DVR1 Digital Voice Recorder
Operation Manual (V1.0)
Feature and Functions:
! Omni directional and high sensible built-in microphone.
! Real-time clock and calendar.
! Daily alarm.
! 199 messages in "OGM" mode and 20 messages in "To Do" mode.
! Key hold : prevents accidental operation when not in use.
! Two compressibility selectable.
! Playback volume selectable : 0-10. The level of 10 means the
volume is maximum.
! Automatic gain adjustable (ALC).
! Voice-Active-Recording (VOX), prevents unnecessary
recording when there is no sound, it will maximize the
recording time.
! Auto-Off : power turn off automatically when stop use for 10
minutes.
! Battery indicator : displays remaining battery capacity.
! Fast forward, fast rewind, pause, repeat play, scan play.
! Indication new message and the time of message in OGM mode,
20 messages of schedule in To Do mode. Informs possible
recording time.
! Selectively delete / All delete messages, protect message of
schedule when All delete in To Do Mode.
! External input – output jack enable to record or play from
external appliances.
! Interface to personal computer by serial port of RS-232
! Upload, download, delete the message and manage it
conveniently. Setting clock and alarm by your personal
computer.
Batteries :
Use two "AAA" Batteries.
In record : 50mA, Stand by : 60uA, Play : 50-80 mA; Please
change batteries when indicate the low power display.
Advertisement
Summary of Contents for Auraland DVR1
- Page 1 DVR1 Digital Voice Recorder Operation Manual (V1.0) Feature and Functions: ! Omni directional and high sensible built-in microphone. ! Real-time clock and calendar. ! Daily alarm. ! 199 messages in “OGM” mode and 20 messages in “To Do” mode. ! Key hold : prevents accidental operation when not in use.
- Page 2 Keys : There are 7 keys and 1 switch : Mode There are 3 modes : OGM, TO DO and TIME. Press K3 (</Rep) or K4 (>/Scan) for less than 2 seconds to select when it is stop. It will back to OGM Mode automatically if no operation in other mode in 30 seconds (except when playing or recording).
- Page 3 the hour and minute will display 2 seconds in order. The OGM on LCD will blink if there has new message. 1. Mode Change : Press K4 (>/Scan) to enter Time Mode. Press K3 (</Rep) to enter To Do Mode. 2.
- Page 4 to enter Fast Rewind Mode, it will release Fast Rewind Mode and resume playback if release the key or arrived the start of the current message. c. Press K4 (>/Scan) for more than 1 second and not release to enter Fast Forward Mode, it will release Fast Forward Mode and resume playback when release the key.
- Page 5 6. All Play Mode : Press K1 (Rec/Stop/Pause) for more than 2 seconds, it will play back all the message from the current to former. The operation is same as Play Mode. 7. Repeat Mode : Press K3 (</Rep) for more than 2 seconds, it will play the current message repeat.
- Page 6 The number of message will display. 3. Schedule Setting : Press K5 (+/Mode/^) for more than 2 seconds to enter Schedule Setting Mode. a. Press K3 (</Rep) or K4 (>/Scan) to select the setting of month, date, hour or minute. b.
- Page 7 e. Press K5 (+/Mode/^) for more than 2 seconds to confirm and quit. The week will change automatically. 3. Setting the alarm time : a. Press K5 (+/Mode/^) for more than 2 seconds to set time. The “TIME” on LCD will blink. b.
- Page 8 (Hold) to HOLD you can disconnect it. Operation On Personal Computer Insert the floppy disk attacked into your PC and copy all the files to your PC. All files must in the same directory. Connect your DVR to you PC first. Run the PC-Link software, Press K6 (-/v) on the DVR for more than 2 seconds to link the PC.
- Page 9 Please restart if the connection is fail. And make sure the cable connects properly and firmly between both ends. Click “HELP” on the menu bar for more details.
