O l i n C a r M P 3 P l a y e r L M 1 0 0 U s e r 's M a n u a l
1. Introduction
Thank you for purchasing O l i n C a r M P 3 P l a y e r L M 1 0 0 . Car MP3 Player is a new type of portable digital
music player, perfectly combines digital music playing, FM transmission, recording, FM tuner and removable
disk, etc.
1.1 Features
l
FM transmission function
l
Dichromatic OLED display
l
Rechargeable battery
l
Support intelligent (forced) charge
l
Support MP3, WMA file
l
Support A-B repeat, multiple sound/playback modes
l
Synchronously Lyric (LRC file) display
l
Perfectly combines MP3 Player with stereo set
l
Built-in FM tuner
l
Support VOICE (optional) and FM recording
l
Built-in flash memory
l
Effectively prevent misoperation with HOLD switch
l
Built-in Mini USB port
l
No driver installation required (except on Windows 98/98SE)
1.2 Functions and Buttons
REC Button
MODE Button/FM Transmission
Previous Button
Next Button
Advertisement
Summary of Contents for Olin LM100
- Page 1 O l i n C a r M P 3 P l a y e r L M 1 0 0 U s e r ’s M a n u a l 1. Introduction Thank you for purchasing O l i n C a r M P 3 P l a y e r L M 1 0 0 . Car MP3 Player is a new type of portable digital music player, perfectly combines digital music playing, FM transmission, recording, FM tuner and removable disk, etc.
- Page 2 2.1 Connecting with the Computer Car MP3 Player connects with the computer through USB cable. Connect standard port of USB cable to the computer, Mini port to Car MP3 Player. 2.2 Utilities Installation Car MP3 Player Utilities includes Windows 98/98SE driver and Firmware tools. The files are available for download at website www.olinstyle.com 2.3 Data Transferring Boot your computer, connect Car MP3 Player with the computer.
- Page 3 termination of Linophir official warranty. 3.2 Power On/Off To power on Car MP3 Player, please hold Play/Pause button, Car MP3 Player enters MUSIC menu after power on. To power off Car MP3 Player, please hold Play/Pause button. Car MP3 Player would power off automatically if no operation based upon preset time (Please refer to “4.5 SET ->...
- Page 4 When there is VOICE menu in Car MP3 Player, Hold REC button to switch to VOICE menu in stop status of MUSIC menu. Press REC button to switch play mode in stop status of MUSIC menu. 4.2TRAN Car MP3 Player can send the playing music to FM radio, so you can enjoy the music in Car MP3 Player through FM radio.
- Page 5 Manual Scanning: Press Previous/Next button to search channel ahead/backwards by 0.1MHz manual in receiving status. Store: Press Play/Pause button to save channel(s), the OLED displays “Station Saved”. Exit: Press Play/Pause button to return to MAIN MENU. Note: Car MP3 Player would search and save channel(s) automatically when enter FM menu for the first time.
- Page 6 Press MODE button to enter sub menu, press Previous/Next button to select “Yes” or “No”. Select “Yes”, and press MODE button to delete, the OLED would display “SUCCESS”. Select “No”, press MODE button to choose the file until last one. Select “Exit”, press MODE button to return to sub menu.
- Page 7 Temperature Relative Humidity under Working 20% ~ 90% (40°C) Relative Humidity under Storage 20% ~ 90% (40°C) and Transportation Atmospheric Pressure 86 KPa ~ 106 KPa Menu display Language English, Simplified Chinese, Traditional Chinese Computer IBM PC, Compatible Notebook or Mac with USB port. Windows 98/98SE/Me/2000/XP/Server 2003, Mac OS 10.2 or Operating System above, Linux 2.4.2 or above.
- Page 8 All promotional materials are offered for reference only. Actual products may vary. All brand names in this manual are the property of their respective owners. Linophir and its stylized logo are registered in the Australian IP office. OLIN is a registered trademark of Linophir International Pty Ltd. All rights reserved.
