READ ALL INSTRUCTIONS BEFORE ASSEMBLING CRIB.
KEEP THE INSTRUCTIONS FOR FUTURE USE.
Barry Imports East Corp.
165 Oval Drive,
Islandia,
NY 11749, USA
This crib has been designed for your child's comfort and your convenience.
Quality material and workmanship have gone into this crib which will provide a
sound and comfortable bed for your baby if properly assembled and maintained.
For the security of your child be sure to follow the assembly instructions exactly.
A periodic check should be made of all bolts and screws, which should be
tightened if needed.
Moisture and heat are harmful to the finish; for this reason use extreme caution
when a vaporizer is in use. Some types of soft plastic toys that come into contact
with finish materials could also be harmful to the finish on your furniture.
This crib conforms to applicable regulations promulgated by the Consumer
Product Safety Commission.
CRIB/BED ASSEMBLY
INSTRUCTIONS
Page 1/14
Instructions for Crib Model:
ALEXANDER
SYDNEY
4200
4400
Advertisement
Table of Contents
Related Manuals for Bellini ALEXANDER 4200
Summary of Contents for Bellini ALEXANDER 4200
- Page 1 CRIB/BED ASSEMBLY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE ASSEMBLING CRIB. KEEP THE INSTRUCTIONS FOR FUTURE USE. Instructions for Crib Model: Barry Imports East Corp. 165 Oval Drive, ALEXANDER 4200 Islandia, SYDNEY 4400 NY 11749, USA This crib has been designed for your child’s comfort and your convenience. Quality material and workmanship have gone into this crib which will provide a sound and comfortable bed for your baby if properly assembled and maintained.
- Page 2 WARNING: Failure to follow these warning and the assembly instructions could result in serious injury or death. To reduce the risk of SIDS, pediatricians recommend healthy infants be placed ■ on their backs to sleep, unless otherwise advised by your physician. Infants can suffocate on soft bedding.
- Page 3 • Check this product for damaged hardware, loose joints, loose bolts or other fasteners, missing parts, or sharp edges before and after assembly and frequently during use. Securely tighten loose bolts and other fasteners. DO NOT use crib if any parts are missing, damaged or broken. Contact Barry Imports East Corp. for replacement parts and instructional literature if needed.
- Page 4 ALEXANDER CRIB HARDWARE TOOLS REQUIRED FOR ASSEMBLY: Metric Allen Wrench( Included) Standard Size Screwdriver (Not included) Alexander Crib Hardware Alexander Crib Hardware Quantity Quantity A Allen head bolt 1-3/8" Cam screw B Allen Wrench J Self Locking washer C Barrel Nut K Small metal washer D Big Metal Washer L Allen head bolt 4"...
- Page 5 SYDNEY CRIB HARDWARE TOOLS REQUIRED FOR ASSEMBLY: Metric Allen Wrench( Included) Standard Size Screwdriver (Not included) Sydney Crib Hardware Sydney Crib Hardware Quantity Quantity A Allen head bolt 1-3/8" Cam screw B Allen Wrench J Self Locking washer C Barrel Nut K Small metal washer D Big Metal Washer L Allen head bolt 4"...
- Page 6 CRIB PARTS DRAWING DESCRIPTION Stabilizer Bars Mattress Support Spring Dust Cover Stationary Front Rail Left Crib End Right Crib End Right Crib End Left Crib End Headboard Drawer Metal Guide Page 6/14...
- Page 7 ADDITIONAL PARTS DRAWING DESCRIPTION Drawer Front Drawer Back Left Drawer Side Drawer Center Right Drawer Side Drawer Bottom Board Page 7/14...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 1- Drawer Glides Assembly Diagram 1: Unpack and familiarize yourself with all parts and components by comparing them with the pictures and descriptions on pages 4,5,6,7. Mounting the drawer guides to the bottom of the left crib end and right crib end. Using Allen wrench B, mount the two drawer guides to the bottom of the left crib end and right crib end with screws(A) , self locking washer (J), and small metal washer (K) like...
- Page 9 ASSEMBLY INSTRUCTIONS STEP 3- Matress Support Assembly Diagram 3: To attach the mattress support spring, carefully place the spring frame in the crib so it rests on the stabilizer bars. Attach lower portions of the brackets to stabilizer bar using 4 screwes(H),4 self locking washers (J), and 4 wing nuts (G) like Tighten with a phillips screw DIAGRAM 3/A.
- Page 10 ASSEMBLY INSTRUCTIONS STEP 4- Headboard Assembly Diagram 5: To assemble the headboard to the crib, insert the screw N through the holes at the top of the legs with self locking washer(J), big metal washer(D), like and screw with the allen DIAGRAM 5/A wrench B.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 5- Stationary Front Rail Assembly Diagram 7: DIAGRAM 7 Position the stationary front rail against the ends of the crib.Insert screws F, self locking washer (J), and small metal washer (K) like through the holes of DIAGRAM 7/A front rail and tighten with the allen wrench B.
- Page 12 DRAWER ASSEMBLY INSTRUCTIONS Diagram 10: Screw in all 6 piece screws (E) into drawer back panel, put 6 cam screws(I) into drawer right side, left side,and drawer center piece. Make sure cam screws(I) are in open position. Diagram 11: Attache drawer sides and drawer center to the drawer back.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE Maintenance: After completing the assembly process, you are advised to read and be aware of all WARNINGS, CAUTIONS, CLEANING, STORAGE, USE AND MAINTENANCE notices contained in these instructions. Check this product for damaged hardware, loose joints, loose bolts or other fasteners, missing parts, or sharp edges before and after assembly and frequently during use.
