Instruction Manual
Wireless Network Equipment
Optima Series: Models AP24, BR24, CP24
Configuration Type: 24-AE-19F
Optima Series: Models AP58, BR58, CP58
Configuration Types: 58-AE-26F
Instruction Manual (v3)
Alico Systems Inc
th
2461 W. 205
Street, Suite B105
Torrance, California 90501-1464
Telephone: 310-781-9500
www.alicosystems.com
1
Advertisement
Table of Contents
Related Manuals for Alico Optima AP24
Summary of Contents for Alico Optima AP24
- Page 1 Wireless Network Equipment Optima Series: Models AP24, BR24, CP24 Configuration Type: 24-AE-19F Optima Series: Models AP58, BR58, CP58 Configuration Types: 58-AE-26F Instruction Manual (v3) Alico Systems Inc 2461 W. 205 Street, Suite B105 Torrance, California 90501-1464 Telephone: 310-781-9500 www.alicosystems.com...
-
Page 2: Fcc Notice
Notices FCC Notice: Part 15 Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Setup Instructions
What You Need to Get Started: • You need to provide 2 straight patch segments of CAT-5e Ethernet cable with RJ45 connectors on each end. You may also need a crossover cable to configure the AP24/58 if you are connecting directly to a PC. •... - Page 4 Follow the instructions in the next section to assemble the Ethernet weatherproof cable feed through assembly. Connect one end of a patch (straight through) CAT 5e Ethernet cable to the AP24/58 through the Feed through assembly. Connect the other end of the CAT5e cable to the power and data port of the Power Over Ethernet Module.
- Page 5 Cable Feed-through Assembly Step 1: Use a Cat 5/6 cable with a open RJ45 connector without a boot. • Do not tighten compression gasket until you are finalizing the installation. The gasket should only be fully tightened once. Thorough inspection of the compression fitting should be done if it is re- used.
- Page 6 Starting Winbox Using the MAC Address Note: In order to connect using the MAC address your PC must be on different subnet than the default AP24 IP address 192.168.0.239 1. Copy the WinBox application from the CD to a convenient folder on your PC 2.
- Page 7 Starting Winbox Using IP Address 1. If your PC is setup on the same subnet as the default AP24 IP address 192.168.0.239 then you must use the IP address to login. Using a MAC address will not work. 2. To log in to the WinBox enter the IP address 192.168.0.239 in the Connect To field 3.
- Page 8 Looking at Interfaces 1. Click on the “Interfaces”’ button on the left column Double click on the “ether1” interface to see the illustrated traffic pattern Setting Up the Bridge (already setup) 1. Click the “Bridge” button on the left column of WinBox Click on the “+”...
- Page 9 Select “bridge1” on the Bridge Port <ether1> window Click OK Double click on the “wlan1” line Select “bridge1” on the Bridge Port <wlan1> window Click OK Bride1 Operating You now have an operating bridge inside the AP24, close “Bridge” window.
-
Page 10: Setting Up The Ip Address
IP address is only needed for the management interface. 5. If you are setting the AP24 as a router then you would need to add IP addresses for the “ether1” and the “wlan1” as well as setting up the appropriate routes. -
Page 11: Using The Web Interface
The AP24 is setup with manually set frequency channels. If you want the AP24 to auto select the frequency setup the DFS mode to either “no radar detect” or “radar detect”. In the “no radar detect”... -
Page 12: Limited Warranty
Alico Systems warrants that your device is free of defects in material and workmanship for a period of one year from date of purchase. Alico will, in this period of time, repair or replace, any Alico product returned to the factory, freight prepaid.
