Summary of Contents for ISE W288 ECO
-
Page 1: Operating Instructions
Operating Instructions Washing Machine ISE W288 ECO... - Page 3 Washing Machine ISE W288 ECO Dear ISE customer! Welcome to the family of ISE customers. We hope that you will have many years of use from your new machine. The machine has many features. To make the most of its functions, we recommend that you read the operating instructions before using the machine.
-
Page 4: Table Of Contents
Contents Before using your machine for Washing the first time Sort your laundry. Transport protection Turn on the main power switch Packing material Open the washer door and load the washing Washer door Add detergent and fabric softener, Language selection as required Checking water hardness Select the programme... - Page 5 Contents Technical information Information on energy labelling Information for test institute Technical data Transport protection Installation Positioning the washing machine Adjusting the feet Connection to water supply Drainage connection Electrical installation Service Before contacting the service division Quick guide...
-
Page 6: Before Using Your Machine For The First Time
Before using your machine for the first time Transport protection Remove any transport protection devices before installing the machine. See the "Transport protection" chapter. Packing material Please sort waste materials in accordance with local guidelines. Washer door • The washer door cannot be opened until the machine is connected to the electricity supply. -
Page 7: Safety Instructions
Safety instructions General Transport/Winter storage • Read the operating instructions and keep them If the machine is to be transported or stored in in a safe place. unheated premises where the temperature can • Installation of water and electricity, if required, fall below freezing, do as follows: should be carried out by a qualified •... -
Page 8: Child Safety
Child safety Keep an eye on children! Child safety catch • Always close the washer door and start the 1. Turn off the machine using the main power programme immediately after you have added switch. detergent. 2. Press and hold the Door opening button and •... -
Page 9: Description Of The Washing Machine
Description of the washing machine 1. Main power switch 2. Detergent compartment 3. Programme panel 4. Serial number plate (on inside of washer door) 5. Drainage pump cover 6. Drainage pump (behind cover) 7. Washer door Detergent compartment 1. Pre-wash 2. -
Page 10: Advice And Tips Before Washing
Advice and tips before washing Here are some tips that may help you before washing. Sorting your laundry Sort items according to: • how soiled they are • colour • material Clothing 1. Do up zips and close Velcro straps so that they don’t harm fabrics. -
Page 11: Hot Water Connection
Advice and tips before washing Hot water connection Rayon fibres and synthetic fibres Hot water intake has a positive effect on grease Materials made of rayon fibres, such as viscose, stains and certain pigment stains, such as oil, soot and some synthetic fibres are very delicate and and coffee. -
Page 12: Detergents
Advice and tips before washing Detergents Eco-labelled detergents are less harmful to the environment. Detergent overdosing does not give better washing results; it merely causes a greater impact on the environment. Try to use less detergent, and increase only if you are not satisfied with the results. -
Page 13: Washing
Washing Wash ball or net Sort your laundry. If you use a wash ball or net, place it directly in See the "Advice and tips before washing" the drum and select a programme without chapter. pre-wash. Place underwired bras in a laundry net. Empty pockets. -
Page 14: Select The Programme
Washing 4. Standard cotton Select the programme Program for normally to heavily soiled laundry, You select a programme by turning the whites and colors. You can select the temperature programme selector. The selected freely, so follow the washing instructions for each programme is shown in the display. - Page 15 Washing 8. Synthetics 10. Rinse Programme for delicate garments made of This program performs one cold rinse cycle + synthetic fibre, mixed fibre, rayon and easy care spin. Suitable for laundry that just needs to be cotton. The maximum temperature is 60 °C, but dampened and for cleaning cloths and mops.
-
Page 16: Programme Chart
Washing Programme chart Water consump- Energy consump- Programme time Pre- Number of (approx. hrs and Spin Speed Max. load tion tion Program wash Temp. °C Rinses ( kg) (approx. liter) (approx. kWh) min.) 1. Auto 2. Time program 1800 2:45 3. -
Page 17: Select Options
Washing • Select options , means that the programme does not You can select options to adjust the wash include a spin cycle and ends by draining. programme to suit your own specific • No D, No drain means that the programme requirements. - Page 18 Washing High water level Delayed start Use High water level if a garment's laundry label When you select Delayed Start, the machine will shows this symbol. High water level means that start 1-24 hours after you press the Start/Stop additional water is used during the main wash and button.
- Page 19 Washing Pre-soak If the washing is stained with blood, for example, we recommend a presoak. The washing will soak in cold water for two hours before the wash programme starts. • Select Presoak by pressing the button under the symbol. •...
-
Page 20: Close The Washer Door And Press The Start/Stop Button
Washing Stopping or changing a programme Close the washer door and You can stop a programme by pressing the press the Start/Stop button Start/Stop button for three seconds. "Stop" appears in the display. To restart the machine, select a new programme, add any extra detergent needed and press the Start/Stop button. -
Page 21: Settings
Settings You can change the following Door opening settings: The washer door opens automatically once the programme has finished. You can deactivate this • Child-safe function if you would rather use the the Door • Door opening opening button to open the door. •... -
Page 22: Hot Water
Settings Hot water However, if you choose to connect your ECO-machine to only the cold water it is important that you shut off the hot water connection. Now select "Hot water Off". If your machine is connected to both hot and cold water, you should select "Hot water On". -
Page 23: Care And Cleaning
Care and cleaning Cleaning the trap and the drainage Cleaning the detergent pump compartment The washing machine has a trap where smaller NOTE! objects such as coins and hairpins can collect. To clean the trap and the drainage pump, do as Do not wash the detergent compartment or the follows: insert in a dishwasher! -
Page 24: Rinse Holes Under The Agitator
Care and cleaning Rinse holes under the agitator If you have hard water If you suspect that objects such as nails or paper If you live in an area with hard water (high clips may have fallen into the wash drum, you limescale content), a greyish-white coating may should check the space under the agitator. -
Page 25: Troubleshooting
Troubleshooting If in the future the washer door does not open The washer door will not open when the wash programme has finished, call the 1. Check that the main power switch is on. service division. 2. Is there power? Check your home’s fuses The machine will not start (circuit breakers). -
Page 26: Error Messages
Troubleshooting Error messages Water inlet fault If an error occurs during the programme a Check: message is shown on the display. To exit the • that the tap on the water pipe is open. message after taking measures, turn the machine •... -
Page 27: Technical Information
Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1061/2010 Model designation: W288 Max. washing capacity: 8 kg Energy efficiency class: A+++ Annual energy consumption (AE 196 kWh per year Energy consumption Standard cotton 60 °C with full load (E 1,10 kWh t,60 Standard cotton 60 °C with half load (E... -
Page 28: Information For Test Institute
Technical information Information for test institute Program Max. load Temp. °C Auto 2) 3) Standard cotton 40, 60 Easy Care Short programme for test institutes, max. 1/2 load. Test programme for cold water connection in accordance with EN 60456. For large volumes of detergent we recommend removing the insert and adding detergent directly to the detergent compartment. -
Page 29: Transport Protection
Transport protection Remove the three transport bolts and the plastic plugs for locking the machine for transport before using the machine. NOTE! If the machine is to be transported, the bolts and plastic plugs for locking the machine during transport must be installed to prevent damage to the machine through shaking. -
Page 30: Installation
Installation Positioning the washing machine The washing machine can be installed as a built-in or freestanding unit. Position the machine so that the electrical plug is easily accessible. A. Built-in The washing machine can be installed under a counter top with a working height of 850-900 mm. Leave a 5 mm space around the entire machine, including between the rear edge of the top cover and the wall behind it. -
Page 31: Electrical Installation
Installation Electrical installation The machine can also be connected to the drain Connect the machine by plugging it into an via a spigot connection. In this case the hose earthed wall socket. The electrical wall socket should also be 600-900 mm above the floor. The must be placed outside of the installation area to internal diameter of the hole should be at least 18 be easily accessible. -
Page 32: Service
Service Before contacting the service Model division designation Before you contact the service division, make sure that you know the model designation, type Type plate designation and serial number. The model designation can be found on the panel. The type designation and serial number can be found on the type plate on the inside of the washer door. - Page 33 Your notes...
-
Page 34: Quick Guide
Quick guide fabric softener into the compartment on Washing the right with the -symbol. 1. Empty pockets and refasten zips. 2. If you use liquid detergent, follow the 2. Read the item’s laundry label. detergent manufacturer’s 3. Sorting laundry. recommendations. NOTE! Select the programme Place underwired bras in a laundry net.
