Summary of Contents for llaza WINBOX-350

Page 1 WINBOX-350 Technical Manual WINBOX-350 Page - Copyright Llaza, S.A. - May 2012...
Page 3: Table Of Contents
WINBOX-350 Contents Descriptive specifications Cutting, selection, and classification tables Annotated cross-sectional diagrams 9-10 Assembly instructions 11-15 Installation instructions 16-17 Examples of installations 18-19 Page 3 - Copyright Llaza, S.A. - May 2012...
Page 5: Descriptive Specifications
2– DESCRIPTION OF THE SYSTEM The advanced technology applied to the LLAZA-WIN system provides a series of advantages which guar- antee that the awning performs at peak efficiency: ■ Improved durability of the fabric and the system as a whole ■...
Page 6 Two stainless steel bearings are also used to provide improved du- rability and to eliminate noise during operation. The LLAZA-WIN System's arms consist of profiles, an internal double ten- sioning system (elongation and compression), and a system for transmis- sion of the longitudinal difference by means of a patented flexible tape system.
Page 7 Resistance to traction Rm (Mpa) Elastic limit Rp 0,2 (Mpa) Elongation A50 mm (%) Brinell Hardness MAXIMUM DIMENSIONS MAXIMUM WIDTH MAXIMUM PROJECTION ANGLE OF INCLINATION WALL CEILING 6° to 60° 6° to 60° Page 7 - Copyright Llaza, S.A. - May 2012...
Page 8: Cutting, Selection, And Classification Tables
WINBOX-350 WIND CLASSIFICATION WIDTH PROJECTION MOTOR SELECTION TABLE (in Nw/m) PROJECTION ROLLING TUBE Ø 80 70 Nw/m 85 Nw/m MINIMUM WIDTH No. of ARMS ARM PROJECTION Distance between joints 4 cm Page 8 - Copyright Llaza, S.A. - May 2012...
Page 9: Annotated Cross-Sectional Diagrams
WINBOX-350 Annotated cross-sectional diagrams FACE MOUNTING CROSS-SECTIONAL DIMENSIONS Page 9 - Copyright Llaza, S.A. - May 2012...
Page 10: Annotated Cross-Sectional Diagrams
WINBOX-350 Annotated cross-sectional diagrams CEILING MOUNTING CROSS-SECTIONAL DIMENSIONS Page 10 - Copyright Llaza, S.A. - May 2012...
Page 11: Assembly Instructions
(D). Next, attach the interior part of the side bracket to the other side as done with the first one, using the three DIN 7982, 4.2x45 screws. Page 11 - Copyright Llaza, S.A. - May 2012...
Page 12 Prior to re-joining the two elements of the bracket, insert the DIN 933, M6x35 bolts with the heads on the inside, and use the plastic washers to hold them in position while the two components are assembled. Page 12 - Copyright Llaza, S.A. - May 2012...
Page 13 (H). IMPORTANT In order to ensure perfect clo- sure of the WINBOX system, the motor power selection cal- culations must be respected. Page 13 - Copyright Llaza, S.A. - May 2012...
Page 14 DIN 7991, M10x60 bolt (N). Also position the plate for attachment to the drop bar profile. The position of each end piece must correspond with the letter marked on it. (L = left, R = right) Page 14 - Copyright Llaza, S.A. - May 2012...
Page 15 There are two of these strips for each side, so that one will match up with each of the arm forks and arm joints. Page 15 - Copyright Llaza, S.A. - May 2012...
Page 16: Installation Instructions
The cassette is attached using the DIN 933, M8x25 bolts on the bottom of the bracket plate. To tighten these bolts, two DIN 557, M8 nuts must be inserted in the slot. Page 16 - Copyright Llaza, S.A. - May 2012...
Page 17 This screw is made of polyamide, so that if the mo- tor malfunctions with the cassette closed, the cap can be pried off to provide access to the motor for replacement. Page 17 - Copyright Llaza, S.A. - May 2012...
Page 18: Examples Of Installations
WINBOX-350 Photos 8. EXAMPLES OF INSTALLATIONS Page 18 - Copyright Llaza, S.A. - May 2012...
Page 19 NOTE: LLAZA S.A. owns the copyrights to the photographs, illustrations, and text in this publication, and these may not be used, copied, or reproduced in any form, nor by any means, without prior permission from LLAZA, S.A. The company reserves the right to take legal action in cases of unauthorised usage.
Page 20 LLAZA, S.A. - Tramuntana, 1- Polígono Ind. Roques Roges IV (P.O. Box 11) - 43460 - ALCOVER Tel. +34 977 990 600 - Fax +34 977 990 610 info@llaza.com - export@llaza.com www.llaza.com Page 20 - Copyright Llaza, S.A. - May 2012...
