- Page 1 TRANSPORTABLE PORTAL MONITOR MODEL TSA TPM-903B Operations & Service Manual Doc: # 5058 Rev. A March 2013 LAURUS Systems, Inc. - Ph: 410-465-5558 - Fax: 410-465-5257 - www.LaurusSystems.com...
- Page 2 Every effort is made to keep the manuals up to date and accurate. However, because Rapiscan Systems is constantly improving and upgrading the product line, Rapiscan can make no guarantee as to the content of current manuals.
- Page 3 The pages and drawings listed below have been changed. The manual has been updated to standardize this documentation. Title: TSA TPM903 Operations and Service Manual Date: March 2013 Pages: All _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited...
-
Page 4: Table Of Contents
5.5. RECOMMENDED SPARE PARTS......Error! Bookmark not defined. TROUBLESHOOTING .....................37 6.1. COMPONENT ACCESS....................37 6.2. COMPONENT TROUBLESHOOTING ..............39 _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... - Page 5 6.2.3. INFRARED DETECTOR ..................39 GLOSSARY.......................40 PARTS LISTS......................42 SPARE PARTS ORDERING INFORMATION............42 LIST OF DRAWINGS ....................43 _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited...
- Page 6 TSA TPM903 Operations and Service Manual Doc: # 5058 Rev. A _____________________________________________________________________________________________________________________ CONFIGURATION TRACKING SHEET RAPISCAN MODEL NUMBER:______________ SERIAL NUMBER:________________ SOFTWARE VERSION:______________ DATE RECEIVED:________________ OPTIONS AND ACCESSORIES:_________________________________________ SYSTEM MODIFICATIONS MODIFICATION: _______________________________________________________ _______________________________________________________________________ INSTALLED BY:________________________________ DATE: ________________ MODIFICATION: _______________________________________________________ _______________________________________________________________________ INSTALLED BY:________________________________ DATE: ________________...
-
Page 7: Introduction
TPM-903B. Since applications are necessarily site-specific, operation procedures are given in general terms. Service and repair are covered to the board level. Anything more complex than this requires that the instrument or assembly be returned to Rapiscan Systems. 1.2. GENERAL DESCRIPTION The Personnel Portal Monitor, Model TPM-903B, is a highly reliable system for the detection of radioactive isotopes. -
Page 8: Specifications
Dimensions: Two, 4.5" diameter x 84" high pillars (11 x 213cm), with a 4.5" (11cm) diameter crossover which provides 32" (81cm) pillar spacing _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 9: Inspection And Set-Up
If the instrument is damaged in transit or fails to meet specifications upon receipt, notify the carrier and Rapiscan Systems immediately. Shipping cartons, packing materials, waybills and other such documentation should be preserved for the carrier’s inspection. Rapiscan will assist in providing replacement or repair of the instrument if necessary. -
Page 10: Assembling The System To Scan Pedestrians
(*) key on the keypad. To disable constant occupancy and return the unit to normal operation press the pound key (#) on the keypad. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 11: Assembling The System To Scan Vehicles (Optional)
The distance adjustment on the back of the IR should be set to its maximum range. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 12: Set-Up And Programming
It has many user programmable parameters that can be used to optimize it for a wide variety of applications. Refer to Section 3.4 for details on programming the controller. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 13: Password Control
The set-up menu presents the operator with a choice of parameters or functions. Pressing the "one" key will present a menu of the available PARAMETERS. Pressing the "two" key will present a menu of the available FUNCTIONS. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 14: Parameters
(last two digits only) from the keypad. When the pound (#) key is pressed after the last entry, the data are written to the internal clock/calendar. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... - Page 15 NOTE: Since the Digital to Analog Converters (DACs) have limited resolution, manual entries will be rounded to nearest value the DACs can output. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited...
-
Page 16: Functions
Performs a variance test on all detectors. The system runs 15-second variance passes. In the TPM-903B system, Rapiscan recommends running five 15-second passes. After five passes all variance readings should be less than 0.10. Refer to Appendix A for further detail on the variance test and the formulas used. -
Page 17: Tsa Tpm903 Operations And Service Manual
PC. This number must be used by the PC to establish a communications link. This range of this number is 1 - 32,767. This number is set to 1 when the system is shipped. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... - Page 18 This variable is automatically cleared on a power cycle and at midnight each day. Fields are padded for 32 bytes. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited...
- Page 19 If the user does not know the depreciated value of the calibration source but does know when the source was manufactured, then the user can go to the Rapiscan Systems web site (tsasystems.com) and look under archives/software/ SourceDepr determine the depreciated value.
- Page 20 PRESS ANY KEY After user presses key the same info will be presented for pillar 2 Pressing any key at this point returns to menu. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited...
- Page 21 _____________________________________________________________________________________________________________________ 3.4.2.8 RESET CAL: This routine restores the factory calibration HVDAC value. When pillar is calibrated at Rapiscan, the HVDAC value is stored in the DM-757 in the pillar. If a calibration fails, the user may attempt to recover by using the Reset Cal routine.
-
Page 22: Pc Communication
The parameters cannot be changed from the PC. 3.9. SHOW COUNT Displays detector counts, in CPS, updated and averaged over the most recent 5 second data. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 23: History
After the download is complete, the operator will be prompted for a file name, and given the option to view a file at this time. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 24: Initial Installation Checklist
___ Variance test; variance detector 1: _______ 2: _______ ___Test; list sources and sizes used: ________________________________________ ______________________________________________________________________ Performed by:_____________________________ Date: __________________ COMMENTS:________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 25: Theory Of Operation
(look after). The amount of time selected for this parameter is based on the estimated speed of passage and pillar spacing. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 26: Modes
DET X:LO/HI NNNN, where X is the detector number, and NNNN is the current background for that detector. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 27: Fast Count Mode
In this mode, the unit takes 75 0.2 second background counts and performs a variance calculation on the data. A more detailed description of the variance test may be found in the Appendix. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 28: Components
5. Alarm LED and buzzer - A red LED and piezo-electric buzzer are used to indicate a Radiation Alarm. 6. Ready LED - A green ready LED indicates the monitor is on and ready to scan. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 29: Maintenance
(under a hat), and at shoe or ankle level. Repeat the test several times and record the sources and sizes used. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 30: Performance Verification Checklist
___ Walk-through test; list test source serial number and activity: Performed by: _____________________________ Date: ______________ COMMENTS:________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ _________________________________________________________________________ _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 31: Recommended Spare Parts
SC-771 Circuit Board 8753 6668 Infrared Detector Banner QS30DQ 7491B Power Supply, 7V 7491B 9480 TPM-903B Controller 9480B 6466D D Cell Battery Holder Bulgin BX0017 _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... -
Page 32: Troubleshooting
Install the replacement LED, and resolder the wires. The pillars contain the detector assemblies, the detector module, and the high voltage module. Verify problems by substituting the detectors. Return the defective pillar to Rapiscan for repair. _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. -
Page 33: Component Troubleshooting
This assembly is difficult to remove and then get reinserted into the PVC tube without damaging any of the parts. It is recommended that if a detector assembly is defective that it be returned to Rapiscan for repair. 6.2.3. INFRARED DETECTOR A green LED located on the top of the IR detector will illuminate on power up. -
Page 34: Glossary
Usually set in CPS. POST: Power On Self-Test Rolling Background: This is the background accumulation method used in most of Rapiscan’s instruments. Background accumulation is done in ten separate buffers, each buffer representing 1/10 of the total background time. As each buffer is filled, the background is updated. This results in a background update at background time/10. -
Page 35: Parts Lists
The parts list in this manual includes parts that were being used at the time this manual was written. Parts for systems produced prior to this date may be different. It is recommended that for older equipment you should contact Rapiscan Systems at RapiscanTSASales@osi-systems.com. 1.1 SPARE PARTS ORDERING INFORMATION To facilitate the processing of spare parts orders the following information is required. -
Page 36: List Of Drawings
GPRB Wiring Diagram ..........................17 GPRB Component Designator ........................18 TRAN-1 Differential Transmitter PCB ......................19 TRAN-1 Component Designator........................20 VD-1924 Schematic Diagram ........................21 VD-1924 Component Designator........................22 _____________________________________________________________________________________________________________________ This document is the exclusive property of Rapiscan Systems. Unauthorized use or distribution is strictly prohibited... - Page 37 CROSSOVER CONTROLLER CALIBRATION SPOTS DM-757 AND PILLAR "2" GHA-472 BOARDS PILLAR "1" TPM-903B TPM-930B PEDESTRIAN MODEL PICTORIAL VIEW PEDESTRIAN MODEL TPM-903B DCN: EDCN EDWG # PRoss .xxx UNLESS OTHERWISE NOTED. REV. NA TPM-903B_Manual12-08.tcw...
- Page 38 PILLAR "2" CALIBRATION SPOTS CONTROLLER DM-757 AND GHA-472 BOARDS CROSSOVER DM-757 AND PILLAR "1" GHA-472 BOARDS 10 FEET TPM-930B VEHICLE MODEL PICTORIAL VIEW TPM-903B DCN: EDCN EDWG # TPM-903B .xxx PRoss UNLESS OTHERWISE NOTED. VEHICLE MODEL REV. NA TPM-903B_Manual12-08.tcw...
- Page 39 GPRB-756...
-
Page 40: External View
BATTERY COMPARTMENTS PILLAR '1' (REF) READY INDICATOR POWER SWITCH COMPUTER CONNECTION ALARM INDICATOR INFRARED VIEW A OCCUPANCY PILLAR '2' DETECTOR FRONT OF CONNECTION BOX (REF) DISPLAY POWER INPUT JACK (FOR OPERATION WITHOUT BATTERIES) PILLAR '1' VIEW B CONNECTION AUDIO SONALERT NUMERIC KEYPAD (SETUP/DIAGNOSTICS) TPM-930B CONTROLLER... - Page 49 DM-757B BOARD COMPONENT DESIGNATOR - - - DCN: EDCN EDWG # PRoss .xxx UNLESS OTHERWISE NOTED. REV. NA DM-757B_CD.tcw...
- Page 53 GHA-472AA CD E - M - S DCN: EDCN EDWG # .xxx UNLESS OTHERWISE NOTED. REV. NA GHA-472AA_8674AA_CD.tcw...
