- Page 1 ® ELECTRIC HOT PLATE MODELS 501FF, 502CF, 502FF Installation and Operation Instructions 2M-Z16005 Rev. - 5/05/12 50FF...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: Specifications
Specifications Electrical Specifications Dimensions Model Voltage Width Depth Height 501FF 208/240 1.95/2.6 17.25” 10.7” 12” (30.4cm) (43.8cm) (27.2cm) 501FF-208V 208V 502CF 3.1/4.2 11 5/8” 208/240 12” (30.5cm) 28 (71.1cm) (29.5cm) 502FF 3.9/5.2 GENERAL OPERATING INSTRUCTIONS This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. - Page 4 CLEANING The exterior surfaces can be kept clean and attractive by regularly wiping with a clean soft cloth. Any discoloration can be removed with a non-abrasive cleaner. For models 502D and 502DS, the heating elements may be raised for access to the drip pans, which may be removed for cleaning and the bottom pan may be removed by sliding pan forward.
-
Page 5: Wiring Diagram
PART NO. MATERIAL MODEL NO. SK1986 STAR MANUFACTURING INTERNATIONAL INC. 502D/502FD #10 SUNNEN DRIVE, ST. LOUIS, MO. 63143, USA FINISH TITLE WIRING DIAGRAM 4-9-03 DATE TOLERANCES UNLESS OTHERWISE NOTED THIS DRAWING CONTAINS CONFIDENTIAL INFORMATION REVISIONS DATE DESCRIPTION OF CHANGE NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED. FRACTIONS ±... - Page 6 MODEL 502CF, 502FF STAR MANUFACTURING INTERNATIONAL, INC. 501FD NOT ILLUSTRATED SK2593 06-05-12...
-
Page 7: Parts List
Model: Star-Max Electric Hot Plate Fig No Part No Description Application I3-Y7822 COVER 502CF I3-Y7891 STRAIN RELIEF CHAIN 502CF 2N-11120-12 ELEMNT TK 208V 2600W 501FF (208/240V) 2N-Y3301 ELEMENT 2600 WATTS 240V 501FF-208V 2N-Y7779 ELEMENT 502CF 2D-6470 502CF 2P-6468 RING 502CF I2-Z6175... - Page 8 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit.
