Summary of Contents for Xonix MP3 Sunglasses
- Page 1 MP3/VOICE RECORDING SUNGLASSES...
-
Page 2: Table Of Contents
TABLE OF CONTENT GENERAL DESCRIPTIONS----------------------------------------- Basic Function----------------------------------------------------- Accessories-------------------------------------------------------- OPERATION--------------------------------------------------------- Button function overview---------------------------------------- Function light overview------------------------------------------ Power on/off------------------------------------------------------- Mode switch------------------------------------------------------- Playing MP3 music-------------------------------------------------- Playing voice recording------------------------------------------- Recording shortcut----------------------------------------------- Volume & music / recording control-------------------------- Deleting music/voice recording------------------------------- PC connection---------------------------------------------------- Battery power indicator ----------------------------------------- Battery recharging----------------------------------------------- INSTALLATION------------------------------------------------------ System requirements--------------------------------------------... - Page 3 USB connection--------------------------------------------------- Installation guide------------------------------------------------- USB Disk Partition and Encrypt-------------------------------------- Firmware upgrade------------------------------------------------ CAUTIONS---------------------------------------------------------- HELPFUL TIPS-------------------------------------------------------- PRODUCT SPECIFICATIONS--------------------------------------...
-
Page 4: General Descriptions
GENERAL DESCRIPTIONS Basic Functions 1. Playable music format: MP3/ WMA/ ADPCM (Full Speed) 2. USB2.0 interface (Full Speed) 3. Portable storage disk USB2.0 4. Playing function: Sequence, Repeat Random, Pause, Resume 5. Delete (current track / voice recording) 6. Built in Microphone: ADPCM voice recording 7. - Page 5 Flashing once per second indicates 10% power remains; (also as USB indicator) : lights up / in proper connection with PC. MP3 Light (MP3): Lights up / MP3 mode; flashing once per second / playing MP3 in Sequence; flashing twice per second / playing MP3 in Repeat Random. REC light (voice recording / playing): lights up / playing mode of voice recording;...
-
Page 6: Accessories
Accessories Below are the standard accessories in the packing, please check they are complete MP3 sunglasses Instruction Manual Installation CD USB extension cable Charging adapter (optional) -
Page 7: Operation
Power on/ Power off / Playing MP3 Play / Pause Right side elevational view of the MP3 sunglasses Decrease volume Increase volume /Reverse /Forward USB port Voice recording microphone Back view of right temple of the MP3 sunglasses Button function overview... -
Page 8: Function Light Overview
Right side elevational view of the MP3 sunglasses Recording Power Indicator/ USB port MP3 recharging jack Recharging Function light overview... -
Page 9: Power On/Off
Power on/ power off ---- Press button momentarily POWER light lights up, Please wait for 10 seconds until MP3 light lights power on up, the MP3 player is ready to play. Press and hold button for 3 seconds-power off Note: default mode when power on 1) MP3 playing mode, MP3 light lights up. -
Page 10: Playing Mp3 Music
Playing recording mode Playing MP3 mode Press momentarily Press momentarily MP3 sequence mode MP3 random mode Press momentarily Press momentarily Playing MP3 music (under MP3 mode) Press momentarily----play, with MP3 light flash Press again momentarily---- pause, MP3 light lights up Playing voice recording (under recording playing mode) Press momentarily----play,... -
Page 11: Recording Shortcut
Recording shortcut (when voice or MP3 playback are paused) Press and hold for 3 seconds---- twice recording starts, REC light flashing per second Press again momentarily---- record- ing stops Volume & music/ track or voice recording control (under music playing or voice recording mode) Press and hold---- increase volume Press... -
Page 12: Pc Connection
NOTE: Please connect with PC to delete the songs or recordings which are less than 2 seconds. PC connection Turn on the MP3 player 2.Firstly connect the USB extension cable with the USB port on the right arm of the sunglasses, then connect insert to the with PC USB port. -
Page 13: Battery Recharging
5V 0.25V, output current 500mA. insert to 100v-240v AC power insert to the PC USB port insert to the port on the right arm of the MP3 sunglasses insert to the port on the right arm of the MP3 sunglasses... -
Page 14: Installation
INSTALLATION OF DRIVER System requirements IBM compatible personal computer Pentium 166 MHz MMX or faster insert to the Windows 98SE / ME / 2000 / XP PC USB port USB port (Universal Serial Bus) insert to the Mac Os X / Mac Os 9.0 port on the right arm of the MP3 64MB RAM or more... -
Page 15: Installation Guide
Installation guide Install the USB driver: Put the installation CD into CD-ROM Drive and then it will be in- stalled automatically. The following window will pop up: Click Continue, and the window below will pop up. - Page 16 Click Next to continue...
- Page 17 Select the installation folder and then click Next.
- Page 18 Click Next to start installation...
- Page 19 Installation completed,and the window below will pop up...
- Page 20 Click Close and restart your PC according to the PC requirement.
-
Page 21: Usb Disk Partition And Encrypt
USB Disk Partition and Encrypt MP3 player 1.Turn on the (Please refer to PC Connection) 2.Connect the MP3 player to PC 3.Click (Start) (Program) (MP3 Player U ilities ) (MP3 Player Disk Tool) The following windows will pop up. Select Partition and Encrypt and the window below will pop up. - Page 22 Set suitable encrypted disk capacity. Set new username and new password, and then click Start.
- Page 23 Partition completed, the window below will pop up. Click OK, and restart your PC according to PC requirement.
- Page 24 4. There will be two removable disks at this moment. The encrypt- ed disk will show the following documents. 5. Click RdiskDecrypt.exe, and type in the correct username and password to open the disk. 6. Correct username and password are needed to open the encrypted disk, whenever connect the MP3 player to the PC.
-
Page 25: Firmware Upgrade
Firmware upgrade MP3 player 1. Turn on the (Please refer to PC Connection) 2. Connect the MP3 player to PC 3. Click (Start) (Program) (MP3 Player Utilities) (MP3 Player Update Tool) The following window will pop up. Please 4. Click Select new firmware file, select new firmware ( download from manufacturer's website) 5. -
Page 26: Cautions
CAUTIONS 1. Do not disassemble or change any part of the product that is not mentioned in this manual. 2. Do not pull or plug the product with wet hands, which may cau- se short circuit of the product. 3. Do not expose the product to fire or excessive heat. 4. -
Page 27: Helpful Tips
HELPFUL TIPS Problem Analysis Solution Recharge the battery Battery low Unable to play MP3 Delete this music, Non standard MP3/WMA files download standard MP3/WMA files Unable to USB cable broken or not Check the USB connected properly. connection and reinsert download music Unable to... - Page 28 MP3 file made at compression Using lower compressing Sound level exceeding 320kbps. level to record the file into skips or MP3 format. resets Wrong music format/ Delete this music, damaged music file download correct music file Press buttons of Product fails to work properly Buttons unworkable together to reset...
-
Page 29: Product Specifications
PRODUCT SPECIFICATIONS Hardware Media Built in flash memory Capacity 128MB/256MB/512MB/1GB File system Audio Frequency range 20Hz~20KHz Earphone output 5mW + 5mW 80dB Supported Music MP3, WMA Music file file formats Bit rate MP3:32Kbps~320Kbps WMA: 5Kbps~256Kbps Recording format ADPCM power 230mAH macromolecule polymer Li-ion rechargeable battery other Work temperature -10... - Page 30 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may c ause und esired operation. NOTE: 1.The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
- Page 31 ESD REMARK: In case of malfunction due to electrostatic discharge just reset the product (reconnect of power source may be required) to resume normal operation.
