INSTALLATION OF INK CASSETTE

Install the ink cassette included with the optionally
available color print paper sheet set.
1 OPEN CASSETTE DOOR
Pull the door in the direction indicated by the
arrow to open it.
2 TAKE UP SLACK
Remove the shipping material which locks the
rollers.
Turn the roller on the side with the
in the direction of the arrow.
Do not turn the part marked with
3 INSTALL INK CASSETTE
Insert the ink cassette with the
mark
toward the left, on the end going into the
printer. The
lamp. Push it until you hear a click.
4
CLOSE CASSETTE DOOR
The door clicks when it is fully closed.
When removing ink cassette
Push up the lock lever.
The ink cassette is unlocked and can be removed.
CAUTION
Do not stick your fingers into the ink cassette
storage space. You may be burned or injured.
A
mark
mark points toward the power
mark
.
