Page 1 Imagestore 2 User Manual 02359-11 © April-2005 Software version 2.20 Miranda Technologies Ltd. Tel: +44 (0) 1491 820000 Fax: +44 (0) 1491 820001 Email: uksales@miranda.com Web: www.miranda.com...
Page 2 Copyright © 1999 - 2005 Miranda Technologies Ltd. All rights are reserved and, under the copyright laws, this manual may not be reproduced in any form, in whole or in part, without the prior written consent of Miranda Technologies Ltd.
Page 3: Preface
Preface Preface Warranty Miranda Technologies Ltd offer a 24 months free parts and labour warranty on Oxtel Series equipment from the date of the initial invoice, providing there is no evidence of negligence, abuse or failure to reasonably follow instructions given by the Company for its proper use.
Page 4: Important Safety Notices
5. Use an appropriate fuse. To avoid fire hazard, use only the fuse type and rating specified for Imagestore. 6. Do not operate in wet/damp conditions. To avoid electrical shock, do not operate Imagestore in wet or damp conditions. Page 4 Miranda Technologies Ltd...
Page 5: Product Damage Precautions
If you suspect there is damage to Imagestore, have it inspected by qualified service personnel. Certifications and Compliances Imagestore has CE approval and complies with the standards detailed in EN50082-1:1992 and BS EN 60950:1992 Amd 3. Imagestore is fully Year 2000 millennium compliant. Miranda Technologies Ltd Page 5...
Page 6: Scope Of The Manual
Part No. 02954 Easysound Standalone User Manual Part No. 02349 Intuition User Manual Part No. 03457 Intuition Builder User Manual Part No. 03454 Electronic copies of the manuals are available from the Miranda website at: http://www.miranda.com/library.en/Automation%20Protocol/ http://www.miranda.com/software.php Page 6 Miranda Technologies Ltd...
Page 7: Symbols And Conventions
(escape or enter) or by the icons The two-line display provides a range of prompts in response to key presses. Where reference is made to an actual display prompt this will be shown italicised, e.g. Manual Override or image file erase. Miranda Technologies Ltd Page 7...
Page 8: Contacts
Preface Imagestore User Manual Contacts For technical assistance, please contact your nearest Miranda Technical Support centre: Americas Telephone (9:00am - 9:00pm EST) +1-800-224-7882 techsupp@miranda.com Asia Telephone (9:30am - 5:30pm JST) +81-3-5730-2987 asiatech@miranda.com Europe, Middle East, Africa, UK Telephone (10:00am - 7:00pm CET) +44 (0) 1491 820222 eurotech@miranda.com...
Page 9: Manual Structure
Oxtel-RCP for new users. It identifies the user controls and explains how they are used. It describes the way the panel may be used to control more than one Miranda Technologies Ltd unit through an Intelligent Panel Router (IPR). The full range of remote control panel functions available, when used with Imagestore, are detailed and a description is given of each feature.
Page 10 Support The support section describes the procedures for using the return-to-base warranty. It explains how to contact the Miranda Technologies Ltd technical support team and outlines a series of preliminary unit checks that should be made prior to calling.
Page 11 This appendix contains a series of diagrams representing the front panel operation and configuration menu trees. Appendix 4 Custom Configuration Notes This appendix provides blank pages that may be used to record useful unit configuration data. Miranda Technologies Ltd Page 11...
Page 12 Preface Imagestore User Manual Page 12 Miranda Technologies Ltd...
Page 13: Table Of Contents
Emergency Alert System ---------------------------------------------------10 Imagestore Intuition----------------------------------------------------------10 Configuration ------------------------------------------------------------------10 Installation and Integration -------------------------------------------------10 Support -------------------------------------------------------------------------10 Appendix 1 Product Specification ----------------------------------------11 Appendix 2 Glossary --------------------------------------------------------11 Appendix 3 Menu Trees ----------------------------------------------------11 Appendix 4 Custom Configuration Notes-------------------------------11 Table of Contents Miranda Technologies Ltd Page 13...
Page 14 Checking Installed Options --------------------------------------------- 35 Front Panel Operations Controls--------------------------------------------------------------------------- 37 VFD Display ------------------------------------------------------------------- 37 VFD tallies (mixer/keyer states) --------------------------------------- 38 Escape and Enter Keys ---------------------------------------------------- 38 Left and Right Arrow Keys ( ) ---------------------------------------- 38 Page 14 Miranda Technologies Ltd...
Page 15 Setting the Preview Output ------------------------------------------------59 Cascade Mode Operations (IS2 Only) ------------------------------------61 Midground and Foreground Programme Operations ----------------62 Cut Up/Down and Fade UP/Down ------------------------------------62 Cut Up/Down and Fade UP/Down ------------------------------------63 Switching Fade to Black On and Off----------------------------------63 Loading Images------------------------------------------------------------64 Miranda Technologies Ltd Page 15...
Page 16 Transmission Control ------------------------------------------------------- 77 Program Fade to Black -------------------------------------------------- 77 Program Image "On Air/Off Air"---------------------------------------- 78 Exchanging Program and Preview Images ------------------------- 78 Selecting Transition Speed --------------------------------------------- 78 Cut or Fade Selection ---------------------------------------------------- 78 Loading Images -------------------------------------------------------------- 79 Page 16 Miranda Technologies Ltd...
Page 17 Loading a Live Image ----------------------------------------------------90 Saving Images ----------------------------------------------------------------90 Editing Images ----------------------------------------------------------------90 Set-Up---------------------------------------------------------------------------91 Connecting through an IPR --------------------------------------------------91 Channel Set Display---------------------------------------------------------91 Panel ----------------------------------------------------------------------------92 Current --------------------------------------------------------------------------92 New ------------------------------------------------------------------------------92 Selecting a New Channel --------------------------------------------------93 Rotary ------------------------------------------------------------------------93 Up and Down ---------------------------------------------------------------93 Miranda Technologies Ltd Page 17...
Page 18 Squeeze modes -------------------------------------------------------------- 105 Squeeze presets ------------------------------------------------------------- 108 Controlling Squeezy DVE -------------------------------------------------- 108 Using Squeezy with the Oxtel RCP-------------------------------------- 109 Imagestore front panel ------------------------------------------------------ 110 GPIs ----------------------------------------------------------------------------- 111 Automation control system------------------------------------------------- 112 Analogue faders -------------------------------------------------------------- 113 Page 18 Miranda Technologies Ltd...
Page 19 Preview ----------------------------------------------------------------------- 130 Audio model mode with the Oxtel RCP --------------------------------- 131 AB Mix and Voice Over Mode------------------------------------------- 131 I/P ------------------------------------------------------------------------------ 132 A/B ----------------------------------------------------------------------------- 132 VO ----------------------------------------------------------------------------- 133 O/P----------------------------------------------------------------------------- 133 Two Voice Over Mode ---------------------------------------------------- 133 Miranda Technologies Ltd Page 19...
Page 20 Emergency Alert System EAS Receivers ------------------------------------------------------------- 149 Baud Rates ------------------------------------------------------------------ 150 Load EAS (EAS On)------------------------------------------------------- 150 Unload EAS (EAS Off)---------------------------------------------------- 150 EAS logs --------------------------------------------------------------------- 150 Imagestore Intuition Imagestore Intuition Control ----------------------------------------------- 153 Control -------------------------------------------------------------------------- 154 Page 20 Miranda Technologies Ltd...
Page 21 GPI Setup (Commands and Macros)------------------------------------ 166 GPI Inputs Assign ---------------------------------------------------------- 166 Assigning GPI Inputs ------------------------------------------------------ 178 Create or Edit an Input Macro ---------------------------------------- 178 List a Macro--------------------------------------------------------------- 179 Create a Macro ---------------------------------------------------------- 179 Edit a Macro -------------------------------------------------------------- 179 Miranda Technologies Ltd Page 21...
Page 22 625/525 Lines--------------------------------------------------------------- 195 Audio Control --------------------------------------------------------------- 195 Swap-Preview or Cascade Mode -------------------------------------- 195 Reference Source Selection -------------------------------------------- 196 Serial Comms Set-up ----------------------------------------------------- 196 Aspect Ratio----------------------------------------------------------------- 196 EAS Msg Protect ----------------------------------------------------------- 197 Timecode Options --------------------------------------------------------- 197 Page 22 Miranda Technologies Ltd...
Page 23 Returns Procedure ----------------------------------------------------------- 207 Transit Packaging ---------------------------------------------------------- 207 Appendix 1 Imagestore specifications -------------------------------------------------- 209 SDI Inputs and Outputs --------------------------------------------------- 209 Analogue Reference Video Input--------------------------------------- 209 Analogue Preview Video Output---------------------------------------- 209 Power Requirements ------------------------------------------------------ 210 Interfaces--------------------------------------------------------------------- 210 Miranda Technologies Ltd Page 23...
Page 24 Menu Trees-------------------------------------------------------------------- 215 Swap Preview Mode menu tree ---------------------------------------- 215 Cascade Mode menu tree ----------------------------------------------- 216 Set Up Menu Tree --------------------------------------------------------- 216 System Set Up Sub-Menu Tree ---------------------------------------- 217 Appendix 4 Custom Configuration Notes ---------------------------------------------- 219 Page 24 Miranda Technologies Ltd...
Page 25: Overview
More detailed and specific information regarding operation, configuration, installation and support are provided in later sections. Imagestore (Product code IS2) is part of Miranda Technologies Ltd's professional broadcast equipment range of products and its primary use is to insert logos and audio into a SDI digital video signal. The capabilities of this...
Page 26: Concept
Imagestore Solo is NOT Presmaster compatible but does support all other standard Imagestore sales options including the A/B Mixer, Squeezy Easyplay, Oxtel RCP etc. Imagestore Solo can be upgraded to an Imagestore 2. For full details on how to upgrade please consult your local Miranda Technologies representative. Page 26...
Page 27: Swap-Preview Mode (Is2 - Solo)
PAL/NTSC output although this option uses an 8-bit DAC and is intended for monitoring purposes only. The preview output may also be used to view system information and, where the Edit Pack option is installed, thumbnails of the library images. Miranda Technologies Ltd Page 27...
Page 28: Cascade Mode (Is2 Only)
In Cascade mode the two keyers are arranged in series as shown above. This configuration allows two images to be keyed simultaneously, but independently, over the background video. Cascade Mode provides a more restricted preview capability whilst still providing the ability to view images prior to transmission. Page 28 Miranda Technologies Ltd...
Page 29: Getting Started
50 seconds. The unit first checks to see if there is a disk in the floppy drive and, if it finds one, it will attempt to boot from that disk. Miranda Technologies Ltd issues specialised floppy disks for use as part of the boot-up sequence when software upgrades are being implemented. No other disk should ever be present in the floppy disk drive during the boot sequence.
Page 30: Facilities And Features
The imported images are copied directly to the preview channel and also saved within the internal image library. Images, animations, clocks and audio files saved to floppies from Miranda Technologies Ltd's Media Conversion Software - (or other Miranda Technologies Ltd units) can be loaded in the same way.
Page 31: Transmission
(preview) output of the Imagestore. The preview output may either provide a digital or analogue output signal and the monitor attached must be appropriate. The polyphoto feature may only be used when Imagestore is configured for Swap-Preview mode and is not available in Cascade mode. Miranda Technologies Ltd Page 31...
Page 32: Clock Insertion
Overview Imagestore User Manual Control of Polyphoto, Playlist and Image clean-up features may only be achieved using a Miranda Technologies Ltd remote controller, Oxtel RCP. Clock Insertion The Bugclock option allows Imagestore to insert customised in-vision clocks. A wide range of clocks and timers can be generated, with hour, minute and second indications.
Page 33: Ab Mixer
VFD display, a General Purpose Interface (GPI) macro editor and a facility to load configuration settings from, and save system configurations to, a floppy disk. Imagestore is highly suited to automated broadcast environments and remote control options include RS422/RS232, as well as GPI and analogue fader inputs. Miranda Technologies Ltd Page 33...
Page 34: Remote Control Panels
Overview Imagestore User Manual Remote Control Panels Miranda Technologies Ltd offers a versatile remote control panel for use with Imagestore which include alphanumeric displays, menu driven soft-keys and multiple dedicated keys. The Oxtel RCP can provide for control of all Imagestore's functions. Each key can be individually disabled so that, for example, accidental "fade-to-...
Page 35: Checking Installed Options
MEM-200A Audio storage expansion to 200 minutes (Not with MEM-4000). Imagestore Imagestore 2 licence Solo Imagestore 2 SOLO licence EAS1 Emergency Alert System Checking Installed Options The Imagestore can display the internal options installed using either its front panel display or on a monitor connected to its rear panel PVW output.
Page 36 Press the enter key once and if a monitor is connected to the preview output it will display an on-screen summary of the options, together with power supply information for the unit. Page 36 Miranda Technologies Ltd...
Page 37: Front Panel Operations
Where there are more options available than there is room for on the display, the symbols < and > are used to indicate that other options exist to the left Miranda Technologies Ltd Page 37...
Page 38: Vfd Tallies (Mixer/Keyer States)
Common Mode Operations Imagestore's top-level menu provides the option to choose either manual (operations) or set-up (configuration). When manual is selected the Manual Override menu is revealed. Sub-menus accessed through the operate option Page 38 Miranda Technologies Ltd...
Page 39: Erasing Image Files
Once the appropriate image name is displayed and the enter key is pressed, the user is required to confirm or cancel the decision before erasure occurs. When confirmed, the display acknowledges the operation selected and returns to the Manual Override menu. Miranda Technologies Ltd Page 39...
Page 40: Setting A/Bgnd, Fill And Key Inputs
When the Colour option is applied, the user is presented with three adjustments in turn, which together set the colour of the field to be inserted. The first adjustment only affects the red component of the field. Page 40 Miranda Technologies Ltd...
Page 41: Emergency To Air
This is achieved by allocating the emergency to air command to one of Imagestore's GPI inputs. The procedure for allocating GPI commands is described in the installation and integration section of this guide. Miranda Technologies Ltd Page 41...
Page 42: Operating Modes
To check the mode of Imagestore, select manual/operate from the boot-up menu. With operate displayed, press the enter key. The first line of the display will now indicate Imagestore's current mode by showing either Swap- preview Operate or Cascade Operate. Page 42 Miranda Technologies Ltd...
Page 43: Swap/Preview Mode (Is2 - Solo)
Select manual/operate/programme/cut swap from the boot-up menu to locate the feature. Press the enter key to action a cut-swap. When the operation takes place, the arrow may change from ↓ to ↑ otherwise no change can be detected on the Miranda Technologies Ltd Page 43...
Page 44: Fade Swapping Images
If an image is on air, the cut up/down feature can cause the current image to be taken from air, and when cleared, a subsequent command will take the image to air. The cutting action is instantaneous. Page 44 Miranda Technologies Ltd...
Page 45: Fade Up/Down
During the transition the arrow is replaced by the intermediate state symbol – acknowledging the fade is taking place. No other change can be detected on the VFD display, which remains showing the same menu selection for further fade up/down operations. Miranda Technologies Ltd Page 45...
Page 46: Fade To Black On/Off
During the FTB transition the intermediate state symbol – appears next to the arrow acknowledging FTB is taking place. No other changes can be detected on the VFD display, which remains showing the same menu for further FTB on/off operations. Page 46 Miranda Technologies Ltd...
Page 47: Fade Transition Rates
To change the current setting, use the left and right arrow keys to adjust the appropriate frame rate up or down. Pressing the enter key will apply the new setting. Miranda Technologies Ltd Page 47...
Page 48: Preview Operations
Fill and Key SDI inputs. Images loaded from the library or FDD may be used immediately, or edited and saved. Select manual/operate/preview/load image from the boot-up menu to locate the feature. Page 48 Miranda Technologies Ltd...
Page 49: Live Input
The filenames of the original file forms are used to form the file name within the image library so that FRED.JPG will be saved in Imagestore's library as FRED.OXT. Image File Types Miranda Technologies Ltd Page 49...
Page 50 JPEG (*.JPG) 'Lossy' compressed images. This format does not support key information. Miranda OXT (*.OXT) Miranda Technologies Ltd still images and logos. 4:2:2:4 format, 10 bits per pixel. Miranda OXA (*.OXA) Miranda Technologies Ltd animations and clocks. 4:2:2:4 format 10 bits per pixel...
Page 51: Library Images
The image/animation will NOT be displayed until it is fully loaded. Cut Load Cut load is similar to clean load but the existing image remains active until the new file is loaded. A cut transition then replaces the new image for the old one. Miranda Technologies Ltd Page 51...
Page 52: Saving Images
When a save is to be made to the image library, the arrow keys are used to increment and decrement the image number for the save. Where a filename is already in use an asterisk will appear following the displayed name. Page 52 Miranda Technologies Ltd...
Page 53: Grabbing Images
Key. Animations and clocks cannot currently be saved to floppy disk. Images are saved in the Miranda Technologies Ltd format (.OXT). When the process has started, the display provides full dialogue and prompts for floppy disk changes.
Page 54: Editing Images
Once changed, the image may be used immediately, or saved for later use. The following four groups of parameter may be changed: ♦ Clip, Gain and Transparency ♦ Set Position ♦ Masking ♦ Key Parameters Select manual/operate/preview/image editor from the boot-up menu to locate the feature. Page 54 Miranda Technologies Ltd...
Page 55: Adjusting Clip, Gain And Transparency
The gain level amplifies the key signal, forcing grey levels towards, and up to, white level. In a keying process this will result in the fill signal being less transparent than it otherwise would be in areas with a grey key signal. Miranda Technologies Ltd Page 55...
Page 56: Set Position
Images may be masked by restricting the margins and confining an image to less than full screen. Before any image can be masked the feature must be turned to enabled. An option within the Set Masking sub menu provides the enable/disable switching. Page 56 Miranda Technologies Ltd...
Page 57: Key Parameters
When the Key Parameters option is selected, the parameters are displayed for selection as shown below. Use the arrow keys to move the brackets to enclose the parameter to be changed and press the enter key to view the appropriate sub-menu. Miranda Technologies Ltd Page 57...
Page 58 Type With Full Key the foreground image is passed only where the key signal is present. Alternatively, with Linear Key the background and foreground are summed and the foreground is unaffected by the key. Page 58 Miranda Technologies Ltd...
Page 59: Setting The Preview Output
Setting) A/Background Background input Presmaster Preview IS2 only B Input B input (AB Mixer only) AB Mix AB mixer output (AB Mixer only) Select manual/operate/preview/preview output set from the boot-up menu to locate the feature. Miranda Technologies Ltd Page 59...
Page 60 When the appropriate selection is displayed press the enter key to apply that choice. The output setting should be returned to Program Preview once monitoring is complete to ensure operation of the Polyphoto feature. Page 60 Miranda Technologies Ltd...
Page 61: Cascade Mode Operations (Is2 Only)
"off-air" first. To change between Swap Preview or Cascade mode select Set-up/system/Swap-PVW / Cascade. Press the enter key then use the arrow key to select the new mode. Once selected press enter key. Miranda Technologies Ltd Page 61...
Page 62: Midground And Foreground Programme Operations
AB Mixer and Audio selection may appear depending on licences installed. Having selected the midground or foreground keyer the sub-menus are as follows. select midground or f oreground transition rates cut up/dow n f ade up/dow n FTB on/of f load image Page 62 Miranda Technologies Ltd...
Page 63: Cut Up/Down And Fade Up/Down
The replacement rate is determined by the setting under transition rates. Select manual/operate/midground or foreground/FTB on/off from the boot- up menu to locate the feature. Miranda Technologies Ltd Page 63...
Page 64: Loading Images
Once loaded the image may be taken on air using the cut-up or fade-up operations. Select "manual/operate/midground or foreground/load image from the boot- up menu to locate the feature. Page 64 Miranda Technologies Ltd...
Page 65 With the load from FDD prompt displayed, and with a disk in the drive, press the enter key to load the file. Full details of FDD image loading are found under Swap-Preview mode. Miranda Technologies Ltd Page 65...
Page 66: Image Load Mode
Cut Load Cut load is similar to clean load but the existing image remains active until the new file is loaded. A cut transition then replaces the new image for the old one. Page 66 Miranda Technologies Ltd...
Page 67: Setting Transition Rates
Setting the Preview Output In Cascade mode, the Preview output may be "attached" to any one of ten monitor points around the unit. Select manual/operate/preview output set from the boot-up menu to locate the feature. Miranda Technologies Ltd Page 67...
Page 68 After the preview output has been used for monitoring it is good practice to return the setting to Program Preview. Only when attached to this setting will images being edited be seen at the PVW output. Page 68 Miranda Technologies Ltd...
Page 69: Editing Images
"on-air". Ensure that there will be no requirement for the midground image to be taken "on-air" during an editing session. When using the Cascade mode editing features refer to the "editing images" section of Swap-PVW Mode, Preview Operations, given in earlier paragraphs of this guide. Miranda Technologies Ltd Page 69...
Page 70 Front Panel Operation Imagestore User Manual Page 70 Miranda Technologies Ltd...
Page 71: Oxtel Rcp Operations
Further information and support on the Unit is available from the Miranda Technologies Ltd Support Desk at the phone number on the cover of this manual. Miranda Technologies Ltd's Intelligent Panel Router (IPR) enables one or more Oxtel RCP’s to operate multiple Imagestore, Logostore or Playstore...
Page 72: Controls
Lamp brightness can also be adjusted to suit ambient conditions. Push Button Switches The RCP has thirty dedicated pushbuttons of which eleven comprise an alphanumeric keypad ("0" to "9YZ" plus ENTER). The following paragraphs describe the use of each button in turn. Page 72 Miranda Technologies Ltd...
Page 73: Esc Key
The EDIT key provides access to any image editing options that are available on the controlled equipment. Play List The PLAY LIST key provides access to the options for creating, loading, unloading and editing a Playlist. Miranda Technologies Ltd Page 73...
Page 74: Setup
For example, if a file were to be named "MIRANDA" and was incorrectly entered as "MIRANAD", the NEXT DEL key could be used to delete the final "D" and "A" allowing a correction to be made.
Page 75: Previous (Prev)
With the swap legend illuminated the "TAKE" button exchanges the logo/image on air with the preview logo/image using the selected cut or fade effect. With the swap legend not illuminated successively pressing the "TAKE" button simply takes the programme logo/image on and off air. Miranda Technologies Ltd Page 75...
Page 76: Cut/Fade
Channel Set The "CHAN'L SET" key is only effective when the RCP is used via an Miranda Technologies Ltd Intelligent Panel Router. Pressing the "CHAN'L SET" key will provide access to the "Channel Set" menu. Soft-Keys The remote control panel features four soft-keys which are positioned from left to right under the LCD.
Page 77: Swap/Preview Mode Operations
Pressing the button again will cause the normal program output to reappear over the same number of frames and the button light will go out. The FTB option may be disabled where appropriate and the Miranda Technologies Ltd helpdesk will provide details on request.
Page 78: Program Image "On Air/Off Air
(in fields) using the "Set-Up" menu. Cut or Fade Selection When the "Cut/Fade" button is pressed, the type of keyer transition toggles between cut and fade. The current setting is shown illuminated above the button. Page 78 Miranda Technologies Ltd...
Page 79: Loading Images
The keypad may be used to amend any character. Once the required image is indicated on the display, pressing the ENTER key will cause it to load into the preview store. Miranda Technologies Ltd Page 79...
Page 80: Loading A Live Image
"Capture" soft key to freeze the image as before. Once the desired image is captured it remains held in the preview store and can be subsequently saved, edited or transmitted. To return to the RCP basic display press the "ESC" key. Page 80 Miranda Technologies Ltd...
Page 81: Saving Images
"No" prompts on the screen to confirm the action. Erasing a Library Image Use the "Letter" and "File" rotary controls so that the name and title of the file to be erased are displayed on screen. Press the "Erase" soft key and Miranda Technologies Ltd Page 81...
Page 82: Editing Images
Turning the Sense rotary control clockwise will select "Normal" and counter-clockwise will select "Invert". The Source control tuned clockwise will select Separate and anti-clockwise will select Self. The Type control selects "Full" (clockwise) and "Linear" (anti- clockwise). Page 82 Miranda Technologies Ltd...
Page 83: Masking
The two digital interpolation options and the two enhancement algorithms favour alternate sub-frames. The effect of each process may be tried to see which has the most beneficial effect. Miranda Technologies Ltd Page 83...
Page 84: Clip, Gain And Transparency
To exit without making any changes simply press the ESC button. Add to Current Playlist Files identified under the load procedure may be added or appended to the current playlist by selecting the soft key above the "Playput" prompt. Page 84 Miranda Technologies Ltd...
Page 85: Playlist
ENTER key exits the polyphoto mode and provides the cursor thumbnail image to full screen. Successive pressing of the "TAKE" key increments the playlist through its images and displays each at the PVW output. Miranda Technologies Ltd Page 85...
Page 86: Set
"System Set-up". When enabled, pressing the soft key under the "Mirror" prompt will bring a front panel emulation display to the LCD. Four keys on the RCP keypad will illuminate and these keys emulate the four front panel Page 86 Miranda Technologies Ltd...
Page 87: Transition Rates
Imagestore, press the soft key beneath the "Preview" prompt. The left- and right-hand soft-keys are now used to step through the on screen options and changes are immediately effective. For normal usage the preview output must be left set to "Program Preview". Miranda Technologies Ltd Page 87...
Page 88: Cascade Mode Operations
FG or MG button which will illuminate accordingly. If the TAKE button is illuminated the image for that layer is already on air and vice versa. Pressing the TAKE button will either take the image on-air (button illuminated) or off air (button extinguished). Page 88 Miranda Technologies Ltd...
Page 89: Selecting Transition Speed
"live" from the "Fill" and "Key" ports. Load from the Image Library In order to load an image from the Imagestore library the image to be loaded must be identified. Locating an image for loading can be achieved using the Miranda Technologies Ltd Page 89...
Page 90: Loading A Live Image
"on-air". Ensure that there will be no requirement for the midground image to be taken "on-air" during an editing session. When using the Cascade mode editing features refer to the "editing images" section of RCP Swap-PVW Mode given in earlier paragraphs of this guide. Page 90 Miranda Technologies Ltd...
Page 91: Set
The remote control panel achieves channel selection using a special display that can only be accessed when a connection is made between the RCP and IPR. Channel Set Display Pressing the "CHAN'L SET" key reveals the "Channel Set" display. Miranda Technologies Ltd Page 91...
Page 92: Panel
The "Current" field shows the unique number and given name for the channel currently connected to the RCP. In the example above the channel number shown is "200" and the given name is "Imagestore 2". The "New" display shows the unique number and given name for the channel that will become selected when a channel change is applied.
Page 93: Selecting A New Channel
"New" selection reverts to its previous value. At any point when entering a channel number the process may be exited by pressing the ESC key. Miranda Technologies Ltd Page 93...
Page 94: Applying A New Channel
The user who has had his connection broken will have a message displayed on his RCP advising the identity of the controller breaking the connection. Please refer to the IPR User Manual for more detailed information. Page 94 Miranda Technologies Ltd...
Page 95: Ab Mixer
You can control the video switcher (cuts and x-fades from 1 to 999 fields) using: ♦ the Oxtel RCP remote control panel ♦ the Imagestore front panel ♦ programmable GPIs ♦ the RS422 and RS232 automation interfaces analogue faders Miranda Technologies Ltd Page 95...
Page 96: Using Ab Mixer With The Oxtel Rcp
(see above). You can now press TAKE to switch (toggle) between the A and B inputs according to the transition type (fade/cut) and rate. When you choose wipe, the V-fade transition is enabled. Page 96 Miranda Technologies Ltd...
Page 97: Imagestore Front Panel
A or a B symbol will appear on the top line of the VFD display showing the active source. No other changes can be detected on the VFD display, which remains showing the same menu selection for further cut A/B operations. Miranda Technologies Ltd Page 97...
Page 98: Fade A/B
This option allow the user to select the following range of transition types: ♦ Cut ♦ X-fade ♦ V-fade ♦ Wipe L to R ♦ Wipe R to L ♦ Wipe T to B ♦ Wipe B to T Page 98 Miranda Technologies Ltd...
Page 99: Set Mix Rate
Select manual/operate/AB Mixer/set mix rate from the boot-up menu to locate the feature. Press the enter key then use the arrow keys to increase or decrease the value. To select the value, press enter. To go back a level press escape. Miranda Technologies Ltd Page 99...
Page 100: Wipe Softness
Press the enter key then use the arrow keys to increase or decrease the colour field value. Pressing the enter key after adjusting the Red value will change to the next colour field i.e. Green. Pressing the enter key after Page 100 Miranda Technologies Ltd...
Page 101: Gpis
You can control the AB mix using the RS422 and RS232 automation interfaces. For full details about how to control MIX-2000 automatically, contact the Miranda Technologies Ltd support desk and ask for a copy of the Miranda Technologies Ltd Oxtel Series Automation Protocol document.
Page 102: Analogue Faders
In addition to the physical fader inputs (shown as Vid_ADC1 to Vid_ADC8) you can also control the state of the internal system parameters using various pseudo faders such as keyer and FTB levels. This enables features such as Page 102 Miranda Technologies Ltd...
Page 103 The list of controllable functions and the set of fader inputs available to control them will depend on the options fitted to your version of Imagestore. See Faders Setup for a complete list of faders. Miranda Technologies Ltd Page 103...
Page 104 AB Mixer Imagestore User Manual Page 104 Miranda Technologies Ltd...
Page 105: Squeezy Dve
(for example, in cascade mode, in swap- preview mode, or in all modes). Note: You can change squeeze modes from the unit’s front panel, GPIs, automation control, and the Oxtel RCP (see below). Miranda Technologies Ltd Page 105...
Page 106 AB Mixer option note that both program and preview outputs are affected bypass squeeze no video delay Page106 Miranda Technologies Ltd...
Page 107 (see above) except the midground stored image is squeezed squeeze FG store cascade this is the same as squeeze MG store (see above) except the foreground image is squeezed Miranda Technologies Ltd Page 107...
Page 108: Squeeze Presets
Note that preset zero is a full screen preset and cannot be edited or overwritten. Controlling Squeezy DVE You can control Squeezy DVE using: ♦ the Oxtel RCP remote control panel ♦ the Imagestore front panel ♦ programmable GPIs ♦ the Imagestore’s automation control system ♦ analogue faders Page108 Miranda Technologies Ltd...
Page 109: Using Squeezy With The Oxtel Rcp
ENTER (note that when you load a preset, a mimic display on the Oxtel RCP screen shows you the position of the squeezed image in relation to the full screen display) Miranda Technologies Ltd Page 109...
Page 110: Imagestore Front Panel
Imagestore is configured and whether you are in swap- preview or cascade mode) squeeze rate set a rate in fields for subsequent squeeze effects (note that you can also set a rate using a GPI) – note that the Page110 Miranda Technologies Ltd...
Page 111: Gpis
Setup/GPI Outputs Assign). See GPI Commands and Macros for a complete list of GPI outputs. You can perform various squeezes using GPIs. The following GPI actions are available in the Squeezy sub-list on the GPI Input Assign menu: Miranda Technologies Ltd Page 111...
Page 112: Automation Control System
For full details about how to control Squeezy automatically, contact the Miranda Technologies Ltd support desk and ask for a copy of the Miranda Technologies Ltd Automation Protocol document. Page112...
Page 113: Analogue Faders
The list of controllable functions and the set of fader inputs available to control them will depend on the options fitted to your version of Imagestore. See Faders Setup for a complete list of faders. Miranda Technologies Ltd Page 113...
Page 114 Squeezy DVE Imagestore User Manual Page 114 Miranda Technologies Ltd...
Page 115: Easysound Audio
Easysound Audio What is Easysound? Easysound is a digital audio mixer board that can be added to the Miranda Technologies Ltd range of broadcast products to enable you to add voice- overs, programme jingles, and other audio inserts over background video soundtracks.
Page 116: Audio Mixer Matrix
Ethernet to Miranda Technologies Ltd's Windows based Media Distribution System). Audio files used with Easyplay can be either 16-bit, 48kHz stereo .WAV format or Miranda Technologies Ltd's own .OXW format. The audio store can store up to 40 minutes (optionally 200 minutes) of digital audio, which can be sub-divided into a number of audio files.
Page 117: Audio Playout
Audio Files All audio files used by Easyplay must be in Miranda Technologies Ltd's proprietary audio file format and given an .OXW file extension. The Miranda Technologies Ltd Media Distribution System (MDS) software is able to create these files from 16-bit, 48kHz stereo .WAV format files.
Page 118: Controlling Easysound
These modes are mutually exclusive so the user will need to select the appropriate mode via the front panel. Select setup/system/Audio Control from the boot-up menu to locate the feature then press the enter key. Use the arrow keys to select Model mode then press enter. Page 118 Miranda Technologies Ltd...
Page 119: Model Mode
Easysound Audio Model mode The audio model provides the following two audio modes: ♦ AB Mix and VO mode ♦ Two Voice Over mode Note that these two modes accommodate the majority of audio configurations. Miranda Technologies Ltd Page 119...
Page 120: Model Mode Configuration
♦ press escape You are now ready to choose the available options in the selected mode. Note that the following options are not always available in both modes (details about availability are included in each section). Page 120 Miranda Technologies Ltd...
Page 121: Audio Follow Video
– and therefore perform pair swaps to choose the appropriate input channel (1, 2, 3 or 4) for the shuffle setting use < and > Miranda Technologies Ltd Page 121...
Page 122: Vo1 Input/Vo2 Input
3 or 4 or AES) VO1 Input/VO2 Input You use the VO1 Input and VO2 Input menu to specify the following settings (note that VO2 Input is not available in AB Mix and VO mode): Page 122 Miranda Technologies Ltd...
Page 123: Vo1 Settings/Vo2 Settings
- duck level and VO level (these are described below). You use the following menu to specify the VO1 and VO2 settings (note that VO2 Settings is not available in AB Mix and VO mode): Miranda Technologies Ltd Page 123...
Page 124 – 0% indicates that voice over is fully off and 100% indicates that voice over is fully on The above diagram shows the voice over parameters and how they affect the actual audio levels. Page 124 Miranda Technologies Ltd...
Page 125: Embed Op Settings
Effects Send allows you to select an AES output (pair 1 or pair 2) to route an audio signal to an external special effects unit. Use the Effects Send menu to select the following options: Miranda Technologies Ltd Page 125...
Page 126: Ab Mix And Vo Mode
Fx Send Gain -100 < 0 > +28 Sets the gain of the output signal Fx Return Pair 1 Pair 2. Sets the return (input) path from the external effects unit. Signal path for AB Mix mode Page 126 Miranda Technologies Ltd...
Page 127: Two Voice Overs Mode
Selecting Data allows the Imagestore to pass and cut a data stream (non audio signal) carried in the AES path i.e. Dolby Digital® or Dolby E®. The signal is passed through without applying any gain. When a video AB cut Miranda Technologies Ltd Page 127...
Page 128: Ab Mix And Vo Mode
BGND Pair 1 BGND Pair 2 VO1 Pair 1 VO1 Pair 2 VO2 Pair 1 VO2 Pair 2 Output Pair Preview Pair 1 Preview Pair 2 Programme Pair 1 Page 128 Miranda Technologies Ltd...
Page 129: Front Panel Control
VO One Pair 2 Fade Down VO VO One Pair 1 VO One Pair 2 Easplay Load Foregnd Clip (select file) Play Foregnd Clip Stop Foregnd Clip Load Midgnd Clip (select file) Play Midgnd Clip Miranda Technologies Ltd Page 129...
Page 130: Front Panel Audio Metering
To display audio meters on the front panel select Output Metering then select from the list the point use wish to meter. The output is un-calibrated and for indication purposes only. Preview A Input B Input Voice Over Voice Over Enabled Programme Full AB Mix Silence Page 130 Miranda Technologies Ltd...
Page 131: Audio Model Mode With The Oxtel Rcp
(note that the options vary according to whether you are in AB Mix and Voice Over mode or Two Voice Over mode). AB Mix and Voice Over Mode In AB Mix and Voice Over mode, the following options are available: Miranda Technologies Ltd Page 131...
Page 132: I/P
To fade to A or fade to B, press the appropriate soft key to choose Fade A or Fade B and then adjust the fade using the rate key (to change between slow, medium and fast (note that this menu is not accessible if the A/B audio follow video mode is set). Page 132 Miranda Technologies Ltd...
Page 133: O/P
♦ choose Mute to mute pair 1, pair 2 or the whole group (press the appropriate soft key immediately under the pair or group on the LCD display) Two Voice Over Mode In Two Voice Over mode, the following options are available: Miranda Technologies Ltd Page 133...
Page 134: I/P
LCD display) ♦ adjust the VO level and duck level for the selected pair or group using the rotary controls above Level or Duck on the LCD display Page 134 Miranda Technologies Ltd...
Page 135: O/P
You can control the audio in model mode using the automation control system. For full details about how to control the audio model mode automatically, contact the Miranda Technologies Ltd support desk and ask for a copy of the Miranda Technologies Ltd Oxtel Series Automation Protocol document. Miranda Technologies Ltd...
Page 136: Gpi File Mode
Audio sub menu: GPI outputs See GPI Setup (Commands and Macros) for a complete list of all the GPI output commands, which are available from the GPI Output Assign menu: Page 136 Miranda Technologies Ltd...
Page 137: Analogue Faders
In addition to the physical fader inputs (shown as Aud_ADC1 to Aud_ADC8) you can also control the state of the internal system parameters using various pseudo faders such as keyer and FTB levels. This enables Miranda Technologies Ltd Page 137...
Page 138: Easysound And Easyplay External Interfaces
If you have been supplied with Easysound in kit form this section describes the installation of the board and its driver software. The Easysound board may be installed with Miranda Technologies Ltd's Imagestore host units. Configuration When a host unit with Easysound or Easyplay installed has power applied, the boot-up sequence includes reading the audio layer configuration from the unit's hard disk.
Page 139: Rear Panel Connections
AES_IN_1 to AES_IN_6. Each input source should be connected to the Easysound module over two wires using balanced (differential) signals and a grounded shield. Signal and associated pin-out connections are given in the following table. Miranda Technologies Ltd Page 139...
Page 140 AES_IN_2 (+) AES_IN_2 (-) A input AES_IN_5 (+) AES_IN_5 (-) Voice over 2 or B input if AB Mixer fitted AES_IN_6 (+) AES_IN_6 (-) Voice over 2 or B input if AB Mixer fitted No connection Page 140 Miranda Technologies Ltd...
Page 141: Aes Output
Level transitions from external hardware on specific GPI input ports can be programmed to invoke user-defined actions. Status conditions can be allocated to GPI output ports and may be used externally. In addition to internal pseudo-faders, external Miranda Technologies Ltd Page 141...
Page 142 GPI Voltage Source (+12V) GPI Ground Fader 1 Fader 2 Fader 3 Fader 4 Fader 5 Fader 6 Fader 7 Fader 8 Fader Voltage Source (V+) Fader Ground Return Not Used 1, 2, 14 Not Connected Page 142 Miranda Technologies Ltd...
Page 143: Cross-Connecting Gpis
GPI status outputs you can use the GPI out port of one control to trigger the GPI in port of the other. This concept is also suitable for triggering the functions of other non-Miranda Technologies Ltd equipment. Connection of external analogue faders Analogue faders may be used to control fades and mixes.
Page 144: Output From Gpi
In this way pair swaps, mono to stereo copies, and other audio manipulations can be achieved. Each output channel can take its input from one or many of the input channels and each input can be copied to multiple output channels. A familiar set-up is such: Page 144 Miranda Technologies Ltd...
Page 145 15 to indicate which audio outputs will have a contribution from the selected input. The following grids fully show the relationship between the value selected (0-15) and the output channels the audio is copied to (OP1-4). Miranda Technologies Ltd Page 145...
Page 146: Example
OP 3 OP 4 Example: Assigning a value of 15 to ‘VO IP Shuf Chan 1’ will copy the mono audio feed coming into channel 1 of the voice over input to all 4 output channels. Page 146 Miranda Technologies Ltd...
Page 147: Installing Easysound
Miranda Technologies Ltd generally recommends that Easysound is installed by our own experienced technicians. If appropriate Easysound can be made available to customers in kit form. If you need any help contact the Miranda Technologies Ltd support desk on tel +(44) 1491 820222 or fax +(44) 1491 820002).
Page 148 Refitting is the reverse of removal. Start by refitting the ISA bus board back onto the main PCB, ensuring that it is now securely fitted onto both the main PCB and the Easysound. Install the Easysound Driver using the instructions supplied with the disk. Page 148 Miranda Technologies Ltd...
Page 149: Emergency Alert System
TFT EAS 911 To select an EAS model use the: Set-up, System, Serial Comms Setup, RS232 Protocol, menu path. Use the arrow keys to select the required unit then press enter. The system will need restarting. Miranda Technologies Ltd Page 149...
Page 150: Baud Rates
LOG{Serial number}.old. Access to the log file can be gained by copying it to a floppy disk. From the front panel menu select Set-up/File/Diagnostics to FDD. The file can then be viewed on a PC. Page 150 Miranda Technologies Ltd...
Page 151: Imagestore Intuition
Intuition to load the graphic into the first Intuition keying layer. To do this it must subtract 2 from the layer value before relaying the command. Remember that layer zero in the intuition is the first layer. To illustrate this further: Miranda Technologies Ltd Page 151...
Page 152 Layer Number 0x0 (Midground) 0x1 (Foreground) Using this method we can see that our existing keyer load and control commands will now address up to 16 keying layers, 2 in Imagestore and 14 in Intuition. Page 152 Miranda Technologies Ltd...
Page 153: Imagestore Intuition Control
Keyer ID: A Erase Store Keyer ID: C Set key source Keyer ID: D Set key linear or full Keyer ID: E Set key normal or invert Keyer ID: F Set clip grain transparency Keyer Miranda Technologies Ltd Page 153...
Page 154: Control
4) Cut up one of the Intuition layers. Intuition layer now visible 5) Cut down one of the Intuition layers 6) Cut down the Imagestore layer assigned to load live. 7) Turn off load live. Page 154 Miranda Technologies Ltd...
Page 155: Front Panel Menu
Imagestore to automatically perform the following actions: If an Intuition keyer was turned on and an Imagestore keyer was already assigned to the Intuition, then that keyer would be turned on. Miranda Technologies Ltd Page 155...
Page 156: Keyer Release Mode
Intuition keyer is activated. The Enabled mode provides fully automatic management of the Imagestore keyer. Keyer Status This item displays the intuition keyer status. _1____6____ If a layer number is visible it means that layer is cut up. Page 156 Miranda Technologies Ltd...
Page 157: Keyer Management Example
Intuition using the front panel, the Imagestore will not be aware of any change and therefore not be able to perform automatic keyer management correctly. The same is true if the Intuition is controlled directly by another automation system (not via the Imagestore). Miranda Technologies Ltd Page 157...
Page 158 Intuition Imagestore User Manual Page 158 Miranda Technologies Ltd...
Page 159: Configuration And Set Up
Imagestore can have up to twenty-one rear panel connectors (four are installed when the EasySound/EasyPlay option is fitted) and an earth- bonding stud. A description of the purpose of each connector is given in the following table. Miranda Technologies Ltd Page 159...
Page 160: Installation And Integration
D-type, 9-way, male Not used. Only fitted with EasySound/EasyPlay option. OXTEL RCP D-type, 9-way, female Connection for Miranda Technologies Ltd Remote Control Panel only. AES Control Port D-type, 25 way, female Connection for EasySound or EasyPlay "GPI's and Faders". (when sound option installed).
Page 161: Serial Remote Control
Imagestore features three serial remote control ports identified as "Oxtel RCP", "RS-232" and "RS-422 Oxtel RCP The "Oxtel RCP", D-type, 9-way connection is used to connect Miranda Technologies Ltd remote control panel Oxtel RCP and the pin format is shown in the following table.
Page 162: Rs422
Not Used SDI Control Port The SDI Control Port is used to connect external faders, GPI's and linear time code. A full listing of the pin format for this connection is shown in the following table. Page 162 Miranda Technologies Ltd...
Page 163: Pinout Functions
- transparency input analogue fader - gain input analogue fader - clip input analogue fader - main fade input not connected GPI 9 input (user assigned). GPI 7 input/output (user assigned). Miranda Technologies Ltd Page 163...
Page 164: Connection Of Analogue Faders
GPI ports 8 and 9 are only available as inputs. Where a GPI port is used as an input, the command macro may be activated by either connecting or disconnecting the input line to GPI ground (pin 13) depending whether GPI 'on' or GPI 'off' has been assigned. Page 164 Miranda Technologies Ltd...
Page 165: Output From Gpi
Hardware interface listings deliberately exclude details of the unit's rear panel "kybd" and "vga" connectors. The "kybd" and "vga" connections are solely for use by the Miranda Technologies Ltd development team and no user functions can be accessed via these ports. Making any connection to these ports is a high-risk activity that Miranda Technologies Ltd would strongly advise against.
Page 166: Gpi Setup (Commands And Macros)
The AB Mixer sub menu is only available when AB Mix is fitted. cut A cut B toggle cut A/B fade A fade B toggle fade A/B set mix rate 0<->999 set mix type {X-fade/V-fade/Wipe L to R/Wipe R to L/Wipe T to B/Wipe B to T} Page 166 Miranda Technologies Ltd...
Page 167 Toggle VO 1 PR2 Fade VO 2 Pair 1 On Fade VO 2 Pair 1 Off Toggle VO 2 PR1 Fade VO 2 Pair 2 On Fade VO 2 Pair 2 Off Toggle VO 2 PR2 Miranda Technologies Ltd Page 167...
Page 168 [Easyplay (Swap Preview mode - PGM/PVW] Load PVW Clip {<0-4000>} Load PGM Clip {<0-4000>} Play PVW Clip Play PGM Clip Stop PVW Clip Stop PGM Clip [Easyplay (Cascade mode - MG/FG] Load MG Clip {<0-4000>} Load FG Clip {<0-4000>} Page 168 Miranda Technologies Ltd...
Page 169 FG timer reset the FG Bugclock countdown timer stop MG timer stop the MG Bugclock countdown timer start MG timer start the MG Bugclock countdown timer reset MG timer reset the MG Bugclock countdown timer Miranda Technologies Ltd Page 169...
Page 170 FG keyer image to and from air using FG fade up fade up to air the image in the FG keyer FG fade down fade down from air the image in the FG keyer Page 170 Miranda Technologies Ltd...
Page 171 Fill/Key image directly to air and the PVW keyer unload image remove live Fill/Key image from air and PVW keyer grab freeze a frame from the Fill/Key ports into the PVW keyer Miranda Technologies Ltd Page 171...
Page 172 B Input Level: 17 VO Input Level: 18 A Input Trim: 19 B Input Trim: 20 VO Input Trim: 21 Squeeze Xsize: 22 Squeeze Ysize: 23 Squeeze Hpos: 24 Squeeze Vpos: 25 Squeeze Move Pos%: 26 Page 172 Miranda Technologies Ltd...
Page 173 VO Input Level: 18 A Input Trim: 19 B Input Trim: 20 VO Input Trim: 21 Squeeze Xsize: 22 Squeeze Ysize: 23 Squeeze Hpos: 24 Squeeze Vpos: 25 Squeeze Move Pos%: 26 FG FTB: 27 MG FTB: 28 Miranda Technologies Ltd Page 173...
Page 174 B Input Trim: 20 VO Input Trim: 21 Squeeze Xsize: 22 Squeeze Ysize: 23 Squeeze Hpos: 24 Squeeze Vpos: 25 Squeeze Move Pos%: 26 FG FTB: 27 MG FTB: 28 FG Video: 29 MG Video: 30 Page 174 Miranda Technologies Ltd...
Page 175 FG keyer fade to black rate to nnn frames Fade rate 0<->999 FTB rate 0<->999 set the FTB rate to nnn frames [EAS] The EAS sub menu is only available if the EAS licence is installed. EAS On EAS Off Miranda Technologies Ltd Page 175...
Page 176 Wipe On from Bottom Wipe On Horizontally from Centre (Barn doors) Wipe On Vertically from Centre (Blinds) Pan Off to the Left Pan Off to the Right Pan Off to the Top Pan Off to the Bottom Page 176 Miranda Technologies Ltd...
Page 177 The Pan effects work on all graphics files, OXTs, Animations, Bug Clock and Easy Text files but the Wipe effects work on all BUT Animations. Triggering these effects automatically cuts the layer up so it does not need the Cut/Fade up commands to be sent. Miranda Technologies Ltd Page 177...
Page 178: Assigning Gpi Inputs
GPI input options is to be created or edited. In the following example GPI 2 on has been used to describe a process that is identical for the other seventeen GPI input options. Page 178 Miranda Technologies Ltd...
Page 179: List A Macro
Further commands are added to the macro using the same procedure. Edit a Macro Where a macro is already programmed, the display will indicate the first command in the sequence and the arrow keys may be used to step Miranda Technologies Ltd Page 179...
Page 180: Gpi Outputs Assign
FTB fader disd fade to black fader is disabled FTB fader enbld fade to black fader is enabled Page 180 Miranda Technologies Ltd...
Page 181: Gpi Outputs In Cascade Mode
MG FTB at on midground fade to black is turned on FG FTB at off foreground fade to black is turned off FG FTB at on foreground fade to black is turned on Miranda Technologies Ltd Page 181...
Page 182: Gpi Outputs Available With The Audio Model
Audio FTS off VO 1 Pair1 off VO 1 Pair1 on VO 1 Pair2 off VO 1 Pair2 on VO 2 Pair1 off VO 2 Pair1 on VO 2 Pair2 off VO 2 Pair2 on Page 182 Miranda Technologies Ltd...
Page 183: Assigning Gpi Outputs
Pressing escape will return the display to the earlier menu leaving the assignment unchanged. Miranda Technologies Ltd Page 183...
Page 184: Clearing Output Assignments
Show GPI Status The status screen shows the 9 video and 9 audio GPI ports. As the GPI is triggered externally the corresponding number will be displayed on the front panel. Page 184 Miranda Technologies Ltd...
Page 185: Fader Setup (Commands And Menus)
The current status of the fader is shown by the option enclosed in brackets. The brackets are moved using the arrow keys and when the required option is selected, pressing the enter key will apply the selection. Miranda Technologies Ltd Page 185...
Page 186: Faders Setup
VO 1 Pair 2 Duck VO 2 Pair 1 Level VO 2 Pair 2 Level VO 2 Pair 1 Pset VO 2 Pair 2 Pset VO 2 Pair 1 Duck VO 2 Pair 2 Duck A Input Level Page 186 Miranda Technologies Ltd...
Page 187: Faders
The following faders are only available with the Easysound new audio model: AudioMeter 1 AudioMeter 2 AudioMeter 3 AudioMeter 4 AudioMeter 5 AudioMeter 6 AudioMeter 7 AudioMeter 8 Aud_ADC 1 Aud_ADC 2 Aud_ADC 3 Aud_ADC 4 Aud_ADC 5 Aud_ADC 6 Aud_ADC 7 Aud_ADC 8 Miranda Technologies Ltd Page 187...
Page 188: Show Fader Status
Imagestores. Files created by a diagnostic save are sometimes requested by the Miranda Technologies Ltd Customer Support staff to aid in resolving customer queries. Configuration Save This procedure requires a DOS formatted, 3½"...
Page 189: Configuration Load
The feature saves diagnostic data to the floppy disk that is in the front-panel disk drive. The Miranda Technologies Ltd support team may request a copy of this diagnostic data to assist in resolving customer queries. Place a DOS formatted blank disk in the front panel drive and select set-up from the start- up menu before pressing the enter key.
Page 190: Load System Codes
The Load System Codes feature is used to provide for the entry of "licence" codes that enable specific options such as "Edit Pack" and "Bugclock". The Miranda Technologies Ltd support team will provide full installation and operation instructions at the time of issue of a licence. Licences are typically issued as files and may be provided on a 3½"...
Page 191: What Are Licence Codes
PASS_CAPTIONS: ON PASS_CAPTIONS: OFF enables support for line 21 close captions * A valid licence code can only be obtained from Miranda Technologies Ltd. What are licence codes? Licence codes are issued by Miranda Technologies Ltd to enable you to use various software options.
Page 192: System Information
PVW output changes immediately without the need to press the enter key. Pressing either the enter or escape key will cancel the PVW status display and return the VFD display to the earlier menu. Miranda Technologies Ltd Page 192...
Page 193: System Status
Imagestore power supply voltages become out of tolerance, an alarm indication will appear against the value. Should any alarm condition be indicated on this display, seek advice from the Miranda Technologies Ltd "Helpdesk" at the phone number given on the cover of this manual. Licences...
Page 194: View Licence
The arrow keys are now used to adjust the day and further presses of the enter key will allow changes to be made to the year, hour, minutes and seconds in a similar manner. Page 194 Miranda Technologies Ltd...
Page 195: 625/525 Lines
To view or change the current mode of the Imagestore, select "Swap- PVW/Cascade" from the "System Set-up" menu and press the enter key. The "Operation Mode" display will appear showing the current setting. To return Miranda Technologies Ltd Page 195...
Page 196: Reference Source Selection
To operate as part of a broadcast system, or to operate stand-alone, Imagestore digital video frames must be synchronised to a reference source. Miranda Technologies Ltd recommends the use of a common analogue "black and burst" reference source. Once the initial phase-lock has been set up, phase locked loop circuits within the Imagestore automatically maintain the synchronisation.
Page 197: Eas Msg Protect
If the unused option is selected, no external timecode will be used. The internal battery-backed clock will be used to supply time-of-day information. This internal clock is not recommended for use in applications other than testing as this source has relatively poor accuracy. Miranda Technologies Ltd Page 197...
Page 198: Timecode Source
The setting allows the same clock image to be used in either format. Digital clock components are unaffected by the setting. Page 198 Miranda Technologies Ltd...
Page 199: Clock Offset
Aspect Ratio – 4x3 Midground – FTB on/off Clear Squeeze PAL Filter (Text Chroma Filter) Easytext character generation has a frequency content which is too high to be passed through a PAL encode/decode process without generating chroma Miranda Technologies Ltd Page 199...
Page 200: Restart System
To obtain the highest standard of performance from the Miranda Technologies Ltd Imagestore it is highly recommended that the user be acquainted with the concepts of synchronisation and timing.
Page 201: Overview
Imagestore to the propagation delays of other Imagestores or of other broadcast equipment. Miranda Technologies Ltd always recommends the use of a separate analogue, "Black and Burst", reference signal for timing all the equipment within a system. Where this method of timing is used, it is common for the reference source to be located some distance from the Imagestore and it is possible that the synchronisation of the SDI input signals and the "Black and...
Page 202: Measurement And Test Equipment
If either signal is late with respect to the A/BGnd input then the lower propagation delay limit value is effectively increased accordingly. For example, if Key is 5µS late and B/FILL is 5µS early, with respect to A/BGnd Page 202 Miranda Technologies Ltd...
Page 203: Analogue Reference (Black And Burst)
With this achieved, view both an analogue copy of the BGnd/A signal and an analogue output signal. Adjust the propagation delay as described taking care not to alter the "line" value. Miranda Technologies Ltd Page 203...
Page 204 Installation and Integration Imagestore User Manual Page 204 Miranda Technologies Ltd...
Page 205: Support
Warranty and Non-Warranty Repairs Miranda Technologies Ltd provides all products that are sold new with a two- year, return-to-base warranty. Products that are purchased as “ex-demo” may have a limited warranty and reference should be made the original acknowledgement of order or the Product Certificate for warranty details.
Page 206: Obsolescence
Obsolescence Obsolete products will be supported for a minimum of 3 years from the date of obsolescence. Miranda Technologies Ltd will continue to provide support beyond this period, but will not replenish service stock and is therefore unable to guarantee the availability of every component used.
Page 207: Web Page
Miranda Technologies Ltd’s web page can be found at www.miranda.com. Returns Procedure Should there be a need to return any Miranda Technologies Ltd product for upgrade or repair, telephone the Helpdesk and request a "return number". The helpdesk will ask for details of the return including the unit’s serial number, reason for return and any fault information.
Page 208 Support Imagestore User Manual Page 208 Miranda Technologies Ltd...
Page 209: Appendix 1
As an alternative to the standard SDI preview video output, the CPV-001 analogue composite video output option will provide a 1V peak-to-peak analogue signal in either PAL or NTSC video format. The output is provided on a 75Ω BNC connector. Miranda Technologies Ltd Page 209...
Page 210: Power Requirements
The unit is contained within a 1RU chassis with the following mechanical specification. Height: 44mm (1.75") Width: 482mm (19") with mounting ears, 442mm (16.75") without ears. Depth: 444mm(17.55") with rear connectors, 423mm (16.75") without connectors. Weight: 7.0kg (15.4lbs) Cooling Forced air via internal fans Page 210 Miranda Technologies Ltd...
Page 211: Environmental
20°C - 80°C non-condensing Power Requirements Voltage +12V DC The Oxtel RCP obtains its power from either the Imagestore it’s connected to or from an Intelligent Panel Router, IPR, using the signal data interconnection lead. Miranda Technologies Ltd Page 211...
Page 212: Appendix
Appendix 1 Imagestore User Manual Page 212 Miranda Technologies Ltd...
Page 213: Appendix 2 Glossary
Megabits per second (10 bits per second) Midground Megahertz (10 cycles per second) Millivolt (10 volt) NTSC Colour TV system used in; USA, Canada, Mexico and Japan Phase Alternate Line Printed Circuit Board Programme Personal Identification Number Miranda Technologies Ltd Page 213...
Page 214 Remote Control Panel RS422/232 Types of serial data communication standards Serial Digital Interface SMPTE Society of Motion Picture and Television Engineers TARGA Image-file format developed by Truevision Inc. Vacuum Florescent Display VITC Vertical Interval Time Code Page 214 Miranda Technologies Ltd...
Page 215: Appendix 3 Menu Trees
Swap Preview Mode menu tree Miranda Technologies Ltd Page 215...
Page 216: Cascade Mode Menu Tree
Set Up Menu Tree set-up set up set-up Faders inputs outputs image inputs Audio Enable Assign Assign loads System System Faders File Inform- screen time of (see Setup ation Info below) Set Up Menu Tree Page 216 Miranda Technologies Ltd...
Page 217: System Set Up Sub-Menu Tree
Imagestore User Manual Appendix 3 System Set Up Sub-Menu Tree System set-up serial 625 525 Audio Set up Select Restart Clean comms clock line casc Mirror System restart set up options System Set Up Sub-Menu Tree Miranda Technologies Ltd Page 217...
Page 218 Appendix 3 Imagestore User Manual Page 218 Miranda Technologies Ltd...
Page 219: Appendix 4 Custom Configuration Notes
Imagestore User Manual Appendix 4 Appendix 4 Custom Configuration Notes Miranda Technologies Ltd Page 219...
Page 220 Appendix 4 Imagestore User Manual Page 220 Miranda Technologies Ltd...
