65 inch Class 1080p Plasma HDTV
TC-65PS14
Model No.
GPF12DU Chassis
© Panasonic Corporation 2009.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.MTNC091064CE
B34 Canada: B07
