QSR5000
DOLBY
DIGITAL
SURROUND RECEIVER
DOLBY DIGITAL SURROUND RECEIVER
VOLUME
REMOTE
SENSOR
POWER (STANDBY)
STADIUM
CONCERT
THEATER
CHURCH
ARENA
CLUB
DSP OFF
NIGHT
MUTE
BASS
TREBLE
LEVEL
SURR. MODE
PRESET EQ
BY PASS
TEST/SET UP
6 CH.
TUNING
P. SCAN
VCR 2
DVD
SAT
VCR 1
VCR 2
CD
FM/AM
TV
TAPE
MODE/
S-VIDEO
VIDEO
L AUDIO R
PHONES
SET
INSTRUCTIONAL MANUAL
Advertisement
Table of Contents
Summary of Contents for Quest Engineering QSR5000
- Page 1 QSR5000 DOLBY DIGITAL SURROUND RECEIVER DOLBY DIGITAL SURROUND RECEIVER VOLUME REMOTE SENSOR POWER (STANDBY) STADIUM CONCERT THEATER CHURCH ARENA CLUB DSP OFF NIGHT MUTE BASS TREBLE LEVEL SURR. MODE PRESET EQ BY PASS TEST/SET UP 6 CH. TUNING P. SCAN...
- Page 2 FEDERAL COMMUNICATIONS COMMISSION (FCC) INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Table Of Contents
GETTING STARTED Unpacking the Receiver........................2 Inserting Batteries into Remote Control....................3 Set Up and Maintenance of the Receiver....................3 Protect your Components from Overheating..................3 Connecting to Audio-Visual Components....................4 Digital Connection..........................5 Connecting Antennas..........................5 Connecting the Speakers........................6 Connecting the Subwoofer........................6 Positioning your Speaker........................7 Front Speaker Placement........................7 Advanced Setting..........................7 Preferred Surround Placement......................8 Advanced Surround Setting.........................8... -
Page 4: Unpacking The Receiver
FM/AM TAPE TAPE TUNER MODE/ S-VIDEO VIDEO L AUDIO R PHONES PRESET EQ. SLEEP DIMMER One Quest QSR5000 receiver unit TUNING CHANNEL MEMORY One external FM Dipole antenna DIGITAL TEST VOLUME SURR. MODE LEVEL One external AM loop antenna QSR5000... -
Page 5: Inserting Batteries Into Remote Control
GETTING STARTED INSERTING BATTERIES INTO THE REMOTE Insert two "AAA" batteries according to the + and -signs on the battery compartment. To use the remote control, point it directly at your receiver. SET UP AND MAINTENANCE OF THE RECEIVER • Provide spaces for sufficient ventilation as indicated: 10cm/4"... -
Page 6: Connecting To Audio-Visual Components
GETTING STARTED CONNECTING TO AUDIO-VISUAL COMPONENTS If your video component has a S-Video jack included you can make use of it to enjoy enhanced video quality by connecting it to the relevant S-Video jack at the rear side of the receiver. One video cable is needed for each component. When S-Video cable is used, composite video (yellow RCA connector) cable must also be connected for VCR recording. -
Page 7: Digital Connection
AUDIO VIDEO RECEIVER undesired operation. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, MODEL NO.: QSR5000 DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Manufactured under license from Dolby Laboratories. AVERTISSEMENT: AFIN D'ÉVITER LES DANGERS D'INCENDIE ET... -
Page 8: Connecting The Speakers
GETTING STARTED To ease speaker connections, the terminals are color CONNECTING THE SPEAKERS coded. • Red/Black (Front Speakers) RIGHT LEFT • Blue”Black (Center Speaker) • Grey/Black (Rear Speakers) Connect the L, R speaker to the red/black terminal on the receiver. Do the same for the center (with MAIN SPEAKERS(8 ) blue/black terminal), rear speaker (with grey/black terminal). -
Page 9: Positioning Your Speaker
GETTING STARTED POSITIONING YOUR SPEAKERS Alignment 1) Left & Right (Front Speakers) Align the center speaker evenly with (A), or slightly They carry primary music and sound effects. behind (B), the left and right speakers, but not ahead of them. 2) Center Speaker In surround mode, the center speaker carries much of the dialogue as well as music and effects. -
Page 10: Preferred Surround Placement
GETTING STARTED PREFERRED SOUND PLACEMENT TEST TONE/CHANNEL BALANCE Location Channel balance If possible, place surround speakers to either side of Your receiver is equipped with a test signal the listening area, not behind it. generator for balancing the channels. As the signal “travels”... -
Page 11: Operating Your Receiver
OPERATING YOUR RECEIVER DOLBY DIGITAL SURROUND RECEIVER VOLUME REMOTE SENSOR POWER (STANDBY) STADIUM CONCERT THEATER CHURCH ARENA CLUB DSP OFF NIGHT MUTE BASS TREBLE LEVEL SURR. MODE PRESET EQ BY PASS TEST/SET UP 6 CH. TUNING P. SCAN VCR 2 VCR 1 VCR 2 FM/AM... -
Page 12: Your Remote Control
Used to manually store radio stations in the unit’s memory. 13. Channel Up/Down buttons Used to select programmedstations (in TUNER mode). QSR5000 REMOTE CONTROL UNIT 14. Sleep Press repeatedly to put the unit in the sleep mode. Unit will scroll between 30, 60, 90 &... -
Page 13: Display
OPERATING YOUR RECEIVER DISPLAY • Audio output is in Dolby Digital mode. • Audio output is in Dolby Pro Logic mode. • Audio output is in 3 Stereo mode. STEREO • Tuner stereo signal detected. TUNED • Tuner station detected. Sound Source/Speakers icons •... -
Page 14: Switching On/Off
OPERATING YOUR RECEIVER SWITCHING ON/OFF Example 1: If you connect a DVD player to the DVD input • To switch to the receiver, press STANDBY/ON (audio & video) on the receiver and press the DVD button once. Alternatively, you can press any of the button, you will be able to have the sound and source buttons to power on the receiver. -
Page 15: Using The Receiver To Play A Source
OPERATING YOUR RECEIVER When a source is selected, the source name will be shown on the display. POWER MUTE SURR. MODE PRESET EQ BY PASS TEST/SET UP 6 CH. TUNING P. SCAN Example: DVD/6CH. VCR 1 VCR 2 VCR 1 VCR 2 FM/AM TAPE... -
Page 16: Operating The Radio
OPERATING YOUR RECEIVER OPERATING THE RADIO BASS TREBLE LEVEL PRESET EQ. SLEEP DIMMER The receiver has a built-in tuner that allows for 6 CH. TUNING P. SCAN AM/FM radio function. TUNING CHANNEL VCR 2 FM/AM TAPE S-VIDEO VIDEO L AUDIO R MEMORY Manual Tuning... - Page 17 OPERATING YOUR RECEIVER Storing Radio Stations: Manual Preset The receiver can store up to 30 radio stations in 1) Select the band wave by pressing TUNER memory. You can enter every single radio station repeatedly. yourself or the receiver can store all available radio 2) Tune to a radio station (see “Manual Tuning”...
- Page 18 AUDIO VIDEO RECEIVER WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, MODEL NO.: QSR5000 DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Manufactured under license from Dolby Laboratories. AVERTISSEMENT: AFIN D'ÉVITER LES DANGERS D'INCENDIE ET...
-
Page 19: Advanced Sound Control
ADVANCED SOUND CONTROL SOUND ENHANCEMENT SYSTEMS Dolby Digital This receiver is equipped with several built-in sound The Dolby Digital mode lets you enjoy full digital enhancement systems. surround from software processed in the Dolby Digital format. Dolby Digital provides better sound Dolby Pro Logic and Dolby 3 Stereo quality and more powerful presence than conventional Dolby Surround. -
Page 20: Fine Setting Of Components
ADVANCED SOUND CONTROL Stereo Input Signal Setting The stereo mode uses the two main channel outputs The receiver defaults to the most convenient settings from the front of the speakers. Use this mode if you for your easiest use (see table). have connected the front speakers only. - Page 21 ADVANCED SOUND CONTROL Input Signal Selection Select this setting to play analog signals from a cassette deck, VCR or turntable. Available Input Source Button ANL/Optical/Coaxial • SAT • DVD ANL/Optical/Coaxial ANL/Optical/Coaxial • CD • VCR-1 ANL /-/- ANL /-/- • VCR-2 •...
-
Page 22: Care And Maintenance
CARE AND MAINTENACE RECEIVER/TUNER OPERATION No Audio from one channel. • Check the speaker level setting. Stereo indicator is off. • Check the speaker wire or cable connections. • Adjust the antenna The signal is Mono. Severe hum or noise Noise occurs when the TV is turned off. -
Page 23: Limited Warranty
This warranty does not apply to any Quest product which is used for commercial, rental, or industrial purpose, is damaged by accident, misuse, abuse, improper line voltage water lightning, or any acts of God. -
Page 24: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during hanlding and use. • • Carts and Sands - The appliance should be used only with a cart that is Before using the product, please follow and adhere to all warnings, recommended by the manufacturer.
