Summary of Contents for Armodilo Bluetooth Keyboard Tray

  • Page 1 Apple Bluetooth Keyboard Tray Assembly...
  • Page 2 How-To-Videos For help with assembly, assembly with cabling, charging and various other topics please visit our online how-to-videos at: www.armodilo.com...
  • Page 4: Need Help

    If you have any questions regarding your accessory please contact us for immediate assistance. Need help? Call or e-mail us Monday–Friday 8:30–4:30 EST sales@armodilo.com 1.800.975.5946 Assembly Instructions › Keyboard Tray...
  • Page 5 Taking Care of Your Keyboard Tray Your Armodilo Keyboard Tray has been designed to be maintenance free. As with anything a little tender loving care will go a long way to ensuring your Keyboard Tray lasts for years to come and will provide you with endless hours of showcasing prowess.
  • Page 6 Assembly Instructions › Keyboard Tray The Keyboard Tray gets mounted to the “Kiosk” Housing using the VESA Mount Points Grab the Keyboard Tray so that it is oriented as show Align the Keyboard Tray to the back side of the “Kiosk Housing” aligning the four holes in the Keyboard Tray with the VESA Mount Points Important: DO NOT OVERTIGHTEN any of the bolts or screws.
  • Page 7 Insert four VESA Mount Screws through the Keyboard Tray and into the “Kiosk” Housing as shown. Tighten these using the supplied Hex Wrench Insert the Apple® Bluetooth Keyboard into the Keyboard Tray Note: To keep the keyboard from moving on the Keyboard Tray or to secure it further using the optional lock tabs as shown on the next page, it may be useful to add a strip of velcro to the underside of the keyboard and one to the keyboard tray to limit sliding the keyboard side to side in both installations.
  • Page 8 Assembly Instructions › Optional Security Locks Optional security lock tabs are provided* for locking the keyboard into the tray Align the lock tab with the hole in the keyboard tray on both sides Secure the lock tab to the keyboard tray using the supplied bolts provided DO NOT OVERTIGHTEN THESE SCREWS * Available only on version #2...
  • Page 9 Assembly Instructions › Keyboard Tray...
  • Page 10: Warranty Information

    IN NO EVENT WILL ARMODILO DISPLAY SOLUTIONS BE LIABLE FOR MORE THAN THE AMOUNT OF YOUR PURCHASE PRICE, NOT TO EXCEED THE CURRENT LIST PRICE OF THE PRODUCT. Armodilo Display Solutions specifically disclaims all other warranties, expressed or implied, and the user shall deem the installation or use of this product an acceptance of these terms.
  • Page 11: Obtaining Service Under Warranty

    Solutions technical support member verifies your have a hardware problem that requires you to return your product you will be issued an RMA number. You must acquire an RMA number and deliver the defective part to Armodilo Display Solutions in order to obtain service under this warranty. A sales receipt is required to verify the original retail purchase.
