CHEYENNE GRILL & FIREPIT
Owner's Manual
SKU: 259-5062; Model: OOCCHE2-32
Assembly Required
The following tools (not included) are required for assembly:
Two adjustable wrenches (or 14mm sockets / wrenches)
OUTDOOR USE ONLY! NEVER USE INDOORS!
Read and follow all of these manufacturer instructions before beginning assembly or
operation. Failure to do so could result in fire, burns, or other serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product to someone
else, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OOCCHE2-32 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Creations OOCCHE2-32

Summary of Contents for Backyard Creations OOCCHE2-32

  • Page 1 CHEYENNE GRILL & FIREPIT Owner’s Manual SKU: 259-5062; Model: OOCCHE2-32 Assembly Required The following tools (not included) are required for assembly: Two adjustable wrenches (or 14mm sockets / wrenches) OUTDOOR USE ONLY! NEVER USE INDOORS! Read and follow all of these manufacturer instructions before beginning assembly or operation.
  • Page 2 IMPORTANT SAFETY INFORMATION! DANGER CARBON MONOXIDE HAZARD! Burning wood and charcoal releases carbon monoxide, a toxic odorless gas which can cause serious injury or death. NEVER use this product to burn wood or charcoal inside homes, inside vehicles, or inside any other enclosed areas! If used indoors, toxic fumes, including carbon monoxide, will accumulate and cause serious injury or death.
  • Page 3 WARNING  Burn wood logs only. DO NOT burn charcoal, leaves, or other combustible materials.  Use care when lifting or moving the grill and side box to prevent strains and back injuries.  DO NOT use this product in windy conditions. ...
  • Page 4 Parts Diagram Parts and Hardware Image Description Qty No. Image Description Outer Ring Post Legs Segments Adjustable Cooking Fire Bowl Grid Post - Tall Adjustable Cooking Standard Legs Grid Post - Short Ash Catcher Large Cooking Grid Vent Small Cooking Grid Cooking Grid Ash Catcher Handles...
  • Page 5 Assembly STEP 1. NOTE: The post legs (A) should be opposite each other. Attach the post legs (A) and standard legs (C) to the rim of the fire bowl (B) with 4 hex head bolts (S2). Partially tighten the bolts with an adjustable wrench. Do not tighten completely until Step 4. STEP 2.
  • Page 6 STEP 4. Thread four long Allen screws (S1) through the outer ring (G) tube and into the legs. Thread four short Allen screws (S1) through the outer ring (G) tabs and into the legs. Check the alignment of the legs. Securely tighten all bolts and nuts from steps 1~4 with two adjustable wrenches (or 14mm sockets/wrenches) and the Allen wrench (T3).
  • Page 7 STEP 7. Carefully set the vent (E) into the opening in the bottom of the fire bowl (B). Set the ash catcher (D) onto the ash catcher hanger (L) underneath the fire bowl. The grill is now ready to use. Before use, read the Important Safety Information in this manual. Care and Maintenance ...
  • Page 8 Limited Warranty Manufacturer warrants this grill for replacement or repair of parts to the original purchaser for a period of 90 days from original date of purchase. The original sales receipt is required for all warranty claims. This warranty is limited to non-commercial residential use only. Any commercial, public, or institutional use voids all warranties.
