Digi-Wave DLT 100 User Manual

Digi-wave wireless listening system user manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Table of Contents

Need help?

Do you have a question about the DLT 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digi-Wave DLT 100

Page 3: Table Of Contents
Safety Information System Overview DLT 100 6-27 Button Functions Battery Charging 2-Way Mode 10-17 Simultaneous Interpretation Mode 18-25 Repeater Mode 26-27 DLR 50 28-31 Specifications 33-34 DLT 100 Specifications 32-33 DLR 50 Specifications Troubleshooting FAQ’s FCC Statements...
Page 4: Safety Information
safety information H e A R I n g S A F e T y M e D I C A L D e v I C e S A F e T y CAUTIOn! CAUTIOn! This product is designed to amplify sounds to a high volume level which 1.
Page 5: System Overview
The new Digi-Wave™ (digital spread spectrum – DSS) is a simultaneous, two-way wireless listening system in the 2.4 gHz band. Slim, lightweight, simple to set up and use. With the push of a button, users can access 2-way communication for easy group leader/group member participation.
Page 6: Dlt 100
DLT 100...
Page 7: Button Functions
° Press button once to activate the microphone. Press button once more to turn off ° Press once to change mode when in setup mode the microphone ° Press and hold the button for approximately 2 seconds to mute other DLT 100 slave units. Only the CM has this function. vOTIng / SeTTIng BUTTOn °...
Page 8 button functions Talk Button LCD display Internal Speaker external Mic. Jack (3.5mm) external Headphone Jack (3.5mm) Internal microphone iPod Connector (30pin) Power / Menu Volume / Select Down Volume / Select Up...
Page 9: Battery Charging
B A T T e R y C H A R g I n g 1. This Product uses rechargeable lithium polymer battery 2. Use 30 Pin connector, located on the bottom of DLT 100 to charge the battery. Full charging time: approx. 5 hours Red LED flashes while charging.
Page 10: 2-Way Mode
2-way mode steps DLT chairman master (CM) DLT chairman slave (CS) DLT’s slave (SLV) Assists CM in a group. Has 2 2-way communication with all DLT’s in CM works as a master device to control everyone in a group. Guide priority to speak group.
Page 11 DLT’s or DLR’s. Address confirmation Press the MenU button twice. The address for the DLT 100 will be displayed The CM has the ability to lock out other talkers by holding down the TALk for two seconds. NOTE: every DLT 100 MUST have its own address and all button for three seconds. The CM TALK LED will continuously flash while...
Page 12 Press and hold POWeR button for 2 Press nO and yeS button together Mode icon will blink on the LCD Press ( - ) or ( + ) button to select seconds to turn DLT 100 on for 2 seconds screen mode...
Page 13 DLT 100 Press ( + ) button, the mode will change in sequence above. Press ( - ) button for reverse sequence note: In 2-Way Mode, 2 different applications can be used as listed below. each has a different role but they both can be used in 2-Way Mode.
Page 14 2-way setup Press ( + ) or ( - ) button to select Press POWeR / MenU button to Address ( ADD ) icon will now begin to Press POWeR / MenU button to CHAIRMAn MAS / CHAIRMAn SLv enter CHAIRMAn MAS / CHAIRMAn blink Press ( + ) or ( - ) button to select enter Address number / SLv.
Page 15 DLT 100 gROUP icon will now blink. Press POWeR / MenU button to The hour number ( TIMe ) will now Press POWeR / MenU button to Press ( + ) or ( - ) button to select a enter group number blink.
Page 16 2-way setup The minute number ( TIMe ) will now Press POWeR / MenU button to TALk icon will now blink ( speech Press POWeR / MenU button to blink. Press ( + ) or ( - ) button to enter Minute number time ) Press ( + ) or ( - ) button to enter speech time.
Page 17 DLT 100 you are now at the beginning of the setup mode. To save and exit setup, hold nO and yeS buttons together for 2 seconds...
Page 18: Simultaneous Interpretation Mode
simultaneous interpretation mode interpreter attendees main speaker (floor) steps repeater (DLT or DLR) receive only (SLV) master Main speaker’s speech will be Interpreters can be set as 1 repeater per channel. (0-14 Within a group, capable of transmitted through channel 0 many as needed.
Page 19 Power ON/OFF Connecting to external devices Press and hold the Power/Menu button for two seconds. The LED’s will flash The 30 pin charging connector on the bottom of the DLT 100 will also con- and the LCD will turn on. nect to most I-Pod speaker stations. The 3.5mm stereo microphone jack can accept a headphone level or a line level output from audio sources Press and hold the Power/Menu button for two seconds to turn the unit off.
Page 20 Press and hold POWeR button for 2 Press nO and yeS button together Mode icon will blink on the LCD Press ( - ) or ( + ) button to select seconds to turn DLT 100 on for 2 seconds screen mode...
Page 21 DLT 100 Press ( + ) button, the mode will change in sequence above. Press ( - ) button for reverse sequence note: In Interpretation Mode, 4 different applica- tions can be used as listed below. each has a different role but they all can be used in Interpreta- tion Mode.
Page 22 simultaneous interpretation setup Press POWeR / MenU button to When mode selection is made SLv or Press ( + ) or ( - ) button to select SLv Press POWeR / MenU button to enter selected interpretation mode. MAS icon will blink. ( Receive only will ( Slave ) or MAS ( Master ) enter SLv or MAS.
Page 23 DLT 100 Channel icon will now begin to blink Press POWeR / MenU button to group icon will now blink. Press POWeR / MenU button to Press ( + ) or ( - ) button to select a enter Channel number...
Page 24 simultaneous interpretation setup The hour number ( TIMe ) will now Press POWeR / MenU button to The Minute number will now blink Press POWeR / MenU button to blink. Press ( + ) or ( - ) button to enter Hour number Press ( + ) or ( - ) button to select enter Minute number...
Page 25 DLT 100 I M P O R T A n T There can only be one master (floor) per group you are now at the beginning of the setup mode. To save and exit setup, hold nO and yeS buttons together for 2 seconds...
Page 26: Repeater Mode
repeater mode Main Speaker ( Floor ) DLT Main Speaker ( Floor ) DLT Repeaters Interpreter DLT’s Interpreter Repeater DLT’s Must be set to Main Speaker, CH 0 Must be set to Repeater, CH 0 Must be set to Interpreter, CH 1 - Must be set to Repeater, CH and SLV and MAS...
Page 27 CH 12 CH 13 CH 14 DLT 100 [ LISTEN ONLY ] OR DLR 50 DLT 100 [ LISTEN ONLY ] OR DLR 50 MUST BE ON THE SAME GROUP . EACH LISTENER WOULD SELECT A DESIRED CHANNEL / LANGUAGE.
Page 28: Dlr 50
DLR 50...
Page 29 button functions external Headphone Jack (3.5mm) Power On / Off volume up volume down Channel up Channel down Internal Speaker...
Page 30: Operation Guide
operation guide Two AAA batteries must be inserted into the DLR. Be sure to observe cor- User can listen using the speaker on the front of the DLR or by plugging in rect polarity. earphones into the jack (which defeats the speaker operation). Power on by holding the power button for 3 seconds.
Page 32: Dlt 100 Specifications
DLT 100 specifications Dimensions 103 x 62 x 11mm (4.1 x 2.4 x 0.4 inches) Weight 80g (2.8oz) including battery Color Black and silver enclosure Shatter resistant PC/ABS plastic Battery type Li Polymer with smart charge built into transceiver Battery life...
Page 33: Specifications
DLT 100 specifications, cont. Controls Front panel push buttons for volume up/down, group select, menu access and selection, voting, timer, time, MIC on/off and power on/off. System reset button (rear panel) Output 3.5mm stereo/mono jack 30 pin charging jack with audio out to base stations...
Page 34: Dlr 50 Specifications
DLR 50 specifications Dimensions 85 x 55 x 16mm (3.35 x 2.16 x 0.63 inches) Weight 42g (1.5oz) not including batteries Color Black enclosure Shatter resistant PC/ABS plastic Battery type 2 x AAA Battery life Up to 24hrs (Alkaline) Channels Up to 15 simultaneous channels (Interpretation mode) Up to 4 simultaneous groups Operating frequencies...
Page 35: Troubleshooting
troubleshooting P R O B L E M S C A U S E W H A T T O D O Power does not turn-on Dead battery Charge the battery, replace battery Power turned off automatically Master device can’t be found Set Master device Power doesn’t turn off Program error...
Page 36: Faq's
FAQ’s What is the range of the system? What is the battery life for the DLT and DLR? Up to 100ft outdoors and up to 200ft indoors. DLT – up to 14hrs per charge. DLR - up to 20hrs (2 x AAA Alk. batts). What is the benefit of this system over the 72MHz systems? Is this product compatible with any other competitive system? DLT’s can operate in two way mode.
Page 37: Fcc Statements
FCC statements Federal Communication Commission Interference Statement FCC Caution This equipment has been tested and found to comply with the limits To assure continued compliance, any changes or for a Class B digital device, pursuant to Part 15 of the FCC Rules. modifications not expressly approved by the party responsible for These limits are designed to provide reasonable protection against compliance could void the user’s authority to operate this equipment.
Page 38 contact us 10300 valley view Rd eden Prairrie, Mn 55344 U.S.A. 800.843.3544 952.943.2252 Fax 952.943.2174 williamssound.com info@williamssound.com...
