Spy Earpice SE51 Bluetooth neckloop User Manual

3.5W Amplified Bluetooth Neckloop
2012 updated design. Version 3.0.
V3.0 Improvements
1) Add music control function.
Bluetooth button control play/pause.
Short push "Volume +" to previous song, long push to increase volume.
Short push "Volume -" to next song, long push to reduce volume.
2) Mute button is works while play music.
2) Cancelled alarm notice while change volume.
If volume comes minimum or maximal will make alarm also.
Te51 Bluetooth neckloop is build in F class low consumption audio amplifier.
Defined power of amplifier is 3.5watt. It can supports all kinds of wireless
earpieces and provides very loud audio sounds.
2 colors are available, skin and black.
Package includes:
1 x Amplified Bluetooth Neckloop (black or skin color)
1 x USB recharge cable & 1 x USB AC charger

Quick Start

1
Pair with mobile phone
A. Put Bluetooth neckloop in pairing mode
1) With the Bluetooth neckloop power off, press
and hold Bluetooth switch for 6-10 seconds until
indicator turn on and flash between blue and red.
2) If Bluetooth is switched on or indicator flashing,
press and hold Bluetooth switch for 5 seconds to
turn off Bluetooth, then repeat above step 1).
B. Put Mobile phone in pairing mode
1) Go to mobile phone panel, turn on Bluetooth function
and search for new Bluetooth device.
2) Select "T-Loop" then press "OK" or "YES".
3) Enter password "0000" and press "OK".
* Once paired, indicator change from flashing to blue.
Some mobile phone need to "connect" manually after paired.
Note: 1) Bluetooth indicator is nearby "SOS button".
2) If can not switch on Bluetooth, please recharge for 3 hours and try again (refer to "Recharge and Battery").
To be continued..
1
PAGE
V3.0
www.Spy-Earpiece.com
Neckloop
Mute Button
Next / Volume +
Previous / Volume -
SOS
Microphone
Recharge
SOS Button
Indicator
Bluetooth Switch & Pause / Play
