- Page 1 Python 3G User Guide M4040-9900-102 24 July 2014...
-
Page 2: Terms And Conditions
Python 3G to use their product manuals for their own internal business use. Manuals for Grass Valley products may not be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose unless specifically authorized in writing by Grass Valley. -
Page 3: Table Of Contents
Table of Contents 1 About Python 3G ........1 About the Python 3G System . - Page 4 Table of Contents Python 3G Transceiver Rear Panel without CWDM ......31 Python 3G Transceiver Rear Panel with CWDM ....... . 31 Python 3G Units with CWDM and Fiber Capability (Dual Input/Output).
-
Page 5: About Python 3G
About Python 3G This chapter provides an overview of the Python 3G and includes the safety and warranty information about it. About the Python 3G System ............2 Safety and Fiber Optic Systems . -
Page 6: About The Python 3G System
About Python 3G About the Python 3G System About the Python 3G System The Python 3G transmitter multiplexes a number of HD/SDI signals into a fiber optic transport stream. The number of signals can be 4, 8, 12, or 16 – always in multiples of four. Similarly, the Python 3G receiver de-multiplexes a corresponding number of fiber optic signals into HD/SDI. -
Page 7: Fiber Cable Overview
Python 3G User Guide • 270 Mb/s DVB/ASI (re-clocked) • 19.4 Mb/s ATSC: SMPTE 310M • Non-standard digital signals to 3 Gb/s The unit is interoperable with industry standard optical HD/SDI signals to/from other equipment, such as Rattler™, Diamondback™, SHED™, HDX™, and Viper™ series frames and modules, as well as other manufacturers' routers, DAs, etc. -
Page 8: Unpacking The Python 3G
In the unlikely event of damage to your Python 3G during shipping or delivery, take note of any damage with the delivery or shipping service. If any component does not work correctly out of the box, please contact Grass Valley Fiber Solutions service (Contact Us page 49). -
Page 9: Safety And Fiber Optic Systems
There are no manual adjustments to make inside the Python 3G. Do not attempt any type of service on this instrument, other than any procedures as instructed in this Guide. Refer all servicing to the Fiber Solutions division of Grass Valley (see Contact Us on page 49). - Page 10 About Python 3G FCC Part A Manual Notice...
-
Page 11: Hardware And Block Diagrams
Hardware and Block Diagrams This chapter lists the models available with the Python 3G and lists the block diagrams of these models. Available Models ..............8 Block Diagrams . -
Page 12: Available Models
Hardware and Block Diagrams Available Models Available Models The Python 3G is available in a variety of standard models. The following list covers the models available at the time of publication. Please see Understanding Python 3G Model Numbers on page 43 for an explanation of how to understand Python 3G Model Numbers. The Python 3G may contain as many as 16 HD/SDI BNC Connectors on the front panel and as many as 16 ST Fiber Optic cable connectors on the rear panel. - Page 13 Python 3G User Guide HD/SDI HD/SDI CWDM Number of Part Number Type Transmit Receive Equipped Fibers PY3-GHJR-W16 Transceiver PY3-GHGR-W8W8 Transceiver PY3-AAR0-ST12 Transceiver PY3-AARR-ST16 Transceiver PY3-AR00-ST8 Transceiver PY3-HRRR-W8W8 Transceiver PY3-GHRR-W8W8 Transceiver PY3-A0RR-ST12 Transceiver PY3-KRRR-W16 Transceiver PY3-GR00-W8 Transceiver PY3-HR00-W8 Transceiver The following Python 3G Models are Operated as a Matched Pair PY3-G000-W41 Transmitter PY3-R000-W41...
- Page 14 Hardware and Block Diagrams Available Models HD/SDI HD/SDI CWDM Number of Part Number Type Transmit Receive Equipped Fibers PY3-JKRR-W16 Transceiver Table. 2-1: Python 3G Available Models...
-
Page 15: Block Diagrams
Python 3G User Guide Block Diagrams PY3-AA00-ST4 Fig. 2-2: 4 Channels Python 3G on 4 Fibers Block Diagram... -
Page 16: Py3-Aa00-St8 /Py3-Rr00-St8
Hardware and Block Diagrams PY3-AA00-ST8 /PY3-RR00-ST8 PY3-AA00-ST8 /PY3-RR00-ST8 Fig. 2-3: 8 Channels Python 3G on 8 Fibers Block Diagram... -
Page 17: Py3-Ar00-St8
Python 3G User Guide PY3-AR00-ST8 Fig. 2-4: 4x4 Channels Python 3G on 8 Fibers Block Diagram... -
Page 18: Py3-Aar0-St12 / Py3-Rra0-St12
Hardware and Block Diagrams PY3-AAR0-ST12 / PY3-RRA0-ST12 PY3-AAR0-ST12 / PY3-RRA0-ST12 Fig. 2-5: 8x4 Channels Python 3G on 12 Fibers Block Diagram... -
Page 19: Py3-Aaaa-St16 / Py3-Rrrr-St16
Python 3G User Guide PY3-AAAA-ST16 / PY3-RRRR-ST16 Fig. 2-6: 16 Channels Python 3G on 16 Fibers Block Diagram... -
Page 20: Py3-Aarr-St16
Hardware and Block Diagrams PY3-AARR-ST16 PY3-AARR-ST16 Fig. 2-7: 8x8 Channels Python 3G on 16 Fibers Block Diagram... -
Page 21: Py3-G000-W41/Py3-R000-W41
Python 3G User Guide PY3-G000-W41/PY3-R000-W41 Fig. 2-8: 4 Channels Python 3G on 1 Fiber Block Diagram... -
Page 22: Py3-Gh00-W8/Py3-Rr00-W8
Hardware and Block Diagrams PY3-GH00-W8/PY3-RR00-W8 PY3-GH00-W8/PY3-RR00-W8 Fig. 2-9: Eight Channels Python 3G on 1 Fiber Block Diagram... -
Page 23: Py3-Gr00-W8/Py3-Hr00-W8
Python 3G User Guide PY3-GR00-W8/PY3-HR00-W8 Fig. 2-10: 4x4 Channels Python 3G on 1 Fiber Block Diagram... -
Page 24: Py3-Ghjk-W16/Py3-Rrrr-W8
Hardware and Block Diagrams PY3-GHJK-W16/PY3-RRRR-W8 PY3-GHJK-W16/PY3-RRRR-W8 Fig. 2-11: 16 Channels Python 3G on 1 Fiber Block Diagram... -
Page 25: Py3-Ghrr-W8W8
Python 3G User Guide PY3-GHRR-W8W8 Fig. 2-12: 8x8 Channels Python 3G on 2 Fibers Block Diagram... -
Page 26: Py3-Ghrr-W16/Py3-Jkrr-W16
Hardware and Block Diagrams PY3-GHRR-W16/PY3-JKRR-W16 PY3-GHRR-W16/PY3-JKRR-W16 Fig. 2-13: 8x8 Channels Python 3G on 1 Fiber Block Diagram... -
Page 27: Python 3G Components
Python 3G Components This chapter describes the main components of the Python 3G. Python 3G Models ..............24 Python 3G Front Panel . -
Page 28: Python 3G Models
Python 3G Components Python 3G Models Python 3G Models For illustration purposes, the following models will be included: HD/SDI HD/SDI CWDM Number of Part Number Type Transmit Receive Equipped Fibers PY3-R000-ST4 Receiver PY3-A000-ST4 Transmitter PY3-AR00-ST8 Transceiver PY3-GR00-W8 Transceiver Matched Pair PY3-R000-W41 Receiver PY3-G000-W41... -
Page 29: Python 3G Front Panel
Python 3G User Guide Python 3G Front Panel The composition of the Python 3G front panel will vary depending on whether the unit is a receiver, transmitter or transceiver. Identify the particular Python 3G unit of interest and then go to the page indicated. Power and Display Panel Fig. -
Page 30: Area A - Sdi/Data In
Python 3G Components Python 3G Receiver Area A – SDI/DATA IN Fig. 3-6: SDI/DATA Input ports The Python 3G Transmitter has four SDI/DATA In BNC Connectors. All four inputs operate identically,but CWDM models are multiplexed for transmission on the fiber output of the unit for demultiplexing to the four SDI outputs on the receiving unit. -
Page 31: Area A - Sdi/Data Out
Python 3G User Guide Area A – SDI/DATA OUT Fig. 3-8: 4 SDI/DATA Output BNC Connectors The Python 3G Receiver has four SDI/DATA Output BNC Connectors. All four Outputs operate identically. • On units without CWDM, the four outputs correspond to the four Fiber Optic inputs on the back panel. -
Page 32: Python 3G Transceiver
Python 3G Components Python 3G Transceiver Python 3G Transceiver Thefollowing model is the PY3-AR00-ST8 with four SDI/Data inputs and four SDI/Data outputs. The inputs are converted to four fiber outputs and the outputs are converted from four fiber inputs. The number of BNC connectors corresponds to the type model: •... -
Page 33: Area B - Sdi/Data Out
Python 3G User Guide Area B – SDI/DATA OUT Fig. 3-11: 4 SDI/DATA Output BNC Connectors The Python 3G Transceiver has four SDI/DATA Output BNC Connectors. All four Outputs operate identically. • On units without CWDM, the four outputs correspond to the four Fiber Optic inputs on the back panel. -
Page 34: Python 3G Rear Panel
Python 3G Components Python 3G Rear Panel Python 3G Rear Panel The composition of the Python 3G front panel will vary depending on whether the unit is a receiver, transmitter or transceiver. It will also vary depending on whether the unit is a CWDM unit or a one for one SDI to Fiber conversion unit. -
Page 35: Python 3G Receiver Rear Panel With Cwdm
Python 3G User Guide Python 3G Receiver Rear Panel with CWDM The following model is the PY3-R000-W41 with a single ST input. Fig. 3-15: Python 3G Receiver Rear Panel with CWDM Python 3G Transceiver Rear Panel without CWDM The following model is the PY3-AR00-ST8 with four ST outputs and four ST inputs. Fig. -
Page 36: Python 3G Units With Cwdm And Fiber Capability (Dual Input/Output)
Python 3G Components Python 3G Units with CWDM and Fiber Capability (Dual Input/Output) Python 3G Units with CWDM and Fiber Capability (Dual Input/Output) Two available models provide internal primary and backup for sixteen channels. • The transmitter provides duplicate output of up to 16 SDI/Data signals. •... - Page 37 Python 3G User Guide The Python 3G Transmitter equipped with primary and secondary Fiber Optic outputs utilizes an Optical Splitter (D) to take the 16 Channel CWDM signal and split the signal into two equal 16 channel outputs. Fig. 3-20: Python 3G Receiver with Primary and Backup Inputs The Python 3G Receiver equipped with primary and secondary Fiber Optic inputs utilizes an Optical Switch to detect which of the incoming Fiber Optic signals is best.
-
Page 38: Python 3G Rear Panel Operation
Python 3G Components Python 3G Rear Panel Operation Python 3G Rear Panel Operation The Python 3G illustration is repeated for ease of use of this Guide. Note that all Python 3G units operate in the same manner: the only difference is in whether the Fiber Optic ST connectors are inputs or outputs. -
Page 39: Area B - Can Bus Connector
Python 3G User Guide Area B – CAN BUS Connector Fig. 3-23: CAN BUS connector The CAN BUS connector is inactive in this version of the Python 3G. It may be used for system monitoring in the future. CAN is an acronym for Communication Area Network and is a protocol designed to support the monitoring of microcontrollers. -
Page 40: Fiber Adap Power Supplies
ADAP-AC-04-X (X being the specific geography required). Any power supply meeting the required specification and providing power through an XLR-4 Female connector can be used. Please contact Grass Valley (Contact Us on page 49) or your authorized dealer for more information. -
Page 41: Python 3G Operation
Python 3G Operation This chapter describes the operation of the Python 3G. Please keep in mind that once the system is properly set up and configured, there is very little to do during normal operation. Fiber Optical Channel Monitoring ........... . 38 Using the Python 3G Optical Measurement Display . -
Page 42: Fiber Optical Channel Monitoring
Python 3G Operation Fiber Optical Channel Monitoring Fiber Optical Channel Monitoring The Python 3G provides direct digital readout of the Fiber Optic Link signal strength for signals received at the unit. This readout is presented in units of dBm. It is useful to understand both the dB or decibel and the dBm or decibel referenced to one milliwatt. -
Page 43: Using The Python 3G Optical Measurement Display
Python 3G User Guide Using the Python 3G Optical Measurement Display The optical measurement functionality is similar across all three types of Python 3G. A transceiver, transmitter, and receiver work identically with one exception. The system reports fiber optical strength only for fiber optic signals received at a unit. Transmission strength is not measured. -
Page 44: Condition 1: No Optical Link
Python 3G Operation Python 3G Optical Measurement Display Condition 1: No Optical Link If there is no optical link on a particular channel the display will show n/A for not available. Fig. 4-2: No Optional Link Display Condition 2 – Optical Link good but no SDI data present. When an optical link is active, but no SDI data present, the optical power reading will change between a high and low value, such as -7 and -30. -
Page 45: System Firmware Display
Python 3G User Guide System Firmware Display The Python 3G display will display the current firmware version when the unit is powered On. This appears in the display as a scrolling series of alphanumeric character four characters wide. Fig. 4-4: Firmware display Technical Information Display Flicking the CHAN SEL switch to the left provides additional technical information that identifies the specific physical channel that is being measured. -
Page 46: Best Practices
Python 3G Operation Best Practices Best Practices This section is devoted to a number of “Best Practices” for use of the Python 3G System. • Take every precaution to prevent damaging your eyes while using the equipment. • Protect the Fiber Optic Cable and the Fiber Optic Connectors. Always keep these capped unless there are being connected. -
Page 47: Understanding Python 3G Model Numbers
Understanding Python 3G Model Numbers This chapter explains how to decode the Python 3G Part Number. Sample part numbers are decoded at the end of this section. Part Numbers ............... . 44 Example Python 3G Models . -
Page 48: Part Numbers
Understanding Python 3G Model Numbers Part Numbers Part Numbers The Python 3G part number consists of three sections as described below: Fig. 5-1: Python 3G part number • A - The product designation – in this case PY3 stands for Python 3G •... -
Page 49: Fiber I/O Cards
Python 3G User Guide Fiber I/O Cards Desig. Usage Type Wavelength Receive or Transmit 4 – Fiber I/O Receive or Transmit 8 – Fiber I/O ST12 Receive or Transmit 12 – Fiber I/O ST16 Receive or Transmit 16 – Fiber I/O Receive or Transmit 1 –... -
Page 50: Example Python 3G Models
Understanding Python 3G Model Numbers Example Python 3G Models Example Python 3G Models Model PY3-RRR0-W83W43 – Receiver with 12 Channels equipped with CWDM and 2 Fibers I/O Position Item Description Card Slot #1 4 straight-through conversion channels Card Slot #2 4 straight-through conversion channels Card Slot #3 4 straight-through conversion channels... -
Page 51: Specifications
Specifications Video Transmission Method....................... Digital Input Level....................800 mV (Peak To Peak) Input/Output Impedance..................75 Ohms Return Loss ..................>15 dB, 5 Mhz To 1.5 Ghz ......................>10 dB, 1.5 Ghz To 3 Ghz Coaxial Input Equalization Maximum Rate ....................... 3 Gb/S Equalization At 3 Gb/S.............. - Page 52 Specifications...
- Page 53 Contact Us Grass Valley Technical Support For technical assistance, please contact the Grass Valley Technical Support center nearest you: Americas Asia Office hours: 9:00 a.m. – 9:00 p.m. (EST) Office hours: 9:00 a.m. – 6:00 p.m. (GMT+8) Telephone: 1-800-224-7882 Telephone:...
