Marantz SR4400 Service Manual

Av surround receiver
Hide thumbs Also See for SR4400:

Advertisement

Table of Contents

See also: User Manual
Service
Manual
STANDBY
POWER ON/OFF
SECTION
1. TECHNICAL SPECIFICATIONS ............................................................................ 1
2. TECHNICAL DESCRIPTION ................................................................................. 4
3. WIRING DIAGRAM................................................................................................ 5
4. BLOCK DIAGRAM................................................................................................. 7
5. SCHEMATIC DIAGRAM ........................................................................................ 9
6. PARTS LOCATION .............................................................................................. 29
7. IC DATA................................................................................................................ 41
8. EXPLODED VIEW AND PARTS LIST ................................................................. 47
9. SERVICE PROCEDURE ..................................................................................... 51
10. SYSTEM ERROR ................................................................................................ 53
11. ELECTRICAL PARTS LIST ................................................................................. 54
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
AV SURROUND RECEIVER SR4400
SURROUND
DISP
AUTO
CD
DVD
VCR1
6.1CH-IN
TEST
ST
TUNER
TV
DSS / VCR2
TUNED
TAPE
CDR/ MD
CLEAR
MEMORY
A/D
HT-EQ
PHONES
6.1
CH-IN
TV
DVD
VCR1

TABLE OF CONTENTS

SR4400
SR4400 /
AV Surround Receiver
DIRECT
SLEEP
ANALOG
AUTO SURR
EQ
DIGITAL
DIGITAL
EX
PCM
SURROUND
96kHz
NIGHT
ATT
L
C
R
LFE
SL
S
SR
DOWN
TUNING/PRESET
F/P
MODE
S-DIRECT
DISPLAY
MUTE
DSS/VCR2
CDR/MD
TAPE
CD
TUNER
A1B/A1S/K1S/K1G
/N1B/N1S/U1B
VOLUME
UP
PAGE
Part no. 26AW855010
First Issue 2003.05
ecm

Advertisement

Table of Contents
loading

Related Manuals for Marantz SR4400

Summary of Contents for Marantz SR4400

  • Page 1: Table Of Contents

    Service SR4400 / A1B/A1S/K1S/K1G /N1B/N1S/U1B Manual AV Surround Receiver AV SURROUND RECEIVER SR4400 SURROUND VOLUME DISP AUTO VCR1 6.1CH-IN DIRECT SLEEP ANALOG TEST TUNER DSS / VCR2 AUTO SURR DIGITAL DIGITAL SURROUND 96kHz TUNED TAPE CDR/ MD NIGHT DOWN CLEAR...
  • Page 2 Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specifi ed.

  • Page 3: Technical Specifications

    1. TECHNICAL SPECIFICATIONS FM TUNER SECTION Frequency Range ............................... 87.5 - 108.0 MHz Usable Sensitivity ............................IHF 1.8 µV/16.4 dBf Signal to Noise Ratio ..........................Mono/Stereo 76/72 dB Distortion ..............................Mono/Stereo 0.2/0.3 % Stereo Separation............................... 1 kHz 45 dB Alternate Channel Selectivity ..........................± 300 kHz 60 dB Image Rejection...............................
  • Page 4 The relation between the selected surround mode and the input signal The surround mode is selected with the surround mode buttons on SR4400 or the remote control unit. However, the sound you hear is subject to the relationship between the selected surround mode and input signal. That relationship is as follows;...
  • Page 5 Bass signal output from Sub Woofer terminal for SR4400 *Stereo decode : SPK SETUP - BASS MIX : BOTH set SubWoofer Output by Decoded mode SPK setup Surr. Surr.B DD EX Dolby(AC-3 2ch) ,Neo Stereo Virtual Front Center Woofer DTS mES,dES...

  • Page 6: Technical Description

    2. TECHNICAL DESCRIPTION DTS was introduced in 1994 to provide 5.1 channels of discrete Dolby Digital identifi es the use of Dolby Digital (AC-3) audio coding digital audio into home theater systems. for such consumer formats as DVD and DTV. As with fi lm sound, DTS brings you premium quality discrete multi-channel digital sound Dolby Digital can provide up to fi...

  • Page 7: Wiring Diagram

    3. WIRING DIAGRAM TUNER MODULE MAIN JFN101 JFN507 JFN510 JFN512 JFS09 JFS11 JFS07 JFS08 JFS10 VIDEO JFF102 JFM02 JFN509 JFS06 JFV101 DIGITAL/AUDIO FRONT JFS03 JFM05 JFM04 JFN508 JFM01 JFV201 JFN511 JFS01 POWER AMP. JFS05 JFN401 JFF103 JFF101 JFN301 JFN601 JFM03 JFN701 JFN102 JFN702...

  • Page 8: Block Diagram

    4. BLOCK DIAGRAM BUFF X 7 T O N E E-Volu me BU1924 M61516FP Data FM ANT. TUNER Data POWER AMP X 6 MODULE T O N E only 2SA1941/ 2SC5198 REC OUT AM ANT. SPK OUT FUNCTION CD IN AK4529 TAPE IN AUDI O I/ F...

  • Page 9: Schematic Diagram

    5. SCHEMATIC DIAGRAM DIGITAL / AUDIO PC Board (1/4) ( AUDIO ) POWER PC Board JFM01 6.1 CH / PRE OUT PC Board JFK1 6.1 CH / PRE OUT PC Board JFK2...
  • Page 10 DIGITAL / AUDIO PC Board (1/4) JFS05 6.1CH / PRE OUT PC Board H / P OUT PC Board DIGITAL / AUDIO PC Board (1/4) JSF01 MAIN PC Board JFN601...
  • Page 11 MAIN PC Board VIDEO PC Board JFV201 FRONT MAIN PC Board TRANSF. JFF101 JFN903 REMOTE CONTROL STANDBY PC Board DIGITAL / AUDIO PC Board (4/4) JW104 JFS10 MAIN TRANSF. DIG-1 IN DIG-2 IN DIG-3 IN DIG-4 IN DIG-OUT (COAX) DIG-OUT (OPT) DIGITAL / AUDIO PC Board (1/4) JFS06 SPK OUT...
  • Page 12 POWER AMP PC Board DIGITAL / AUDIO PC Board (1/4) JFS03 MAIN PC Board JFN511 JFN510 MAIN PC Board JFN509 MAIN PC Board JFN512...
  • Page 13 VIDEO PC Board MONI OUT DIGITAL / AUDIO PC Board JFS08 MAIN PC Board JFN507...
  • Page 14 DIGITAL / AUDIO PC Board (2/4) (AD/DA) DIGITAL / AUDIO PC Board (4/4) (AD/DA) DIGITAL / AUDIO Board (1/4) MAIN PC Board JFN508...
  • Page 15 DIGITAL / AUDIO PC Board (3/4) (DSP) DIGITAL / AUDIO PC Board (4/4) (DSP) DIGITAL / AUDIO PC Board (2/4)
  • Page 16 MAIN PC Board JFN101 DIGITAL / AUDIO PC Board (4/4) (CPU) TO TUNER MODULE VIDEO PC Board JFV101 DIGITAL / AUDIO PC Board (1/4) N.C. FRONT PC Board JFF102 DIGITAL / AUDIO DIGITAL / AUDIO DIGITAL / AUDIO PC Board (2/4) PC Board (1/4) PC Board (3/4)
  • Page 17 FRONT PC Board MAIN PC Board JFN702 DIGITAL / AUDIO PC Board (4/4) JFS11 SURROUND PC Board FRONT STANDBY PC Board JFF104 STANDBY LED Board TO STANDBY LED PC Board JFL1...
  • Page 18 TO MAIN PC Board JFN102 MAIN TRANSF. STANDBY PC Board POWER (MAINS) SW PC Board MAINS INLET MAINS PLUG POWER(MAINS) SW PC Board STANDBY PC Board JW102 MAINS SW...

  • Page 19: Parts Location

    6. PARTS LOCATION MAIN DM301-304 ICN401 DN410 DN101 ICN101 DN307 DN306 QN301 DN404-407 DN411 QN802 DN802 DN801 ICN301 DN305 DN310 DN309 QN607 QN601 QN608 DN401 ICN402 QN801 QN803 QN804 DN308 ICN304 ICN303 DN701 DN702 DN402 DN504 QN609 ICN302 DN501 QN606 DN704 QN701 DN201-204 ICN201...
  • Page 20 DIGITAL / AUDIO A ICS20 QS11 QS208QS303 QS305 QS205 ICS19 QS09 QS12 QS207 QS306 QS206 ICS16 ICS27 ICS38 ICS36 ICS35 ICS37 QS13 QS203 ICS14 ICS28 ICS26 ICS29 ICS15 ICS17 ICS01 ICS07 ICS05 ICS02 ICS21 QS23 QS22 ICS13 ICS18 QS20 ICS04 ICS06 DS09 ICS22...
  • Page 21 DIGITAL / AUDIO B QS10 QS03 QS16 QS17 QS204QS302 QS201 QS301 QS304 QS202 QS14 QS05 QS06 QS04 QS15 ICS25 ICS31 ICS24...
  • Page 22 POWER AMP QM401 QM402 QM414 QM501 QM502 QM514 QM601 QM602 QM614 QM301 QM302 QM314 QM201 QM202 QM214 QM101 QM102 QM114 QM404 QM407 DM404 QM504 QM507 DM504 QM604 QM607 DM604 QM304 QM307 DM304 QM203 QM207 DM204 QM103 QM107 DM104 QM403 QM406 QM405 DM405 QM503...
  • Page 23 FRONT ICF201 QF101 QF102 QF103 ICF101 QF104 VIDEO B ICV202 ICV201 ICV101...
  • Page 24 H/P OUT STANDBY QW101 DW107 DW103 DW105 ICW01 DW104 DW106 DW102 DW101 DW108 POWER SW 1 POWER SW 2 6.1CH / PRE OUT STANDBY LED SURROUND CK227...

  • Page 25: Ic Data

    7. IC DATA ICF101 : PT6302 OSCI SG35 OSCO SG34 RSTB SG33 SG32 CLKB SG31 SG30 SG29 SG28 SG27 SG26 SG25 SG24 SG23 SG22 SG21...
  • Page 26 ICS03 : M61516FP...
  • Page 27 ICS08 : AK4529...
  • Page 28 ICS13 : CS49326...
  • Page 29 ICS19 : AK4112 ICS18 : H8/3026 DVDD CM0/CDTO Name PIN No. Type Notice ST-BY 0.1uF Vss DVSS CM1/CDTI PB-0 RC_KILL PB-1 TVDD OCKS1/CCLK FRPG1 PB-2 ADD15 FRPG2 PB-3 ADD16 OCKS0/CSN V/TX FRPG3 PB-4 ADD17 VOL_CLK PB-5 E-VOL 27 CLOCK VOL_LATCH PB-6 E-VOL 25 LATCH...

  • Page 30: Exploded View And Parts List

    8. EXPLODED VIEW AND PARTS LIST 6.1CH/PRE OUT B'D POWER AMP B'D VIDEO B'D 15 x 7 DIGITAL/AUDIO B'D 27 x 12 SW01 17 x 2 TRN901 STANDBY B'D 16 x 2 18 x 2 POWER SW 1 B'D SURROUND B'D STANDBY LED B'D FRONT B'D MAIN B'D...
  • Page 31 TRN901 /A/N *TS001810R *TS001810R TRANSF POWER TRANSF. 230AC 50HZ VTPAT7203 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS. NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

  • Page 32: Service Procedure

    3 seconds. The FL display shows "SERVICE MODE" for 2 seconds then is shows the model name 1. Each of cement resistors are provided with two test points. Set a voltage meter to DC voltage input, (Ex.: "SR4400" ). Connect the digital voltage meter to the two test points on a cement resistor.

  • Page 33: System Error

    10. SYSTEM ERROR When the micro-computer detects a trouble, the following information is displayed on the FLD. 1. Trouble in DSP If communication with DSP1(Q610) is troubled more than 2 seconds, FLD shows below. * This display stays and sound is muted. 2.

  • Page 34: Electrical Parts List

    11. ELECTRICAL PARTS LIST ASSIGNMENT OF COMMON PARTS CODES. NOTE ON SAFETY FOR FUSIBLE RESISTOR : RESISTORS The suppliers and their type numbers of fusible resistors : 1) GD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W are as follows; : 2) GD05 ×...
  • Page 35 ECEA1HAE2R2MB DM102 *HD201710R DIODE ODI1N4148 DM104 *HD201710R DIODE ODI1N4148 DM105 *HD201710R DIODE ODI1N4148 DM202 *HD201710R DIODE ODI1N4148 DM204 *HD201710R DIODE ODI1N4148 DM205 *HD201710R DIODE ODI1N4148 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 36 JM501 CONNECTOR 2PIN, 2.5mm, UL VJS02EH01E JM501 JUMPER WIRE JPL0000 JM502 JUMPER WIRE JPL0000 JM519 JM520 JUMPER WIRE JPL0000 JM601 CONNECTOR 2PIN, 2.5mm, UL VJS02EH01E NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 37 QM311 *HT100660R *HT100660R TRANSISTOR OTR2SA1964E QM312 HT351981A0 HT351981A0 TRANSISTOR OTR2SC5198O QM313 HT119411A0 HT119411A0 TRANSISTOR OTR2SA1941O QM314 HT322402A0 HT322402A0 TRANSISTOR OTR2SC2240 QM315 HT109701A0 HT109701A0 TRANSISTOR OTR2SA970GR NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 38 *RA001050R TRIMMING RES. EVN2BF000B201 RM107 RES. 560Ω, 1/6W ERD16TJ561T RM108 METAL FILM RES. 2.2kΩ, 1%, 1/6W ERX16BF222V RM109 RES. 10kΩ, 1/6W ERD16TJ103T RM110 RES. 10kΩ, 1/6W ERD16TJ103T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 39 RM231 RES. 10Ω, 1/6W ERD16TJ100T RM232 RES. 10Ω, 1/6W ERD16TJ100T RM233 RES. 10Ω, 1/6W ERD16TJ100T RM234 RES. 10Ω, 1/6W ERD16TJ100T RM301 RES. 2.2kΩ, 1/6W ERD16TJ222T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 40 METAL FILM RES. 62kΩ, 1%, 1/6W ERX16BF623V RM421 RES. 1kΩ, 1/6W ERD16TJ102T RM422 RES. 10Ω, 1/6W ERD16TJ100T RM423 RES. 1kΩ, 1/6W ERD16TJ102T RM424 RES. 22kΩ, 1/6W ERD16TJ223T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 41 RES. 270Ω, 1/6W ERD16TJ271T RM612 RES. 2.2kΩ, 1/6W ERD16TJ222T RM613 RES. 820Ω, 1/6W ERD16TJ821T RM614 *RA001060R *RA001060R TRIMMING RES. EVN2BF000B221 RM615 RES. 150Ω, 1/6W ERD16TJ151T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 42 ECUV1H101JCV CS125 OA47505020 ELECT. CAP 50V, 4.7µF ECEA1HAE4R7MB CS140 CS143 *OF100310R *OF100310R FILM. CAP 63V, 0.10µF ECQQ1J104JZ CS144 *OF100310R *OF100310R FILM. CAP 63V, 0.10µF ECQQ1J104JZ NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 43 OA22605020 ELECT. CAP 22µF, 50V ECEA1HAE220MB CS323 OA47605020 ELECT. CAP 47µF, 50V ECEA1HQE470MB CS324 DD95101300 CHIP CAP. 50V, 100pF ECUV1H101JCV CS350 OA10605020 ELECT. CAP 50V, 10µF ECEA1HAE100MB NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 44 DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103ZFV CS555 OA10705020 ELECT. CAP 100µF, 50V ECEA1HCE101MB CS602 DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFV CS603 DK96331300 CHIP CAP. 50V, 330pF ECUV1H331JCV NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 45 DK96103300 CHIP CAP. 50V, 0.01µF ECUV1H103ZFV CS814 OA47505020 ELECT. CAP 50V, 4.7µF ECEA1HAE4R7MB CS815 DD95101300 CHIP CAP. 50V, 100pF ECUV1H101JCV CS816 DK96104300 CHIP CAP. 50V, 0.1µF ECUV1H104ZFV NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 46 ICS04 HC10035090 HC10035090 IC OICNJM4558MTE3 ICS05 HC10035090 HC10035090 IC OICNJM4558MTE3 ICS06 HC10035090 HC10035090 IC OICNJM4558MTE3 ICS07 HC10035090 HC10035090 IC OICNJM4558MTE3 ICS08 *HC108140R *HC108140R IC OICAK4529VQ NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 47 SMT3 OTRDTA114EKA QS12 BA10023210 BA10023210 TRANSISTOR SMT3 OTRDTA114EKA QS13 BA10023210 BA10023210 TRANSISTOR SMT3 OTRDTA114EKA QS14 BA10023210 BA10023210 TRANSISTOR SMT3 OTRDTA114EKA QS15 BA20005210 BA20005210 TRANSISTOR OTRDTC114EK NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 48 NN05473610 CHIP RES. 47kΩ, 1/16W ERJ3GSKJ473V RS206 NN05473610 CHIP RES. 47kΩ, 1/16W ERJ3GSKJ473V RS207 NN05473610 CHIP RES. 47kΩ, 1/16W ERJ3GSKJ473V RS208 NN05472610 CHIP RES. 4.7kΩ, 1/16W ERJ3GSKJ472V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 49 NN05472610 CHIP RES. 4.7kΩ, 1/16W ERJ3GSKJ472V RS352 NN05472610 CHIP RES. 4.7kΩ, 1/16W ERJ3GSKJ472V RS353 NN05330610 CHIP RES. 33Ω, 1/16W ERJ3GSKJ330V RS354 NN05330610 CHIP RES. 33Ω, 1/16W ERJ3GSKJ330V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 50 NN05101610 CHIP RES. 100Ω, 1/16W ERJ3GSKJ101V RS657 NN05101610 CHIP RES. 100Ω, 1/16W ERJ3GSKJ101V RS658 NN05102610 CHIP RES. 1kΩ, 1/16W ERJ3GSKJ102V RS659 NN05274610 CHIP RES. 270kΩ, 1/16W ERJ3GSKJ274V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 51 NN05221610 CHIP RES. 220Ω, 1/16W ERJ3GSKJ221V RS829 NN05153610 CHIP RES. 15kΩ, 1/16W ERJ3GSKJ153V RS830 NN05103610 CHIP RES. 10kΩ, 1/16W ERJ3GSKJ103V RS831 NN05221610 CHIP RES. 220Ω, 1/16W ERJ3GSKJ221V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 52 NN05000610 CHIP RES. 0Ω, 1/16W ERJ3GSKJ000V RS942 NN05101610 CHIP RES. 100Ω, 1/16W ERJ3GSKJ101V RS943 NN05101610 CHIP RES. 100Ω, 1/16W ERJ3GSKJ101V XRS201 *JX001040R *JX001040R X'TAL VSXEN122883A20A5S NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 53 RF105 RES. 1.8kΩ, 1/6W ERD16TJ182T RF106 RES. 1kΩ, 1/6W ERD16TJ102T RF108 RES. 3.9kΩ, 1/6W ERD16TJ392T RF109 RES. 1.2kΩ, 1/6W ERD16TJ122T RF110 RES. 1.8kΩ, 1/6W ERD16TJ182T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 54 50V, 100000pF, 2F4 ECKR1H104Z06F CN206 CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F CN207 CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F CN208 OA47601640 ELECT. CAP 16V, 47µF ECEA1CAE470MB NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 55 50V, 10µF ECEA1HAE100MB FUSE CRIP VJFHF004N DN101 *HD201710R DIODE ODI1N4148 DN201 *HD201710R DIODE ODI1N4148 DN202 *HD201710R DIODE ODI1N4148 DN203 *HD201710R DIODE ODI1N4148 DN204 *HD201710R DIODE ODI1N4148 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 56 4pin, 2.0mm, UL VJS04PH01E JFN701 CONNECTOR 4pin, 2.5mmUL VJS04XH01E JFN702 CONNECTOR 7pin, 2.5mm, UL VJS07XH01E JN101 JUMPER WIRE JPL0000 JN102 JUMPER WIRE JPL0000 JN104 JUMPER WIRE JPL0000 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 57 QN402 *HT800020R *HT800020R TRANSISTOR OTR9014C QN403 *HT800020R *HT800020R TRANSISTOR OTR9015C QN601 *HT800020R *HT800020R TRANSISTOR OTR9014C QN606 BA20001000 BA20001000 TRANSISTOR OTRDTC114ESA QN607 BA20001000 BA20001000 TRANSISTOR OTRDTC114ESA NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 58 RN618 RES. 1kΩ, 1/6W ERD16TJ102T RN619 RES. 33kΩ, 1/6W ERD16TJ333T RN620 RES. 10kΩ, 1/6W ERD16TJ103T RN621 RES. 10kΩ, 1/6W ERD16TJ103T RN622 RES. 10kΩ, 1/6W ERD16TJ103T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 59 VJS09PH01E JFK02 CONNECTOR 11pin, 2.0mm, UL VJS11PH01E JK01 JUMPER WIRE JPL0000 JRK01 *YT002910R *YT002910R TERMINAL 6 CINCH VJJ01621 JRK03 *YT002890R *YT002890R TERMINAL 4 CINCH VJJ01408 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 60 4.7kΩ, 1/6W ERD16TJ472T RW102 RES. 22kΩ, 1/6W ERD16TJ223T RW104 RES. 1kΩ, 1/6W ERD16TJ102T RW105 RES. 10kΩ, 1/6W ERD16TJ103T SW01 /N *YJ002610R *YJ002610R CONNECTOR OUTLET VJJ0911E NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 61 DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN CV176 DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN CV177 DK96102300 CHIP CAP. 50V, 1000pF ECUV1H102KBN CV186 DD95470300 CHIP CAP. 50V, 47pF ECUV1H470JCN NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 62 ERJ6GEKF000V RV154 NI05000110 NI05000110 CHIP RES. 0Ω, 1/10W ERJ6GEKF000V RV155 NI05000110 NI05000110 CHIP RES. 0Ω, 1/10W ERJ6GEKF000V RV156 NI05000110 NI05000110 CHIP RES. 0Ω, 1/10W ERJ6GEKF000V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 63 ERJ6GEKJ750V RV218 NI05750110 NI05750110 CHIP RES. 75Ω, 1/10W ERJ6GEKJ750V RV219 NI05472110 NI05472110 CHIP RES. 4.7kΩ, 1/10W ERJ6GEKJ472V RV220 NI05102110 NI05102110 CHIP RES. 1.00kΩ, 1/10W ERJ6GEKF102V NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
