Summary of Contents for Kenco Cimbali M52

Page 1 Cimbali M52 Cimbali M52 Fully Automatic Fully Automatic Espresso Machine Espresso Machine...
Page 2 This handbook contains instructions for the Cimbali M52 Fully Automatic Espresso Machine. Please read the handbook before using the machine. Keep this fold out page open while reading the Operator’s Handbook.
Page 3 Machine Layout Cimbali M52 Fully Automatic External Features Coffee Hoppers Cleaning Tablet Access Flap Display Cup Warmer Display Panel Key Sensor Selection Panel Product LEDs Coffee Spout Cover Product Select Milk Tube Keys Milk Control Valve Coffee Grounds Door Cappuccino System...
Page 4: Milk Cooler Technical Details
Technical Details Cimbali M52 Fully Automatic Dimensions: Width 500 mm Depth 640 mm Height 765 mm ELECTRICAL SUPPLY Water pressure at the stoptap must be within 230V ac 32 Amps single phase, or 3 phase, the limits of 1 to 6 bar.
Page 5 Do Not Print Do Not Print This This Page Page...
Page 6: Table Of Contents
Contents Cimbali M52 Fully Automatic Machine Layout Inside Front Cover Cimbali M52 Fully Automatic Technical Details Inside Front Cover Milk Cooler Machine Layout Milk Cooler Technical Details Cup Warmer Machine Layout Cup Warmer Technical Details Important Safeguards Setting Up Instructions...
Page 7 Machine Layout “Frigomilk” Milk Cooler External Features Milk Tube Hole (side or front entry) ON/OFF Switch Temperature Indicator “Fresh Milk” Milk Cooler External Features Reserve Tank Indicator Power ON Indicator Indicator ON/OFF Switch Control High Panel Temperature Temperature Indicator Indicator Milk Tube...
Page 8 Technical Details “Frigomilk” Milk Cooler Dimensions Width 220 mm Depth 350 mm Height 320 mm Power Requirement A 13A socket outlet installed in accordance with the latest edition of the IEE Wiring Regulations. Voltage 12Vdc from a transformer supplied with the cooler Capacity 3 litre Operating Temp...
Page 9 Machine Layout Cup Warmer External Features Cup Basket Top Shelf Middle Shelf Lower Shelf Temperature Control ON/OFF Switch Technical Details Cup Warmer Dimensions Width 370 mm Depth 530 mm Height 680 mm Power Requirement A 13A socket outlet installed in accordance with the latest edition of the IEE Wiring Regulations.
Page 10: Important Safeguards
Important Safeguards Before using, cleaning or servicing the Cimbali M52 Fully Automatic, Milk Cooler or Cup Warmer, always follow these basic safety precautions: Read the instructions carefully before using the machines. Ensure that anyone who will be involved with the cleaning or refilling of the machines also reads the instructions.
Page 11: Setting Up Instructions
Setting Up Instructions Cimbali M52 Fully Automatic Ensure the machine is connected to the electrical Master and water supplies and that both supplies are Programming ON/OFF switched on. Panel switch Manual Switch - On Lift the display panel to gain access to the programming panel.
Page 12 Automatic Switch - On If the “CLOCK” function has been activated the machine will switch on automatically at the previously programmed time and switch off at the previously programmed time. The machine displays will be the same as those for the ESPRESSOTIME Manual Switch - On and the functioning of the machine is also the same.
Page 13 Setting Up Instructions (Cont.) Adjusting the Clock The clock may be adjusted only when the “CLOCK” mode is activated. Switch on the machine, the display will show: ESPRESSOTIME On the programming panel press the + or - keys to Monday 12:30 alter the time as required.
Page 14 Filling the Bean Hoppers The Cimbali M52 machine is fitted with two bean hoppers. Each hopper is fitted with a removable funnel to ensure a smooth flow of beans to the grinders. Note: Use only the amount of beans required for the next 3 to 4 hours, coffee beans lose their aroma and flavour if left in the hoppers for a long time.
Page 15 Setting Up Instructions (Cont.) “Frigomilk” Milk Cooler Ensure the milk cooler is connected to the electrical supply via the voltage transformer. Ensure the milk container is clean and fitted in the machine. Set the ON/OFF switch to ON. Milk Observe the temperature indicator; wait Container until the display reaches 5 C (41...
Page 16 “Fresh Milk” Milk Cooler Ensure the milk cooler is connected to the mains electricity supply and that the supply is switched ON. Insert the milk tube into the hole in the machine. Press the ON/OFF switch and ensure the “machine ON” and “high temperature” lights Milk illuminate.
Page 17 Setting Up Instructions (Cont.) Cup Warmer Ensure that the cup warmer is connected to the mains electrical supply, and that the supply is switched on. Set the ON/OFF switch to ON and ensure that the indicator illuminates. WARNING: THE SHELVES OF THE CUP WARMER ARE HOT DURING OPERATION.
Page 18: Dispensing Drinks
Dispensing Drinks Coffee/Milk Position a cup on the drip tray, underneath the cappuccino system. Press the key on the selection panel for the required coffee or milk product. The product LED adjacent to the selected key will illuminate whilst the product is being dispensed. Delivery will terminate automatically.
Page 19: Daily Cleaning
Daily Cleaning Cimbali M52 Fully Automatic The Daily Cleaning instructions detailed in this section are to be carried out at the end of each working day. WARNINGS: 1. TAKE NOTE OF THE HEALTH AND SAFETY WARNINGS RELATING TO THE CLEANING PRODUCTS.
Page 20 Cleaning the Milk Circuit The milk circuit is cleaned using an automatic cleaning cycle after which the cappuccino system is dismantled and cleaned by hand. This procedure is to be carried out at the end of each day or when requested by the machine. A “wash milk circuit” message will appear in the display window and an audible warning will be heard.
Page 21 Daily Cleaning (Cont.) Rotate and remove the top jet. Top Jet Disassemble the cappuccino system as follows: Remove the coffee tube connector located on the back of the cappuccino system. Rotate the cappuccino system 90 anticlockwise. Gently pull downwards and remove. Unscrew the ring nut and disassemble the five parts.
Page 22 Remove any organic residue. CAUTION: Do not spray any liquids into the ventilation slots. Cleaning Materials The following cleaning materials are available from Kenco Customer Service on 0870 600 6556. Bioguard Milk Cleaner (Product Code 058354) Bioguard Cleaning Tablets (Product Code 058373)
Page 23 Daily Cleaning (Cont.) “Frigomilk” Milk Cooler The daily cleaning instructions detailed in this section are to be carried out at the end of each working day. Milk Switch off and disconnect the electrical Container supply to the machine. Remove the milk cooler lid. Remove the milk tube and lift out the milk container.
Page 24 “Fresh Milk” Milk Cooler The daily cleaning instructions detailed in this section are to be carried out at the end of each working day. Switch off and disconnect the electrical supply to the machine. Open the door of the machine. Remove the milk tube and lift out the milk container.
Page 25: Display Messages
Display Messages Cimbali M52 Fully Automatic When the machine is working normally the display changes to provide operational information. The following is a list of messages that may appear, and the action required if they do. ESPRESSOTIME This message means that the boiler is not up to the required Machine Cold temperature.
Page 26 Monday 12:30 Installation The machine will automatically refill the boiler. The message will remain until the operation is complete. This message is displayed when the machine requires a periodic ESPRESSOTIME service. Contact Kenco Customer Service. Monday 12:30 Service needed...
Page 27: Simple Checks Before Calling A Service Technician
Simple Checks Before Calling A Service Technician The Cimbali M52 Fully Automatic machine together with its associated milk cooler and cup warmer is designed and manufactured to give excellent service. However, faults may occur. Some faults may be remedied quickly by the operator without the need to call a Service Technician.
Page 28: Health And Safety At Work And Electricity At Work Regulations 1989
Health and Safety at Work and Electricity at Work Regulations 1989 The above regulations state that all electrical equipment should be regularly checked for safety. It is recommended that the machine should be regularly checked by the person, or people, responsible for daily maintenance and use, by switching off and disconnecting the plug and checking the general condition of the machine, paying particular attention to the mains electrical lead and plug.
Page 29: Mains Electrical Plug
Mains Electrical Plug The 3-pin plugs at the end of the Milk Cooler and Cup Warmer flexible mains electrical power supply cords are NOT WATERPROOF. Therefore, they must be kept dry. These machines are equipped with plugs which are moulded to the power supply cords and fitted with cartridge fuses.
Page 30: Recommended Spares
Recommended Spares Cimbali M52 Fully Automatic Item Part No. Description 429 181 000 Hopper Funnel 429 056 000 Bean Hopper Lid 412 054 010 Cup Protector 412 520 000 Waste Grounds Container 485 141 006 Union 533 590 400 Filter Assembly 401 347 000 Drip Tray ‘O’...
Page 31 Recommended Spares (Cont.) Cappuccino System...
Page 32 Item Part No. Description 537-024-060 Milk Control Valve 429 399 000 Tube Silicone 433 009 010 Union 401 362 000 ‘O’ Ring 401 338 000 ‘O’ Ring 433 028 020 Top Jet 433 060 000 Ring Nut 401 338 000 ‘O’...
Page 33: Customer Service
Customer Service Supplies KENCO Supplies Shortly after your machines are installed, you will be contacted by KENCO Customer Service to establish an agreed call frequency for supplies of products. However, should you need to contact us with an order: Telephone on 0870 600 6556 or Fax on 01295 267530 Outside normal business hours, a telephone answering service is available.
Page 34 O P E R A T O R ’ S H A N D B O O K...
Page 35 Cimbali M52 Cimbali M52 Fully Automatic Fully Automatic Espresso Machine Espresso Machine...
