Eiconcard™ Family

Installation Guide

for PCI and PCI Express Compatible Bus

www.dialogic.com

Table of Contents

Need help?

Do you have a question about the Eiconcard Family and is the answer not in the manual?

Questions and answers

Summary of Contents for Dialogic Eiconcard Family

Page 1 Eiconcard™ Family Installation Guide for PCI and PCI Express Compatible Bus www.dialogic.com...
Page 2 All contents of this document are furnished for informational use only and are subject to change without notice and do not represent a commitment on the part of Dialogic Corporation or its subsidiaries ("Dialogic"). Reasonable effort is made to ensure the accuracy of the information contained in the document.
Page 3 • Each end user to whom a Licensed System is distributed must agree to license terms with respect to the Program that are at least as protective of Dialogic's rights in the Program as those set forth in this Agreement;...
Page 4 Limited Warranty Dialogic solely warrants the media on which the Program is furnished to You to be free from defects in materials and workmanship under normal use for a period of ninety (90) days from the date of purchase by You as evidenced by a copy of Your receipt. If such a defect appears...
Page 5 The waiver or failure of Dialogic to exercise in any respect any right provided for herein shall not be deemed a waiver of any further right hereunder. All rights and remedies, whether conferred hereunder or by any other instrument or law, will be cumulative and may be exercised singularly or concurrently.
Page 6 Dialogic's legal department at the address below or such other address as may be listed on www.dialogic.com from time to time as being Dialogic's Montreal headquarters. U.S. Government Restricted Rights The Program and all accompanying documentation are provided with RESTRICTED RIGHTS.
Page 7: Table Of Contents
Contents Introduction ..............9 Eiconcard C series ..............9 Eiconcard S series ..............9 Installing the Eiconcard ..........11 Making an ISDN connection ........... 14 In Europe and most countries worldwide ........14 In North America and other countries ......... 14 Termination ................
Page 8 Technical specifications Eiconcard S series ............39 Technical data ................. 39 Hardware installation..............39 Performance................39 Environmental requirements............39 External interface ..............40 VHSI ports ................40 Power requirements ..............40 Power consumption ..............40 International regulatory information ......41 Regulatory information for the USA ..........
Page 9: Introduction
Eiconcard™ Family Installation Guide Introduction ® This booklet describes the Dialogic Eiconcard™ C and S series interface cards. All Eiconcards have been tested and found to comply with the Electromagnetic compatibility, Safety and Network connection regulations within the European Union, North America, and other major territories.
Page 10 Introduction and an ISDN BRI port, supporting line speeds up to 2 Mbps (T1/E1) and 128 kbps respectively. The Eiconcard S Series allows you to connect using WAN protocols such as X.25, Frame Relay, PPP, SDLC and HDLC, over leased lines, dial-up lines or ISDN lines.
Page 11: Installing The Eiconcard
Eiconcard™ Family Installation Guide Installing the Eiconcard If you want the Eiconcard to be available to multiple users on a LAN, install it in the computer that will function as a gateway for the LAN. 1 Prepare the computer Turn off the computer and disconnect its power cable. Wait at least 30 seconds to ensure that all power has drained from the system.
Page 12 Installing the Eiconcard Bracket retaining screw Bracket jackposts c) Insert the Eiconcard into the slot and fasten it with a screw. 3 Test the Eiconcard The application software available for the Eiconcard contains a test program to verify the Eiconcard’s integrity. Consult the documentation supplied with this software for details.
Page 13 Eiconcard™ Family Installation Guide 4 Configure the Eiconcard Before you can use the Eiconcard, you must configure it to work with your communications software. Consult the documentation supplied with this software for complete instructions on how to configure the Eiconcard. 5 Connect to your external line You are now ready to connect the Eiconcard to your external line.
Page 14: Making An Isdn Connection
In other countries, the NT1 must be installed at your premises, either by you or your ISDN provider. You can order an NT1 from Dialogic or from another supplier. In Europe and most countries worldwide...
Page 15: Termination
Eiconcard™ Family Installation Guide Termination This section provides instructions to help set up termination scenarios for installations in Australia and North America. Termination requirements vary according to the number of ISDN devices connected to the NT1 and the distance between the ISDN devices and the NT1.
Page 16: Making A Vhsi Connection
VHSI cables The following table lists the most common connections supported by the VHSI port, and specifies the part number of the required Dialogic cable. For information on making your own cables, see “VHSI port specifications” on page 21. Interface...
Page 17: Making A V.24 Connection
V.24 cables The following table lists the most common connections supported by the V.24 port, and specifies the part number of the required Dialogic cable. For information on making your own cables, see “V.24 port specifications” on page 36. Connection...
Page 18: Status Lights
Status lights Eiconcard C90, C91 S/T, C91 V2, and C91 PCIe LP Status lights Eiconcard C90, C91 S/T, C91 V2, and C91 PCIe LP ISDN D-channel Status (Eiconcard C91 S/T, C91 V2, and C91 PCIe LP only) The D-channel controls the link to your ISDN service provider.
Page 19: Status Lights Eiconcard S91 S/T And S91 V2
Eiconcard™ Family Installation Guide Status Lights Eiconcard S91 S/T and S91 V2 ISDN D-channel status The D-channel controls the link to your ISDN service provider. Off ..The line is not active. The cable may not be connected. Blinking ..The line is active, but a link cannot be established.
Page 20: Eiconcard S90, S92, S94, S94/66 Mhz, S94 V2, And S94 Pcie
Status Lights Eiconcard S90, S92, S94, S94/66 MHz, S94 V2, and S94 PCIe Status Lights Eiconcard S90, S92, S94, S94/66 MHz, S94 V2, and S94 PCIe Configuration status This status light illuminates when the Eiconcard and/or port is being configured. Consult the documentation provided with the configuration software for information about this status light.
Page 21: Vhsi Port Specifications
Eiconcard™ Family Installation Guide VHSI port specifications Each interface on the VHSI port is compliant with the standards listed in Table 1. The rest of this section describes the pinouts that are used to implement the electrical and signaling requirements of each interface.
Page 22: Cable Construction Information
VHSI port specifications Cable construction information If you plan to construct your own VHSI cables, be sure to observe the guidelines given below. Wire gauge, grounding, and pairing • Use 28 AWG 7-strand wire with 0.020 - 0.028" insulation. • The chassis must be grounded both by a drain wire and by the braid;...
Page 23: Dce Interface
Eiconcard™ Family Installation Guide V.24 DCE interface A pin-out diagram for the V.24 PG N D DCE interface is shown in Figure 1. The signal definitions TCLK and names are listed in Table 3. RCLK TEST SG N D DTECLK Figure 1.
Page 24 VHSI port specifications VHSI—V.24 connections The wiring diagram in Figure 2 shows the connections required to construct a VHSI—V.24 DCE cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. VHSI V.24 DRAIN WIRE BRAID Figure 2.
Page 25: Dte Interface
Eiconcard™ Family Installation Guide V.24 DTE interface A pin-out diagram for the V.24 PGND DTE interface is shown in Figure 3. The signal definitions RCLK and names are listed in Table 4. RCLK SGND DTECLK Figure 3. V.24 DTE interface Pin # Signal Name...
Page 26 VHSI port specifications VHSI—V.24 connections The wiring diagram in Figure 4 shows the connections required to construct a VHSI—V.24 DTE cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. VHSI V.24 DRAIN WIRE BRAID Figure 4.
Page 27: Interface
Eiconcard™ Family Installation Guide V.35 interface A pin-out diagram for the V.35 SGND P G N D C T S interface is shown in Figure 5. R T S D C D The signal definitions and names are listed in Table 5. D T R TEST T X D+...
Page 28 VHSI port specifications VHSI—V.35 connections The wiring diagram in Figure 6 shows the connections required to construct a VHSI—V.35 cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. TWISTED PAIRS (MANDATORY) VHSI V.35 DRAIN WIRE BRAID...
Page 29: Eia-530 Interface
Eiconcard™ Family Installation Guide EIA-530 interface PG ND TXD- A pin-out diagram for the TXD+ TRXC+ EIA-530 interface is shown in RXD+ RXD- Figure 7. The signal definitions RTS+ RTXC+ and names are listed in Table 6. CTS+ TEST DSR+ RTS- SG N D DTR+...
Page 30 VHSI port specifications VHSI—EIA-530 connections The wiring diagram in Figure 8 shows the connections required to construct a VHSI—EIA-530 cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. TWISTED PAIRS (MANDATORY) VHSI EIA-530 DRAIN WIRE BRAID...
Page 31: V.36/Rs-449 Interface
Eiconcard™ Family Installation Guide V.36/RS-449 interface A pin-out diagram for the PG N D TXD+ V.36/RS-449 interfaces is shown TXD- TRXC+ TRXC- in Figure 9. The signal definitions RXD+ RXD- RTS+ and names are listed in Table 7. RTS- RTXC+ RTXC- CTS+ CTS-...
Page 32 VHSI port specifications VHSI—V.36/RS-449 connections The wiring diagram in Figure 10 shows the connections required to construct a VHSI—V.36/RS-449 cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. TWISTED PAIRS (MANDATORY) VHSI V.36 / RS-449 DRAIN WIRE BRAID...
Page 33: Interface
Eiconcard™ Family Installation Guide X.21 interface A pin-out diagram for the X.21 interface is shown in Figure 11. PG N D T(B) The signal definitions and T(A) names are listed in Table 8. C(B) C(A) R(B) R(A) I(B) I(A) S(B) S(A) B(B) B(A)
Page 34 VHSI port specifications VHSI—X.21 connections The wiring diagram in Figure 12 shows the connections required to construct a VHSI—X.21 cable. For additional information required to construct your own cables, see “Cable construction information” on page 22. TWISTED PAIRS (MANDATORY) VHSI X.21 DRAIN WIRE BRAID...
Page 35: Back-To-Back Connections
Eiconcard™ Family Installation Guide Back-to-back connections The wiring diagram in Figure 13 shows the connections required to construct a back-to-back VHSI—VHSI cable. Back-to-back operations are conducted through the V.36 interface. For additional information required to construct your own cables, see “Cable construction information”...
Page 36: Port Specifications
V.24 port specifications V.24 port specifications V.24 DCE Interface The V.24 port is wired as a V.24 DCE interface as shown in Figure 14 for the Eiconcard C90, C91 S/T, and C91 V2, and Figure 15 for the Eiconcard C91 PCIe LP. The signal definitions and names are listed in Table 9.
Page 37: Technical Specifications Eiconcard C Series
Eiconcard™ Family Installation Guide Technical specifications Eiconcard C series Technical data ISDN CPU/Memory/ V.24 Connector (up to) Model Flash Ports Ports Eiconcard C90 16 MHz Motorola 32 bits 68302 / 512 KB 33 MHz RAM / 512 KB Flash Eiconcard C91 16 MHz Motorola 32 bits 68302 / 512 KB...
Page 38: Power Requirements
Technical specifications Eiconcard C series Power Requirements Eiconcard +12V -12V Eiconcard C90 50 mA 50 mA Eiconcard C91 S/T 50 mA 50 mA Eiconcard C91 V2 .5 A 50 mA 50 mA Eiconcard C91 PCIe LP 400 mA Note The Eiconcard C91 PCIe LP does not use 3.3V power and always draws less than 10W from the bus connector supply.
Page 39: Technical Specifications Eiconcard S Series
Eiconcard™ Family Installation Guide Technical specifications Eiconcard S series Technical data ISDN VHSI Connector CPU/Memory/ (up to) Model Ports Ports Flash Eiconcard S90 25 MHz Motorola 32 bits 68302 /1 MB RAM / 1 33 MHz MB Flash Eiconcard S91 S/T 25 MHz Motorola 32 bits 68302 / 1 MB RAM / 1...
Page 40: External Interface
Technical specifications Eiconcard S series External interface Model External Interface Eiconcard S90 One 36-pin “D Type” female ports. Eiconcard S91S/T One 36-pin “D Type” female port and one RJ-45 port. Eiconcard S91 V2 One 36-pin “D Type” female port and one RJ-45 port.
Page 41: International Regulatory Information
Eiconcard™ Family Installation Guide International regulatory information Regulatory information for the USA WARNING. Changes or modifications to this unit not expressly approved by Dialogic Corporation could void the user's authority to operate the equipment. Declaration of conformity Dialogic Corporation 1515 Route 10...
Page 42 Connection to party lines is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. Facility Digital Service USOC Interface code Reg. code Order code Jack Type 021S5 6.0N Suppliers declaration of conformity Dialogic’s declaration of conformity can be viewed at: http://www.dialogic.com/declarations page 42...
Page 43: Regulatory Information For Canada
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. The Dialogic Declaration of Conformity can be viewed at: http://www.dialogic.com/declarations page 43...
Page 44: Regulatory Information For Europe
HU: Alulírott, Dialogic nyilatkozom, hogy a ITE megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. IC: Hér með lýsir Dialogic yfir því að ITE er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC.
Page 45 Eiconcard™ Family Installation Guide PT: Dialogic declara que este ITE está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. SL: Dialogic izjavlja, da je ta ITE v skladu z bistvenimi zahtevami in ostalimi relevantnimi doloèili direktive 1999/5/ES.
Page 46: Regulatory Information For Australia
International regulatory information Regulatory information for Australia WARNING This customer equipment is to be installed and maintained by service personnel as defined by AS/NZS 3260 Clause 1.2.14.3 Service Personnel. It may be hazardous if your computer is not properly plugged in and grounded.
Page 47: Declaration Of Conformity
Layer 1 Eicon report, dated 17/04/03, NETC report # 28114386/3/IT0, dated 24/01/2000 covers AS/ACIF S031 Regions: European Economic Area (EEA): Dialogic Corporation (address below) declares the equipment in compliance with the essential requirements of EC Council Directives: 1999/5/EC - R&TTE: 2006/95/EC - Safety/LVD: 89/336/EEC – EMC...
Page 48 Layer 1 Eicon report, dated 17/04/03, NETC report # 28/101907/2/IT8, dated 15/04/1998 covers AS/ACIF S031 Regions: European Economic Area (EEA): Dialogic Corporation (address below) declares the equipment in compliance with the essential requirements of EC Council Directives: 1999/5/EC - R&TTE: 2006/95/EC - Safety/LVD: 89/336/EEC – EMC...
Page 49 Nemko report 6S60518AU1, dated 1002/2006 covers AS/NZS 60950 Regions: European Economic Area (EEA): Dialogic Corporation (address below) declares the equipment in compliance with the essential requirements of EC Council Directives: 1999/5/EC - R&TTE: 2006/95/EC - Safety/LVD: 89/336/EEC – EMC Canada Pty Ltd.
Page 50 Nemko report 6S60518AU1, dated 1002/2006 covers AS/NZS 60950 Regions: European Economic Area (EEA) :Dialogic Corporation (address below) declares the equipment in compliance with the essential requirements of EC Council Directives : 1999/5/EC - R&TTE : 2006/95/EC - Safety/LVD : 89/336/EEC – EMC Canada Pty Ltd.
Page 51 Directives : 1999/5/EC - R&TTE : 2006/95/EC - Safety/LVD : 2004/108/EC - EMC USA : Dialogic Corporation (address below) make this SDoC as Responsible Party for equipment registered with ACTA as number : US: E3SXDNAN50-0473 Canada : Dialogic Corporation (address below) is the Declaring Party for equipment registered with Industry Canada as number : IC: 885E-500473...
