- Page 1 XV0500 Video MCU User's Guide Xorcom multi-point video conferencing stand-alone solution Doc. Version: 2.1.2.8 Xorcom Ltd. www.xorcom.com ● P.O. Box 60, Misgav Industrial Park 20174 ● Tel: +972 4 995-1999 ●...
-
Page 2: Table Of Contents
XV0500 Video MCU Communication Scheme ..................... 5 Methods to Call the MCU ..........................5 PBX Users Call the XV0500 via a SIP Trunk ...................... 6 PBX Users Call the MCU Just Like Regular IP-PBX SIP Extensions ..............7 Users Call the XV0500 Video MCU Directly ..................... 7 IP Settings ................................ - Page 3 Appendix A: How to change MCU-DSP IP settings .................... 27 Appendix B: How to obtain/configure IP address by using a keyboard and a display monitor ......28 Appendix C: XV0500 video MCU endpoint interoperability chart ..............30 Xorcom Ltd. www.xorcom.com...
-
Page 4: Product Description
• VIP Participants: The XV0500 Video MCU allows pre-defined VIP participants to join a conference without requiring PIN code authentication. • Registration on a SIP Server: As an optional feature, the XV0500 Video MCU can register the access numbers and/or conference room numbers on a SIP server. In addition, SIP clients can optionally register on the MCU built-in SIP server. -
Page 5: Xv0500 Video Mcu Communication Scheme
Methods to Call the MCU It is possible to make SIP calls to XV0500 directly or via another SIP server (e.g. IP-PBX). When the MCU-CS receives a call then it behaves as described in the table below: Called number... -
Page 6: Pbx Users Call The Xv0500 Via A Sip Trunk
• there is a conference defined as 100 PBX Users Call the XV0500 via a SIP Trunk In the PBX configuration it is possible to define a SIP trunk for the XV0500 and one or more outbound routes for that trunk. -
Page 7: Pbx Users Call The Mcu Just Like Regular Ip-Pbx Sip Extensions
IP-PBX extension. PBX Users Call the MCU Just Like Regular IP-PBX SIP Extensions a) Define a SIP IP-PBX extension for each access number and a conference number the XV0500 should register. b) Enable the corresponding access number and/or conference number registration in the XV0500 configuration. -
Page 8: Ip Settings
172.16.200.2. In order to change the address the board must be connected via the RS-232 interface. Please refer to Appendix A: How to change MCU-DSP IP Settings for further details. IP Settings of the XV0500 The table below contains the default IP settings of XV0500: Interface name Parameters eth0 DHCP eth1 IP address: 172.16.200.1... -
Page 9: Configuring The Mcu-Cs Ip Settings
Configuring the MCU-CS IP Settings The MCU-CS automatically uses the XV0500 IP settings. If the XV0500 IP addresses and/or the MCU-DSP address have been changed, then it will be necessary to reboot the server in order for the MCU-CS to use the new settings. -
Page 10: System Settings
XV0500 Video MCU User's Guide Page 10 of 30 Select the desired category in the horizontal menu located in the upper section of the screen. Each category has its own vertical menu. Before starting to set up a conference, the system parameters should be configured. -
Page 11: Network Settings
XV0500 Video MCU User's Guide Page 11 of 30 Note: To ensure the system's security, before starting to use the XV0500 Video MCU it is highly recommended to change the default user name and password. Network Settings (SYSTEM SETTINGS / NETWORK SETTINGS) You can change the XV0500 eth0 interface IP settings here. - Page 12 Parameter Values Description Enable Registrar / Check-box If this box is checked then XV0500 can be used as a registrar for SIP clients. Proxy (Yes/No) Listening SIP Port Port This is XV0500’s built-in listening SIP port, used for registration of SIP clients and session establishments.
- Page 13 XV0500 Video MCU User's Guide Page 13 of 30 Parameter Values Description Registrar IP/ Domain IP address The external registrar IP address or domain name Name Registrar Port Port The external registrar SIP port Use REGISTER Au- Check-box Indicates whether the registration requires authentication.
- Page 14 XV0500 Video MCU User's Guide Page 14 of 30 Show Users You can view the MCU’s SIP users. To view the users: Click the Show Users button. The following window is displayed: Figure 0 -2: Show Users Window The columns on this screen can be sorted in ascending or descending order by clicking on any of the column headers.
-
Page 15: Access Numbers
Access Numbers (SYSTEM SETTINGS / ACCESS NUMBERS) There are two ways to join a conference on the XV0500 Video MCU: a) create a SIP call to one of the “access numbers” pre-configured in the MCU. The caller will be prompted to enter a conference number and then, optionally, the PIN number. -
Page 16: Date/Time Settings
XV0500 Video MCU User's Guide Page 16 of 30 For example, if you set “Video Quality” as “Normal” (CIF) for a specific access number and the video conference video quality is defined as “HD” (720p), then all users who access the video conference via the access number will be limited to CIF resolution. -
Page 17: Maintenance
XV0500 Video MCU User's Guide Page 17 of 30 Maintenance (SYSTEM SETTINGS / MAINTENACE) The following maintenance actions can be performed: View System Status – Provides the status of system components, and general system information including CPU usage, free, and total memory. -
Page 18: Software Upgrade
XV0500 Video MCU User's Guide Page 18 of 30 3. After saving the file, Delete Diagnostic Trace, appears on the main Maintenance screen, allowing the user to delete the file. Only one trace file is allowed. To provide a new trace file, the existing file must be deleted. -
Page 19: Conference Management
XV0500 Video MCU User's Guide Page 19 of 30 Conference Management Once the system parameters have been defined, a user can set up a conference. Click “CONFERENCES” on the menu bar. The list of the currently running conferences will be displayed:... - Page 20 XV0500 Video MCU User's Guide Page 20 of 30 Add, remove and edit conferences on this page. Click the “Create a new conference” icon in order to configure a new conference. Define the conference parameters: After entering the parameters, click to save the input.
-
Page 21: Conference Roles
XV0500 Video MCU User's Guide Page 21 of 30 Parameter Values Description Max Shown Participants Number Up to 16, for equal based layouts; up to 8 for dominant based. Meeting room number Number The number of the meeting room PIN Required? -
Page 22: Mcu Monitoring
XV0500 Video MCU User's Guide Page 22 of 30 MCU Monitoring In order to get monitoring information for the conference, click on “Conference” and choose “Summary”. The following screen appears, listing all current ongoing conferences in the system: For more details about each conference, click on . -
Page 23: Main Screen
XV0500 Video MCU User's Guide Page 23 of 30 Main Screen On the main screen of the Leader Dashboard the meeting information, conference participants list, and the parameters for each participant are displayed. The icons displayed on the Leader Dashboard are as follows:... -
Page 24: Inviting Participants
XV0500 Video MCU User's Guide Page 24 of 30 Inviting Participants 1. Click The Invite Participants window opens: 2. Enter one of the following: A PBX extension. It is possible only if there is a SIP trunk between the PBX and MCU-CS (ref. -
Page 25: Show Statistics
XV0500 Video MCU User's Guide Page 25 of 30 One of two layouts can be chosen: Dominant* based: The dominant speaker’s image is larger than the other participants’ images. Equal Presence: All the images are displayed equally. * The dominant speaker is automatically defined by energetic voice detection. - Page 26 XV0500 Video MCU User's Guide Page 26 of 30 Click on Restore Default to restore the original rows settings. Xorcom Ltd. www.xorcom.com ● P.O. Box 60, Misgav Industrial Park 20174 ● Tel: +972 4 995-1999 ●...
-
Page 27: Appendix A: How To Change Mcu-Dsp Ip Settings
XV0500 Video MCU User's Guide Page 27 of 30 Appendix A: How to change MCU-DSP IP settings Changing the IP address is performed via serial connection (i.e. HyperTerminal in Windows or Minicom in Linux). Note! The MCU-DSP card has built-in RS-232/USB adapter. When the MCU-DSP card is connected for the first time to a PC by the USB cable, the system recognizes a new USB device and the user needs to install a driver for it. -
Page 28: Appendix B: How To Obtain/Configure Ip Address By Using A Keyboard And A Display Monitor
XV0500 Video MCU User's Guide Page 28 of 30 Appendix B: How to obtain/configure IP address by using a keyboard and a display monitor Connect a keyboard and a display monitor. Login to system as follows: User name: root Password: akuo-kfo Note: The default system keyboard configuration is U.S. - Page 29 XV0500 Video MCU User's Guide Page 29 of 30 NETMASK=255.255.255.0 ONBOOT=yes TYPE=Ethernet To define the eth1 interface, then: cat> /etc/sysconfig/network-scripts/ifcfg-eth1 <<EOF DEVICE=eth1 BOOTPROTO=static IPADDR=172.16.200.1 NETMASK=255.255.0.0 ONBOOT=yes TYPE=Ethernet Define the default gateway in the /etc/sysconfig/network file: GATEWAY=192.168.0.1 Define the DNS server in the /etc/resolv.conf file: nameserver 192.168.0.1...
-
Page 30: Appendix C: Xv0500 Video Mcu Endpoint Interoperability Chart
XV0500 Video MCU User's Guide Page 30 of 30 Appendix C: XV0500 video MCU endpoint interoperability chart For the current list of interoperable endpoints please refer to the Xorcom Web site. Xorcom Ltd. www.xorcom.com ● P.O. Box 60, Misgav Industrial Park 20174 ● Tel: +972 4 995-1999 ●...
