32" WIDESCREEN LED TV
MODEL NO.: DL-TQL32R1-002
USER MANUAL
Please read this manual carefully before using,
and keep it for future reference.
Dual provide 2 years pick up and return warrantee service for this product,
If there is any technical problem please call helpdesk: 00800-34448378 .During office hours.
Advertisement
Table of Contents
Related Manuals for Dual DL-TQL32R1-002
Summary of Contents for Dual DL-TQL32R1-002
-
Page 1: User Manual
USER MANUAL Please read this manual carefully before using, and keep it for future reference. Dual provide 2 years pick up and return warrantee service for this product, If there is any technical problem please call helpdesk: 00800-34448378 .During office hours. -
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT INSTRUCTIONS ..SAFETY INFORMATION ................... ACCESSORIES………......................4 FEATURES........................5 GENERAL PARTS......................6-7 REMOTE CONTROL......................8-9 REMOTE CONTROL PREPARATION.................10 BASIC CONNECTION………………………………............11-14 OPERATIONS BASIC OPERATIONS.....................15-21 MAIN MENU......................22-27 TV MODE.........................22-26 AV AND OTHER MODES....................26 PC MODE........................27 FOR REFERENCE MAINTENANCE......................28 WALL MOUNTING…………………………………………………………………..…………….28 STAND INSTALLATION…………………………………………………………………………..29 SPECIFICATIONS....................30 TROUBLESHOOTING......................31... -
Page 3: Safety Information
IMPORTANT INSTRUCTIONS SAFETY INSTRUCTIONS De bliksemschicht met VOORZICHTIG: OM HET RISICO OP The exclamation EEN ELEKTRISCHE SCHOK TE point within the pijl in de driehoek is een waarschuwingsteken VERMINDEREN DIENT U HET triangle is a warning dat u attent maakt op DEKSEL (OF DE ACHTERKANT) sign alerting you of “gevaarlijke spanning”... - Page 4 ● Do not operate this product under the following conditions. - When the power-supply cord or plug is damaged. - If liquid has been spilled into or objects have fallen into the product. - If the product has been exposed to rain or water. - If the product does not operate when used according to the operating instructions.
-
Page 5: Accessories
Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance. To avoid possible hearing damage, do not listen at high audio volume for long periods of time. DUAL ELECTRONICS – 79/81 ANCIENNE RN7 – 69570 DARDILLY ACCESSORIES User Manual……………………………………………………………………………………1 Remote Control……………………………….………………………………………………1 All the pictures in this manual are just for your reference, appearance and display should subject to the final product. -
Page 6: Features
FEATURES 32" TFT DISPLAY This player has a built-in 32” TFT display window to provide clear vision and low radiation. Support auto TV scanning Support multi-languages on screen display Support full function remote control Support USB multimedia playback Support HDMI, VGA, SCART, PC AUDIO, YPBPR, CVBS and AUDIO R/L input Support EARPHONE output With detachable stand holder With external antenna jack... -
Page 7: General Parts
GENERAL PARTS MAIN UNIT Front View 1. LED display screen 2. Remote control sensor 3. Power indicator- In standby mode the indicator light will display red color; when switching on the unit the indicator light will display blue color. 4. Stand holder 5. -
Page 8: General Parts
GENERAL PARTS Back View 1. Power input 2. HDMI1/HDMI2/HDMI3 input terminals 3. VGA input terminal 4. SCART input terminal 5. EARPHONE output terminal 6. USB input terminal- For multimedia files playback. 7. CVBS and AUDIO R/L input terminals 8. YPbPr input terminal 9. -
Page 9: Remote Control
REMOTE CONTROL POWER: To set the unit in standby mode; press it again to switch it on. AUTO: To adjust the screen automatically (PC/VGA). RED button GREEN button BLUE button YELLOW button ASPECT: Press this button repeatedly to select desired aspect ratio of screen. TEXT: To display the TELETEXT. -
Page 10: Remote Control
REMOTE CONTROL 26. ▲/▼/◄/►: Navigation buttons 27. SLEEP: To set the sleep time as desired. 28. EXIT: To exit menu page. 29. MUTE: To mute the sound. 30. VOL +/-: To turn up/down the volume. 31. CH+/-: To play the next/previous channel. 32. -
Page 11: Remote Control Preparation
REMOTE CONTROL PREPARATION BATTERY INSTALLATION Install the batteries as the following pictures. Be sure + and – terminals are positioned as indicated in the battery compartment (Fig1). SERVICE LIFE OF BATTERIES - The batteries normally last for one year although this depends on how often the remote control is used. -
Page 12: Basic Connection
BASIC CONNECTION ● Ensure all the cables are disconnected from the main unit before connecting to AC power source. ● Read through the instructions before connecting other equipments. CONNECTING TO AC POWER SOURCE Main unit To power outlet CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture. - Page 13 COMPOSITE AV (CVBS) CONNECTION AV cable For basic connection, use the composite Audio L/R (white/red) and CVBS (yellow) cable to connect the unit with other devices. Back of DVD/VCR COMPONENT (YPbPr) CONNECTION AUDIO cable YPbPr cable Back of DVD/VCR...
-
Page 14: Hdmi Connection
HDMI CONNECTION Use HDMI cable to connect the unit with other devices to receive high-definition multimedia signal. NOTE: Up to 3 roads HDMI can be connected for this TV. HDMI cable Back of DVD/VCR SCART CONNECTION SCART cable Back of DVD/VCR... -
Page 15: Usb Connection
PC/VGA CONNECTION Audio cable VGA cable Back of PC Use VGA cable and Audio cable to connect the unit with TV or PC, and use this product as a monitor. CONNECT EARPHONE TO THE UNIT EARPHONE cable USB CONNECTION... -
Page 16: Basic Operations
MAKE SURE ALL THE EQUIPMENTS AND POWER CORD ARE CONNECTED PROPERLY AND THE UNIT IS SET IN CORRECT MODE BEFORE KINDS OF OPERATIONS. BASIC OPERATIONS - Press POWER button on the unit or remote control to power ON the unit (indicator will glow blue);... - Page 17 SLEEP TIME SETTING - Press SLEEP button on remote control repeatedly to select SLEEP TIME directly. Available options: Off, 10min, 20min, 30min, 60min, 90min, 120min, 180min, 240min. VIDEO SIZE SETTING - Press ASPECT button on remote control repeatedly to select VIDEO SIZE directly. Available options: Auto, 4:3, 16:9, Zoom1, Zoom2.
-
Page 18: Media Playback
MEDIA PLAYBACK - Insert a USB memory device into USB slot. - Press SOURCE button on the unit or remote control to switch this unit to Media mode. - Press EXIT button on remote control to return to previous menu page. 1. - Page 19 - Press RED button to enter a dialog box, and press LEFT or RIGHT navigation button to decide whether delete it or not. - Press OK button to play highlighted file. During PHOTO normal playing: - Press EXIT button on remote control to hide the tool bar. - Press DISPLAY button on remote control to display the tool bar.
- Page 20 - Press RED button to enter a dialog box, and press LEFT or RIGHT navigation button to decide whether delete it or not. - Press OK button to play highlighted file. During MUSIC normal playing: - Press LEFT or RIGHT navigation button to select desired option in the tool bar, and press OK button to confirm selection.
- Page 21 - Press RED button to enter a dialog box, and press LEFT or RIGHT navigation button to decide whether delete it or not. - Press OK button to play highlighted file. During MOVIE normal playing: - Press DISPLAY button on remote control to display the tool bar. - Press EXIT button on remote control to hide the tool bar.
- Page 22 4. TEXT - Press LEFT or RIGHT navigation button to select TEXT item. - Press OK button to enter it and press LEFT or RIGHT navigation button to select desired disk. - Press OK button to enter it and press navigation buttons to select desired folder. - Press OK button to enter it and press navigation buttons to select desired Text file.
-
Page 23: Main Menu
MAIN MENU ● The unit contains different setting menus. Once the initial programming is entered, it will be remained in the memory until change, and the unit can always be operated under the same conditions. ● The settings will be remained in the memory until the settings are changed ever after setting the player to standby mode. - Page 24 1.2 ATV Manual Tuning - Press UP or DOWN navigation button to select this item, and press OK button to enter it. - Press UP or DOWN navigation button to select the second option. - Press LEFT or RIGHT navigation button to adjust 1.3 Programme Edit - Press UP or DOWN navigation button to select this item, and press OK button to enter it.
- Page 25 2.1 Picture Mode Available options: User, Dynamic, Standard, Mild. NOTE: The value of Contrast, Brightness, Colour, Tint and Sharpness is adjustable only when Picture Mode is User. 2.2 Contrast The value of contrast can be adjusted from 0-100. 2.3 Brightness The value of brightness can be adjusted from 0-100.
- Page 26 3.1 Sound Mode Available options: Standard, Music, Movie, Sports, User. NOTE: The value of Treble and Brass is adjustable only when Sound Mode is User. 3.2 Treble This item is used to adjust the level of higher-pitched sounds from 0-100. 3.3 Bass This item is used to adjust the level of lower-pitched sounds from 0-100.
-
Page 27: Av And Other Modes
5. OPTION 5.1 OSD Language This item is used to select desired On Screen Display language. 5.2 TT Language This item is used to select desired TT language. 5.3 Aspect Ratio Available options: Auto, 4:3, 16:9, Zoom1, Zoom2. NOTE: Aspect Ratio may not be adjustable if no available signals are present. 5.4 Blue Screen This item is used to set the blue background ON or OFF. -
Page 28: Pc Mode
PC MODE - Power on your computer and this TV. - Connect your computer to this TV using a VGA cable. - Press SOURCE button on the unit or remote control to switch this unit to PC mode. - Press MENU button to display the main menu and press LEFT or RIGHT navigation button to select SCREEN. -
Page 29: Maintenance
MAINTENANCE ● Be sure to press POWER button to set the player to the standby mode and disconnect the plug before maintaining the player. ● Wipe the player with a dry, soft cloth. ● If the surface is extremely dirty, wipe clean with a cloth which has been dipped in a weak soap-water solution and wrung out thoroughly, and then wipe again with a dry cloth. -
Page 30: Stand Installation
STAND INSTALLATION Your TV may be packaged with the Stand and the Cabinet separated. Before enjoying this TV, please carry out the Stand Installation according to the instructions below. Step 1 Place the TV faced down on a soft cloth or cushion to prevent the panel from being damaged. -
Page 31: Specifications
SPECIFICATIONS Display Device 32 inch LED TV Resolution 1366×768 Display Colors 16.7M Contrast Ratio 3000:1 Aspect Ratio 16:9 30,000 Hrs Life Time Movie: AVI, MP4, TS, MPG, MKV/MOV, DAT, VOB USB Multimedia Music: MP3, AAC Format Photo: JPG/JPEG, BMP, PNG Text: TXT Power Source AC 100~240V, 50/60Hz... -
Page 32: Troubleshooting
GENERAL TROUBLESHOOTING Check the following points before assuming malfunctions of this unit: Symptom Remedy No power. Insert the power plug securely into the power outlet. No picture. Ensure that the equipment is connected properly. ● Ensure that the equipment is connected properly. ●...
