- Page 1 Roadstar Installation Instruction Manual...
- Page 2 Roadstar Installation Instruction Manual This instruction manual describes installation of GPS/GPRS vehicle tracking device Roadstar. Modem is already set to work with system for vehicle tracking, and in case of additional setup check document Roadstar Configuration Instruction Manual. Precautions To ensure correct working conditions for Roadstar, read carefuly following text: Ambient temperature from -30°C to +70°C!
- Page 3 Configuration Manual for details. Placing antenna Next step in installation is placing antenna. Roadstar has two connectors for anntenas: one for GSM signal and other one for GPS signal. Antenna provided with modem has both connectors, for GSM and GPS, and is easily mounted to modem. Both, antenna and modem have specified which connector is for which signal (written on modem and cables) –...
- Page 4 Roadstar Installation Instruction Manual Picture 2 – Connecting antenna to Roadstar It is important to install antenna on a proper place where GSM and GPS signal receiving and transmission will not be disturbed, so that device could work correct. Avoid placing antenna below metal or simmilar surfaces which can disturb signal receiving and transmission.
- Page 5 Roadstar Installation Instruction Manual Connecting power supply and control contacts After placing SIM card and antenna, next step of installation is connecting power supply and contacts. On the following picture is shown 10-wire cable which is connected to device. Cable has connector on one side, and it is connected to modem, and on the other sides are contacts which will be described.
- Page 6 Analog input 1 0V-24V DC Purple AI_2 Analog input 2 0V-24V DC Table 1 – 10-wire cable contact description Device is connected to this cable via connector as shown in picture 4. Picture 4 – Connector on Roadstar Page 6 of 8...
-
Page 7: Led Indicator
GSM signal is present and GPS signal is lost, two blinks each 2 seconds when GSM signal is lost and GPS signal is present, one blink each 2 seconds in other cases, three blinks each 2 seconds Picture 5 shows LED diode on Roadstar. Page 7 of 8... -
Page 8: Recommended Parameters
Roadstar Installation Instruction Manual Picture 5 – Status LED Recommended parameters Following table shows recommended values of parameters for Roadstar. There are minimum, optimum and maximum values. Parameter Pin/Parameter Min. Typ. Max. Unit Supply voltage Supply current °C Ambient temperature Table 2 –...
