KWC PURESTREAM Filter Systems
Installation and Operating Instructions, Models KWC PURESTREAM & KWC PURESTREAM PLUS

Specifications

Inlet Size: 3/8" NPT
Outlet Size: 8mm NPT
Flow Rate: 1.05 gpm (4 lpm)
Temperature Range: 40-100°F (4.4-38°C)
Pressure Range: 30-125 psi (206-862 kPa)
Dimensions: 11" x 4" x 4" (28 cm x 10 cm x 10 cm)
Capacity: 500 gallons (1,893 liters)

Parts Included

KWC PURESTREAM, KWC PURESTREAM PLUS:
KWC PURESTREAM or KWC PURESTREAM PLUS
Replacement Filter Cartridge, Quick Connect Fittings,
System Head, Bracket Assembly & Screws

Installation Precautions

Warning: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system.
Caution: System must be protected from freezing. Drain
filter when room temperature drops below 40°F (4.4°C).
Caution: Do not install on hot water line. Maximum
temperature allow is 100°F (38°C).
• Do not use torch or other high temperature sources
near filter or plastic cartridge.
• Do not install near electric wires or water pipes that
will be in the path of the drill when selecting the
position to mount bracket.
• Do not install in direct sunlight.
• Allow minimum of 2" (5 cm) clear space under filter
to facilitate cartridge change.
• Mount filter in such a position as to prevent it from
being struck by other items such as waste baskets, etc.
• Installation must comply with existing state or local
plumbing codes.

System Installation

1. Mount System
Determine undersink mounting location
Warning: Before drilling holes underneath your sink, locate hidden electrical wires or plumbing behind the
mounting surface. Note adjacent appliances (dishwasher, refrigerator, trash compactor, over) which may
interfere with system fastening screws.
A. Fasten mounting bracket to cabinet wall (screws not included). Note: 2" (5 cm) free space underneath
system required to change filter.
B. Remove the cap from cartridge. Inspect the cartridge for any damage.
10 5/8"
(27 cm)
3 9/16"
(9 cm)
Cartridge
Installed
2
12 9/16"
(32 cm)
Cartridge
Removed
