Summary of Contents for Stanley EH6883
- Page 1 MODEL NO. EH6883 Propane Electric Blow Heater For service, spare parts or product information, please contact Smart Marketing Group Pty. Ltd. AUST. 1300 660 457 N.Z. 0800 474 876 03004 02/13...
-
Page 2: Table Of Contents
CONTENTS Section Page FOR YOUR SAFETY Introduction Warranty If you smell gas: 1. Shut off the gas to the appliance. Operation and Maintenance Instructions 2. Extinguish any open flame. Cylinder Care 3. If odour continues, immediately call your gas supplier. Do not store or use gasoline or other flammable vapour and Operating Instructions liquids in the vicinity of this or any other appliance. -
Page 3: Introduction
How to claim under this warranty. INTRODUCTION • Call customer service, phone number at the top. Dear Customer, • Ensure you have the following: Original purchase receipt, Model of Thank you for purchasing this heater which has passed through our heater. -
Page 4: Warranty
COMPLETE WARRANTY STATEMENT – HEATER GROUP As soon as you have purchased the heater, we recommend that If a warranty fault is found the freight cost will be credited to the you check to make sure it is intact and that you read the operating owner. -
Page 5: Operation And Maintenance Instructions
OPERATION AND MAINTENANCE 3. Heaters must be placed on a level and adequate footing and be readily accessible. INSTRUCTIONS 4. The gas manifold supply pressure must be regulated at 150 kPa utilising only the regulator supplied with the heater. 5. The appliance must be inspected before each use, and at least IMPORTANT SAFETY RULES annually by a qualified service person. -
Page 6: Cylinder Care
CYLINDER CARE POL CYLINDER CONNECTION DEVICE Gas Inlet Connection Screw the coupling nut of regulator into the cylinder valve outlet. Gas inlet connection is a 3/8 internal flare located at the rear of heater, suitable for connection to the hose assembly supplied with heater. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Test Firing Heater Test fire heater, following the lighting instructions on heater case. Leak test all gas connections with soapy water. Soap bubbles indicate gas leakage. DO NOT use a match to test for gas leaks. WARNING: Improper adjustment, alteration, service or maintenance can cause injury or property damage. -
Page 8: Maintenance Schedule
MAINTENANCE SCHEDULE Cleaning Air Intake The main air intake at the rear of the heater should be cleaned on a The following periodic maintenance should be carried out either by the regular schedule. This work can be carried out by the user. Manufacturer or by the User as indicated below. -
Page 9: Parts List
PARTS LIST 1. Data label 2. Fan motor 3. Internal wiring 4. Fan blade 5. Burner 6. Handle for transport 7. Internal body 8. External body 9. Hot air output 10. Burner air intake 11. Igniter button 12. Gas inlet connection 13. -
Page 10: Servicing Instructions
Diameter 25mm in doubt always consult a qualified electrician. Inlet diameter 13mm Rating Label Ignition Press button ignition Fan heater EH6883 Voltage 220-240V AC - 50Hz Flame Safeguard “CH 20psi. Chant CSA K-80” Electro Magnet and Thermocouple Input Wattage 130W... -
Page 11: Specific Safety Instructions
SAFE OPERATION SPECIFIC SAFETY INSTRUCTIONS Children or persons with reduced physical, sensory or mental WARNING capabilities should not be allowed to touch or operate heaters or touch extension cords. All heaters should be kept out of reach of children Do not use the heater in areas where there is a risk of explosion or persons with reduced physical, sensory or mental capabilities or fire from flammable gases. -
Page 12: Technical Information
Do not return to place of purchase. Keep your purchase receipt, this will be required to make any claims under the 12 month warranty. STANLEY® is a registered trademark of Stanley Works and its subsidiaries. Manufactured under license by Smart Marketing Group Pty Ltd.
