- Page 1 Everest Road Lytham St Annes Lancashire FY8 3AZ Tel: +44 (0) 1253 789180 Fax: +44 (0) 1253 789182 www.vitrex.co.uk...
- Page 2 10 3402NDE Compact Tile Cutter Owner’s Safety and Operating Manual...
- Page 3 Compact Tile Cutter Owner’s Safety and Operating Manual Contents Safety Instructions ..........3 Machine Specification & Electrical Requirements ..4 Assembly & Operating Instructions ......5-7 Maintenance & Warranty ........7 Tel: +44 (0) 1253 789180...
-
Page 4: Safety Instructions
Compact Tile Cutter Safety Instructions • Switch machine off between cuts and disconnect from mains supply before carrying out any maintenance, To use this tool correctly, you must cleaning or changing the blade. observe the Safety Regulations, the Assembly Instructions and the Operation •... - Page 5 IMPORTANT Your new Vitrex Torque-Master Power Compact Tile Cutter contains a unique Hi-Torque geared motor, which when in use produces a distinctive loud sound. This is a characteristic of the High Performance motor and is important in producing the torque for optimum cutting performance.
-
Page 6: Operating Instructions
Compact Tile Cutter Assembly & Operation Operating Instructions Straight Cuts To fit the Cutting Blade, first carefully lift the hinged section of the table top. Remove screw from Place the Rip Guide on the table top and line up with splashboard and remove the splashboard to allow the measurement graduations on either edge to the access. - Page 7 Operating Instructions Operating Instructions Angular Cuts Mitre Cuts Press the Mitre Guide into place on the Rip Guide. For mitre cuts, raise the hinged section of the table to the required angle (22.5° or 45°) Slacken the diamond-shaped knob and set the required angle of cut.
- Page 8 Ingress of foreign objects, substances or accident In the unlikely event of a fault occurring, contact should be made through the Vitrex Technical Helpline (01253 789180). The above guarantee is only valid within the UK and does not affect your statutory rights.
