Operation Manual - Port
Quidway S3000-EI Series Ethernet Switches
Chapter 1 Ethernet Port Configuration ....................................................................................... 1-1
1.1 Ethernet Port Overview...................................................................................................... 1-1
1.2 Ethernet Port Configuration ............................................................................................... 1-2
1.2.1 Enter Ethernet port view.......................................................................................... 1-2
1.2.2 Enable/Disable Ethernet Port.................................................................................. 1-2
1.3 Set Description Character String for Ethernet Port............................................................ 1-3
1.3.1 Set Duplex Attribute of the Ethernet Port................................................................ 1-3
1.3.2 Set Speed on the Ethernet Port .............................................................................. 1-4
1.3.3 Set Cable Type for the Ethernet Port...................................................................... 1-4
1.3.4 Enable/Disable Flow Control for Ethernet Port ....................................................... 1-5
1.3.5 Set Ethernet Port Broadcast Suppression Ratio..................................................... 1-5
1.3.6 Set link type for Ethernet port.................................................................................. 1-6
1.3.7 Add the Ethernet port to Specified VLANs.............................................................. 1-6
1.3.8 Set the Default VLAN ID for the Ethernet Port........................................................ 1-7
1.3.9 Set loopback detection for the Ethernet port........................................................... 1-8
1.3.10 Set the Time Interval of Calculating Port Statistics Information............................ 1-9
1.3.11 Port Traffic Threshold Configuration ..................................................................... 1-9
1.4 Display and Debug Ethernet Port .................................................................................... 1-11
1.5 Ethernet Port Configuration Example .............................................................................. 1-11
1.6 Ethernet Port Troubleshooting......................................................................................... 1-12
Chapter 2 Link Aggregation Configuration ................................................................................ 2-1
2.1 Link Aggregation Overview................................................................................................ 2-1
2.2 Link Aggregation Configuration ......................................................................................... 2-1
2.2.1 Aggregate Ethernet Ports........................................................................................ 2-1
2.3 Display and Debug Link Aggregation ................................................................................ 2-2
2.4 Link Aggregation Configuration Example .......................................................................... 2-2
2.5 Ethernet Link Aggregation Troubleshooting ...................................................................... 2-3
Table of Contents
Huawei Technologies Proprietary
i
Table of Contents
Advertisement
Table of Contents
Related Manuals for Quidway S3000-EI Series
Summary of Contents for Quidway S3000-EI Series
-
Page 1: Table Of Contents
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Table of Contents Table of Contents Chapter 1 Ethernet Port Configuration ..................1-1 1.1 Ethernet Port Overview...................... 1-1 1.2 Ethernet Port Configuration ....................1-2 1.2.1 Enter Ethernet port view..................1-2 1.2.2 Enable/Disable Ethernet Port.................. 1-2 1.3 Set Description Character String for Ethernet Port............ -
Page 2: Chapter 1 Ethernet Port Configuration
100Base-T single mode/multi-mode optical interface module, one-port 100Base-FX single mode medium haul optical interface module, one-port 100Base-T SFP interface module, and one-port gigabit GBIC interface module. S3000-EI Series Ethernet Switches support the followi ng Ethernet port features: 10/100Base-T Ethernet port supports MDI/MDI-X auto-sensing. It operates i half-duplex, full-duplex, or auto-negotiation modes. -
Page 3: Ethernet Port Configuration
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration (auto-negotiation) and its speed can be set to 100 (100Mbps) and auto (auto-negotiation). Gigabit Ethernet port operates in gigabit full-duplex mode. The operating mode can be set to full (fu ll-duplex) and auto (auto-negotiation) and its speed can be set to 1000 (1000Mbps) and auto (auto-negotiation). -
Page 4: Set Description Character String For Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration enable the port. If you do not want a port to forward data any more, use the command to disable it. Perform the following configuration in Ethernet port view. -
Page 5: Set Speed On The Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration Note that, 100M electrical Ethernet port can operate in full-duplex, half-duplex or auto-negotiation mode , which can be set as per the requirement he optical 100M/Gigabit Ethernet ports su... -
Page 6: Enable/Disable Flow Control For Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration Table 1-6 Set the type of the cable connected to the Ethernet port Operation Command Set the type of the cable connected to mdi { across | auto | normal } the Ethernet port. -
Page 7: Set Link Type For Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration Table 1-8 Set Ethernet port broadcast suppression ratio Operation Command Set Ethernet port broadcast suppression ratio broadcast-suppression ratio Restore the default Ethernet port broadcast undo broadcast-suppression... -
Page 8: Set The Default Vlan Id For The Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration erform the following configuration in Ethernet port view able 1-10 Add the Ethernet port to specified VLANs Operation Command Add the current access port to a... -
Page 9: Set Loopback Detection For The Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration Operation Command Restore the default VLAN ID of the hybrid undo port hybrid pvid port to the default value Restore the default VLAN ID of the trunk port... -
Page 10: Set The Time Interval Of Calculating Port Statistics Information
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration Operation Command Configure that the system p erforms loopback loopback -detection p er-vlan detection to all VLANs on Trunk and Hybrid ports enable (Ethernet port view) - Page 11 Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration I. Port Traffic Threshold Configuration Task Table 1-14 Port traffic threshold configuration task Item Command Remarks Enter system view <Quidway> system-view – Enter Ethernet port [Quidway] interface { interface_type –...
-
Page 12: Display And Debug Ethernet Port
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 1 Ethernet Port Configuration 1.4 Display and Debug Ethernet Port After the above configuration, execute display comm and in any view to display the running of the Ethernet port con figuration, and to verify the effect of the configuration. -
Page 13: Ethernet Port Troubleshooting
VLAN 2, 6 through 50, and 100 to pass through. [Quidway-Ethernet0/18] port link-type trunk [Quidway-Ethernet0/18] port trunk permit vlan 2 6 to 50 100 # Create the VLAN 100. [Quidway] vlan 100 # Configure the default VLAN ID of Ethernet0/18 as 100. -
Page 14: Chapter 2 Link Aggregation Configuration
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 2 Link Aggregation Configuration Chapter 2 Link Aggregation Configuration 2.1 Link Aggregation Overview The link aggregation means aggregating several ports together to implement the outgoing/incoming payload balance among the member ports and enhance the connection reliability. -
Page 15: Display And Debug Link Aggregation
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 2 Link Aggregation Configuration Table 2-1 Aggregating Ethernet ports Operation Command link-aggregation port_num1 to port_num2 { both | Aggregate Ethernet ports ingress } Remove a configured link undo lin k-aggregation { master_port_num | all }... -
Page 16: Ethernet Link Aggregation Troubleshooting
Operation Manual - Port Quidway S3000-EI Series Ethernet Switches Chapter 2 Link Aggregation Configuration II. Networking diagram Switch B Link aggregation Switch A Switch C Figure 2-1 Configure link aggregation III. Configuration procedure The following configurations are used for Switch A, pl ease configure Switch B in the similar way to activate aggregation.
