  • Page 1 Inverter Generator Owner’s Manual Guide D’Utilisation Manual del Propietario SF1000 SF2200 For product inquires or support, please visit www.evopower.co.uk or call our registered offices support number on 01646 66 38 48. Pour obtenir des renseignements sur les produits ou pour du soutien technique, visitez notre site à...
  • Page 2 Congratulations on owning a Evopower inverter generator! WARNING This manual contains important instructions for operating this generator. For your safety, and the safety of others, be sure to read this manual thoroughly before operating the generator. Failure to properly follow all instructions and precautions can cause you and others to be seriously hurt or killed.

  • Page 3: Product Registration

    PRODUCT REGISTRATION To register your product, please complete the information below and mail to the address at the end of the form or register online at www.Evopowergenerators.com. 18-digit serial number must be completed in order for warranty to be acti- vated.
  • Page 4 3 - DEMOGRAPHIC INFORMATION GENDER: HOUSEHOLD INCOME: MALE LESS THAN $15,000 $100,000 - $124,999 FEMALE $15,000 - $29,999 $125,000 - $149,999 $30,000 - $49,999 $150,000 - $174,999 MARITAL STATUS: $50,000 - $79,999 $175,000 - $199,999 MARRIED $80,000 - $99,999 $200,000 OR OVER SINGLE PRIMARY METHOD OF PURCHASING HOUSEHOLD DATE OF BIRTH:...

  • Page 5: Table Of Contents

    SPECIFICATIONS AND WIRING DIAGRAMS ............... 29 WARRANTIES ........................ 33 NORTHSHORE POWER SYSTEMS CONSUMER LIMITED WARRANTY ..........33 NORTHSHORE POWER SYSTEMS EMISSIONS CONTROL WARRANTY ........... 34 INDEX ..........................37 MAINTENANCE PARTS ....................39 SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 6 THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 7: Important Safety Rules

    NEVER use inside a home away from windows, doors, and or garage, EVEN IF doors Indicates a situation which, if not avoided, vents. and windows are open. NOTICE may result in damage to the generator components. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 8 The muffler becomes very hot during operation and remains hot for a while after stopping the engine. • NEVER touch hot surfaces and avoid hot gases. • Let engine cool before storing the generator indoors. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 9: Location Of Important Labels

    Este es un veneno que no se ve, ni huele. NUNCA lo utilice dentro del hogar Utilícelo siempre AFUERA ni del garaje AUNQUE estén abiertas y lejos de ventanas, las puertas y las ventanas. puertas y ventilas. 101591A SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 10 Owner’s Manual before operating the generator. Failure to properly follow all instructions and precautions can cause you and others to be seriously injured or killed. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 11: Getting Started

    SF2200 Phase: Part Number: 101440A Frequency: 60Hz AC/DC Voltage: 120V/12V Engine RPM: 5000 Power Output: 2.0kW Fuel: Gasoline Max. Ambient Temp.: 40 Insulation Class: F Serial Number: FIGURE 3: Generator Nameplate Location SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 12: Grounding The Generator

    In some areas, generators are required to be regis- tered with local utility companies. • If generator is used at a construction site, there may be additional regulations which must be observed. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 13: Components

    Generator is heavy! Obtain assistance to lift the generator to avoid back or other bodily injury. Accessories Oil Drain Pipe Oil Fill Container Screwdriver Handle Screwdriver Universal Bit Spark Plug Wrench FIGURE 5: Inverter Accessories SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 14: Front And Back View

    Outlets Protect circuits from damage caused by overload or short-circuit by stopping flow 125VAC outlet(s) (NEMA 5-15R [SF1000 model] and NEMA of electricity from generator to the appli- 5-20R [SF2200 model]) to connect 120V appliances to gen- ance. If there is no power at outlets, see erator for power.
  • Page 15 Provides access to air filter, fuel filter, and oil fill cap. fuel consumption and less noise. G—Fuel Cap In DC operation, set the Efficiency Mode Switch to the Provides a secure seal on fuel tank. The SF1000 model has OFF position. a vented fuel cap. B—Top Maintenance Cover H—Fuel Valve...
  • Page 16 THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 17: Operation

    In good condition. Rated for outdoor use and match amperage and voltage ratings of generator outlet. Equipped with proper plugs that contain grounding blades. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 18: Starting Generator

    Starting Generator Move the choke to the ON position. NOTE: WARNING Place the choke in the OFF position when the SF1000 has a warm engine. Before starting generator, be sure to thoroughly read all information provided in this Owner’s Manual.
  • Page 19 After starting, confirm the output ready indicator light times to supply fuel to start the engine. is green and stays on. FIGURE 13: Output Ready Indicator Light (SF1000 model) FIGURE 11: Prime Engine Allow the engine to run continuously and warm up NOTE: before connecting any appliance.

  • Page 20: Ac Operation

    Allow the generator to run for 2-3 minutes. Press the engine control switch to the STOP position. Turn the fuel valve to the OFF position. Turn the fuel cap vent to the OFF position (SF1000 model only). www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 21: Powering Appliances

    This will be indicated Hair Dryer 1200-1875 by a “tripped” breaker. If this happens, power off and Heater, Portable 750-1500 SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 22 CAUTION Do not run power cords under carpet, rugs, or other materi- als where heat might build up or cord damage may go unno- ticed. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 23: Maintenance

    Perform at every indicated month or operating hour interval, whichever comes first. † Clean more often when using generator in dusty areas. ‡ SF2200 model only. ** It is recommended that this maintenance task be performed by a service dealer. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 24: Engine Oil

    Place the generator on a flat, level surface. 0.26 / 250 0.48 / 450 Oil Capacity [qt / ml] Remove the back maintenance cover using the Phil- TABLE 4. Engine Oil Capacity lips end of the universal screwdriver bit. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...
  • Page 25 Hot engine oil can cause severe burns. • ALWAYS stop engine before removing the oil fill cap. Remove the back maintenance cover using the Phil- lips end of the universal screwdriver bit. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 26 Attach the oil drain pipe (do not over tighten) and tilt the generator allowing the oil to completely drain into the oil pan. FIGURE 27: Oil Fill Measurement FIGURE 25: Drain Oil (SF2200 Model) www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 27: Engine Fuel

    NOTICE Oxygenated fuels can damage paint and plastic. Be careful not to spill fuel when filling the fuel tank. Damage caused by spilled fuel is not covered under warranty. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 28: Cleaning Fuel Strainer

    Clean the fuel strainer with soap and water. Wipe the fuel strainer clean with a clean, dry cloth. FIGURE 30: Fuel Level Gently reinstall the fuel strainer and replace the fuel cap. www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 29: Air Filter Maintenance

    FIGURE 35: Dry Air Filter Soak the air filter in clean engine oil. FIGURE 32: Air Filter Removal - SF1000 Model FIGURE 36: Air Filter Oiling SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 30: Cleaning Spark Arrestor Screen

    To clean the spark arrestor screen, you will need: Reinstall the air filter and air filter cover. Screwdriver handle NOTE: For the SF1000 model, carefully place filter between air Screwdriver universal bit filter support pegs without tearing filter. See illustration Wire brush below.

  • Page 31: Spark Plug Service

    Clean any dirt from around spark plug base. age engine. Never use spark plugs that have an improper heat range. Use only recommended spark plugs or equiva- lent. See Maintenance Parts at the end of this manual. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 32: Transporting Generator

    At this point, the piston is coming up on its compres- Turn the fuel valve to the OFF position. sion stroke and both intake and exhaust valves are Turn the fuel cap vent to the OFF position (SF1000 closed. Storing engine in this position will help to pro- model only).

  • Page 33: Troubleshooting

    TROUBLESHOOTING WARNING ANYONE using or servicing the generator must read, understand, and follow all safety and operation instructions provided in the product manual. Failure to closely follow these instructions can result in circumstances leading to death, serious injury, and property damage. DANGER Using a generator indoors CAN KILL YOU IN MINUTES.
  • Page 34 THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 35: Specifications And Wiring Diagrams

    Engine Oil Capacity [qt / ml] 0.024-0.028 / 0.024-0.028 / Spark Plug Gap [in /mm] 0.6-0.7 0.6-0.7 * Under load **Efficiency switch in OFF position TABLE 10. SF1000 / SF2200 Inverter Generator Specifications SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 36: Wiring Diagrams

    WIRING DIAGRAMS WIRING DIAGRAMS WIRING DIAGRAMS SF1000 Model www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...
  • Page 37 WIRING DIAGRAMS WIRING DIAGRAMS SF2200 Model www.evopower.co.uk Inverter Generator User's Manual...
  • Page 38 THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 39: Warranties

    (including, but not limited to, implied warranties of merchantability or fitness for a particular purpose) are limited to the shortest duration permitted by applicable law or the lim- ited warranty period provided herein, whichever is longer. SF1000 / SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...

  • Page 40: Northshore Power Systems Emissions Control Warranty

    NORTHSHORE POWER SYSTEMS EMISSIONSNTROL WARRANTY THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000 / SF2200e Inverter Generator Owner’s Manual...

  • Page 41: Index

    Wattage, Typical Appliance operation safety labels specifications starting stopping storing transporting unpacking guidelines Ground special requirements terminal High Altitude Operation Maintenance air filter changing engine oil cleaning spark arrestor parts listing schedule spark plug SF1000 /SF2200e Inverter Generator Owner’s Manual www.evopower.co.uk...
  • Page 42 THIS PAGE INTENTIONALLY LEFT BLANK www.evopower.co.uk SF1000/SF2200e Inverter Generator Owner’s Manual...

  • Page 43: Maintenance Parts

    Recoil Assembly 101578A 101622A Screw, Back Maintenance Cover 101577A 101621A Screw, Top Maintenance Cover 101759A 101759A Spark Plug 101566A 101566A SF1000/SF2200 Maintenance Parts List For part numbers of replacement product labels, see page 3. www.evopower.co.uk SF1000/ SF2200 Inverter Generator Owner’s Manual...
  • Page 44 Genpower Ltd P/N: 101435B January 2009 Unit 1, Dowty Park, Milford 2009 Genpower Ltd Haven, Pembrokeshire, SA73 The Evopower Trademark is used under license from Evopower International Inc. Evopower makes no representation or warranties TEL 01646 663848 with respect to this product www.evopower.co.uk/...
