INSTALLATION AND INSTRUCTION MANUAL
The Split Phantom
The Split Phantom
™
Undercover Interior LED Lightbar
Models
ULB21
ULB24
(Discrete)
(Gen 4 Starburst)
IMPORTANT:
Please read all of the following instructions before installing your new warning light.
PLIT390 REV. F
10/16/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULB21 and is the answer not in the manual?

Questions and answers

Summary of Contents for Split Phantom ULB21

  • Page 1 INSTALLATION AND INSTRUCTION MANUAL The Split Phantom The Split Phantom ™ Undercover Interior LED Lightbar Models ULB21 ULB24 (Discrete) (Gen 4 Starburst) IMPORTANT: Please read all of the following instructions before installing your new warning light. PLIT390 REV. F 10/16/12...
  • Page 2 Star Headlight & Lantern Co., Inc. assumes no responsibility for the integrity of the installation for this or any of its products. The Split Phantom ™ uses state-of-the-art Light Emitting Diode (LED) technology. This warning light is comprised of ultra-high intensity LEDs that are operated by a micro-controller to efficiently produce light output with lifetimes up to 100,000 hours.

  • Page 3: Optional Mounting Brackets

    Please Note: Every ULB21 comes with a standard baffle included. The 274-ULB21-CH and 274-ULB21-CH11 kits also include a separate baffle that is specifically designed to fit the Dodge Charger. It should be used in place of the standard baffle included.

  • Page 4: Mounting Instructions

    The manufacturer assumes no responsibility for the secure mounting of this light. The ULB21 is designed to be mounted in the front windshield of a vehicle using both of the pre-existing visor clips. An alternate method is also shown using the Universal Brackets.

  • Page 5: Universal Bracket Installation

    The mounting instructions are divided into two separate sections. If you are using the Universal Mount, proceed below. If you will be using one of the vehicle specific brackets, please skip to page 9. UNIVERSAL BRACKET INSTALLATION (Model 274-ULB21-U1) SUCTION CUP WINDOW ADHESIVE MOUNT Two different sets of forked brackets are provided.
  • Page 6 Universal Mounting (CONT'D) Attach Forked Brackets to Light 1. Insert one of the carriage bolts through one of the washers. Please note that washer is used as a spacer on the square neck of the carriage bolt. Slide the bolt and washer through the back of the left bracket.
  • Page 7 Universal Mounting (CONT'D) Attach Forked Brackets to Visor Clips (If you do not have visor clips, or your visor clips will NOT provide a secure mount, or this method will not work in your vehicle for any other reason, use the alternate method on the next page.) 1.
  • Page 8 Universal Mounting (CONT'D) Attach Forked Brackets using Alternate Method If you are not using the visor clip installation described on the previous page, continue below. 1. Some vehicles may not have visor clips appropriate for the previously described installation, or may completely lack any visor clips. An alternate mounting screw hole is provided in the bracket for these situations.
  • Page 9 Universal Mounting (CONT'D) Attach The Suction Cups or Window Adhesive Mounts 1. Remove the two #4 x 1/4" Phillips pan head screws on either end of the bar, along with the washers and nylon spacers. Remove outermost screws from bottom of unit. (Bottom View) 2.
  • Page 10 VEHICLE SPECIFIC BRACKET INSTALLATION (All optional brackets excluding the 274-ULB21-U1) Determine which bracket style you have, Top Mount or Rear Mount. Depending upon which vehicle specific bracket you ordered, there are two different ways the bracket can attach to the light. One style mounts to the top of the light, one style mounts to the back of the light.
  • Page 11 Vehicle Specific Mounting Brackets (CONT'D) For both the Top and Rear mount brackets, you will need to remove the two pairs of screws from each light half as shown to the right. TOP MOUNTED BRACKETS For the rear mounted brackets, skip to the REAR MOUNT section on page 11. 1.

  • Page 12: Rear Mount

    Vehicle Specific Mounting Brackets (CONT'D) 5. Replace and tighten visor clip to 6. Tighten the screws on the visor arm secure the visor bracket to your to hold the visor bracket in place. vehicle. (Passenger’s side shown) (Passenger’s side shown) Note: If you have a Top Mount Bracket, the light will already be attached to the bracket.
  • Page 13 Vehicle Specific Mounting Brackets (CONT'D) 4. Loosen the two Baffle Adjustment Screws located on the bottom of the light to allow the baffle to slide. (Driver’s side shown) With the acorn nuts still slightly loose, slide the light as close to the front windshield as possible.

  • Page 14: Operating Instructions

    “Burst Mode” has ended, the light will be “locked out” of Burst Mode for 30 seconds. 3-Way Mode Switch set for Flashing (Pursuit) Mode: Pattern Select/Burst Mode will act as the Pattern Select button. Each time this Split Phantom switch-button is depressed, the will cycle to the next pattern.

  • Page 15: Pattern List

    Pattern List Slow Warn * Fast Warn Superfast Warn Warn Fade Pre-Pop Warn All Singleflash Alt. Tripleflash All Tripleflash Alt. Quadflash w/Post Pop 10 All Quadflash w/Post Pop 11 Alt. Quintflash 12 All Quintflash 13 Alt. Pre-pop Quintflash 14 All Flicker 15 Alt.
  • Page 16 These lights use state-of-the-art Light Emitting Diode (LED) technology. These warning lights are comprised of ultra-high intensity LEDs that are controlled by a solid state flasher unit to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any LEDs in this light.
