    LS 275e Product description The product is a 5.1 channel home theater system with high performance / high power / acoustic field location accuracy. With PCM decoding and real surround sound effect. 2.4 GHz wireless for rear speakers. Modern design / Easy to install / Remote control operation.

  • Page 42: Safety Instructions

    Brand name: Blaupunkt Responsible party: M3 Electronic GmbH Gutenbergstrasse 5, D-65830 Kriftel. Germany Hereby, Blaupunkt Competence Center Audio M3 Electronic GmbH, declares that this Class 1 equipment is in compliance with the essential requirement and other relevant provisions of Directive 1999/5/EC.
  • Page 43 LS 275e Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products, including amplifiers that produce heat. No naked flame sources, such as lighted candles, should be placed on the apparatus.
  • Page 44 LS 275e The only means of completely disconnecting the product from the power supply is by removing the power cord from the wall outlet or the product. The wall outlet or the power cord entry to the product must remain freely accessible at all times while the product is in use.
  • Page 45 LS 275e Warning This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 46 LS 275e Subwoofer Front Panel - Controls and Functions STANDBY: Power Standby button. INPUT: Audio input source selection button. VOL-: Volume Downwards Adjustment button. VOL+: Volume Upwards Adjustment button. STANDBY: Subwoofer Standby Status indicator. Display Screen...
  • Page 47 LS 275e Subwoofer Rear Panel - Controls and Functions LS 275e Gutenbergstrasse 5,D-65830 Kriftel-Germany TOTAL POWER CONSUMPTION: 200W STANDBY POWER CONSUMPTION: <1W ACHTUNG GEFAHR EINES ELEKTRISCHEN SCHLAGES!GERÄT NICHT ÖFFNEN! POWER Stereo 1 input Stereo 2 input Coaxial 2 input AC Power cord...

  • Page 48: Remote Control - Controls And Functions

    LS 275e Remote Control - Controls and Functions 1. STANDBY: Power Standby 2. COAXIAL 1: coaxial 1 select button MUTE 3. ST1 Input button 4. OPT: Optical input button COA.1 COA.2 5. VOL+: Main volume upwards adjustment 6. SW-: SW volume downwards adjustment 7.
  • Page 49 LS 275e Before using the remote control, please insert the correct type of batteries into the battery compartment. The remote control uses 2 x 1.5V/AAA batteries. Please insert the batteries as indicated below. a. Remove the battery compartment cover. b. Insert 2 batteries as per the polarities marked inside the battery compartment.
  • Page 50 LS 275e Tower Speaker Assembly Drawing The tower speakers are detachable. Please follow up below drawing for assembly. Tower speaker (Top part) Step 3 Tower speaker (middle part) Chassis bottom Step 1 Step 2 Screws...

  • Page 51: Placement Instructions

    LS 275e Placement Instructions After finishing the assembly of tower speaker, please place the speaker system according to below drawing. Please kindly note that the distance between both tower speakers shall be over 2.5m in order to get better surround sound effect in 5.1 mode.
  • Page 52 LS 275e System Connection Instructions Please use the speaker cable to connect the front tower speakers and center speaker with subwoofer according below drawing. Please make sure that the “White” color speaker cable is connected with “Red” color terminal in “+” polarity, and that the “Black” color speaker cable is connected with “Black”...
  • Page 53 LS 275e Digital Inputs and Analog Inputs Connection Instructions Connecting Subwoofer / DVD Player / TV Analog audio connect to Digital inputs optical coaxial Analogue inputs...
  • Page 54 LS 275e Wireless Pairing Operation Guide Pairing wireless rear speakers The speaker system has been already paired in the production line. Once you turn on the subwoofer and then turn on the rear wireless speakers the system will pair them automatically.

  • Page 55: Important Note

    LS 275e 4. After succeeded manual pairing, the system can memory the pairing, and can pair them automatically within 10~15 seconds the next time that you switch on. Important Note: a. Please make sure that you turn on the both wireless rear speakers within 20 seconds after power on subwoofer during the manual pairing procedure, otherwise, the pairing will fail.

  • Page 56: Subwoofer Speaker

    LS 275e Operation Instructions A. Switch On/Off the Product 1. Before turning on the system, please connect it according to the System Connection Instruction. 2. Connect AC power for subwoofer and rear left/right speakers. (Caution: Power source must be consistent with this product.) 3.
  • Page 57 LS 275e H. 5.1 CH PLAY MODE AND REAL SURROUND SOUND EFFECT On digital and analogue input mode, you can press “5.1ch” button to switch to 5.1ch output. But the real surround sound effect is only possible to have via digital inputs (coaxial or optical).

  • Page 58: Troubleshooting

    LS 275e Trouble Shooting 1. NO OUTPUT (1). Check whether the system is connected correctly. (2). Check whether the Volume is set at minimum. Adjust it accordingly. (3). Check whether the Audio Input is in PLAY mode. (4). Check whether the volume on TV or DVD player is set property.

  • Page 59: Specifications

    LS 275e Specifications 1.Power Supply: AC 230V/50Hz 2.Total Power Consumption 200 Watt 3. Input Sensitivity (Subwoofer) 550 mV ±50 mV 4. Input Sensitivity (Satellite) 700 mV ±50 mV 5.Front Speaker Impedance 4 Ohm 6.Center Speaker Impedance 8 Ohm 7.Suboofer Speaker Impedance 4 Ohm 8.Rear Speaker Impedance 4 Ohm...
  • Page 60 There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product. All rights reserved by Blaupunkt Competence Center Audio M3 Electronic GmbH. This material may be reproduced, copied or distributed for personal use only.
