Summary of Contents for Sun-Pec TDA7498
- Page 1 Sun-Pec TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide www.sun-pec.com...
- Page 2 TDA7498 2x100W Class-D BTL Audio Amplifier User User’s Guide Overview www.sun-pec.com...
-
Page 3: Electrical Drawing
TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide Electrical Drawing Schematic Diagram www.sun-pec.com... - Page 4 Description Brief Introduction: This amplifier is a state-of-the-art dual channel Class-D audio amplifier which integrates ST's TDA7498 as the driver. This amplifier is capable of delivering dual-channel amplification with each channel up to 100W. High quality and high performance components are used making this amplifier high-quality amplifier.
- Page 5 TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide Description 35.1 dB and 37.6 dB .Line level audio signal input .Externally synchronizable .Mounting holes facilitate installation and fixing .Several wiring methods facilitate connection .Excellent heat sink and powerful cooling fan eliminate your worry on heat dissipation .Over/under voltage turn off...
- Page 6 TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide Description .Total input noise: <50µV@f = 22 Hz to 22 kHz .100W output power @THD = 10%, 6 36 V .80W output power @THD = 10%, 8 34 V .Operating Temperature: 0℃ to 50℃...
-
Page 7: Mechanical Drawing
TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide Mechanical Drawing Top Size www.sun-pec.com... - Page 8 TDA7498 2x100W Class-D BTL Audio Amplifier User’s Guide Contact us SUN-Pec Co., Ltd . Unit E, 17/F, Success Ind. Building, 17 Sheung Hei Street, San Po Kong, HK Tel: +852-23549977 Fax: +852-23549355 Website: www.sun-pec.com Email: contact@sun-pec.com www.sun-pec.com...
