- Page 2 FCC Compliance Statement Model Name: HDRP4 / HDRP8 / HDRP16 / HDRPJ16 This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conductions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations.
- Page 3 Safety Notes on the Lithium Battery 1 Replace lithium batteries as instructed to avoid danger. 2 Dispose used lithium batteries properly. 【Warnings and Cautions are indicated as follows】 Possible injury or product damage Risk of minor injury or product damage Caution for the usage of the product Information for the usage of the product...
-
Page 4: Table Of Contents
３-１ HDRPJ16 Front Panel ................. 13 ３-２ HDRP8 / HDRP16 Front Panel ............. 14 ３-３ HDRP4 Front Panel ................15 ３-４ Remote Controller: HDRPJ16 / HDRP8 / HDRP16 ........16 ３-５ Remote Controller: HDRP4 ..............17 ３-６ Mouse ....................17 ３-７... - Page 5 ５-４-１ System Information ..................27 ５-４-２ Screen Brightness/Contrast/Color/Saturation/Sharpen/Camera Adjustment ... 28 ５-４-３ Display Setting ..................28 ５-４-４ Screen Saver.................... 28 ５-５ Control ....................29 ５-６ Search ....................30 ５-６-１ Search Mode .................... 30 ５-６-２ Playback Menu ..................30 ５-７ Calendar Search ................. 30 ５-７-１...
-
Page 6: Recommended Ptz Camera Protocol
６-２ Camera ..................... 45 ６-２-１ Camera ....................45 ６-２-２ PTZ ......................45 ６-２-３ POS ....................... 46 ６-２-４ Event Source .................... 46 ６-２-５ Relay ...................... 46 ６-３ Recording ..................46 ６-３-１ Schedule Selection (Schedule1 ~ Schedule4) ..........47 ６-３-２ Event ...................... 47 ６-３-３... -
Page 7: Chapter １. Introduction
Chapter １. Introduction １-１ HD-SDI Real-Time Pro DVR Models HDRPJ16 HDRP8 / HDRP16 HDRP4 １-２ Components After unpacking the product, check to determine if the following accessories are included: - Remote Controller - CD (VMS, VMS Manuals, User Manual) - AAA 1.5V Batteries 2ea... -
Page 8: １-３ Product Introduction
16/8/4 Channel Audio Recording 16/8/1 Channel Spot Output Video output ports (HDMI, VGA, BNC) Video output modes (Full HD, XGA, SDTV) 6 HDD Capacity (HDRPJ16) 3 HDD Capacity (HDRP8 / HDRP16) 2 HDD Capacity (HDRP4) Jog Shuffle (HDRPJ16) 1 Channel POS Interface Pre-Alarm Recording Auto E-mailing Notification Max. -
Page 9: Chapter ２. Installation And Connection
Chapter ２. Installation and connection ２-１ Names and Features of Each Part ２-１-１ HDRPJ16 Rear Panel ２-１-２ HDRP8 Rear Panel ２-１-３HDRP16 Rear Panel Name Feature Type NTSC CONFIG DIP S/W, 2-pin HD / XGA Terminal Block RS-485 / SENSOR IN / RELAY OUT / POS... -
Page 10: ２-１-４Hdrp4 Rear Panel
HD / XGA USB Type A, e-SATA External SATA e-SATA CAMERA IN Video Camera Connection Power , 60 Watts AC Inlet 12V/5A - Level 5 AUDIO IN Audio Input Connection ２-２Installation and Connection [Figure 2-1. HDRPJ16 Basic Connection and Device Connection]... - Page 11 [Figure 2-2. HDRP8 Basic Connection and Device Connection] [Figure 2-3. HDRP16 Basic Connection and Device Connection] [Figure 2-4. HDRP4 Basic Connection and Device Connection]...
-
Page 12: ２-２-１ Basic Connections
Rear Panel Terminal Block 1) SPOT Monitor Connect Spot Monitor to the rear SPOT terminal. HD-SDI Real-Time Pro DVRs support 1ea SPOT terminals. 2) Audio Input/Output HDRPJ16 and HDRP16 support 16ea audio inputs. HDRP8 supports 8ea audio inputs. HDRP4 supports 4ea audio inputs. - Page 13 3) Terminal Block [Figure 2-6. Terminal Block and Description] The terminal block in the rear of the product is for PTZ / Sensor / Relay / POS connections. The numbers on the terminal block may be different depending on the model. ①...
-
Page 14: Chapter ３. Operation And Setup Tools
Chapter ３. Operation and Setup Tools HD-SDI Real Time Pro DVR can be controlled by using the front panel buttons, front panel, remote controller, jog-shuttle (HDRPJ16 only), and mouse. ３-１ HDRPJ16 Front Panel Name Function LABEL Brand Name and Model Name... -
Page 15: ３-２Hdrp8 / Hdrp16 Front Panel
３-２HDRP8 / HDRP16 Front Panel Name Feature LABEL Brand Name and Model Name CD-RW and DVD-RW Eject CD and DVD Media Reverse Play / Fast Reverse Backward Playback/Rewind (in Playback mode) RELAY Relay Control (in Monitoring mode) Backward Playback Frame by Frame (in Playback Reverse Frame by Frame mode) STATUS... -
Page 16: ３-３Hdrp4 Front Panel
３-３HDRP4 Front Panel Name Function POWER Power On/Off System Moves from one category to another or changes the MOVE & DISPLAY display mode Exits the current menu or selects the upper menu MENU Various Modes PLAY Playback/Fast Forward Frame by Frame Play Frame-by-Frame PAUSE Pause during playback... -
Page 17: ３-４ Remote Controller: Hdrpj16 / Hdrp8 / Hdrp16
３-４ Remote Controller: HDRPJ16 / HDRP8 / HDRP16 A) Basic Control Buttons POWER RECORD Turn the system power POWER ON or OFF. Record all channels or stop recording RECORD all channels. NUMBER Input of numeric data. COPY Set up the remote controller ID. -
Page 18: ３-５ Remote Controller: Hdrp4
Example) When the remote controller ID is set to 1 Press the {ID} button, enter {0} and {1}, and press the {ID} button again. To control all DVRs with the different ID, set the remote controller ID to 999. ３-５ Remote Controller: HDRP4 Turn the system power POWER ON or OFF. -
Page 19: ３-７ Jog-Shuttle
３-７ Jog-Shuttle For HDRPJ16 model only: In playback mode, control play direction, speed, and frames. Speed and Direction Control Frame Control ※ Play Direction Control Turning the jog right/left plays forward/reverses frame-by-frame. ※ Speed and Direction Control Turning the jog right/left plays forward/reverse x1/x2/x4/x30. -
Page 20: ４- 2 Storage Setup
４- 2 Storage Setup ① Select {Menu} {Setup} {Storage} and configure HDD. For more detail about HDD and external devices, check [6-5 Storage]. ４- 3 Recording Setup ① Select {Menu} {Setup} {Recording} {Recording} ② Setup [Recording Resolution]/[Recording Quality]/[Continuous Speed]/[Event Speed]/[Audio]/[Text]. The initial recording setup is [Recording Resolution: 960H] [Recording Quality: High] [Continuous Speed: Off]. -
Page 21: ４- 5 Camera / Tv Setup
４- 5 Camera / TV Setup ① Select {Menu} {Setup} {Camera} {Adjust}. ② Setup for [Brightness/Contrast/Color/Hue/Camera Adjustment/TV OUT Adjustment]. ４- 6 Display Setting and Other Setup ① Select and setup via {Menu} {Miscellaneous} {Display Setting}. ４- 7 External Device Setup ①... -
Page 22: Chapter ５. System Operation
Chapter ５. System Operation ５-１ Real Time Monitoring Mode and Icon After booting is finished, Audio/Recording Status/Channel Title/Connection Status/Time/HDD Status are displayed as shown below. [Figure 5-8. Recording Status Window] ※ Recording Event / Recording Mode Indication Icons ※ Motion Detection Recording Recording Sensor Recording Events... -
Page 23: ５-２ System Login
※ Control Bar ※ ① Full Screen ② 4 Channel Screen ③ 8 Channel Screen ④ 16 Channel Screen ⑤ ZOOM function ⑥ Auto Sequence Mode ⑦ Date / Time ⑧ HDD Status ⑨ Playback ５-２ System Login ５-２-１ User Account and Authorization System users are divided into local administrators and general users. -
Page 24: ５-２-３ Logout
With the exception of the initial boot, the system will follow the user's screen division setting upon subsequent boots. The division options vary depending on the model. [Figure 5-10. HDRPJ16 / HDRP16 Divisions] [Figure 5-11. HDRP8 Divisions] [Figure 5-12. HDRP4 Divisions] ※... -
Page 25: ５-３-２Spot
The Spot function is used to output a channel that is set with a certain function; Spot has an independent monitor and output. The priority for Spot is Manual Spot > Event Spot > Sequence Spot. ① Manual Spot The user can designate a spot channel manually. HDRPJ16 /HDRP16 support 4ea Spot channels, and HDRP8 support 1ea Spot channels. -
Page 26: ５-３-３Menu In Monitoring Mode
[Figure 5-13. Spot] ② Navigate to {Menu} {Miscellaneous} {Misc. Control} {Spot} and configure as Single mode, Quad mode, Sequence, or Channel. ③ Event Spot Event Spot enables quickly showing a channel set with the event function when event cases (Sensor, Motion, and Audio) occur. -
Page 27: ５-３-５ Screen Control By Using Ptz
⑥ Using the mouse, move the cursor to an area to be zoomed in the zoom control screen and double-click on it. ⑦ The Zoom function operates in three levels: Normal, x4, and x16. Those three levels can be switched with the mouse wheel. -
Page 28: ５-４ System Information And Screen Setup Change
[Figure 5-17. PTZ Control Mini./Full.] The PTZ can be controlled in "Full" or "Mini" modes. Tour is restricted to [Tour1] and [Tour2]. Home Position Time can be set to 1/5/10/User Setting (1-60) minutes. Presets: Using horizontal/vertical/Zoom/Focus/Iris movement of PTZ Camera, zoom, focus, or move iris to a certain spot of the image. -
Page 29: ５-４-２ Screen Brightness/Contrast/Color/Saturation/Sharpen/Camera Adjustment
５-４-２ Screen Brightness/Contrast/Color/Saturation/Sharpen/Camera Adjustment Select {Adjust}. The screen division will change to 1 channel mode and a window will pop up as shown below. [Figure 5-19. Screen Setup Window] Moving the camera, down, right, or left excessively may cause black or gray areas to appear on the screen. -
Page 30: ５-５ Control
All models support 1 output channel. ③ Navigate to the Text tab. In regards to ethernet POS, HDRPJ16 / HDRP16 support 8ch POS, HDRP8 supports 4ch POS, and HDRP4 supports 1ch POS. All models support 1ch mode for RS232 POS. -
Page 31: ５-６Search
５-６Search ５-６-１ Search Mode Navigate to {Menu} {Search} in real-time monitoring mode. [Figure 5-25. Playback Menu] ５-６-２ Playback Menu (1) Calendar Search Calendar Search allows the user to search and playback by [Year/Month/Day/Hour/Minute], [Multi-Channel/ Multi-Time/Multi-Day] and [Motion/Sensor/Audio/Pattern]. (2) Go To The Last The user can search and playback the last recorded data via Multi-Channel Mode. -
Page 32: ５-７-３ Time Index
５-７-３ Time Index ① Anytime the user changes the time via {Menu} {Setup} {Time} {Date and Time} tab, a new folder (i.e. "index") is created; files saved in the folder before the time change can be found at {Menu} {Calendar Search} ... -
Page 33: ５-７-８List All
５-７-８List All The Time index can be checked in the order of the timeline. [Figure 5-27. Time Index] ５-８POS Search ５-８-１POS Search Mode {Menu} {Search} {POS Search}. A search window will On the real-time monitoring screen, select appear (as shown below). ５-８-２Year/Month/Day/Text/Time Selection Select date/time, Time index, Text 1~3, and start time for the channel. -
Page 34: ５-９Playback
５-９Playback [Figure 5-29. Playback Screen] ※ There are five methods to play recorded images: "Calendar Search" Playback Select {Playback} in {Menu} {Search} {Calendar Search} {Search}. "Go To The Last" Playback Navigate to {Menu} {Search} {Go to The Last}. "Go To The First"... -
Page 35: ５-９-２ Smart Search
Description of the Search Buttons Button Name Features Channel Mode Change Switch channel mode. Zoom Mode Switch to Zoom mode. Press one time - Playback forward (ⅹ1) Press two times - Fast forward (ⅹ2) Press three times - Fast forward (ⅹ4) Press four times - Fast forward (ⅹ8) Forward Play / Fast Forward Press five times - Fast forward (ⅹ16) -
Page 36: ５-９-３ Pos Search
① Navigate to Smart Search and select the desired channel. ② After the shift to 1-channel mode, select zone(s) to be smart-searched. [Figure 5-32. Smart Search Area Designation] The 14 x 15 pixel mosaic mode appears. By default, all pixels are selected. Left-click and drag the pixel ③... -
Page 37: ５-９- 7 Multi-Channel
５-９- 7 Multi-Channel Multi-Channel Search is used to play recorded images of different channels over a designated time frame. ５-９- 8 Panorama Play Panorama Play is used to play recorded images of a particular channel frame-by-frame. Panorama Play can be viewed at 16-frame / 8-frame / 4-frame / 1-frame divisions. -
Page 38: ５-１０-１ Log Type
[Figure 5-36. Log View] ５-１０-１ Log Type Logs related to power ON/OFF, file copy/backup failure, setup start/end, Normal playback, and other basic system operations Logs related to recording including motion, sensor, and audio Recording Event detection Logs related to network operations including network login, logout, Network and live Logs related to system operation failures including signal loss and... -
Page 39: ５-１１Recording
[Figure 5-37 . Move to the log list of the certain time zone in Log View] Changed Time Log Data View The stored data folder is created every time the user changes the time. When time changes are made, a blue triangular icon is displayed on a date in the calendar window. Otherwise, a red triangular icon is displayed on unchanged dates. -
Page 40: ５-１２ Backup
５-１２ Backup In order to backup data, internal or external storage devices (CD, DVD or HDD) must support USB 2.0 connections. For supported external devices, refer to A PPENDIX. The user can back up data from real-time monitoring, search, log, or playback modes. ５-１２-１... -
Page 41: ５-１２-５ Common Backup Procedure
５-１２-５ Common Backup Procedure [Figure 5-38. Backup Window] ① [Figure 5-38] shows the backup window menu. ② Underneath "Information," available devices can be selected from the drop-down list. ③ Upon selecting a device from the list, its free space and total capacity will be displayed underneath. ④... -
Page 42: ５-１４ Log Backup
[Figure 5-39. Backup and Sub-menu Setup Backup] ① A backup device must be connected for Setup Backup. ② Navigate to {Menu} {Backup} {Setup Backup}; the window shown below will appear. The backup name is generated as shown below. [Figure 5-40. -
Page 43: ５-１５Capture
５-１５Capture The Capture function allows the user to create a JPG file in real-time monitoring, playback, search, or log modes and back up the image data. ① To back up the currently displayed image, navigate to {Menu} {Backup} {Capture} in real- time monitoring, Playback or Log modes. -
Page 44: Chapter ６. Setup
Chapter ６. Setup ６-１Time ※ Function Description 1. Time Synchronization 1) Synchronization with the NTP server The time is synchronized once every hour with the NTP Server. A. Automatic Setup The nearest server from the user’s zone will be selected for connection. If the connection fails, the next nearest server will be chosen. -
Page 45: ６-１-２ Date And Time
６-１-２ Date and Time (1) Date and Time Only available when Time Server is off. The system date and time format is Year/Month/Day Hour/Minute/Second. ① By using the arrow keys and the Select button, move the focus onto the desired field: Year/ Month/Day/Hour/Minute/Second and press the Select button. -
Page 46: ６-２ Camera
[Figure 6-43. Setup / Auto Reboot Menu] ６-２ Camera [Figure 6-44. Setup / Camera Menu] ６-２-１ Camera ① Connect Used to set whether to connect or disconnect each camera channel. ※ When the camera channel is set to disconnected, the video contents will not be displayed even if the camera is connected physically still. -
Page 47: ６-２-３ Pos
６-２-３ POS Set up the protocol and baud rate of the POS device. ６-２-４ Event Source Navigate to {Menu} {Setup} {Camera} {Event Source}. (1) Motion Area The user can setup the motion detection area. Motion zones can also be created. [Figure 6-45. -
Page 48: ６-３-１ Schedule Selection (Schedule1 ~ Schedule4)
[Figure 6-46. Setup / Recording] ６-３-１ Schedule Selection (Schedule1 ~ Schedule4) ① Each channel can be given 4 different recording schedules. ６-３-２ Event Motion / Sensor / Sound / Text Input / Text Search events can be set to On/Off in this menu. Recording Description Type... -
Page 49: ６-３-４ Alarm
(3) Frame Rate If the user configures Normal Speed and Event Speed at the same time, the continuous recording will be set to Normal Speed frame rate, and the event recording will be set to Event Speed frame rate. Normal Speed Set the recording frame rate for Continuous recording. -
Page 50: ６-５ Storage
(1) Selection Tips ① Select the day and time to be set by using the arrow keys. ② The user can configure a whole line at once by moving the cursor onto Time (0-23) or Day (Sun.-Holiday) and selecting. ③ Using the mouse may be easier when making these changes. (2) Holiday Registration This feature enables the user to set the holidays and schedule independently. - Page 51 ① Recording The Recording storage is managed directly; it stores data on the hard disk in real time. Five commands can be executed, but depending on the S/W status however, some commands cannot be executed. Returns the status of the selected storage device to New; if this command is executed, the selected storage device will be moved to the {New} storage device manager.
-
Page 52: ６-６Network
※ Selecting {Recording-Format} or {Backup-Format} causes all data in the device to be erased. Use caution when preforming this task. ※ While {Recording-Format} or {Backup-Format} is being set up, do not remove the device (may cause an error when detecting the device). ※... -
Page 53: ６-６-３Port
※ Access DynDDNS server (http://www.dyndns.org), apply for a user account, and then register the domain name to use and enter URL. ※ More information regarding this procedure can be found at this site. ６-６-３Port Navigate to {Menu} {Setup} {Network} {Port}. This feature is used to set up the network port. - Page 54 [Figure 6-52. Setup Network E-Mail Window 1] To set automatic E-mail transmission service when an event occurs: Configure {E-mail} in {Menu} {Setup} {System} {Alarm} or {E-mail} in {Menu} {Setup} {Action} {Alarm}. [Figure 6-53. Setup Network E-Mail Window 2] ②...
-
Page 55: ６-６-５ Bandwidth
６-６-５ Bandwidth Navigate to {Menu} {Setup} {Network} {Bandwidth}. This sets up the limit of the bandwidth to be used when viewing live images, adjusting resolution/quality, and transmitting the data by using the network. Image Resolution CIF / D1 / 960H Adjust quality of the image (as the value increases, the Image Quality compression rate gets higher and image quality gets lower;... -
Page 56: ６-７-３ Id For Keyboard Controller
As shown below, only the DVR with matching remote controller ID can receive input signals from said remote controller. ① Navigate to {Menu} {Setup} {System} {Remote Controller ID}. ② In the selection window, enter ID by using arrow keys and Select button (numbers 0~99 available for ID). -
Page 57: ６-７-５ Admin. Password
６-７-５ Admin. Password Set up the Administrator Password (up to 5 digits). ６-７-６ Upgrade The firmware and menu settings of the product can be easily upgraded using external or portable storage devices via USB 2.0 port. ※ Find and copy the upgrade file to the highest folder in the external or portable storage device supporting USB 2.0. -
Page 58: ６-７-７ Factory Default
６-７-７ Factory Default ① Navigate to {Menu} {Setup} {System} {Factory Setup}. ② Select "Yes" when Initialization (Yes/No) Window appears. All setting data will be initialized. In other words, all values will return to their factory defaults. ６-７-８ Console / POS Port ①... -
Page 59: Appendix
APPENDIX A/P/P/E/N/D/I/X Recommended PTZ Camera Protocols Vendor Model Protocol ULTRA_7 A.D. SENSORMATIC ULTRA_8 CHOU COHU3925 COHU DRX-500 Dongyang Dongyang DY-255 DYNACOLOR DSCP DSCP EYE VIEW EYE VIEW EYE VIEW FINE SYSTEM CRR-1600i/s CRR-1600i/s GE_KALATEL CYBERSCAN_1 HITRON FASTRAX2 FASTRAX2 HONEYWELL SCANDOME2 HSDN-251 LG_MULTIX, LG_OLD...
