Nickel Plate Road L1a & L1b 4-6-4

Steam Locomotive

Owner's Manual

(2-Rail & 3-Rail Models)

PO BOX 231 ~ 315 POINT TOWNSHIP DRIVE ~ NORTHUMBERLAND, PA 17857

PHONE: 570-473-9434 FAX: 570-473-3293

Web Site: www.weavermodels.com ~ E-mail: customerservice@weavermodels.com

Table of Contents

Need help?

Do you have a question about the Weaver Nickel Plate Road L1a and is the answer not in the manual?

Questions and answers

Summary of Contents for Quality Craft Weaver Nickel Plate Road L1a

Page 1 Nickel Plate Road L1a & L1b 4-6-4 Steam Locomotive Owner's Manual (2-Rail & 3-Rail Models) PO BOX 231 ~ 315 POINT TOWNSHIP DRIVE ~ NORTHUMBERLAND, PA 17857 PHONE: 570-473-9434 FAX: 570-473-3293 Web Site: www.weavermodels.com ~ E-mail: customerservice@weavermodels.com...
Page 2 Table Of Contents Traction Tires CAB-1 Remote Controller® Commands Before You Use Your Engine CAB-1 Remote Controller® Numeric Keypad Commands Maintaining Your Engine Turning Your Locomotive's Performance Momentum Operating Instructions For The TAS Fan Driven Smoke Unit Braking and Boosting Adding Smoke Fluid To Your Smoke Unit Stall Smoke Unit Operation...
Page 3 Figure 2 Greasing Points Adding Smoke Fluid To Your Smoke Unit The TAS fan driven smoke unit is capable of holding up to 40 drops of fluid. Before running the locomotive be sure to add at least 20 drops of fluid to prime the unit. While running without fluid will not damage the smoke unit it is advisable to add fluid at start up. Smoke Unit Operation There is a smoke unit on/off selector switch located under the locomotive cab.
Page 4 The e-unit in your locomotive alternates between three states: forward, neutral, and reverse. You may deactivate the operation of the e- unit by moving the "Full - Signal" switch to the "Signal" position. This will put your locomotive in a Forward lock out operating state. This will allow your engine to only run in the Forward position.
Page 5 CAB-1 Remote Controller® Numeric Keypad Commands When you press the AUX1 on CAB-1 Remote Controller®, you turn the numeric keypad into 10 command buttons. The keypad lets you control extra command features (until you press any top row button). 0 Stops and resets the steam locomotive to forward. Whistle blows. Headlight flickers. 1 Raises the volume of RailSounds™.
Page 6 Reprogramming LCRU Circuit Boards To Restore Features Due to the inevitable derailments, static and the nature of electricity, it is possible that your LCRU could someday lose its setup program. The symptoms of this condition would be unresponsiveness in command mode. This can easily be remedied by "reprogramming" your LCRU using the following steps.
