Barracuda 5400.1 Installation Guide
ST340015A and ST340015ACE
ATA Interface Disc Drives
Publication Number: 100264272, Rev. B, January 2003
The easiest way to install your drive
DiscWizard , available exclusively from Seagate, provides you with cus-
TM
tomized installation instructions for your hard drive. You can download Dis-
cWizard for free from the Seagate web site at www.seagate.com/support
or run the program directly from your web browser. In either case, you
should run DiscWizard before you install your drive.
If you cannot run DiscWizard, follow the instructions on this installation
sheet to install and configure your drive.
What you need
• A Phillips screwdriver and four 6-32 UNC drive mounting screws
• Forced-air ventilation to provide adequate drive cooling
• An ATA interface cable. For optimum drive performance and data integ-
rity, we recommend using an 80-conductor Ultra ATA/100 cable (which
can be identified by its blue, gray, and black connectors).
Handling precautions/Electrostatic discharge protection
• Disc drives are fragile. Do not drop or jar the drive. Handle the drive only
by the edges or frame. Keep the drive in the protective SeaShell
tainer until you are ready to install it to minimize handling damage.
• Drive electronics are extremely sensitive to static electricity. While
installing the drive, wear a wrist strap and cable connected to ground.
• Turn off the power to the host system during installation.
• Do not disassemble the drive; doing so voids the warranty. Return the
entire drive for depot service if any part is defective.
• Do not apply pressure or attach labels to the circuit board or to the top of
the drive.
Installation instructions
1. Set the jumpers
Note. The instructions below assume that you are installing your new
Seagate drive in a system that already has a working hard drive. To
install the drive in a system that has no working hard drive, see the
section titled, "What to do if you don't have a working hard drive"
located on back of this sheet.
a. Make sure that your existing drive is set up as a "master." See the drive
label or manufacturer's web site for jumper settings.
b. Your new drive is shipped with a jumper in the "cable select" position.
Set the drive as a "slave" by removing this jumper from the jumper
pins. Save the jumper in case you ever need to reconfigure the drive.
Jumper settings for this drive are shown below
Master/slave jumpers (see table for key to jumper settings)
2. Mount the drive and attach cables
a. Slide the drive into a 3.5-inch drive bay. You can mount the drive in any
orientation, but we recommend mounting with the circuit board down.
Note. To mount the drive in a 5.25-inch drive bay, you must purchase
mounting brackets, available from your computer dealer.
b. Secure the drive using four 6-32 UNC mounting screws in either the
side-mounting or bottom-mounting holes. Insert the screws no more
than 0.20 inches (5.08 mm) into the bottom-mounting holes and no
more than 0.14 inches (3.55 mm) into the side-mounting holes.
Caution. Do not overtighten the screws or use metric screws. This may
damage the drive.
c. Make sure the blue connector on your Ultra ATA/100 cable is plugged
d. Make sure the black connec-
e. Plug the gray connector into
Caution. When plugging in the
f.
con-
TM
Note. If your computer does not have an unused power cable for your new
3. Start up your computer
close your computer case and restart your computer. your computer may
automatically detect your new drive. If your computer does not automati-
cally detect your new drive, follow the steps below.
a. Restart your computer.
b. While the computer restarts, run the System Setup program (some-
c. Within the System Setup program, instruct the system to auto detect
d. Enable LBA and UDMA modes if the Setup program gives you this
e. Save the settings and exit the Setup program. When your computer
Drive is master
4. Partition and format the drive
or single drive
Before your new drive can store data, it must be partitioned (assigned one
Drive is slave
or more drive letters) and each partition must be formatted. You can parti-
Use cable select
tion and format the drive using DiscWizard or using programs built into
Windows. Using DiscWizard is generally easier and faster.
Drive is master with non-
ATA-compatible slave
Partitioning and formatting using DiscWizard
1.
2.
3.
4.
Caution. Partitioning or formatting a drive erases all the data on that drive.
5.
Congratulations. You're done!
If you have problems with your installation, see the troubleshooting infor-
mation on the back of this sheet.
into the primary IDE port on
your computer's motherboard
or host adapter. See your com-
puter manual to determine the
location of the primary IDE
connector.
tor on the cable is plugged into
your existing hard drive.
your new Seagate hard drive.
interface cable, make
sure that pin 1 on the
cable (indicated by a
stripe along the edge) is
attached to pin 1 on the
drives and on the moth-
erboard's IDE connector.
Attach the 4-pin power connector to the drive. See figure below.
Key on cable connector
fits into slot on drive connector
Pin 1
Stripe on cable
hard drive, you can purchase a Y-shaped power splitting cable from
your computer dealer which effectively converts one power connec-
tor into two.
times called BIOS or CMOS setup). This is usually done by pressing a
special key, such as DELETE, ESC, or F1 during the startup process.
your new drive.
option.
restarts, it should recognize your new drive. If your system still doesn't
recognize your new drive, see the troubleshooting section on the back
of this sheet.
Download DiscWizard for free from the Seagate web site at www.seagate.com/
support or run the program directly from your web browser.
Within DiscWizard, choose to "Setup a New Drive."
DiscWizard asks you a series of questions to determine the best way to set up
your new drive. Make sure to indicate that the drive is already installed in your
system.
Select the drive to be partitioned and formatted.
Make sure you select the correct drive!
Follow the on-screen instructions to complete the setup process.
Existing
hard drive
BLACK
connector
r
u t e
a r d
m p
r b o
C o
t h e
M o
Primary
IDE port
New
Seagate
drive
GRAY
connector
BLUE
connector
Power connetor
