be done using the hypertext Link List in the left column. The Link List is a two-tier list with the frame’s devices at the highest tier and sub-pages for each device in a secondary tier (sub-list) below the parent device.
  • Page 35 Slot contains a fully Frame Bus capable module. Yellow Warning Module 8900NET has detected a warning condition in module due to lack of input sig- nal or incomplete support for remote monitoring and control. Ability of module to perform intended operation is limited. Fault Module 8900NET has detected a fault condition in module.
  • Page 36 The first release of 8960DEC module code causes a Fault condition because it never responds on the Frame Bus. There is no way for the 8900NET module to tell the difference between a fully functional early release of 8960DEC and a module whose Frame Bus Interface has failed.

  • Page 37: Older 8900 Module Support

    Note When the 8900NET is first installed or when many modules are installed simultaneously, it may take some time for the 8900NET to poll, update status and build the HTML pages, especially if there are modules that do not respond as expected, such as legacy modules. During these periods the Frame Status Page may fall behind temporarily until the 8900NET board can catch up and present a true current status.
  • Page 38 10 and 50 (see Figure 16). Incompatible legacy modules can be returned to Grass Valley for upgrade to the new con- nector. Note If an unmodified legacy module is installed in the frame, the frame commu- nication bus will be interrupted and all module icons in the frame status display will be red.

  • Page 39: Frame Configuration Web Page

    Locate Frame Flash Locate Frame flash the front cover FAULT Indicator LED on the 8900NET module on and off with a 50 ms duty cycle to help locate the 8900 frame. Note This function can also be performed using the NetConfig application. For Net- Config, right click on the frame name in the menu tree on the left side of the NetConfig screen and select Identify Device.
  • Page 40 Using the 8900NET GUI Figure 17. Gecko Frame Configuration Web Page 8900NET—Instruction Manual...

  • Page 41: Frame Connections Web Page

    Using the 8900NET GUI Frame Connections Web Page Selecting the Connections link will bring up the Connections web page. This page provides a summary of the type and IP Address of any Newton this software or hardware panel or other control panel communicating with link any module in the frame.

  • Page 42: Frame Alarm Reporting Web Page

    Using the 8900NET GUI Frame Alarm Reporting Web Page Selecting the Frame Alarm Reports link on any Frame or 8900NET web page will bring up the Frame Alarm Reporting web page shown in Figure 20 on page 43. This page provides a summary of the various alarms...
  • Page 43 Using the 8900NET GUI Figure 20. Frame Alarm Reporting Web Page Reports status of Module Health Report checkbox in Frame Health Reporting table. Disable or Enable Module Health Fault reporting to Frame Status web page and Frame Heath Reporting. Enable (Report checked)
  • Page 44 Using the 8900NET GUI Figure 21. Frame Status Web Page with Internal Module Healthbus Enabled Figure 22. Frame Health Reporting Table with Internal Module Healthbus Enabled 8900NET—Instruction Manual...
  • Page 45 Using the 8900NET GUI Setting the control to turns off the Module Internal Module Healthbus Disable Health bus fault reporting to the Frame Status web page, and changes the reporting of the module with a fault and the Module Health selection in the Frame Health Reporting table to green.
  • Page 46 Using the 8900NET GUI Figure 24. Frame Health Reporting Table with Internal Module Healthbus Disabled Fault reporting (Red) has been disabled and set for Pass (green). 8900NET—Instruction Manual...
  • Page 47 • Media module (Slots 1-10) fault alarms, and loss of signal, loss of reference, and configuration error warnings (as specified for each specific module), • 8900NET module fault reporting, • Power supply 1 and 2 fault reporting, • Frame Bus status fault reporting, •...

  • Page 48: Led Reporting Web Page

    Figure 25 on page 49. This web page allows enabling and disabling of LED reporting from modules and other components in the frame to the LEDs on the front of the 8900NET module. this link •...
  • Page 49 Using the 8900NET GUI Figure 25. LED Reporting Web Page 8900NET—Instruction Manual...

  • Page 50: Snmp Reporting Web Page

    Using the 8900NET GUI SNMP Reporting Web Page Selecting the SNMP Reporting web page link from any frame or 8900NET web page will bring up the web page shown in Figure 26 on page 51. When an SNMP Managers such as Thomson Grass Valley’s NetCentral is installed, SNMP trap reporting from the frame and modules can be config- ured using these controls.
  • Page 51 Using the 8900NET GUI Figure 26. SNMP Reporting Web Page 8900NET—Instruction Manual...

  • Page 52: Power Supply/Demand Web Page

    Using the 8900NET GUI Power Supply/Demand Web Page The Power Supply/Demand web page (Figure 28 on page 53 for GeckoFlex frame and Figure 29 on page 54 for Gecko frame) provides the following for the 8900 power supplies installed: •...
  • Page 53 Power Status – is also reported on the Frame Status page. • – a Power table lists each of the media modules, the 8900NET Power module, and the power supplies present in the frame and their power demand. The total amount of power demand is totaled at the bottom of the display.
  • Page 54 Using the 8900NET GUI Figure 29. Gecko Frame – Power Supply/Demand Web Page 8900NET—Instruction Manual...

  • Page 55: Frame Power Supply Web Pages

    PS1 and/or PS2 LED on the front of the 8900NET module can be disabled if desired. • When an SNMP manager is installed on the 8900NET module, an SNMP Trap Reports link will be present. This will link to the SNMP...

  • Page 56: 8900Net Module Interface

    Using the 8900NET GUI 8900NET Module Interface This section describes the web browser interface for the 8900NET module. 8900NET Module Status Web Page The Status web page illustrated in Figure 31 displays 8900NET: this • Module identity, location and internal Net Card diagnostic...

  • Page 57: 8900Net Module Configuration Web Page

    – the 8900NET module can be assigned as asset tag Asset Tag Assignment identifier by entering numbers or text in the Asset Tag field. This infor- mation will appear on the 8900NET Status web page and in the module inventory when using the NetConfig Network Configuration applica- tion.
  • Page 58 Using the 8900NET GUI Install SNMP Agent When SNMP Agent software is installed on the 8900NET module, enabled status reports are sent to an SNMP Manager such as the Grass Valley’s Net- Central application. Refer to Establishing Frame Network Identity on page 22 for more information.
  • Page 59 DELETE it remains active until the next module reboot. Note Report destination status does not change until the 8900NET module is rebooted. The status column to the left of the activation operation pull-down window provides one of the following status reports: •...
  • Page 60 Using the 8900NET GUI Figure 34. 8900NET Configuration Web Page (SNMP Agent Installed) 8900NET—Instruction Manual...

  • Page 61: 8900Net Network Web Page

    Note Depending on the type of frame this module is installed in, this network con- link figuration is saved on either the 8900NET module or on the frame backplane. Refer to Network Configuration Storage on page 25 for details.

  • Page 62: Media Module Slot Configuration

    Both frame and module names and configuration information can be saved to file and recalled as necessary. This allows quick and easy reconfiguration of the 8900NET module if it must be replaced or moved to another frame (see Frame Configuration Web Page on page 39).
  • Page 63 (see the 42). • An link is provided to the LED Reporting web page for LED Reports setting up LED reporting to the 8900NET module for this media module (see the LED Reporting Web Page on page 48). • An...

  • Page 64: Upgrading 8900Net Software

    Software field upgrade packages for modules are available from the Thomson Grass Valley Customer Service FAQ site and the public ftp site. You may connect to the Grass Valley FAQ site to access the latest module and free NetConfig software and subscribe to software updates automati- cally at the following URL: http://www.thomsongrassvalley.com/downloads...

  • Page 65: Service

    LED indications. If the module is still not operating correctly, replace it with a known good spare and return the faulty module to a designated Grass Valley repair depot. Call your Grass Valley representative for depot location. Contacting Grass Valley...

  • Page 66: Troubleshooting Gui Operation

    Troubleshooting GUI Operation Troubleshooting GUI Operation The following is a list of possible 8900NET GUI and network problems and logical steps for troubleshooting them. Cannot Open Any of the Frame’s Web Pages 1. Check power to the frame. a. Is at least one of the power supplies operating? b.
  • Page 67 Using a crossover Ethernet cable, connect the frame directly to a workstation. The workstation should be assigned an IP Address on the same Subnet as the frame. Attempt to load the frame’s web page from a Browser on this workstation. 8900NET—Instruction Manual...
  • Page 68 Check if the LOC/REM – LOCAL jumper on the module is set for local control only. (Refer to that specific module’s manual for help.) b. In version 2.0 and later of the 8900NET module software, the web pages for a module in the remote lockout state will indicate that module remote control is disabled and the module’s controls on the...
  • Page 69 Refer to the module’s instruction manual. 3. If only the 8900NET module is read-only, the 8900NET module may be in remote lockout mode. a. Check the 8900NET module’s status page to see if the NET CARD status is disabled.
  • Page 70 Event Messages From the Frame Are Not Being Displayed by NetCentral or Another SNMP Manager Application 1. Check that the frame is powered on and configured with an 8900NET module on the Network. 2. Check that the 8900NET module in the frame is loaded with software version 2.1 or later.
  • Page 71 5. Check that the particular event has been enabled in the frame. • For all events, check that the STATUS switch (Switch 1) on the S2 DIP switch block of the 8900NET module is Enabled. • For Module Failure-Fixed events:...
  • Page 72 Troubleshooting GUI Operation block of the 8900NET module is Enabled, and Check that the parameter on the frame’s MODULE HEALTH REPORTING page is Enabled. CONFIGURATION • Check that the SNMP Manager is properly configured to receive the Event Messages. Check that the SNMP Manager has been assigned the same commu- nity name as in the frame’s configuration.

  • Page 73: Logprint Procedure From Gecko/Geckoflex Frame

    Troubleshooting GUI Operation LogPrint Procedure From Gecko/GeckoFlex Frame You may use the logging function of the 8900NET module to troubleshoot errors from modules in the Gecko or GeckoFlex frame. The log will report the last 300 commands received by the Gecko frame. It will contain all com- mands from changes made through the web interface or control panel.
  • Page 74 Figure 39. Connect To Window This will bring up the telnet window shown in Figure 40 on page 5. In the field that appears, type the IP address of the frame Host address you wish to connect to and press 8900NET—Instruction Manual...
  • Page 75 This will bring up the telnet-HyperTerminal screen shown in Figure Figure 41. Telnet Screen 6. To save the log to a .txt file while it is running, select the Transfer pulldown in HyperTerminal and select before running the Capture Text (Figure 42 on page 76). 8900NET—Instruction Manual...
  • Page 76 10. Once the log has stopped, you may also stop the text capture by selecting Capture Text in the Transfer pulldown again and select Stop (Figure 45). The text file will now contain a record of the last 300 commands received by the frame. 8900NET—Instruction Manual...
  • Page 77 Troubleshooting GUI Operation Figure 45. Stop Text Capture The log will also appear in the HyperText window as shown in Figure Figure 46. Log Print 8900NET—Instruction Manual...

  • Page 78: Functional Description

    Functional Description Functional Description Refer to the block diagram in Figure 47 while reading the following func- tional description. Figure 47. 8900NET Block Diagram +5 V On-board +12 V Regulator +3.3 V Temperature Boot ROM Sensing SDRAM NVRAM RS-232 RS-232 (9-pin D)

  • Page 79: Rom And Ram

    Ethernet Port The 10Base-T Ethernet port provides configuration and monitoring access to the frame, frame modules and the 8900NET module using a web browser. RS-232 Serial Port The RS-232 port is used to initialize the module with critical network parameters including a static assigned IP Address.

  • Page 80: Fan Speed Control And Monitor

    8995UDX which require a dual rear slot in the GeckoFlex frame. This setting is made on the 8900NET module switch S1 segment 7 (refer to 8900NET Module Alarm DIP Switches on page 11).

  • Page 81: Specifications

    Specifications Specifications Table 6. 8900NET Specifications Parameter Value Recommended Software Web browser Netscape 4.x or Internet Explorer 4.x or later PC operating system Windows 95/98 or later Terminal emulation Hyperterminal Environmental Frame temperature range 0 to 45° C Operating humidity range...
