Summary of Contents for Dai Telecom Roadrunner
- Page 1 Car Phone installation guide Generic This document and all the information herein are confidential, and the exclusive Page 1 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom.
-
Page 2: Revision History
Vadim Zukovsky Updated with diagram 02/01/2011 This document and all the information herein are confidential, and the exclusive Page 2 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 3: Table Of Contents
Trouble Shooting ....................20 Appendix ....................... 21 This document and all the information herein are confidential, and the exclusive Page 3 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 4: Carphone Kit
1 Carphone kit This document and all the information herein are confidential, and the exclusive Page 4 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. - Page 5 This document and all the information herein are confidential, and the exclusive Page 5 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom.
-
Page 6: Installation Diagram
2 Installation Diagram This document and all the information herein are confidential, and the exclusive Page 6 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 7: Carphone Layout
3 Carphone layout This document and all the information herein are confidential, and the exclusive Page 7 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 8: Preplanned Accessory Positioning
Ensure the Phone would be protected from mechanical damage by the car’s accessories. This document and all the information herein are confidential, and the exclusive Page 8 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 9: Plan The Microphone's Position
This document and all the information herein are confidential, and the exclusive Page 9 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 10: Installing The Cradle And Phone
Ensure it is safe and convenient to operate the Phone and read the display from the driver’s seat. This document and all the information herein are confidential, and the exclusive Page 10 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 11: Installing The Cradle And Phone
5. Direct the control cable coming out of the Phone behind the car panel. This document and all the information herein are confidential, and the exclusive Page 11 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 12: Installing The Microphone
1.5 meters between them. This document and all the information herein are confidential, and the exclusive Page 12 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. - Page 13 5. Connect the microphone cable plug to the correct port on the control cable. This document and all the information herein are confidential, and the exclusive Page 13 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom.
-
Page 14: Installing The Speaker
6. Ensure the speaker cable is not exposed to damage by the passengers. This document and all the information herein are confidential, and the exclusive Page 14 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 15: Installing The Electrical Connections
Only use the kit’s original fuses (250V / 2A). This document and all the information herein are confidential, and the exclusive Page 15 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 16: Installing The Voltage Cable
This document and all the information herein are confidential, and the exclusive Page 16 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 17: Installing The Antenna
This document and all the information herein are confidential, and the exclusive Page 17 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. - Page 18 11. Examine the antenna and cable’s proper working order with an efficiency meter. This document and all the information herein are confidential, and the exclusive Page 18 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom.
-
Page 19: Installing The Sim Card
Insert the SIM card when the phone is off. Note! This document and all the information herein are confidential, and the exclusive Page 19 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 20: Trouble Shooting
(red cable) power source switching off car This document and all the information herein are confidential, and the exclusive Page 20 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom. -
Page 21: Appendix
Type code *#06# Find locking code *5625# This document and all the information herein are confidential, and the exclusive Page 21 of 21 property of Dai Telecom. Do not copy, distribute or disclose this material without prior permission from Dai Telecom.
