RADIKAL TECHNOLOGIES SAC-2K Manual

Logic audio platinum
Hide thumbs Also See for SAC-2K:
Table of Contents

Advertisement

Quick Links

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAC-2K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RADIKAL TECHNOLOGIES SAC-2K

Summary of Contents for RADIKAL TECHNOLOGIES SAC-2K

  • Page 2 SAC-2K/SAC-2.2 in LGC (Logic Control) operating mode...
  • Page 4 Copyright 2002 Radikal Technologies, Inc. This manual cannot be reproduced, in whole or in part, without the express written permission from Radikal Technologies, Inc. All company names and trademarks mentioned in this manual are the property of their respective owners.

  • Page 5: Table Of Contents

    Cycle Mode Editing ..............................23 1)Quickly repositioning the Cycle Locator ..................23 2)Cycle Editing ............................ 23 Transport Overview ..............................24 Attention!! If a Logic Audio presents you with a dialog box when it recognizes the SAC-2K/2.2, suggesting you update the firmware, press [Cancel].

  • Page 6: Installation And Setup

    The basic assumption of this manual concerning using the SAC-2K/2.2 in Logic Control mode is that you have already connected, set up and installed the SAC-2K or SAC 2.2. You can use either the MIDI or the USB connection, the functionality is the same.

  • Page 7: Relative Control Resolution

    Click on the Logic Control icon. On the left side of the setup window you should now see the parameters of the selected control surface. In the section “Special Parameters” you should definitely deactivate the option “Touchless movable faders”. Use of this function with equipment with reliable touch sensitivity technology is not advisable, because in this mode fader movement is also used to recognize activation of the fader.

  • Page 8: Maximum Midi Bandwith (%)

    display blank spaces for a correct replication of Track Names between the individual channels. If these options are checked it is possible that long parameter names can be separated in pieces. Display duration (s) This parameter determines how long the alternate longer version of the parameter name is shown in the display, after releasing the relevant encoder.

  • Page 9: Sac Mixer Mode Buttons

    SAC Mixer Mode Buttons Located Between the two fader groups of the SAC are the Mixer Mode buttons. In the following chart you can see the LGC assignments. SAC M ixe r M ode B uttons Track Send Assignment Pan/Surround Plugin Instrument MIDI-Tracks...

  • Page 10: The Master Select Button

    The Master Select Button The [Master Select] button above the master fader has been assigned the [Global view] button function of the Logic Control. Master-Select Button SAC Button LC Mode Function Master Select Global View Button The Channel Strip Buttons The Channel Strip buttons of the SAC are used to activate the various automation modes of Logic Audio.

  • Page 11: The Mute And Select Buttons

    Instructions for storing the startup operation mode can be found in your SAC manual. The Start-up mode can only be stored with the SAC 2.2 model. Users of the SAC-2K can store their setting via MIDI dump to a computer. See more about this in the SAC-2.2 Manual.
  • Page 12 than one is assigned to the same environment object. The [Masterselect] button is used for the selection of the various display modes. Global-View Buttons Modifier Button Function Button Toggles between "Track View" and "Global View" Global View Toggles between "Track View" and "Extended Shift Track View"...

  • Page 13: Assignment Buttons, „Channel Strip" Display And „Multi Channel" Display

    The lowest four of the Mixer Mode buttons are used for moving the display section of the mixer. Instead of directly selecting a specific fader group (as just described) you can move the selection of the currently displayed track upwards or downwards.

  • Page 14: Channel Strip Display

    Parameters available for selection are shown blinking in the display. The selection won’t take place until you have pushed the according encoder button. Parameters which are not available for editing are not displayed in the SAC at all nor offered for selection. For instance, if you would like to change the position [Pre/Post] of a FX Send, this FX send has to be activated.

  • Page 15: Motorfader Off

    By pushing down the [shift] button while pushing the [flip] button, Logic will activate a “Flip-Swap” mode. In this mode the parameter assigned to the encoder will be assigned to the fader, while the fader parameter can be edited with the encoder.

  • Page 16: Recording Of Track Automation

    Recording of Track Automation Of course you can automate all parameters in Logic Audio. To turn on automation you won’t need a mouse! You can comfortably call up the various automation modes with the channel strip buttons of the SAC. Automation Buttons Modifier Button...
  • Page 17 Function Buttons 1 - 8 Modifier Function Button Function Button Calls up Screenset 1 Shift Opens/closes the Arrange window. Track Calls up Volume on multiple tracks Pan/Surround Calls up Pan/Surround on multiple tracks Calls up Bypass on multiple tracks Send Calls up Sends on multiple tracks Marker Jump to the first Marker position...
  • Page 18 Calls up Screenset 4 Shift Opens/closes the Note Editor Track Calls up Input on multiple tracks Calls up Pan/Surround Mode on multiple Pan/Surround tracks Calls up Gain on multiple tracks Send Calls up Mute on multiple tracks Marker Jumps to the fourth Marker position Nudge Nudge-Value: Bar Calls up Screenset 5...

  • Page 19: The Cursor And Zoom Functions

    The Cursor and Zoom functions Cursor and Jog-Wheel Functions The cursor keys of Logic Control are replaced on the SAC-2K and SAC-2.2 by the first two Encoder under the third display. This way you can quickly dial in extreme zoom-settings more efficiently than with repeated button presses. The Zoom enable button is on the push-button of the third Encoder.

  • Page 20: The Track Mixer Element Functions

    In the "Multi Channel" Mode: Call of the next or previous parameter for the current operation In the "Channel Strip EQ", "Send" or "Plugin/Instrument-Editor" mode. Scrolls the pages of the current editor. Scrolls the parameters of the current editor. Encoder 2 - Otherwise...
  • Page 21 Track M ixe r Ele me nt Functions M odifie r Ele me nt Function Button changes the value of the parameter assigned in the display Encoder Changes the according parameter to the Option maximum or minimum value The Encoder works in finest resolution Recalls the non-edited value of the parameter or toggles between two options If a selection was made (Display flashes)

  • Page 22: Setting Markers

    Track volume In the Duplicate Flip operating mode Parameter currently controlled by encoder also controlled by fader In the Swap Flip operating mode Exchanges parameter currently controlled by the encoder and controls it with the fader With Surround Angle/Diversity displayed Fader Surround Diversity control.

  • Page 23: Moving The Object By A Fixed Value

    first display you can now see the currently set nudge value as well as the current position of the move object. In the third mode the selected object will be moved to the selected song position. 1) Moving the object by a fixed value Keep the [nudge] button pushed and use the [FWD] and [RWD] buttons in the transport field.

  • Page 24: Transport Overview

    Encoder-Button 1 turns Cycle Mode off and on Encoder Button 2 turns Cycle Mode On and Off according to the current selection in the arrange window Encoder Button 3 moves the Cycle Zone by Bar Encoder Button 5 sets the current song position as the left Locator Point Turning Encoder 5 moves the left Locator by Bar Turning Encoder 6 moves the left Locator by Beats.
  • Page 25 Fast Rewind Marker Jumps to the previous Marker Nudge Shifts the current " Nudge" value to the left Turns on Cycle mode and brings the Cycle in Cycle position to the current playback location Rewind Turns on Drop mode and brings the Drop in Drop position to the current playback location In "Marker"...

This manual is also suitable for:

Sac-2.2
