Page 1: Installation Guide
M O D E L Hardware Installation Guide... - Page 3 V I D A B O X ™ – L U X ™ Hardware Installation Guide © VidaBox LLC 172 Garden Street • Garden City, NY 11530 Support: http://www.vidabox.com/support...
-
Page 4: Table Of Contents
Connecting Directly from a Coaxial cable 10 Service Information How Many STBs Do You Have? Contact your Dealer/Place of Purchase Connecting a Splitter Contact VidaBox LLC How Did You Connect the TV to the STB? Connecting from a Coaxial Cable Connecting from S-Video/RCA Cable... -
Page 5: Introduction
I N T R O D U C T I O N M O D E L Introduction Congratulations on your purchase of the VidaBox LUX™! You have made an investment in attaining a state-of-the-art audio and visual experience for your home! he VidaBox™... -
Page 6: O V E R V I E W
FILL IN AND SAVE Look in the rear of your VidaBox™ and locate the serial number & Windows Product Key. Write it here and retain it for future reference. Serial No. -
Page 7: Parts List
Please check and make sure all of the parts below are in your box before getting started. See the Packing List to find which optional accessories came with your VidaBox LUX™. VidaBox LUX™ Unit (Black or Silver) This Installation Guide Software Configuration Guide Comprehensive User’s Guide... -
Page 8: I N S T A L L A T I O N
I N S T A L L A T I O N VidaBox Diagrams Please take some time to familiarize yourself with the LUX™ before proceeding. A Dual-layer DVD±RW Drives B Indicator F DVD Tray Eject Lights G Front Audio Ports... -
Page 9: Vidabox™ Placement
I N S T A L L A T I O N VidaBox™ Placement The VidaBox™ should be placed in a well-ventilated area. This will help facilitate the Help! My Parts exchange of heat out of the system, thereby minimizing operating fan noise. At a Look Different! minimum, any area with a fan grille should have about four (4) inches of clearance. -
Page 10: Lan Port
I N S T A L L A T I O N Connect the LAN Port If you have a hard line internet connection available, you can connect to it directly with a CAT-5 Ethernet cable to the S LAN Port. CAT-5 Ethernet Cable Connect the USB Card Reader Connect the USB card reader remote receiver into any available USB port. -
Page 11: Connect The Tv Inputs
I N S T A L L A T I O N Connect the TV Inputs (Analog) Depending on your TV provider source, you may connect the TV inputs in one of the following ways: Do You Have a Set-top Box (STB)? 1. -
Page 12: How Did You Connect The Tv To The Stb
1. If not already connected, connect one end of a coaxial cable into the “Out” port of 3. S-video (Best) your STB. 2. Plug the other end into the U TV Coaxial Input on the back of the VidaBox™. 3. You’re finished connecting the first set-top box! Repeat if you have another STB. Move on to Connect the HDTV Inputs on page 12. -
Page 13: Connect The Hdtv Inputs (Signal)
I N S T A L L A T I O N Connect the HDTV Inputs (Optional) If your VidaBox came with HDTV input(s), you may directly connect them to the VidaBox’s X ATSC HDTV OTA Input(s). Before doing so, make sure that your HDTV antenna is installed properly. -
Page 14: Connect The Video Output
I N S T A L L A T I O N Connect the Video Output Every VidaBox™ LUX™ comes with a high-quality S-Video cable. If you wish to Want the Best connect your LUX™ to the TV’s video input using a different cable(s), please Video Output purchase it from your local dealer, or through our online store. -
Page 15: Connecting Via S-Video
I N S T A L L A T I O N Connecting via S-Video 1. Take the TV-Out Dongle and plug it into the J S-Video & Component Output on the back panel. 2. Connect one end of the supplied S-video cable into the TV-Out Dongle 3. -
Page 16: Connect The Audio Output
– Connecting via Digital Sound There are two SPDIF outputs for the LUX™ - coaxial & optical. You can choose to use either output – but do not use both at the same time. The coaxial outputs use an RCA cable, and the optical output uses a TOSLink cable, as depicted below. -
Page 17: Connect The Wireless Keyboard
After installing the video and audio outputs, it is time to connect and synchronize the wireless keyboard to its receiver. Make sure that the wireless keyboard receiver is connected to the VidaBox™, and start the LUX™ by pressing the D Power Button. 1. Place the 3 included ‘AA’... -
Page 18: P O S T I N S T A L L A T I O N
The Next Step ☺ Congratulations! You’ve set up all of the physical connections for the VidaBox™ LUX! The next step is to properly configure the software. Refer to the “Software You’ve Finished Configuration Guide” for the next steps. the Hardware... -
Page 19: Service Information
VidaBox™ and need service – be 1. VidaBox™ Online Support – Our forums are full of common tips and prepared to give your troubleshooting knowledge. Feel free to search your answer. If you... - Page 20 September 2006. However, VidaBox LLC reserves the right to make modifications or changes to the document without further notice. This document is not intended to obligate VidaBox LLC or any other entity to any functionality and technology, but to merely inform the audience. VidaBox LLC makes no warranties, expressed or implied in or by this document and specifically disclaims any implied warranty of merchantability or fitness for a particular purpose.
