  • Page 1 TOuCh P10 FOR DISPLAYS: 55”, 70” AND 82” ENgliSh V01.3 - 2014-7...

  • Page 2: Table Of Contents

    Thank you for purchasing our product. Please read this manual carefully before operation your set and retain it for future reference. FT55-P10 FT70-P10 FT82-P10 CONTENTS EMC Certification ____________________________________________________________ Safety Precautions __________________________________________________________ Introduction _________________________________________________________________ Connections _________________________________________________________________ OSD Menu __________________________________________________________________ Troubleshooting ____________________________________________________________ Specifications _______________________________________________________________ Dimensions _________________________________________________________________ Product Warranty ___________________________________________________________...

  • Page 3: Emc Certification

    1. EMC (ElECTrO MagNETiC COMPaTibiliTy) CErTifiCaTiON This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Please read the following safety instructions as they are designed to prevent damage to property and harm to the user. Please read the following safety instructions as they are designed to prevent damage to property and harm to the user. For the impact of misprints or mistypes no liability is accepted. Subject to (technical and specifications) changes.

  • Page 4: Safety Precautions

    2. SafETy PrECauTiONS Warning 1. Before using your monitor, please thoroughly check all the items in this manual. 2. Please keep this manual in a safe place for future purposes. 3. Before handling the monitor, you need to unplug the power cable of the monitor. Clean the monitor with soft cloth, without using any liquid spray type detergent. 4. Do not use the parts not recommended by us. Doing so might cause danger. 5. When unplugging the main power cable or the adopters, hold the place with your hand do not pull them out. 6. Main power cord: Do not put anything on top of the male power cord or set on it. Do not place the monitor in moist places. For example, bathtub, sink, or laundry machine. Do not go near wet floor or pool. 7. The holes on top, back and bottom of the monitor are designed for air circulation. Do not fill in this hole or cover it, in order to sustain its functions and avoid over heating. The monitor must be placed next to the heater or radiator, nor should it be placed in a place without the proper ventilation. 8. When using, keep at least 5 cm of space between the monitor and the wall or other objects. 9. You can only use 12V adaptor type power. If you have a question about the type of adapter, please ask the retailer. 10. The power socket and cord in use should be able to handle the sum of current. 11. Do not install the monitor in places the user might easily bump into. 12. Please comply with all warnings and contents of this manual. 13. Do not overload the outlet and avoid using external extension cord. Not doing so may be the cause of fire and electric shock. 14. Opening the cover and exposing the monitor will expose you to the high voltage current. Do not disassemble the monitor yourself and seek the repair from the licensed professional.

  • Page 5: User Guide

    15. In case of the following happenings, please unplug the power plug or adaptor and seek help from professional. - The damage of the power cord plug. - When monitor was dropped or component is damaged. - There is significant abnormality in the monitor. 16. Power cord is the main component of turning on and off the monitor. If not in use for a long time, please unplug the power plug. 17. Place in a wall ventilated place and avoid strong sunlight, high temperature or moisture. 18. Please use the monitor between -20 degree Celsius 55 degree Celsius. 19. Using it outside of this range might cause permanent damage. user guide NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 6: Introduction

    3. iNTrODuCTiON 3.1 Summary Thank you for purchasing our monitors. This product will give you satisfaction with great resolution, light weight, power saving, no electromagnetic waves, comfortable, safe and eco friendly. We sincerely thank you for purchasing and using our product. 3.2 Performance and features - Use Active Matrix LCD - No electromagnetic wave due to MYCOM digital technology - Built in AV signal connection component - Complies with International Power saving code VESA DPMS - Supports DDC 1/2B and window PNP Plug & Play - International VESA size holes for mounting on walls. 3.3 Packing list Please make sure all of the following items are included. - LCD Monitor (1) - VGA Cable (2), Power Cord (3) - Touch & Camera Cable (USB or Serial) (4), 3.5 mm Audio cable (5) - Remote Control (6), Touchpen (7) - Manual (8) ➊ ➋ ➌ ➍...

  • Page 7: Connections

    4. CONNECTiONS 1. Before connect turn off your monitor and unplug its power cord. 2. Place the monitor on a flat hard surface, like a table or a desk. 3. Plug in the main power cable. Use of multi contents is recommended to avoid damaging the monitor due to abnormal electricity flow. 4. Please connect the signal cable. When connecting, please tighten the screw very well, with out using any tools but by using your hand. 5. Turn on Monitor power and then turn on Computer power. 6. Please refer to the diagram below for connection. Display SPDIF Component Port PC RGB Video L/R Y/Pb/Pd/L/R 2 x HDMI Audio RS-232 Media Player Audio Touch/Cam Input & FW Touch & Cam, and Mic Cable D-Sub Cable HDMI Cable...

  • Page 8: Osd Menu

    5. OSD MENu Hardware buttons at the backside of the monitor. POWER DOWN VOL + VOL - MENU SOURCE ➊ ➋ ➌ ➍ ➎ ➏ ➐ 1. Power Use this button for Power On / Off 2. UP move menu up 3. DOWN move menu down 4. VOL_+ Volume Up / move menu bottom / Menu Value Increase 5. VOL_- Volume Down / move menu top / Menu Value Decrease 6. MENU Menu mode active / menu mode close / move top 7. SOURCE select the input signal (External input/Component/RGB-PC/HDMI/DP)
  • Page 9 5.1 uSE OSD MENu OSD Menu Mode / Picture Mode • Press MENU button, open the OSD Menu mode UP / DOWN / VOL+ / VOL- buttons allow you to change setting after moving up/down/ left/right. • The remote control uses the up/down/left/right and use select button • Picture mode allows you to pick Dynamic / Standard / Mild / User You can adjust Brightness, Contrast, Tint, Color and Sharpness • Color Temperature - 6500K / 9300K / 11000K / User You can adjust Color Temperature. • Aspect Ratio - Auto, 4:3, 16:9, Zoom1, Zoom2, Full Screen, Panorama You can adjust Picture size. • Noise Reduction - Off / Low / Middle / High You can remove noise when noise appears on the screen. • Back Light - 0 ~ 100 When the number is lowered, power consumption is lowered as well. • Color Range - 16~235, 0~255 To finish, press MENU button...
  • Page 10 audio Mode • Press MENU button, open the OSD Menu mode UP / DOWN / VOL+ / VOL- buttons allow you to change setting after moving up/ down/left/right. • The remote control uses the up/down/left/right and use select button • Sound mode - Music / Standard / User / Sports / Movie You can adjust Bass and Treble. • Balance -50 ~ +50 You can adjust left and right level of sound output. • Auto Volume On / Off • Surround Mode - Off / Surround / SRS True surround X T • SPDIF Mode - Auto / PCM • EQ - 120Hz / 500Hz / 1.5kHz / 5kHz / 10kHz You can adjust the sound of each frequency range. To finish, press Menu button...
  • Page 11 Option mode • Press MENU button, open the OSD Menu mode UP / DOWN / VOL+ / VOL- buttons allow you to change setting after moving up/ down/left/right. • The remote control uses the up/down/left/right and use select button • OSD Language You can change the language of OSD Menu. • Restore Factory Default Restore user changed data back to default value. • Transparency - Off / Low / Middle / High You can adjust the transparency of OSD Menu. • OSD Duration - Off / 5sec / 10sec / 15sec You can set up the time when OSD menu will disappear. • Software Update[USB] You can update software through USB.
  • Page 12 Time mode • Press MENU button, open the OSD Menu mode UP / DOWN / VOL+ / VOL- buttons allow you to change setting after moving up/ down/left/right. • The remote control uses the up/down/left/right and use select button • Clock - Date / Month / Year / Hour / Minute You can set up current date and time. • Off time - Off / Once / Every day / Mon ~ Fri / Mon ~ Sat. / Sat ~ Sun / Sunday - Hour / Minute Product can be turned off automatically by setting day and time. • On time - Off / Once / Every day / Mon ~ Fri / Mon ~ Sat. / Sat ~ Sun / Sunday Hour / Minute PC-RGB/ HDMI1 / HDMI2 / DP / AV VOLUME Product can be turned on automatically by setting day, time, volume and input mode. • Sleep time - Off / 10min / 20min / 30min / 60min / 90min / 120min /180min / 240min Product can go into sleep mode after certain period of time. • Auto sleep - On / Off When Auto Sleep is On, product will be turned off automatically when there is no input signal.
  • Page 13 Multi media mode • Press MENU button, open the OSD Menu mode UP / DOWN / VOL+ / VOL- buttons allow you to change setting after moving up/ down/left/right. • The remote control uses the up/down/left/right and use select button • PHOTO You can play image file. • MUSIC You can play sound file. • MOVIE You can play movie file. • TEXT You can play text file.

  • Page 14: Remote Control

    remote Control Function 10 Multi Media Not define Selects the Multi Media mode directly. Selects the PC mode 11 POWER directly Turns the product On/Off. HDMI Selects the HDMI 12 VIDEO mode directly. Selects the VIDEO mode directly. 3* Number buttons Press to change the 15* CH channel. Press to change channels. 4* – Press to select 13 SLEEP additional channels. Poweroff time selection. Volume Press to increase or 14 P.Size decrease the volume.

  • Page 15: Display Settings

    5.2 DiSPlay SETTiNgS Your monitor is equipped with standard VESA DDC function, which automatically sends data such as scan frequency, output, performance to the PC, and distinguishes the connection method and selects the appropriate resolution, when using a video card with the optimum mode at shipping is displayed below. Resolution 640 x 480 800 x 600 1024 x 768 1280 x 720 1280 x 768 1280 x 800 1280 x 1024 1360 x 768 1680 x 1050 1920 x 1080 5.3 POWEr lED SySTEM Power On + Signal ➝ Green Power On + No Signal ➝ Red Power Off ➝ Off...

  • Page 16: Troubleshooting

    6. TrOublEShOOTiNg When you experience difficulty using the product, you can use this diagnosis to check it. If the problem persists after the diagnosis, please inquire at the retailer where you purchased the product. 1. When the screen does not turn on - check to see if the power cord is properly plugged into the outlet. - check if you have proper connection of 220V Power - check the LED to see if it is on stand-by (If the power is stand-by, it will turn red and turn off_ - turn on the power by pressing Power button. 2. Color is too bright - adjust brightness and contrast 3. Screen is too dark - adjust brightness and contrast 4. Screen in on but no picture shows - press source button and select right input...

  • Page 17: Specifications

    7. SPECifiCaTiON Model Focus Touch P10 55 inch Screen Size (Inch) Brightness (cd/m Contrast ratio 4000:1 Angle 178(H) / 178(V) Maximum resolution 1920 x 1080 Input Signal, Terminated D-SUB / HDMI / DP / VIDEO / COMPONENT Touch& Camera &Mic I/F Model Focus Touch P10 70 inch Screen Size (Inch) Brightness (cd/m Contrast ratio 4000:1 Angle 178(H) / 178(V) Maximum resolution 1920 x 1080 Input Signal, Terminated D-SUB / HDMI / DP / VIDEO / COMPONENT Touch& Camera &Mic I/F Model Focus Touch P10 82 inch...

  • Page 18: Dimensions

    8. DiMENSiONS fT55-P10 fT70-P10 fT82-P10...
  • Page 19 WarNiNg When you attache the wall bracket to the backside of the display check the measure of the screws ! Screws The measure of the screw can be MAXIMUM 40 mm. Wide: 8 mm, Metrical. Monitor back Monitor top Max. 40 mm Monitor front...

  • Page 20: Product Warranty

    9. PrODuCT WarraNTy lCD MONiTOr PrODuCT WarraNTy Product name TFT LCD Monitor MODEL Number Date of Purchase Place of Purchase Telephone...
