Page 15: Preface
1. Preface Chapter 1 is an introduction to the NV5100MC Master Control Reference Manual. It presents the following topics: • Chapter Structure • The PDF Document • Terms, Conventions and Abbreviations • Document Usage Chapter Structure This guide provides an architectural and functional description of the NV5100MC master control system.
Page 16: The Pdf Document
• Entries written in a monospaced font denote pathnames, parts of your file system, or items that you must select or enter, within the scope of Windows XP: C:\Program Files\Miranda\Master Control\... • The term “MC” is an abbreviation for “master control.”...
Page 17: Document Usage
Intuition XG processor. • Xbuilder and Xstudio are creative software applications under XMedia. • Oxtel is a division of Miranda. Its name is used to identify certain parts of the Intuition XG hardware. A reason for this is probably unobtainable.
Page 18 • If your master control system is to support Intuition XG functions, administrators should obtain and distribute all Intuition XG documentation and related documents from Miranda. The terms used here (MCPM, SCP, etc.) will become clearer if you read the introduction to this ref- erence manual (or the Glossary).
Page 19: Introduction
2. Introduction Chapter 2 is an introduction to the NV5100MC master control system. It presents the following topics: • Overview • Aspects of the System Overview Miranda’s master control systems have many modular parts and provides many options. You can order a master control system that is optimal for your facility.
Page 20 • Video and audio inputs. Miranda’s master control frames have slots for input cards of different formats: AES audio, analog audio, analog video, SD video, and HD video. The formats can be used together. These are the inputs that the MCPM switches and mixes. An MCPM (or MCE) can also obtain inputs...
Page 21: Aspects Of The System
The input cards allowed in an MC system include AES audio (synchronous), analog audio, analog video, SD video, and HD video. An MFR supports input cards of those formats and also supports time-code and machine control formats. The MFR typically requires one or more output cards. NV5100MC Master Control • Reference Manual...
Page 22: Nv9000 Router Control System
2. Introduction Aspects of the System The design of your system must take into consideration how the master control and MFR compo- nents (if present) fit together mechanically and architecturally. NV9000 Router Control System An MC (master control) system can be viewed as a part of an NV9000 system. Alternatively, the NV9000 can be regarded as a provider of inputs to the MC system.
Page 23: Operational Features
NV5100MC-FECP “Full-size” enhanced control panel. A console similar in size and function to the FFCP, but with features that support Miranda’s “next generation” of master control. The FECP sits on a desktop or work surface. In most cases, a panel’s function buttons have dynamic legends and change color and brightness as required to indicate the function state.
Page 24 2. Introduction Aspects of the System Basic transition types include cut, V-fade (or fade-fade), cut-fade, cross-fade, and fade-cut. (Other types exist. See Manual Transition Behavior on page 63.) Audio transitions are of the same type and rate as the video transitions. Video effects include keyer 1, logo A, squeezeback, keyer 2, keyer 3, and logo B and are performed in that order (although some MCPMs do not support all effects and some control...
Page 25: Intuition Xg
M CE. Obtaining input from multiple MCEs requires a router or a multiplexer. Intuition XG Miranda’s Intuition XG graphics processor and its associated Xmedia software can be integrated with the master control system. The Intuition XG subsystem includes a graphics processor that stores, and plays out, video keys.
Page 26: Mcpms
2. Introduction Aspects of the System MCPMs MCPMs (master control processing module) are the devices that perform master control switching and mixing. There are several types of MCPMs: MCPM-SD 2-slot modules that process standard definition (SD) video. Provides 3 keyers, 2 logos, 1 squeezeback layer, 4 AES outputs, and 8 analog audio outputs in addition to program output.
Page 27: Ancillary Hardware
Tally Processor Miranda offers a third-party “tally processor”— a 1RU device that provides 32 optically isolated inputs and 32 relay outputs, also optically isolated. Through Miranda’s NVISION Ethernet protocol (NVEP), the tally processor can sense master control events such as main source selections and transitions and trigger master control events.
Page 28: Device Controller
Aspects of the System Device Controller Miranda offers a third-party “device controller”— a 1RU device that can control 4 VTRs or other devices using a serial protocol (Sony, Odetics, or VDCP) and up to 16 devices using start and stop pulses.
Page 29: Frames
UniConfig takes only a short time if you know what to do. Deciding how your router(s) will work with master control is a bigger task. Contact Miranda (or visit www.miranda.com) if you wish to receive an application note (AN0004) that presents a case study.
Page 30: Control Cards
Redundant control cards are not supported by all third-party router control protocols. Please contact Miranda if you have questions about this. The EM0374 control card can process control information from an external router control system such as the NV9000.
Page 31: Inputs And Outputs
• Two (EM0374) router control cards. Note the two “wing” slots of the MCPM-HD. The wing slots accept optional SWB router out- put cards. NV5100MC frames allow the use of multiple independent SWB input and output cards. NV5100MC Master Control • Reference Manual...
Page 32: System Alarms
3. Frames Overview Figure 3-2 shows a rear view of the NV5128-MC frame. The organization of I/Os and MCPMs matches the organization of the frame shown in Figure 3-1. Secondary Backplanes Control Output 65 –128 Input 128 –1 Output 64 –1 Primary Control AES Ref.
Page 33: Numbering
G = (16 – slot) × 16 + 64 + C where slot = 13–16 Inverse Numbering Given G (1–128), any connector C (1–16) is C = [(G – 1) mod 16] + 1 NV5100MC Master Control • Reference Manual...
Page 34: Signal Formats
3. Frames Overview Signal Formats Master control signal formats can be a mix of AES audio, analog audio, analog video, SD video, and HD video. The MFR can route time-code signals and machine-control signals. The master con- trol (MC) system does not accept signals of these types at the motherboard. I/O cards can be mixed in many combinations.
Page 35: Local Vs. Router Input
Many of the connectors are used when a router is present in the frame and are not necessarily useful for master control. Control Ports At the top left portion of the rear of the frame are 6 serial connectors, and further below that are 2 Ethernet connectors: NV5100MC Master Control • Reference Manual...
Page 36: Serial Control
3. Frames Connectors Serial Control The CTRL1 and CTRL2 ports are DE9, RS-422. for Primary for Secondary Control Card Control Card CTRL 1 CTRL 2 Diagnostic You can use these connectors for control using a serial protocol from (1) a primary or secondary NV9000 router control system, (2) a primary or secondary third-party router control system, or (3) a router automation system.
Page 37: Ethernet Control
There are two pairs of connectors for AES reference — one for the primary control card and one for the secondary control card. Each control card can use either: • BNC (75-ohm). • A 3-pin Phoenix connector for STP connections. NV5100MC Master Control • Reference Manual...
Page 38: Aux Bus
At software release 6.1.0, MCEs derive AES reference from their video reference. Aux Bus At the middle left portion of the rear of the frame are 2 ‘Miranda Aux Bus’ (BNC) connectors:. Aux Connectors (BNC, 50Ω ) If you are using an SMS7000 router control system with the master control system, connect the SMS7000 to the Miranda aux bus connector.
Page 39: Video Reference
If either reference fails, it will be replaced with the internally generated signal and any outputs using the failed reference will switch asynchronously. Each of these modes requires that configuration settings be made using UniConfig software. This mode allows the use of SD and HD video with video reference. NV5100MC Master Control • Reference Manual...
Page 40: Time Code Ref
3. Frames Connectors Time Code Ref At the lower left portion of the rear of the frame are 2 connectors for time-code reference. BNC Connector Phoenix Connector Master control does not use time-code reference. You can ignore these connectors unless there is a router in the frame that includes time-code I/O.
Page 41: Power Supply Alarms
At the lower right portion of the rear of the frame is a Phoenix 3-pin connector for power supply alarms: The frame has alarm outputs for each power supply installed in the frame. An internal solid-state relay is provided for each supply. The relay turns on when there is an alarm condition. NV5100MC Master Control • Reference Manual...
Page 42: Power
3. Frames Connectors Figure 3-7 shows suggested alarm circuit implementations. You can use signalling devices other than LEDs or in addition to LEDs. For example, you can operate a buzzer or other audible alarm to warn operators of a potential problem. Figure 3 -7.
Page 43: Power Supply
At the lower left portion of the rear of the frame is a ground lug: Ground Lug Connect this “lug” to earth ground using 8–14 AWG wire. 4. Older master control frames in the field might still use PS6000 power s upplies. NV5100MC Master Control • Reference Manual...
Page 44: Input (And Output) Cards
3. Frames Input (and Output) Cards Input (and Output) Cards Each input (and output) module employs one or more DC-DC converters to convert the +48VDC on the backplane into the appropriate regulated supply voltage(s).The combination of pre-regula- tors and DC-DC converters and supply voltages varies from module type to module type, depend- ing on the requirements of the associated circuitry.
Page 45: Cases
LOOP AUX BUS THRU VIDEO VIDEO REF 1 REF 2 LOOP THRU ALARMS TIMECODE INPUTS 113-128 97-112 81-96 65-80 49-64 33-48 17-32 1-16 8 SD Input Cards MCPM-SD The frame must be an NV5128-MC. NV5100MC Master Control • Reference Manual...
Page 46: Output Backplane
3. Frames Input (and Output) Cards Case 2: An MCPM-HD with 64 HD inputs, an MCPM-SD with 32 inputs, and 32 audio inputs. The frame may be an NV5128-MC or an NV5100MC. PRI CTRL SEC CTRL CTRL 1 CTRL 1 CTRL 2 CTRL 2 DIAG...
Page 47: Analog Audio
The module can accommodate nearly synchronous input signals by either deleting or repeating samples to bring the signal into synchronization. Bal- anced drivers feed the signal to the internal motherboard. NV5100MC Master Control • Reference Manual...
Page 48: Synchronous Aes Input Backplanes
3. Frames Input (and Output) Cards Figure 3-9 shows the synchronous AES signal path: Retime & Sync AES In Format Data Backpla ne Motherboard Figure 3 -9. Synchronous AES Signal Flow Synchronous AES Input Backplanes The IO5000-AES-IN-TP backplane module has 16 Phoenix connectors for balanced signals. The IO5000-AES-IN-BNC backplane module has 16 BNC (75Ω) connectors for unbalanced signals.
Page 49: Sd Video Input Backplane
The NV5000-HD-OUT is a special card that plugs into a wing slot of an MCPM-HD, -HD2, or -SDHD. The NV5000-HD-OUT also fits in the wing slots of an output mod- NV5000-HD-XPT/OUT ule (when an MFR is present). NV5100MC Master Control • Reference Manual...
Page 50: New Swb Output Module
3. Frames Input (and Output) Cards In either case — master control or MFR — the output card is part of the MFR crosspoint matrix. When an MFR is present, it can use the SWB output card for routing HD, SD, and asynchro- nous AES signals.
Page 51: Other Modules
EM0374 Jumpers on page 176 for more information. EM0414 The EM0414 is an AES clock generator card. It does not support any router control functions. EM0414 Jumpers on page 177 for more information. NV5100MC Master Control • Reference Manual...
Page 52: Power Supply
3. Frames Other Modules Power Supply The PS6100 power supply module accepts a wide range of AC input voltages and produces five outputs, each +48 VDC. Each of the five circuits producing the 48 V outputs is identical. The power supply automatically senses the AC input voltage (90–130 or 180–250VAC) and adjusts itself to maintain a relatively constant DC output;...
Page 53 Figure 3 -12. Fuse Location, PS6000 or PS6100 Power Supply Replacing the fuse without determining what caused it to fail could cause equipment damage or fire by restoring power to an already damaged unit. NV5100MC Master Control • Reference Manual...
Page 54 3. Frames Other Modules Rev 2.10 • 17 Feb 11...
Page 55: Mcpms
(Not all transitions involve mixing.) At the end of the transition, what was on preset is now on program. The MCPM also has options to swap the preset and program settings and to clear effects from preset after the transition. NV5100MC Master Control • Reference Manual...
Page 56: Video Effects And Audio Overs
4. MCPMs Overview The MCPM applies video effects and audio overs in the left-to-right sequence shown in Figure 4-1. What is on the right is considered downstream and what is on the left is considered upstream. Downstream effects modify any upstream effects. For instance, a squeeze effect affects logo A, because logo A is upstream of the squeeze function, but does not affect logo B, which is down- stream.
Page 57: Transition Types
A hot cut should be considered an emergency measure — to correct an error quickly — because it can have noticeable artifacts that would be absent in a normal transition. NV5100MC Master Control • Reference Manual...
Page 58: Mcpm Types
4. MCPMs Overview MCPM Types There are 7 MCPM types: • MCPM-SD • MCPM-HD, MCPM-HD2 • MCPM-SDHD • MCPM-MK-SD (“Mixer/Keyer”) • MCPM-MK-HD (“Mixer/Keyer”) • MCE All MCPMs have common characteristics, such as audio meter outputs, GPIO, clean-feed outputs, and emergency bypass capability, but also have many differences. Refer to Table B-19 in Appendix B for a comparison.
Page 59: Mcpm-Sd
The MCPM-SD has 8 analog audio outputs in addition to audio meter and monitor outputs. The MCPM-SD has Ethernet (control) and RS-422 (automation) connections. (An additional 10BaseT port is unused.) The aux connector has time-code inputs and Dolby metadata outputs in addition to GPI and relay contacts. NV5100MC Master Control • Reference Manual...
Page 60: Mcpm-Hd, -Hd2
4. MCPMs Overview MCPM-HD, -HD2 The MCPM-HD and -HD2 are 4-slot modules. Each of these processes high definition (HD) video. The MCPM-HD2 is an improved version of the -HD. NV5000-XP-HD PGM OUT PGM OUT 1/2 AES Audio BYPASS IN BYPASS IN 1/2 Video Connections Cons ole Port...
Page 61: Output Card
MasterConfig’s ‘Wing Output’ page erroneously includes two aux bus options for wing out- puts. The MCPM-HD2 has no aux bus. These options do nothing. 2. The main video output is unproces sed original video. It does not contain video effects applied by the MCPM . NV5100MC Master Control • Reference Manual...
Page 62: Mcpm-Sdhd
4. MCPMs Overview MCPM-SDHD The MCPM-SDHD is a 3-slot module. It processes either HD or SD video, as a field-programma- ble option. It provides all the features of an SD or HD process and these two extensions: • It has an internal black/silence generator for use as a program or preset main source, or as a squeeze background.
Page 63 3. The main video output is unproces sed original video. It does not contain video effects applied by the MCPM . 4. Similarly, the main audio output is unprocessed original audio. It does not contain audio changes applied by the MCPM. NV5100MC Master Control • Reference Manual...
Page 64: Mcpm-Mk-Sd
4. MCPMs Overview MCPM-MK-SD The MCPM-MK-SD is a 1-slot module. MCPM-MK-SDs are also named “mixer/keyers” or “branding engines.” The MCPM-MK-SD processes standard definition (SD) video. The MCPM- MK-SD is a lower-cost and smaller alternative to the MCPM-SD, but has a reduced feature set: •...
Page 65 The MCPM-MK-SD has Ethernet (control) and RS-422 (automation) connections. The aux con- nector has time-code inputs in addition to GPI and relay contacts. Because the MCPM-MK-SD does not have a Dolby E decoder, the aux connector does not have Dolby metadata outputs. NV5100MC Master Control • Reference Manual...
Page 66: Mcpm-Mk-Hd
4. MCPMs Overview MCPM-MK-HD The MCPM-MK-HD is a 2-slot module. MCPM-MK-HDs are also named “mixer/keyers” or “branding engines.” The MCPM-MK-HD processes high-definition (HD) video. The MCPM-MK- HD is a lower-cost and smaller alternative to the MCPM-HD, but has a reduced feature set: •...
Page 67: Mcpm Architecture
(at a control panel or by automa- tion). Any of the 3 keyers can accept input from one of 8 keyer sources. Logos are stored in memory. Any logo effect can use any of 64 logo images. NV5100MC Master Control • Reference Manual...
Page 68 4. MCPMs MCPM Architecture The squeezeback layer can accept input from any of 32 background sources. (Basic and enhanced squeezeback differ slightly.) Preset Audio Disembedder 8 Audio Channels Preset — non-sync bypass path Preset Preset Source Vanc Audio Monitor Out Logo Logo .Ins.
Page 69: Video Summary
Figure 4-9. Discrete audio inputs are “stereo” inputs. The MCPM treats the separate stereo channels as distinct. During MCPM configuration, you can select any of up to 256 single, a.k.a. “mono,” channels at any time. NV5100MC Master Control • Reference Manual...
Page 70: Audio
4. MCPMs MCPM Architecture An MCPM has 8 internal audio channels for program and 8 internal audio channels for preset. Any or all of these can be associated with the main video source. You can combine different audio types on these channels as you wish. The MCPM accepts 8 discrete audio over inputs for preset and 8 discrete audio over inputs for pro- gram.
Page 71: The Over/Main Mixing Ratio
During configuration you can distribute buses A and B on the monitor outputs in 4 ways. (If you reverse A and B, you get an additional 4 ways.) Monitor A might, for example, play program audio and monitor B might play preset audio. NV5100MC Master Control • Reference Manual...
Page 72: Audio Summary
4. MCPMs MCPM Architecture Monitor and meter outputs can be configured as fixed or dynamic. (When a monitor or meter output is configured as “user can modify,” the operator may choose “Program,” “Preset,” “Aux,” or “Off Air” buttons on the control panel. In any event, the distribution of audio across monitors A and B on the monitor outputs does not change during operation.
Page 73: Transition Modes
1 In flip-flop mode, whatever was on the program bus — main source, effects, and overs — appears the preset bus immediately after the transition. 2 In normal mode, whatever was on the preset bus remains on the preset bus. NV5100MC Master Control • Reference Manual...
Page 74 4. MCPMs MCPM Architecture 3 An effect in “clear preset” mode is removed from the preset bus immediately after a transition (unless it was on program before the transition). While the MCPM is performing a transition, it does not allow changes to: 1 The preset bus.
Page 75: Transition Types
Normal Mode Flip-Flop Mode Program Legend: Video Preset Program Audio Preset Video effects turn on or off instantly. Audio overs switch quickly (6 frames). The small circle(s) indicates where the MCPM stops using source A. NV5100MC Master Control • Reference Manual...
Page 76 4. MCPMs MCPM Architecture 2 V-Fade (or fade-fade) Program video mixes to matte (in the first half of the transition period) and then mixes from matte to the new source. Audio fades to silence (in the first half of the transition period) and then fades from silence to the new source.
Page 77: Manual Transition Behavior
(This cannot occur, in a preset black transition, after the lever reaches the midpoint.) 2 If the operator cancels a manual transition before moving the lever, the MCPM exits manual transition mode and makes no changes to the program bus. NV5100MC Master Control • Reference Manual...
Page 78 4. MCPMs MCPM Architecture 3 If the operator cancels a manual transition while the transition is in progress, the MCPM exe- cutes a “cut” to the end of the transition and exits manual transition mode. 4 If the operator (or automation) requests a non-manual transition before the lever is moved, the MCPM exits manual transition mode and performs the requested non-manual transition.
Page 79: Transitions Involving The Video Mixer
(key and fill) comes from discrete video sources and a logo is graphic, static or ani- mated, stored in memory. The MCPM configuration software provides a few keyer parameters that apply to both logos and video keyers: • Opacity. • Video clip. NV5100MC Master Control • Reference Manual...
Page 80 4. MCPMs MCPM Architecture • Video gain. These parameters apply only to video keyers: • Self-key enable. • S-Shape enable. • Luma filter bypass. • Chroma filter bypass. • Additive key mix. Video Clip and Video Gain Key clip and key gain are parameters of a transform applied to the incoming key signal. The con- figurer may set the key clip parameter from 0 to 100%.
Page 81 A key value of 1.0 means that the corresponding point is fully opaque. Any value in between 0 and 1 means that the corresponding fill point is partially opaque (when it mixes with upstream video). NV5100MC Master Control • Reference Manual...
Page 82: Transitions Involving Squeeze
4. MCPMs MCPM Architecture For MCEs, gain ranges from 0 to 63 15/16, in discrete multiples of 1/16. In MasterConfig, keyer gain is expressed as an integer in the range [0,1023]. Unity gain is given as a value of 16; a value of 32 represents a gain of 2.0.
Page 83: Ftb Transitions
FTB stands for “fade to black/silence.” The fade actually transitions to the defined matte color, which is not necessarily black. Audio also fades to silence. The FTB transition rate is independent of the preset/program transition rate. NV5100MC Master Control • Reference Manual...
Page 84: Ancillary Data And Switch Point
4. MCPMs Other General Features There are 4 FTB transition types. These are similar to, but not quite the same as, the basic transition types for effects: 1 Fade from synchronous source — the program output mixes with matte: Output = matte × T + program × (1 –T) as T progresses from 0 to 1. 2 Fade from matte to synchronous source —...
Page 85: Bypass At System Startup
• Level control of the emergency bypass relay. While the GPI input is on, the MCPM sets the EBR to “bypass.” While the GPI input is off, the MCPM sets the EBR to “normal.” NV5100MC Master Control • Reference Manual...
Page 86: Router Pre-Select
4. MCPMs Other General Features • Set the EBR to “bypass.” This behavior is used in conjunction with the emergency bypass control panel (EBCP). • Set the EBR to “normal.” This behavior is used in conjunction with the emergency bypass control panel (EBCP). •...
Page 87: Compared To Router Preselect
— determined dynamically— can be available to the mas- ter control operator. 5. It is possible, but unlikely, for any local main or over source to cons ume 8 local audio ports. NV5100MC Master Control • Reference Manual...
Page 88: Main Source Connections
4. MCPMs Other General Features Main Source Connections External main sources (that are not chosen during operation as squeeze sources) reach the frame through two ports, designated A and B. The designations are not important and serve only to distin- guish one port from the other.
Page 89: Squeezeback Source Connections
Use MasterUIConfig to assign a GPI output to a configurable panel button. (The button is a tog- gle. Pressing the button once activates the MPCM’s GPI relay. Pressing it again relaxes the relay.) 3 Video Effect Status. NV5100MC Master Control • Reference Manual...
Page 90: Breakaway
You will use MasterDiag software to set the IP addresses of the MCPMs in your network. RS-422 Automation Contact Miranda for the master control serial protocol and how to use an automation system with master control. Rev 2.10 • 17 Feb 11...
Page 91: Router Output Cards
The MCPMs have little or nothing to do with the router output except to supply the crosspoints and connectors. However, the -HD2 and -SDHD both allow limited control over the outputs. See MCPM-HD, -HD2 , page 46, and MCPM-SDHD, page 48, for more information. NV5100MC Master Control • Reference Manual...
Page 92 4. MCPMs Other General Features Rev 2.10 • 17 Feb 11...
Page 93: Mces
• Program, preset, preview, and aux processing paths (i.e., buses). • All transition types, normal and preset black. • Three k eyer effects, 2 logo effects, squeezeback and enhanced squeezeback. (The effects occur in fixed order.) NV5100MC Master Control • Reference Manual...
Page 94: Structure
5. MCEs Structure • Four Intuition XG keyer layers, with support for Xstudio programming. • 16 independent audio channels (the maximum). 24-bit audio processing internally, with values reduced to 20-bit at output. • Program/preset mixer and main/over mixer. Gain control and inversion. •...
Page 95: Differences
Decoders C and D support program and preset over audio and, in particular, audio for enhanced squeezeback’s image 2. Decoders E supports preview main audio . Decoders F supports preview over audio, including audio for enhanced squeezeback’s image 2. Decoders G and H are not needed. NV5100MC Master Control • Reference Manual...
Page 96 5. MCEs Structure • Dual Dolby decoders supporting overs on the program and preset buses. (Refer to Figure 5-2.) Decoders A, B, C, and D support program and preset main audio. Decoders E, F, G, and H support program and preset over audio. •...
Page 97 Off Air Inputs Preview (16) (16) Preview Dolby E Main Preview Dolby E Processing Embedder Preview Video Out and Mixing Preview Over Figure 5 -3. Audio Processing Section (Program, Preset, and Preview Main Sources) NV5100MC Master Control • Reference Manual...
Page 98: Channel Processing
5. MCEs Structure In addition, the MCE accepts up to 16 “auxiliary” inputs and 16 “off air” inputs. These are discrete inputs only. Although these names perhaps suggest a use for the inputs, the aux and off-air inputs are simply two extra sets of inputs. However, the aux and off-air inputs are not processed or mixed with program audio, but feed directly to the audio meter and monitor outputs.
Page 99: The Over/Main Mixing Ratio
Monitor and meter outputs can be configured as fixed or dynamic. When a monitor or meter output is configured as “user can modify,” the operator may press “Program,” “Preset,” “Aux,” “Off Air,” or “Preview” buttons on the control panel. NV5100MC Master Control • Reference Manual...
Page 100: Audio Summary
5. MCEs Structure Each monitor — A and B — has independent gain and a “dim” function. When an operator presses the monitor’s “dim” button at a control panel, the monitor level decreases (by as much as 108 dB). The default attenuation is 20 dB. It is possible to include program or preview output instead as ‘black’...
Page 101: Aux Bus
Under breakaway, the aux audio output still comes from the video source. • Program Audio The aux output (A or B, whichever one you choose) carries the video and audio of the main source(s) chosen on the control panel’s program bus. NV5100MC Master Control • Reference Manual...
Page 102: Aux Button Row
5. MCEs Structure Under breakaway, the aux audio output comes from the audio source. This option does not appear unless you have checked ‘Enable Main Disembedders’ in the general settings of MasterConfig. • Preset Audio The aux output (A or B, whichever one you choose) carries the video and audio of the main source(s) chosen on the control panel’s preset bus.
Page 103: Intuition Xg
Structure Intuition XG Miranda’s Intuition XG graphics processor and its associated Xmedia software can be integrated with the master control system. The Intuition XG subsystem includes a graphics processor that stores, and plays out, video keys. It can access “live” data including feeds from wire services and databases.
Page 104 5. MCEs Structure DVEs are optional. The two labeled “C” and “D” are required for squeezeback. A third (“B”) is required for dual (enhanced) squeezeback. The fourth (“A”) is for future expansion. The audio processor (not shown above) operates at 48 kHz (48,000 samples per second). It receives audio from backplane inputs 65–128.
Page 105: Preview Card
The preview board is optional. The board implements the preview bus, to which a panel’s preview buttons correspond. The preview bus allows operators to examine video sources independently, applying video effects and audio overs at will, without affecting program content or interfering with automation. NV5100MC Master Control • Reference Manual...
Page 106 5. MCEs Structure The preview board contains a 1-channel video processor and up to 4 DVEs. It receives all its sig- nals from the core. Video Inter-card proces sor connectors (4) “D” “A” “B” “C” Alignment holes (2) DVE cards (4) Alignment blocks (underside, 2) DVEs are optional.
Page 107 The output is video only. Although an operator can apply audio overs, they would have no effect. Only the CECP, CECP GUI, and FECP have preview buttons. (The CECP M1 does not.) Preview bus B is not yet operational. Presently, preview output B simply replicates output A. NV5100MC Master Control • Reference Manual...
Page 108: Audio Expansion Module
5. MCEs Structure Audio Expansion Module The audio expansion module is optional. This illustration shows the AXM board and the location of the Dolby E cards on the board: Dolby E module (1 of 8) Alignment blocks (underside, 2) “B” “C”...
Page 109 The AXM backplane presents Dolby metadata and AES outputs: MCE AXM Metadata outputs 1–8 META DATA AES output channels 1 –8 AES output channels 9 –16 9-16 AES output channels 1 7–24 17-24 AXM Connectors on page 186. NV5100MC Master Control • Reference Manual...
Page 110: Dve
6 A 2-board assembly requires four 2-board (T-shaped) connectors. A 3-board assembly requires three 3-board connectors and one 2-board connector. There are detailed assembly instructions that customers may obtain from Miranda customer ser- vice. Customers should not ordinarily assemble MCEs.
Page 111: Summary
There are no AES connectors except on the AXM board and those are DB25s. Its diagnostic port (at the front of the core module) includes the top 3 pins of a Phoenix 6-pin con- nector. NV5100MC Master Control • Reference Manual...
Page 112 5. MCEs Summary Rev 2.10 • 17 Feb 11...
Page 113: Control Panels
CECP • Aux/Preview GUI Overview Presently, Miranda master control systems include these panel types: • FFCP — Full-Function Control Panel. • PC GUI — (Old) software control panel. • CFCP — Compact Full-function Control Panel. • SCP — Simple Control Panel.
Page 114: Features For The Panel
6. Control Panels Overview All control panels have GPI input and output functions. Hardware control panels have 2 hardware inputs and 2 hardware outputs; software control panels (GUIs) of course do not. All control panels, including the GUIs, can read the two GPI inputs from the MCPM or MCE and control the two GPI outputs in the MCPM or MCE.
Page 115: Features For Mces Only
See Transition Lever Arm on page 148. The FFCP is designed so that you can place it in a recess in the surface of an operator’s console. Cutouts on page 190 for dimensions. NV5100MC Master Control • Reference Manual...
Page 116: Pc Gui
6. Control Panels Overview PC GUI This older software control panel executes on a PC (and can run remotely). The user interface emu- lates the hardware of the FFCP, but there are a few slight differences. The GUI can be used with a touchscreen PC allowing operators to press buttons directly with their fingers.
Page 117: Cecp
Like the FFCP, it has 16 button pairs for main sources, 6 video effect buttons, and 2 audio over but- tons, 24 pairs in all. All buttons have color-coded LCD legends. NV5100MC Master Control • Reference Manual...
Page 118: Cecp Gui
6. Control Panels Overview The FECP’s touchscreen is large and has 8 menu knobs. The CECP has a joystick for fine visual control over certain video effects and for scrolling. The menu has a “live audio levels” display. The FECP supports the MCE’s preview and aux buses, and provides control over enhanced squee- zeback parameters such as border width and color, and dual-image squeezeback.
Page 119: Standard Control Panel Features
Refer to the NV9000-SE Utilities User’s Guide for instructions on programming system salvos. You can also execute salvos that are assigned to buttons. 2. A third-party device, servicing 32 optically isolated inputs and 32 (optically isolated) solid-state relay outputs. NV5100MC Master Control • Reference Manual...
Page 120 6. Control Panels Overview • Independent keyers. A control panel controls 3 independent linear keyers. A keyer is a video overlay with discrete key and fill inputs, and separate controls for “clip,” gain, and opacity. (The keyers and their parameters are functions of the MCPM.) The panel can select up to 8 keyer “settings.”...
Page 121: New Control Panel Features
• Router pre-select. One of the most important features of Miranda master control is its ability to perform takes in a upstream router, redirecting any of hundreds (or even thousands) of router source to a master control input where it can be switched to program output.
Page 122: Ffcp
The generation of, and management of, key sources in the Intuition XG subsystem is a big sub- ject. Please refer to Miranda’s Intuition XG documentation. • Live level display (integrated visual audio monitor). The CECP GUI does not support this.
Page 123: Ffcp Buttons
Pressing a deselected toggle button will cause it to become selected. Pressing a selected toggle but- ton will make it deselected. NV5100MC Master Control • Reference Manual...
Page 124: Ffcp Knobs
6. Control Panels FFCP Some groups of buttons operate as a mutually exclusive set. Pressing a deselected button will cause it to become selected and all other buttons in the set to become deselected. There are two types of mutually exclusive buttons: 1 Pressing a selected button makes it deselected.
Page 125: Ffcp Connectors
Minor Alarm unused Major Alarm GPI Out 2 unused GPI In 2 – Refer to the GPI section in the appropriate control panel user’s guide for connection information. GPI/Alarms on page 188 for more information. NV5100MC Master Control • Reference Manual...
Page 126: Cp Aux' Connector
6. Control Panels PC GUI ‘CP Aux’ Connector The FFCP has a DB15 connector to which you connect the optional TLA. See Transition Lever on page 148. Ground Lug Connect the ground lug, using 8–14 AWG copper wire to earth ground. (This is a safety measure and is not required for the control panel to operate.) PC GUI The old GUI (a.k.a.
Page 127: Gui Buttons
If an MCPM configuration permits, the operator may not only select keyer settings, but modify them. The GUI’s “Transition” button is large and at the lower right. NV5100MC Master Control • Reference Manual...
Page 128: Absence Of Knobs
6. Control Panels PC GUI The PC GUI does not have an aux button row or a preview button row. Absence of Knobs The GUI has no knobs. Values in the menu are either set or selected using the up/down arrow but- tons next to the menu.
Page 129: Cfcp
The bank selection button itself turns green or amber depending on which bank is selected. The CFCP has 2 monitor knobs, but no monitor/meter buttons. (Monitor/meter functions can be found in the touchscreen menu or the customer-programmable buttons.) The CFCP has 1 system button; it is configurable. NV5100MC Master Control • Reference Manual...
Page 130: Cfcp Buttons
6. Control Panels CFCP The surface of the CFCP is charcoal gray and black, matte, as it is for the FFCP. At the rear of the panel are 2 power connections, 2 Ethernet ports, a ‘CP Aux’ connector (DB15) used for the optional TLA, and a GPI/alarm connector (DB25). Power Connectors Aux Connector (for TLA) Ground Lug...
Page 131: Functional Sections Of The Cfcp
Up to 6 buttons are for video effects: 3 keyers, 2 logos, and a squeezeback function. The panel can have up to 2 audio “over” buttons. Some MCPMs do not support all video effects. 6 Breakaway buttons. Two buttons at the left allow operators to perform video breakaway or audio breakaway. NV5100MC Master Control • Reference Manual...
Page 132: Cfcp Connectors
6. Control Panels CFCP 7 Transition buttons The transition buttons include 2 groups: transition type, transition rate, and a larger orange but- ton that initiates transitions. There are 5 transition types: cut, V-fade, cross-fade, cut-fade, and fade-cut. There are 3 transition rates: slow, medium, and fast. (The actual rates are configured in the current MCPM.) 8 System button.
Page 133: Ground Lug
Figure 6 -6. SCP (front view) At the rear of the panel are 2 power connections, an Ethernet port, a fan, and a GPI/alarm connec- tor. Power Connectors Ethernet Connector GPI/Alarms Connector Figure 6 -7. SCP (rear view) NV5100MC Master Control • Reference Manual...
Page 134: Scp Buttons
6. Control Panels SCP Buttons Buttons appear in several colors and 3 brightness levels: off, low-tally, and high-tally. Buttons allow you to choose sources, video effects, audio overs, and to make menu selections. Some buttons display status. Nothing happens when you push a button that is disabled or off and nothing happens when you push a button that only displays status.
Page 135 (Menu functions exist for MCPM or MCE meter outputs, but there are no meter knobs.) 6 Transition button The transition button displays the transition type (as a graphic) and the transition rate (in text). ‘Cut’ transitions involve no rate and therefore display no rate text. NV5100MC Master Control • Reference Manual...
Page 136: Scp Connectors
6. Control Panels The button is bright orange for non-pre-roll transitions. It is low-tally red and the word “Pre- roll” appears on the button when a pre-roll transition is pending. Pressing the transition button initiates a transition in the MCPM or MCE currently controlled by the SCP.
Page 137: Cecp
The rightmost aux buttons not committed to main sources can be “aux delegates” — buttons that select the function of the aux but- ton row. NV5100MC Master Control • Reference Manual...
Page 138: Cecp M1
6. Control Panels CECP With a “bank select” button in the customer-programmable button section, the operator can switch between two banks of main sources. The button mnemonics change when the sources are switched. The bank selection button itself turns green or amber depending on which bank is selected. The CECP has 2 monitor level knobs.
Page 139: Cecp Knobs
B) and a bus for audio metering. The panel has a monitor level knob for each of the monitor buses. An operator must use the menus to choose which source to monitor or meter: program audio, preset audio, preview audio (when it becomes available), aux audio, or “off-air” audio. A NV5100MC Master Control • Reference Manual...
Page 140 6. Control Panels CECP “Dim” function for monitor A and for monitor B can be configured as customer-programmable buttons. 5 Program audio control The program audio section includes 2 rotary knobs for adjusting (1) the output level of the source selected on program and (2) the over/main ratio for the program bus. Preset levels and ratios must be adjusted using the menus.
Page 141: Cecp Connectors
At the rear of the CECP are 2 power connectors, one Ethernet connector, a USB port, a ‘CP aux’ connector, a GPI/alarm connector, and an audio metering input. (See Figure 6-9 on page 124.) NV5100MC Master Control • Reference Manual...
Page 142: Power
6. Control Panels CECP Power There are 2 AC connectors, PS1 and PS2, for redundancy. You need not use both if you are not con- cerned with redundancy. Ethernet The CECP has one RJ-45 Ethernet port. The CECP connects to the Ethernet switch of the master control network.
Page 143: Fecp
The rightmost aux buttons not committed to main sources can be “aux delegates” — buttons that select the function of the aux but- ton row. NV5100MC Master Control • Reference Manual...
Page 144: Fecp Buttons
6. Control Panels FECP The FECP has a complete audio monitor/meter control section. It has 12 function buttons in 3 rows. The 12 buttons are independently configurable (despite the labeling on the panel). Each button directs an audio to the meters, to m monitor A, or monitor B. There are 5 audio sources: program audio, preset audio, preview audio, audio from “Aux In”...
Page 145: Fecp Knobs
The program audio section includes 2 rotary knobs for adjusting (1) the output level of the source selected on program and (2) the over/main ratio for the program bus. Preset levels and ratios must be adjusted using the menus. NV5100MC Master Control • Reference Manual...
Page 146 6. Control Panels FECP (When they become available) preview levels and ratios must be adjusted using the menus. 6 Program / preset button rows The program bus corresponds to what is on program output at present. The preset bus allows you to premix a source with video effects and audio overs in preparation for a transition to the program bus.
Page 147: Fecp Connectors
It is on this network that the FECP communicates with MCPMs and with the configuration soft- ware. You (or your system administrator) must provide a unique IP address for the FECP. Use the NV5100MC Master Control • Reference Manual...
Page 148: Gpi/Alarm
6. Control Panels CECP GUI Panel ID menu under the Panel Menu to set the IP address and IP subnet mask. The default IP address is 192.168.7.100 and the subnet mask must always be 255.255.255.0. GPI/Alarm The FECP has a DB25 connector that supports GPI inputs, GPI outputs, and alarms: GPI In 1 GPI Out 1 –...
Page 149 With a “bank select” button in the customer-programmable button section, the operator can switch between two banks of main sources. The button mnemonics change when the sources are switched. The bank selection button itself turns green or amber depending on which bank is selected. NV5100MC Master Control • Reference Manual...
Page 150: Gui Buttons
6. Control Panels CECP GUI The CECP GUI has 3 system control buttons and 8 transition control buttons. These buttons are configurable. GUI Buttons The buttons are large and appear in several colors (grey, green, amber, red, blue, white, and violet) and 3 brightness levels: off, low-tally, and high-tally.
Page 151: Monitor/Meter Section
16 virtual main source buttons. It is the MCPM or MCE that performs the effects and overs, and the order in which it applies them does not change. Some MCPMs do not support all video effects. NV5100MC Master Control • Reference Manual...
Page 152 6. Control Panels CECP GUI 5 Preview button row. The preview bus (in the MCE) and the preview button row (on the GUI) allow an operator to view video sources in combination with video effects without affecting program or preset out- put and therefore without interfering with automation.
Page 153: Aux/Preview Gui
Each button has 3 lines of text, 8 characters per line. Buttons are green, amber, red, blue, white, or violet and off, low-tally, or high-tally. Buttons that are unused are just gray. Red generally indicates an error condition. Buttons that are defined, but disabled momentarily, show dimmed text. NV5100MC Master Control • Reference Manual...
Page 154 6. Control Panels Aux/Preview GUI Figure 6-3 identifies the sections of the Aux/Preview GUI: Title Bar Customer-Definable Buttons Menu Area (Reduced) Monitor/ Meter Section (Disabled) Menu “Knobs” Aux/Preview Bus es Program and Preset Bus es (Dsiabled) Customer-Definable Buttons System Control Transition Button (Disabled) Figure 6 -13.
Page 155: Gui Buttons
The GUI has knob “proxies.” When you click or touch a proxy, the proxy turns bright green and the GUI’s slider appears. An operator can adjust parameter values using the slider. Monitor/Meter Section The monitor/meter section is disabled. NV5100MC Master Control • Reference Manual...
Page 156: Functional Sections Of The Gui
6. Control Panels Aux/Preview GUI Functional Sections of the GUI Following are brief descriptions of each section. Refer to Figure 6-12 on page 135. 1 Customer-programmable buttons The customer-programmable section includes 16 function buttons. Each may be programmed to perform functions such as channel selection, GPIO, or transition control. There are about 40 functions that can be assigned to these configurable buttons.
Page 157 These buttons are configurable. 8 System buttons. The system buttons include 3 buttons: ‘Panel Lock’, ‘Automation Off’, and master ‘Fade to Black’ by default. The buttons are configurable. 9 Transition button. The transition button is disabled. NV5100MC Master Control • Reference Manual...
Page 158 6. Control Panels Aux/Preview GUI Rev 2.10 • 17 Feb 11...
Page 159: Other Mc Products
Pressing the green button switches the MCPM or MCE to normal mode, barring other conditions that put the MCPM in bypass mode. Pressing the red button places the MCPM or MCE in bypass mode, overriding the bypass switch at the front of the MCPM or MCE. NV5100MC Master Control • Reference Manual...
Page 160: States
7. Other MC Products Emergency Bypass Control Panel States The EBCP and the MCPM (or MCE) cycle between normal mode and bypass mode based on sev- eral different inputs: Bypass switch off Green button pressed Normal Mode: Bypass switch: on to off Bypass switch: off to on Green button pressed Red button pressed...
Page 161: Configuration
GPI input. In conjunction with the cabling of figures 7-2 or 7-3, make the following settings: For GPI2, choose ‘Set Emergency Bypass Relay to Normal’. For GPI1, choose ‘Set Emergency Bypass Relay to Bypass’. Refer to the MasterConfig User’s Guide for configuration details. NV5100MC Master Control • Reference Manual...
Page 162: Transition Lever Arm
7. Other MC Products Transition Lever Arm Transition Lever Arm The optional Transition Lever Arm (NV5128-MC-LVR) is a device with which operators can per- form manually controlled transitions. It can be used with either the FFCP or the CFCP. The TLA has a simple lever that swings between two limits. There are two limit indicators (LEDs). Each tells you when the lever is at the limit.
Page 163: Operation
TLA is disarmed. When the MCPM is in transition, regardless of whether the transition has resulted from pressing the ‘Transition’ button or using the TLA, changes to keyers, logos, and squeezeback settings are not permitted. NV5100MC Master Control • Reference Manual...
Page 164: Manual Transition To Non-Sync Sources
• As a GPI/tally distributor, one input can be routed to many outputs. • As a GPI/tally combiner, many inputs can be routed to one output. The tally processor can receive signals from, and send signals to, an MCPM or MCE using Miranda Ethernet protocol (NVEP).
Page 165: Device Controller
The DC21 provides a choice of 3 protocols: Sony, Odetics, and VDCP. The device controller communicates with MCEs using Miranda’s Ethernet protocol (NVEP). The unit includes, at the front, a 2×16 character display and an 8-key button pad. The unit comes with its own switching power supply.
Page 166 7. Other MC Products Device Controller Rev 2.10 • 17 Feb 11...
Page 167: Appendix A Special Features
Master control is enhanced by it but does not require it. When it is integrated with an NV5100MC master control system, the Intuition XG processor feeds HD or SD keys (fill and key video inputs with up to 16 audio channels) to MCEs. It is a single- or dual-channel graphics processor that provides multi-level character generation, and animation, still, and clip playout with multi-channel audio.
Page 168: Integration With Mce
A. Special Features Intuition XG Integration with MCE The XG processor delivers two channels of HD or SD video (each with fill and key and up to 16 audio channels) to the MCE. (See Connections, following.) Audio reaches the MCE through the the keyer fill input dedicated to the XG channel.
Page 169: Xstudio Functions
The add-on functions are built into non-standard XML files that must be obtained either from the installation CD (SB0221) or from Miranda technical support. The special XML files are for customers who want to make use of the MCE embedded commands.
Page 170 A. Special Features Intuition XG At the bottom of the context menu is an ‘Add Command Channel’ entry. Clicking that entry pre- sents another menu. Click ‘Custom’ to get the MCE add-ons list: You may disregard the first entry which is ‘Custom command’. Choose any of the other commands. Choosing a command creates a track.
Page 171 Squeeze image 2 further has an opacity value specified by opacity. “P2” is Miranda’s internal code for squeeze image 2. Units are 0.1 percent and range from 0–1000. The size parameters must be at least 300 (30%).
Page 172: Connections
A. Special Features Intuition XG 12 Squeeze override run with P2 cut ( number ) Executes the squeeze effect identified by number (in the range 1–32). Being a cut, there is no duration. This squeeze uses both squeeze images, background and image 2, and thus uses the overrides of item 8 and item 7.
Page 173: Intuition Xg Configuration
IP address on the master control network. 2 Verify the software versions. At revision 6.3.1, MCEs are compatible with: XMedia Suite version 4.3 build 249 (or later) Vertigo XG version 1.11.35.0 (or later) NV5100MC Master Control • Reference Manual...
Page 174 A. Special Features Intuition XG In earlier software revisions, MCEs are compatible with XMedia Suite version 4.2, but not ver- sion 4.3. 3 There are 3 files in .ini C:\Program Files\VertigoXmedia\Apps\ XPlay.ini (These names are arbitrary) Channel_A\VCG2.ini Channel_B\VCG2.ini 4 Verify the configuration of XG channels A and B. Start the Dashboard.
Page 175 Choose Xplay > Tools > Settings > General. Ensure that the layout is ‘Multidevice’. Ensure that the number of devices is 4. Choose Xplay > tools > Device manager: Verify that your channels (named CGA and CGB here) are present. NV5100MC Master Control • Reference Manual...
Page 176: Nv5100Mc Configuration
A. Special Features Intuition XG Choose Xplay > Tools > Configure Automation. For channel A (“program” in MasterConfig) the TCP port must be 5006. If it exists, channel B (which corresponds to “preset” in MasterConfig) must be 5007. 6 Recall IDs Customers define XG keys (clips, animations, etc.) using Xmedia creative software such as Xbuilder or Xstudio.
Page 177: Masterconfig
(when enabled) but present no detect- able audio. 10 Specify the maximum number of layers. The lower this value, the better your system performance will be. NV5100MC Master Control • Reference Manual...
Page 178: Mcs Panel Configuration Editor
During operation, Xplay must be running, channel A must be running, and channel B (if it exists) must be running. Master control cannot process Intuition keys unless these conditions are met. Follow these guidelines: 1 Boot the Intuition XG and login. You’ll see the desktop with its Miranda report. Rev 2.10 • 17 Feb 11...
Page 179: Behavior
It is possible to use Xplay to watch the channel A and B cue and output buffers load and switch during transitions. Note that manual control of clips under Xplay is not recommended because it would interfere with the MCE. XG layers with higher numbers have visual priority over layers with lower numbers. NV5100MC Master Control • Reference Manual...
Page 180: Machine Control And Pre-Roll
A. Special Features Machine Control and Pre-Roll Machine Control and Pre-Roll Machine control and pre-roll are two independently configurable master control options. Machine control applies to VTRs, video disk players, video servers, and similar devices that need to be started, stopped, paused, rewound, and so on. Pre-roll generally applies to tape media (VTRs, etc.) that need to be tensioned and brought up to speed before playing.
Page 181: Mce Parameters
The transition button blinks during the period of pre-roll and reverts to its normal color (orange). A transition is always a pre-roll transition when the MCE’s system pre-roll value is non-zero. NV5100MC Master Control • Reference Manual...
Page 182: Theory
A. Special Features Machine Control and Pre-Roll The pre-roll period is essentially the longest pre-roll value of the pending sources. Theory The pre-roll period is calculated in relation to the point at which new video appears on the program bus. In a V-fade, for example, that is in the middle of the transition. (See Figure A-2, following.) MasterConfig refers to the cue point.
Page 183: System Pre-Roll
3 Master control’s machine control and pre-roll functions do little to ensure that a tape, or any other medium, is properly cued. Correct playout is always the operator’s responsibility. 4 There is an ‘Abort’ button to cancel pre-roll transitions before a transition completes the pre- roll period. NV5100MC Master Control • Reference Manual...
Page 184 A. Special Features Machine Control and Pre-Roll 5 Pre-roll values (expressed as a number of frames) must account for the 50, 60, or 59.94 frames per second of progressive video and the 25, 30, or 29.97 frames of interlaced video. Rev 2.10 •...
Page 185: Appendix B Specifications
B. Specifications Appendix B provides specifications for the NV5100MC master control switcher. It presents these topics: • Frames • Control Panels • MCPMs • Other Products • MCEs MCEs are distinct enough from other MCPMs to warrant their own section.
Page 186 B. Specifications Frames Table B-4. Analog V ideo Specifications Parameter Specification Input level 1.0 V p-p, nominal. Input impedance 75Ω, internally terminated. Output level 1.0 V p-p, nominal into 75Ω. Output impedance 75Ω, source terminated internally. DC on output ±50mV Insertion gain 0dB ±...
Page 187 SMPTE 292M, automatic re-clocking for HD-SDI data rates ≥ 15 dB, 5MHz to 1.5GHz Output return loss Output DC offset 0.0 VDC, ± 0.5V ≥ 270ps Output rise/fall time ≥ 0.2UI p-p Output jitter ≥ 10% of amplitude Output overshoot NV5100MC Master Control • Reference Manual...
Page 188 B. Specifications Frames Table B-8. AVC Video Specifications Parameter Specification Input signal type NTSC or PAL analog composite video. Output signal type SD-SDI (internal, delivered to system motherboard) Note: output signal is line-locked to composite input signal. Input level 1.0 V p-p, nominal 75 Ω, internally terminated.
Page 189 2 Phoenix twisted pair screw terminal blocks, one for each installed control module. Phoenix ports accept AES3 format signals at 48kHz sample rate. Note: only one connector type may be used on each AES reference input. Time-code reference This port is not supported. port NV5100MC Master Control • Reference Manual...
Page 190: Jumpers
B. Specifications Frames Jumpers EM0374 Jumpers The EM0374 router control card has several jumper sets: JUMPER SBUS SBUS 10B2 SBUS 10B2 10B2 SBUS 10B2 SMS7 SBUS SMS7 SBUS TIME CODE HI Z SICK SMS7 LED7 ACTIVE SBUS LED8 HEALTH SMS7 LED9 AESREF2 AESREF1...
Page 191: Em0414 Jumpers
Table B-13. EM0414 Jumpers Jumper Settings J13, J16 AES reference termination options. See Figure B-2 for jumper settings. (The settings are the same for the EM0374 and EM0414.) Leave this jumper in the RUN_PLL position. NV5100MC Master Control • Reference Manual...
Page 192: Connectors
B. Specifications Frames Connectors Control Port Connectors The master control frame has two sets of these connectors — one for the primary control card and one for the redundant control card. CTRL1, CTRL2 DIAG Router Control Card At the front of the EM0374 router control card is a DE9 diagnostic port: An alternative to the 9-pin diagnostic port is the Phoenix 3-pin “console”...
Page 193: Phoenix Audio Cards - 3-Pin
< 0.5% per SMPTE method, using a 60Hz, + 12 dBu sine wave and a 7kHz, 0 dBu sine wave. Noise 95dB below + 24 dBu Crosstalk –80dB worst case Insertion gain/loss ± 0.1dB CMRR > 75dB from 60Hz to 20 kHz NV5100MC Master Control • Reference Manual...
Page 194 B. Specifications MCPMs Table B-16. MCPM AES Audio Specifications Parameter Specification Signal format AES3-id BNC, unbalanced 75 Ω connectors, or DB25 connectors for balanced 110 Ω I/O connectors twisted pairs. Sample rates Synchronous modules, 48 kHz. Inputs and outputs Meets or exceeds AES3 digital audio specifications. Input levels Balanced inputs, 110 ohms, 200mV to 10Vp-p.
Page 195: Connectors
Metadata 1 carries decoded Dolby E metadata from the program bus. Metadata 2 carries decoded Dolby E metadata from the preset bus. The MCPM-MK-SD and -HD have no Dolby E audio and therefore no metadata outputs. NV5100MC Master Control • Reference Manual...
Page 196: Meter And Monitor Connectors
B. Specifications MCPMs Meter and Monitor Connectors All MCPMs have an digital output port for metering and monitoring: The MCPM-SD, -HD, -HD2, and -SDHD also have an analog output connector for metering and monitoring: The MCPM-MK-SD and -HD do not. Automation Connectors All MCPMs have an automation connector: (The protocol is RS-422.)
Page 197: Mces
75 Ω, 5–270MHz, internally source terminated. Output impedance Supported rates SMPTE 259M A, B and C (143, 177, 270Mb/s serial rates.) ≥ 15 dB, 5–270MHz. Output return loss Output DC offset 0.0 VDC, ± 0.5V NV5100MC Master Control • Reference Manual...
Page 198 B. Specifications MCEs Parameter Specification Output rise/fall time Varies, nominally in the range of 0.4 to 1.5 ms ≤ 0.2UI p-p Output jitter ≤ 10% of amplitude. Output overshoot Table B-23. MCE SWB Video Specifications (SMPTE 259M, 344M, and 292M) Parameter Specification Input equalization...
Page 199: Core Connectors
The diagnostic protocol is RS-232. So is the console protocol, but the console is not used with Mas- terDiag. It is the diagnostic part of this port to which you connect when using MasterDiag. NV5100MC Master Control • Reference Manual...
Page 200: Axm Connectors
B. Specifications MCEs AXM Connectors The MCE-AXM has unusual connectors. The signals on these 4 DB25 connectors will change at a later revision. The connectors are called J1–J4, J1 being at the top of the AXM backplane module: 13 Unused 13 Unused SHLD SHLD...
Page 201: Control Panels
Agency approvals UL listed, CE compliant Dimensions 19.0″ w × 5.22″ h × 3.17″ d. (482.6mm × 132.6mm × 80.5mm) Weight 5.1 lb (2.3 kg) Operating temperature 0–40° C (32–104°F) Humidity 0–90%, non-condensing NV5100MC Master Control • Reference Manual...
Page 202: Connectors
B. Specifications Control Panels Table B-28. FECP Specifications Parameter Specification AC power 90–130 or 180–250VAC, 50/60Hz, auto-ranging. 90 W maximum, power factor corrected. Receptacles Two standard IEC 60320 C13/C14, filtered. One receptacle for each of two power supplies. The second power supply is optional. Agency approvals UL listed, CE compliant 28.25″...
Page 203 1 mA. Loads for the GPI and alarm outputs can be larger: Max current: Max voltage: 125 VAC, 110 VDC. Max capacity: 62.5 VA, 33W. Rated loads: 1 A at 30 VDC; 0.3 A at 110 VDC; 0.5A at 125 VAC. NV5100MC Master Control • Reference Manual...
Page 204: Cutouts
B. Specifications Control Panels Cutouts The FFCP, CFCP, and TLA are designed so that they can be mounted in a recess in console surface. The following figures show the recess cutout patterns. FFCP CFCP Figure B-3. Panel Cutouts Note that placing the panel (or TLA) in a properly constructed recess does not prevent you from raising its lid.
Page 205: Other Products
“–” signals. Outputs: The upper pins are the COM (common) connections for each relay out- put. The lower pins are the NO (normally open) connections. Inputs 17–32 and outputs 17–32 have the same ordering. NV5100MC Master Control • Reference Manual...
Page 206: Device Controller
B. Specifications Other Products Device Controller Table B-31. Device Controller Specifications Parameter Specification AC power 100–240 VAC, 1.6A, 50–60 Hz. DC power APX4108 switching power supply, 24V, 2.5A Dimensions 19.0″ w × 1.75″ h × 8.5″ d. (483 mm × 45mm × 216 mm) Weight 7 lb (3.2kg).
Page 207: Ebcp
Agency approvals UL listed, CE compliant Dimensions 5.6″ w × 5.75″ h × 7.75″ d. (142 mm × 146mm × 197mm) Weight 3.72 lb (1.689 kg) Operating temperature 0–40° C (32–104°F) Humidity 0–90%, non-condensing NV5100MC Master Control • Reference Manual...
Page 208: Ps0001 Power Supply
B. Specifications Other Products PS0001 Power Supply The PS0001-00 is a small power supply used for the SCP and the EBCP. Table B-34. Power Supply Specifications Specification De tail AC power 90–264 VAC (127–300VDC), 47–447 Hz. Inrush current < 50 A at 230VAC, cold start, at 25°C, Input current <...
Page 209: Appendix C Misc. Information
A third-party device (1RU) used by master control systems to execute device control functions. DE9, DB9 A common 9-pin subminiature D connector. Electronic Industries Alliance, Arlington, VA (www.eia.org). See also TIA. EIA-422 See RS-422. NV5100MC Master Control • Reference Manual...
Page 210 Ethernet or machine control signals. RS-422 Recommended standard 422. Also called TIA/EIA-422-B. A bidirectional serial communications standard. Miranda documents refer to the latest standard in effect at the time the product was devel- oped. Simple Control Panel. The NV5128-MC-SCP hardware control panel.
Page 211: Components
Sync AES See Async AES. (Super Wide Band). A term originated by Miranda that means a wide range of digital bit rates and formats. Miranda’s SWB supports data rates from 10 Mbps to about 1.5 Gbps. The SWB input cards reclock at 143, 177, 270, 360, and 540 MB/s and 1.483 and 1.485 Gb/s.
Page 212 C. Misc. Information Components Part De scription Order Code EM0389 AES sync input card NV5000-SA-IN EM0391 AES input backplane, balanced (STP) IO5000-AES-IN-TP EM0393 AES input backplane, unbalanced (BNC) IO5000-AES-IN-BNC EM0396 SWB input backplane. See EM0466. IO5000-HD-IN EM0424 SWB output backplane. See EM0465. IO5000-HD-OUT EM0432 AVC input card.
Page 213: Nv9000 Integration
• More than 128 inputs (depending on the external router size). • Router source names appear on buttons (because of integration). • A control panel can control the upstream router in certain ways. Router information is displayed on the control panel. NV5100MC Master Control • Reference Manual...
Page 214: Snmp
C. Misc. Information NV9000 Integration • The ability to execute router salvos (either automatically with a channel change or explicitly) from the control panel. The NV9000 router control system’s device names are formatted for display on control panel but- tons according to NV9000 rules. Some editing of the NV9000 mnemonics within the NV9000 con- figuration software might be needed to correct display problems on master control panels.
Page 215: Integrating Both Master Control And An Mfr
The following MCS Panel Configuration Editor windows include NV9000 configuration settings: • NV9000 Settings. Additional Information For more information, you might want to read Miranda’s application note Routing and Master Con- trol. It is available on our web site. NV5100MC Master Control • Reference Manual...
Page 216: Application Notes
With many stations running multiple channels of master control, video and audio monitoring can be difficult. One of the unique attributes of Miranda master control can help. You can allocate space in the frame for a small (multi-format) router in addition to the master control channels. The program and monitor outputs of the MCPMs can be switched through the router.
Page 217: Using External Router Sources
ERS configuration is performed entirely in MasterConfig. Any MCPM, including MCEs, can per- form external router source selection. ERS must be enabled in MasterConfig’s general settings. 1. See the Miranda application note Routing and Mas ter Control Integration (AN0004-xx). NV5100MC Master Control • Reference Manual...
Page 218: Caveats
C. Misc. Information Application Notes External router sources can be main sources, over sources, key sources, and squeeze images. Each type must be enabled individually. The configurer should enable only what is needed because ERS consumes inputs ports: Main sources require up to 12 ports (in pairs). Key sources require (usually) 6 connectors, but you can get by with 3 if all you have are self- keys.
Page 219: Maintenance
Miranda master control panels require no maintenance. Periodic Inspection Periodically inspecting the frame for signs of trouble is the best way to prevent unplanned outages.
Page 220: Intake Filter Screen Cleaning
C. Misc. Information Maintenance 4 Look at each MCPM and verify that none of the red alarm LEDs are illuminated. Normally, the green and amber LEDs are illuminated. Refer to Table C-7 on page 208 to interpret the LED status indicators. 5 Look at the control card(s) and verify that the green and amber LEDs are illuminated on the active control card, and that the green LED is on for the standby controller (if present).
Page 221: Fuse Replacement
Contact technical support for assistance if a fault problem cannot be isolated. Replacing the fuse without determining what caused it to open could cause equipment damage or fire by restoring power to a damaged unit. NV5100MC Master Control • Reference Manual...
Page 222: Trouble-Shooting
These indicators are located on the module PCB and are intended for more advanced troubleshooting. Miranda customer support representatives might ask for the status of these indicators and will pro- vide instruction on locating them on the specific module if necessary.
Page 223: Module Replacement
(IEC 320-C13) at one end and stripped conductors (50/5 mm) at the other end. Conductors are CEE color-coded: Other IEC 320-C13 type power supply cords can be used if they comply with the safety regulations of the country in which they are installed. NV5100MC Master Control • Reference Manual...
Page 224 C. Misc. Information North American and International Power Cord s Rev 2.10 • 17 Feb 11...
Page 225: Index
..124, 127–128, 130, 133–134, 188 ......81–82, 86 NV5100MC Master Control • Reference Manual...
Page 226 Index ......106 ... . 34, 195 functions AVC (analog video conversion) .
Page 227 CFCP ......ii CE declaration NV5100MC Master Control • Reference Manual...
Page 228 Index ......179, 183 ... . . 7, 26, 37, 171, 176, 206 Compliance Control card .
Page 229 ......ii EEPROM FCC statement ..10, 41–42, 54–55, 59–61, 99–103, Effects, video 106, 109–111, 113–117 , 120–121, 123–124, 126, 129–130, 132, 135–137, 140–141, 199 NV5100MC Master Control • Reference Manual...
Page 230 Index . . 9–10, 88, 99, FECP (full-size enhanced control panel) ... .103, 130–131, 133, 196, 199 ......188 dimensions Gain .
Page 231 ....... . 44 .....57, 84, 106 status audio signal NV5100MC Master Control • Reference Manual...
Page 232 Index ......208 ......106 status indicators Master fade to black .
Page 233 NVISION serial protocol for master control ......68 Multiplicative mix NV5100MC Master Control • Reference Manual...
Page 234 Index Overview ......99 control panels ......41, 97 MCPM .
Page 235 ......21 Router pre-select .29, 38, 44, 171, 199, 205, 207 PS6100 (power supply) NV5100MC Master Control • Reference Manual...
Page 236 Index ......21 ....... 107 Router sources Shutdown .
Page 237 ...194 power specifications, power supply ....9, 43, 111, 114, 118 slow NV5100MC Master Control • Reference Manual...
Page 238 ......iii Website, Miranda Weight ....... 188 CECP .
Page 239 Xstudio ..101, 108, 126, 129, 132, 135, XG layer (button) ....137, 140, 159, 163–164 NV5100MC Master Control • Reference Manual...
Page 240 Index Rev 2.10 • 17 Feb 11...

Miranda NV5100MC Master Control Reference Manual

S-Shape

Symbols

Swapping Audio Channels

Appendix A Special Features

Appendix B Specifications

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miranda NV5100MC Master Control

Summary of Contents for Miranda NV5100MC Master Control
