- Page 1 MODEL CD-750 PORTABLE AM/FM STEREO CD MP3 ENCODER/PLAYER USER MANUAL Please read this User Manual carefully before using the unit and retain it for future reference...
-
Page 2: Dear Jensen® Customer
The serial number of this product is found on its bottom cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: CD-750 Serial Number:... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. -
Page 4: Compliance With Fcc Regulations
supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14. This appliance shall not be exposed to dripping or splashing water and that no object filled with liquids such as vases shall be placed on the apparatus. -
Page 5: Protect Your Furniture
CAUTION Follow the advice below for safe operations. ON PROTECTION AGAINST LASER ENERGY EXPOSURE As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to disassemble the casing. Stop operation immediately if any liquid or solid object should fall into the cabinet. -
Page 6: Functions Of Controls
FUNCTIONS OF CONTROLS MAIN UNIT REAR VIEW 1617 1916 Function Selector Volume Control POWER Button FOLDER – Remote Sensor FOLDER + Tuning Control REPEAT Button USB Port 10. SD/MMC Slot 11. DISC/USB/SD Function Button 12. DC Jack 13. HEADPHONE Jack 14. -
Page 7: Remote Control Unit
LCD DISPLAY UNIT : CD disc indicator : Program play indicator USB SD REP1 ALL : Random play mode indicator REP1 : Repeat one track/ chapter indicator REP All : Repeat the entire disc : USB function indicator : (SD or MMC) card Disc play indicator Pause indicator Message or number indicators... -
Page 8: Battery Replacement
Do not dispose of batteries in fire, batteries may explode or leak. BATTERY REPLACEMENT When the battery becomes weak, the operating distance of the Remote Control is greatly reduced and you will need to replace the Lithium battery. Remove the battery compartment from bottom of the Remote Control. -
Page 9: Power Source
15-20 feet POWER SOURCE Your player is designed to operate using the included 120V~ 60Hz power adaptor or 8 'C' (UM-2) batteries (Not included). Do not attempt to operate the player from any other power source. You could cause damage to the radio and void your warranty. -
Page 10: Listening To Radio
Insert one end of the AC adaptor (Included) into the DC Jack on the back of the CD-750 and plug the AC adaptor end into a wall outlet with a 120V~ 60Hz power supply. The CD-750 will automatically disconnect the batteries and operate from the AC Power adaptor. -
Page 11: Play Mode
Note: The " " icon indicates that the function is only available when using the Remote Control Turn ON the CD-750 by pressing the POWER Button. The Power indicator will light. Set the Function Selector to the DISC/USB/SD position. The LCD display lights and “rEAd”... -
Page 12: Usb/Sd Card Operation
" once. A track/file will be selected at Random and playback starts at once.. IMPORTANT: Because there are so many different MP3 file types available, the CD-750 might not support all of the formats available due to the changing encoding methods. - Page 13 "STOP" appears in the LCD Display. If "STOP" is not pressed during the encoding process, the successive tracks will be encoded one by one. CD-750 will stop when the last CD track has been encoded. “STOP” will appear on the Display.
-
Page 14: Aux Operation
Plug one end of the connection cord (not included) into the AUX IN jack on the left hand side of CD-750. Plug the other end of the connection cord into your external player. Power on CD-750 and then the external player. -
Page 15: Line Out Operation
LINE OUT OPERATION You can connect CD-750 to an external Hi-Fi system by connecting the LINE OUT Socket (15) on the back of CD-750 to the AUX IN Socket of your Hi-Fi system with a RCA cables (Not included). Remark: The sound from the CD-750 built-in speakers will not be disabled when using the LINE OUT socket. -
Page 16: Troubleshooting Guide
TROUBLESHOOTING GUIDE If you experience difficulties in the use of this system please check the following before calling 1-800-777-5331 for Customer Service and Support. Symptom Possible Cause Solution Retune the AM or FM Station not tuned properly for broadcast station. AM or FM. -
Page 17: Specifications
SPECIFICATIONS TUNER Section FM…………………………………………………………. ……..……. 88 – 108 MHz AM………………………………………………………..……..…….535 – 1705 kHz MP3 PLAYER Section MPEG-1 Layer 3 (Mp3)………………………………………..……..MPEG AUDIO Bit Rate………………………………………………………………..……..128 kbps GENERAL Power Source AC Adaptor…………..………………………………………..…Input: 120V 60Hz Output: 12V DC Battery (Not included)…………………………………..…1.5V DC 'C' (UM-2) x 8 Speaker……………………………………………………..…3-1/2 Inch 8 Ohm x 2 Power Output……………………………………………………………1.5W + 1.5W AUX IN Sensitivity…………………………………………….……………..500 mV... - Page 18 90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A ONLY SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or factory workmanship for a period of 90 days from the date of original customer purchase and provided the product is utilized within the U.S.A. This warranty is not assignable or transferable.
