HDS-21R / 41R
The World's Best 2x1 / 4x1 HDMI/HDTV Switch
Owner's Manual
Dtrovision LLC
9A Bergen Turnpike
Little Ferry, NJ 07643
USA
Tel: +1.201.488.3232
Fax: +1.781.207.0351
Email: support@dtrovision.com
www.dtrovision.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@dtrovision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDS-21R and is the answer not in the manual?

Questions and answers

Related Manuals for Pure Link HDS-21R

Summary of Contents for Pure Link HDS-21R

  • Page 1 HDS-21R / 41R The World’s Best 2x1 / 4x1 HDMI/HDTV Switch Owner’s Manual Dtrovision LLC 9A Bergen Turnpike Little Ferry, NJ 07643 Tel: +1.201.488.3232 Fax: +1.781.207.0351 Email: support@dtrovision.com www.dtrovision.com For order support, please contact your local dealer. For technical support, please contact us at...
  • Page 2 It is perfect for home theater systems. No more hassles of manually plugging in different HDMI connectors to view different video sources (e.g., DVD, Satellite receiver, computer, TiVo). ITEM DESCRIPTION Model Name HDS-21R / HDS-41R Input Signal HDMI Single Link , 2 Port / 4 Port for HDS-41R Output Signal HDMI (TMDS ) Single Link...

  • Page 3: Environmental And Reliability Specifications

    Environmental and Reliability Specifications 1. Operating Conditions Temperature: 10℃~ 40℃ Humidity: 10% ~ 80%, non-condensing 2. Transportation Conditions Temperature: -25℃~ 60℃ Humidity: 5% ~ 95%, non-condensing Altitude: maximum 15,000m 3. Storage Conditions Temperature: -20℃~ 45℃ Humidity: 5% ~ 95%, non-condensing Altitude: maximum 3,000m 4.

  • Page 4: Main Features

    High Quality Picture - No Signal Loss and Digital Noise Free HDS-21R is built to deliver the highest quality picture preserving the native resolutions of the video sources (with audio) without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated.
  • Page 5 HDMI Connection Instruction 1. Connect your video source’s HDMI output port to the HDMI switch’s HDMI input port using standard HDMI cables (not included). Make sure all your HDMI sources and the display is turned off before connecting the cables) 2.

  • Page 6: Rs232 Connection Diagram

    RS232 Connection Diagram...

  • Page 7: Mechanical Specification

    Mechanical Specification Dimensions: L 9 x W 4.1 x H 1.2 inches DC 5V: DC Power 5V Input RS-232: Com Port for Switch Function Control HDMI IN CH1 & 2: HDMI Inputs *HDMI IN CH1,2,3,4: HDMI Inputs for HDS-41R* HDMI OUT : HDMI Output LED CH1~2 : Selected Channel Indication...

  • Page 8: Technical Specification

    Technical Specification Frequency bandwidth: 1.65 Gbps (Single Link) Supporting Graphic Resolution: Computers up to UXGA (1600 X 1200 at up to 75Hz) AV equipments up to 1080p (1920 X 1080 at up to 60Hz) Inputs: HDMI Female port(x2) (* 2 ports if HDS-41R) Output: HDMI Female port(x1) Power supply: DC 5V, 1.2A Adapter included.

  • Page 9: Warranty Information

    Warranty Information Two Year Warranty Dtrovision warrants that this HDS-21R / HDS-41R HDMI Switch to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) year from the date of purchase from Dtrovision or its authorized resellers.

  • Page 10: Troubleshooting

    Troubleshooting Problem Solution Switch will not operate Make sure the 5V power is plugged in the back of the unit. Check to see if the power LED light is on. No picture(or signal) 1. In case your video source is HDCP enabled, make sure your video or Poor picture display (HDTV) is HDCP compliant.
