- Page 1 INSTALLATION AND MAINTENANCE MANUAL GROUND SOURCE HEAT PUMP WITH DC INVERTER (SPLIT TYPE) MODEL: BWB-SS-7 (DC) BWB-SS-9 (DC) BWB-SS-12 (DC) BWB-SS-15 (DC) - Please Read This Manual Before Using The Heat Pump -...
-
Page 2: Table Of Contents
Contents System description Sub-menu Heat Curve ........... 20 Principle of BWB-SS-DC heat pump ..... 2 Sub-menu Temperature ........21 Unit General Description ........3 Sub-menu Integral ..........21 Operation Principle of BWB-SS-DC ..... 3 Degree Minute's(DM) instruction......22 Sub-menu Time setting ......... 25 General information for the installer Sub-menu SETTING .......... -
Page 3: System Description
System description Principle of BWB-SS-DC heat pump BWB-SS-DC series heat pump can exploit the energy contained in natural heat sources. Or, to put it differently, the heat pump 'collects' heat energy from the heat source. The heat from the heat source (rock, soil, lake) is taken up via a closed collector system in which a mixture of water and antifreeze circulates;... -
Page 4: Unit General Description
System description Unit General Description In order to get the best result from the climate system BWB-SS-DC series, you should read through the section for the system manager in these installation and maintenance instructions; BWB-SS-DC is the ground source heat pump with DC inverter; it is a climate system for heating houses and apartment buildings as well as industrial properties. -
Page 5: General Information For The Installer
General information for the installer Transport and storage Inspection of the installation The BWB-SS DC series must be transported and stored Current regulations require the heating installation to upright and dry. The BWB-SS DC series may however be be inspected before it is commissioned. The inspec- carefully laid on its back when being moved into tion must be carried out by a suitably qualified person a building. -
Page 6: Pipe Connections
Pipe connections General Pipe installation must be carried out in accordance NOTICE! with current norms and directives. The heat pump can operate up to a return temperature of about 58* °C 7KH SLSH V\VWHP QHHGV WR EH IOXVKHG and an outgoing temperature of about 70* °C from the heat pump. -
Page 7: Pipe Connection (Heating Medium)
Pipe connections Pipe connections (heating NOTICE! medium) 1. in line filter on the return line; Pipe connections for the heating medium side are 2.To clean system with a power flush before installing located at the top of indoor unit. All required safety the heat pump and fill with clean water;... -
Page 8: Pump Capacity Diagrams, Heating Medium Side
Pipe connections Pump capacity diagrams, heating medium side Available pressure BWB-SS-7 (DC) WILO RS-25/6 Flow BWB-SS-9 (DC) BWB-SS-12 (DC) Available pressure WILO RS-25/8 Flow BWB-SS-15 (DC) Available pressure WILO RL-25/7.5 Tillgängligt tryck Flow... -
Page 9: How To Adjust The Rate Of Flow
Pipe connections How to adjust the rate of flow pump adjustable to adjust WILO RS-25/6 the flow: 1, 2, or 3. pump WILO RS-25/8 adjustable to adjust the flow: 1, 2, or 3. pump adjustable to adjust WILO RL-25/7.5 the flow: 1, 2, or 3. -
Page 10: Pump Capacity Diagrams, Collector Side
Pipe connections Pump capacity diagrams, collector side Available BWB-SS-7 (DC) BWB-SS-9 (DC) BWB-SS-12 (DC) BWB-SS-15 (DC) pressure WILO RS-25/8 Flow pump WILO RS-25/8 adjustable to adjust the flow: 1, 2, or 3. Connection of the power cord Five core cable ( 2.5mm2 x 2.1m,5cord) Power Supply NOTICE! -
Page 11: Electrical Connections
Electrical connection Connecting The Room Temperature Sensor Room temperature sensor Room temperature sensor RT=Room temperature sensor Connecting The Outside Temperature Sensor Outside air temperature sensor Outside air temperature sensor OCT=Outside air temperature sensor Connecting The Outside Temperature Sensor WTT=Water tank temperature sensor... -
Page 12: Layout Of The Pcb
Electrical connection 1.5mm2 terminal connection FEED GWIT GWOT ROOM CFDT RETURN 2.5mm2 terminal connection From Fuse 1 From Electrical heater 1 From Fuse 2 From Electrical heater 2 From K1 N From Fuse 3 From Electrical heater 3 From K1 N From Electrical heater From From Compressor... -
Page 13: Wiring Diagram ( 230V / 3X400V / 50 Hz )
Electrical connection Wiring Diagram ( 7K / 9K ) - Page 14 Electrical connection Wiring Diagram ( 12K / 15K )
-
Page 15: Commissioning And Adjusting
Commissioning and adjusting the container with tap water until it emerges from Preparations the return hose without being mixed with air. Before starting up the system, check that the heating, 10. Stop machine, heat medium water pump stop running. collector and hot water circuits are full and thoroughly Depressing the white manual lever lightly and then vented. -
Page 16: Inspection
Commissioning and adjusting Inspection NOTE! Adjust the brine and the heating medium pump 7KH FRPSUHVVRU PXVW QRW EH IRUFHG WR VWDUW ZLWK SHULRGV VKRUWHU WKDW VWDUW 1). Read the brine temperatures on the panel. The dif- SHU PLQXWHV ference between these two temperatures should be 2—5 °C when the system has come into bal- ance. -
Page 17: Control Panel
Control panel Layout Left button button Display Right button Down button Power On/Off • One button pointing upwards marked with a up arrow • One button pointing downwards marked with a down arrow • One button pointing to the right marked with a right arrow •... -
Page 18: Functions
Control panel Functions The control computer is operated with the help of a user friendly menu system that is displayed on the control panel. There is a main menu and several sub-menus accessible from the main menu. The menus are described in detail further down. -
Page 19: Control
Control General information Menu Navigation The right-hand button on the control panel is used to open the desired menu. The left-hand button is used to return to the previous menu. The up and down buttons are used to navigate between the parameters of a menu. A cursor (arrow) on the left-hand side of the display indicates which menu can be opened. -
Page 20: Sub-Menu Operation
Control Menus INTEGRAL Integral is a program to set the startup time and distance between compressor and electrical heater, to set stop conditions of compressor and electrical heater. This program is depends on the "feed water temperature degeneratiaon" and Time. COMPRESSOR A -60 0 ADD1... -
Page 21: Sub-Menu Heat Curve
Control Menus ADD.HEAT ON or OFF ON select ON, electrical heater is running normally. OFF select OFF, only switch off electrical heater the others are running normally. If you wish to change operating mode: Open the main menu INFORMATION by pressing the right-hand button once. You will find the cursor at the sub-menu named OPERATION. -
Page 22: Sub-Menu Temperature
Control Menus Sub-Menu TEMPERATURE This menu shows the different temperatures of the heating system. All temperature changes registered over the last 60 minutes are stored in the control system and can be viewed in the shape of graphs. OUT Display outdoor ambient temperature. WARMWT water tank temperature, the first value is water tank real temperature, the second value in ‘... -
Page 23: Degree Minute's(Dm) Instruction
Control Menus Integral (DM) is a program to set the startup time and distance between compressor and electrical heater according to heat demand and heat output, to set stop conditions of compressor and electrical heater. This program is depends on the "feed water temperature degeneratiaon" and Time. To enter this menu operator can change the factory setting: Menu Text Description... - Page 24 Control Degree Minute s(DM) instruction Before the Degree Minute reach - 60 (adjustable) ,the compressor is off, but when the Degree Minute reach - 60 (adjustable) ,the compressor automatic start, and the flow temperature will begin increase. (Higher than desired temperature) when the actual water supply temperature reach / higher than the desired temperature, the DM will be changed.
- Page 25 Control The relationship between compressor and DM T=T1-Ts+2 +1.0 +0.5 After compressor start running, when ‘setting return water temperature – actual return water temperature constant temperature setting, and the electrical heater does not start, then enter constant temperature control The temperature and its frequency during constant temperature program. Recorded by the above chart temperature program’s frequency is T=T1-Ts+2 , T has 10 areas, from 0 to 9, the rule of constant...
-
Page 26: Sub-Menu Timesetting
Control Menus Sub-Menu TIMESETTING How to enter the Sub-Menu TIMESETTING: You need to choose the " TIMESETTING" on the main menu ( INFORMATION). Press the right button. Then " TIMESETTING" menu can be seen. ROOM TIME 2 ON ROOM TIME 2 OFF ROOM TIME 1 ON ROOM TIME 1 OFF TIMESETTING use button Up and down to select each item. -
Page 27: Sub-Menu Setting
Control Menus Sub-Menu SETTING ADD ENFORCE WATER PUMP ADD DIF TEMP EMERGENCY1 (ON or OFF) Emergency mode 1 emergency 1 ON or OFF factory setting is OFF(after select emergency mode, the unit will continuously execute the same objective (room heating only, water tank heating only, or auto) When select ON, compressor will be switch off, only electrical heater, water pump or other temperature protection are available. -
Page 28: Sub-Menu Operate Time
Control Menus ADD START : ( 10 to 65 degree adjustable , factory setting is 40 degree ) Electrical heater start water temperature, it is adjustable from 10 - 65°C, factory setting is 40°C, this means when compressor heat the water temperature over 40°C, then allow the electrical heater to start, this setting is for energy-saving and water tank heating (WARMWATER) only. -
Page 29: Sub-Menu Reset
Control Menus Menu Text Description Adjustable by HEATPUMP Total operating hours of heat pump since installation. can not Operating time will not be reset to zero. Total operating hours of auxiliary heater 1 can not (3kW) since installation. Operating time will not be reset to zero. -
Page 30: Adjustments To Be Made Regularly
Control Adjustments to be made regularly Sub-Menu LANGUAGE Language selection : How to enter the Sub-Menu of LANGUAGE: DEUTSCH You need to choose the " L ANGUAGE" on the Main menu ( INFORMATION ). Press the right button. Then " LANGUAGE" menu can be seen. Use Up and Down button to select the language , and press Right button to confirm. -
Page 31: Adjustment Of Room Valve
Control Adjustments to be made regularly CURVE is program that adjusts feed water temperature according outdoor ambient temperature, factory setting is ambient temperature 0 as feed water temperature 40 , that is CURVE =40; the value of CURVE is adjustable from 22 to 56 . - Page 32 Control Adjustments to be made regularly If you wish to change the ROOM value: Press the ”up” or ”down” button once to open the ROOM value for adjustment. Increase or reduce the preset value using the ”up” or ”down” button so that the desired room temperature is reached.
-
Page 33: Adjustment Of Part Of The Heat Curve
Control Adjustments to be made regularly Adjustment of Part of the Heat Curve At outdoor temperatures between -5°C and +5°C part of the heat curve may need adjusting if the indoor temperature does not stay at the preset ROOM value. For this reason, the control system includes a function adjusting the curve at three outside temperatures: -5°C, 0°C, +5°C. -
Page 34: Adjustment The Min And Max Valve
Control Adjustments to be made regularly Adjustment of the MIN and MAX value The MIN and MAX value is the lowest respectively highest value that is allowed for the supply line temperature. Adjusting the minimum and maximum supply line temperature is particularly important if your home has floor heating. -
Page 35: Graph Of Recent Change In Temperature
Control Adjustments to be made regularly Press the ”down” button to move the cursor to HIGH T STOP or LOW T STOP. Open the selected parameter by pressing the right-hand button once. The cursor moves to HIGH T STOP or LOW T STOP. Raise or lower the value, using respectively the ”up”... -
Page 36: Maximum Return Line Temperature
Control Maximum Return Line Temperature The maximum return line temperature, i.e. temperature of the water returning from the heating system, should be adapted to each individual installation. The correct temperature value for your system will be entered by your installation contractor in connection with installation and can be adjusted later. Warm Water Production The temperature of the water distributed to the water heater is controlled by the regulating pressure switch and cannot be adjusted. -
Page 37: Checking The Brine Level Of The Brine System
Control Regular Checks Checking the Brine Level of the Brine System The Brine system must be filled with the correct volume of brine. Otherwise the heat pump unit risks being damaged. Brine system liquid (brine) must be added if the brine level gets so low that it is no longer visible in the expansion vessel. -
Page 38: Alarm Messages
Control Alarm Messages In the event of an alarm message, try to re-start the unit with the safety switch. If this does not work, try to solve the problem with the help of the table below. Call your installation contractor if you need help. - Page 39 Control Alarm Messages The cause of alarm ‘IPM MODULE’ could be: 1 The communications between Module and outdoor main circuit board is jamming; 2 Module is jamming and can not detect current or compressor; 3 Module can not start compressor; 4 Module’s rated 15VDC voltage is not steady 5 Module’s current overload How to do:...
- Page 40 Control Alarm Messages 6. check the if DC voltage between A(first wire) and B(third wire) is normal, it should be 13.5V ~16.5V The cause of alarm ‘TRANSITION-MAIN COMMUNICATE’ could be: 1. The connection between transition circuit board and main circuit board is wrong; 2.
- Page 41 Control Alarm Messages The cause of alarm ‘CMP TOP OVER’ could be: 1. Water flow was not enough; 2. Refrigerant was not enough 3. Ambient temperature was too high; How to do: 1. Check if the water flow was not enough, so that the heat exchange efficiency was not good; 2.
- Page 42 Control Alarm Messages The cause of alarm ‘WARM WATER TEMP.’ could be: 1. The connection of water tank temperature sensor was loose; 2. The water tank temperature sensor was broken; How to do: 1. Find the connection and make sure it is fine; 2.
- Page 43 Control Alarm Messages The cause of alarm ‘CMP TEMP.’ could be: 1. The connection of compressor exhaust air temperature sensor was loose; 2. The compressor exhaust air temperature sensor was broken; How to do: 1. Find the connection and make sure it is fine; 2.
- Page 44 Control Circuit Board Picture For BWB-SS- 7 (DC) and BWB-SS-9 (DC) Display Transition circuit board Module Main circuit board Circuit Board Picture For BWB-SS-12 (DC) and BWB-SS-15 (DC) Display Transition circuit board Power board Module Main circuit board...
- Page 45 Control Sensors resistance table compressor exhaust temperature sensor resistance Unit (compressor exhaust temperature sensor R(K ) R(K ) R(K ) R(K ) 542.7 68.66 13.59 3.702 511.9 65.62 13.11 3.595 62.73 12.65 3.492 455.9 59.98 12.21 3.392 430.5 57.37 11.79 3.296 406.7 54.89...
- Page 46 Control Sensors resistance table 2 water/ambient/pipe sensor resistance Unit water/ambient/pipe sensor) 115.266 12.6431 2.35774 0.62973 108.146 12.0561 2.27249 0.61148 101.517 11.5 2.19073 0.59386 96.3423 10.9731 2.11241 0.57683 89.5865 10.4736 2.03732 0.56038 84.219 1.96532 0.54448 79.311 9.55074 1.89627 0.52912 74.536 9.12445 1.83003 0.51426 70.1698...
-
Page 47: Terminology And Abbreviations
Control Terminology and Abbreviations Evaporate the evaporator, energy from the heat source is absorbed by the refrigerant passing through the evaporator. The refrigerant turns into gas. (See ”Heat Pump Principle” on p. 4). INTEGRAL INTEGRAL is the heat balance of the heating system. Production of heat is regulated acc. to a calculated heat demand value. -
Page 48: Description Of The Switch Panel
Description of the Switch panel Function When test or repair the machine, the compressor, water cycle pump and outdoor fan motor can be force manual startup. Water Pump : Control the Water Cycle Pump E-Heater : Control the Electrical Heater 1 and 2 O-Warm Water : Control the 3 way valve turn to the Water Tank Heating side ( B side ) I-Room Heating : Control the 3 way valve turn to the Room... -
Page 49: Dealing With Malfunctions
Dealing with malfunctions Draining, heat medium side Draining, collector side Close the shut-off valves in heating medium system. When replacing the brine pump or drive side or when Open the drain valve (27). A small amount of cleaning the pump, the shut-off valves in the collector water runs out, however, to fully empty the heating system should be closed. -
Page 50: Component Placement
Component placement Please Note : The picture for reference only ! -
Page 51: Component Positions 2
Component placement BWB-SS-12 (DC) for example Please Note : The picture for reference only ! -
Page 52: Component Positions 3 X 400 V / 3 / 50 Hz
Component placement 3X400 V / 3 / 50 HZ Please Note : The picture for reference only ! -
Page 53: List Of Components
List of components Please Note : The list is for reference only! Plastic top board High pressure pressostat 2 Control panel Expansion valve Left side board Condenser Right side board Electrical Control Box Front board Electric relay Handles Capacitor Stainless steel adjustable feet AC contactor 1 Heating Flow pipe connection( To Water Tank ) Ø... -
Page 54: Dimensions
Dimensions Dimensions and setting-out coordinates... -
Page 55: Accessories
Accessories 62 (optional) 59 (optional) Enclosed kit Outside air temperature sensor Room temperature sensor... -
Page 56: Technical Specifications
Technical specifications Technical specifications 3 x 400 V IP 21 Refrigerant : R410A Model BWB-SS-7(DC) BWB-SS-9(DC) BWB-SS-12(DC) BWB-SS-15(DC) Heating Capacity at B0/W35 (KW) 6.950 8.900 11.905 14.500 Heating Power Input at B0/W35 (KW) 1.703 2.197 2.930 3.598 Power supply (V/Ph/Hz)) 400V/3/50Hz 400V/3/50Hz 400V/3/50Hz 400V/3/50Hz...
