- Page 1 4902000 HWS100 Wireless Home Security System Owner’s Manual WARNING: Security system devices cannot compensate for loss of life or property. Company is not responsible for any loss or intrusion.
-
Page 3: Table Of Contents
1.4 Introduction to the HWS100 Main Panel 1.5 Introduction to the HWS100 Main Panel Sound Alert and Backlight Section 2 – Installing the Wireless Home Protection System ......4 2.1 Installing the Main Panel... -
Page 4: Section 1 - Getting Started
System is managed by a HWS100 main panel, which gathers information from wireless sensors placed inside and at the entry points of your home. If the HWS100 main panel detects a security breach, you will be alerted via indicator lights and sounds. For installation and proper use of the HWS100 main panel, please familiarise yourself with this User Guide. -
Page 5: Introduction To The Hws100 Main Panel
Remote system Controller Motion Sensor Adapter Bracket Owner’s Plugs, Manual Screws & Adhesive Door/Window Sensors 1.4 Introduction to the HWS100 Main Panel LCD Screen Keypad Function Buttons HOME ALERT Numeric Buttons Programming Buttons Other 9 volt DC input port For AC adapter... -
Page 6: Introduction To The Hws100 Main Panel Sound Alert And Backlight
Section 1 - Getting Started 1.5 Introduction to the HWS100 Main Panel Sound Alert and Backlight tiie OPERATING SITUATION SOUND ALERT & BACKLIGHT INDICATION MODE Zone triggered Alarm duration 1 minute (Siren) under ARM status Whole HWS100 Main Panel (All in RED) flashes every 1.5 seconds with triggered zone indication... -
Page 7: Section 2 - Installing The Wireless Home Protection System
Section 2 - Installing the Wireless Home Protection System 2.1 Installing the Main Panel Determine the location of the main panel. *NOTE: - The panel should be placed within a few feet of an electrical outlet. - The panel should be easily accessible. - The panel should not be placed near doors or windows that could be accessed by intruders. -
Page 8: Transmitting Emergency Signal
Section 3 - Using Your HWS100 Home Protection System 3.1 Programming Your New 4-Digit PIN STEP KEYS DESCRIPTION NOTE You must be *To make sure you are in STANDBY mode: in STANDBY - Enter the factory default PIN “1, 2, 3, 4”... -
Page 9: Operating Different Modes
PIN; three beeps indicate that an invalid operation was performed). 3.3.2 Arm Mode If in Arm Mode, the Main Panel alarm will sound and the whole HWS100 Main Panel (All in RED) flashes every 1.5 seconds when the system is triggered. ARM mode default setting:... - Page 10 Section 3 - Using Your HWS100 Home Protection System A. Arming the System: On the Main Panel: First make sure the Main Panel is in STANDBY mode by following the steps below for arming the system. On the Remote System Controller: Press to activate.
- Page 11 Section 3 - Using Your HWS100 Home Protection System B. Disarming the System: - On the Main Panel: Enter your 4-Digit PIN followed by to disarm the system. - On the Remote System Controller: Press to disarm the system .
- Page 12 Section 3 - Using Your HWS100 Home Protection System D. Triggers in ARM Mode: Example: Zone 1 trigger. STEP DESCRIPTION NOTE Under the The Main Panel will display the below image: “ARM” mode Main Panel’s alarm will sound and a Red LED and will flash when the system is triggered.
-
Page 13: Exiting The Alert Mode
Section 3 - Using Your HWS100 Home Protection System A. Entering the ALERT Mode - First make sure the Main Panel is in STANDBY mode. On the Main Panel: First make sure the Main Panel is in STANDBY mode by following the steps... - Page 14 Section 3 - Using Your HWS100 Home Protection System C. Zone Settings Programming each zone in ALERT mode: STEP KEYS DESCRIPTION NOTE (1234 / You must be *To make sure you are in STANDBY mode: 4-DIGIT PIN) in STANDBY - Enter the default default PIN “1, 2, 3, 4” OR...
-
Page 15: Exiting The Home Mode
Section 3 - Using Your HWS100 Home Protection System 3.3.4 HOME Mode There are default settings that allow the system to operate after opening the package. You can adjust the settings to suit your needs. This mode allows the system operate in both the Arm and Alert Modes in different zones. -
Page 16: Zone Settings
Section 3 - Using Your HWS100 Home Protection System C. Zone Settings Programming each zone in HOME mode: STEP KEYS DESCRIPTION NOTE (1234 / You must be *To make sure you are in STANDBY mode: 4-DIGIT PIN) in STANDBY - Enter the default default PIN “1, 2, 3, 4” OR... -
Page 17: Section 4 - Installing The Sensors
Section 4 - Installing the Sensors 4.1 Introduction to the Sensors This package includes 3 wireless Sensors and one Remote System Controller, which will have a pre- programmed default setting that begins working immediately once the battery is activated. It is advisable to install the main package first and then personalize the settings once the System is functioning properly. -
Page 18: Installing The Sensors
Section 4 - Installing the Sensors C. Mounting with the Double-Sided Adhesive - Ensure the mounting surface is clean. - Peel back one layer of the protective film and attach it to the transmitter. - Peel back the remaining layer of protective film and press the transmitter firmly in place against the mounting surface until firmly attached. -
Page 19: Walk Test
Section 4 - Installing the Sensors D. Walk Test After mounting the sensor at the desired location, it is important to perform a walk test to determine if the sensor is detecting the correct area. In order to control how far the sensor can detect motion, you can adjust the angle of the sensor. -
Page 20: House Security Code And Zone Code Settings
Section 4 - Installing the Sensors ALERT – Press the “ALERT” button on the remote, the system will enter into ALERT mode and the chime will sound. The green backlight will flash and indicating a triggered zone. HOME – Press the “HOME” button on the remote, the system will enter into HOME mode which will operate both the ARM and ALERT modes in different preset zones. -
Page 21: Section 5 - Troubleshooting
Section 5 - Troubleshooting 5.1 FAQ Q1: What is the best way to set up my system? Where should I put my HWS100 Wireless Panel and the sensors? A1: We recommend that you take some time in advance to think about the placement of the Main Panel and Sensors. - Page 22 Section 5 - Troubleshooting Q9: Why does my Motion Sensor keep generating false alarms? A9: If you have a pet, make sure they have not triggered the system. Remember, sensitivity to pets increases in certain circumstances e.g. the nearer the pet to the Sensor. TROUBLESHOOTING AC Power Failure: This may occur if your security system is accidentally unplugged or if there has been an AC...
-
Page 23: Section 6 - General Information
- A receiver can only respond to one transmitted signal at a time. - Wireless equipment should be tested regularly to determine whether there are sources of interference and to protect against faults. 6.2 Specifications 6.2.1 HWS100 Main Panel Power source: AC adapter Back up power:... -
Page 24: Maintenance
6.5 Optional Devices Available to add to your System HWS100 Wireless Auto-Dialer 4902013 HWS100 Wireless Door/Window Sensor 4902008 HWS100 Wireless Motion Sensor 4902009 HWS100 Wireless Garage Door Sensor 4902001 HWS100 Wireless Flood Sensor 4902002 HWS100 Wireless System Controller 4902004 HWS100 Wireless Inactivity Sensor 4902012 6.6 Warranty...
